STACORE BASIC/BASIC+
USER MANUAL
Thank you for purchasing a STACORE anti-vibration platform! Before
Setting Up The Platform, please read carefully the instructions below. In case
of any additional questions or problems, please contact us at
info@stacore.pl
WARNING!
The platform is very heavy at 62kg (137 lbs.). It should be manipulated
by two strong adult persons.
The air pressure in any of the sections should not be higher than 5 bar
max (72 psi). The maximum load capability is 65kg (145 lbs.) for BASIC
and 160kg (353 lbs) for BASIC+.
The maximum platform elevation should not exceed 10mm (0,4") under
any conditions.
Do not lift or move the platform when pressurized. Do not pressurize it
in the upside down position. This can damage the air springs.
The slate surfaces, especially the logo, are sensitive to scratches,
fingerprints, and stains. Please use the attached gloves to manipulate the
platform and keep it away from any sharp objects and liquids to secure a
superb look for a long time.
Advertisement
Table of Contents
Summary of Contents for Stacore Basic
-
Page 1: User Manual
The air pressure in any of the sections should not be higher than 5 bar max (72 psi). The maximum load capability is 65kg (145 lbs.) for BASIC and 160kg (353 lbs) for BASIC+. The maximum platform elevation should not exceed 10mm (0,4”) under any conditions. - Page 2 I. Setting up the platform 1. Wearing the attached gloves, carefully unpack the platform. 2. Place the platform on a solid foundation. The weight of the platform alone is 62kg (137 lbs.). The foundation must be able to reliably carry that weight plus the weight of the equipment to be placed on the platform.
- Page 3 5 bar max pressure, your equipment is way above the max allowable load. BASIC PLATFORM: The section on the left side of the platform (looking from the switches' side), controlled by the leftmost switch, will need to be pumped to a higher pressure than the other two sections. For...
- Page 4 II. Leveling the platform Some audio equipment will require leveling, like turntables of CD players. STACORE platforms allow for an easy and reliable leveling using the air pressure in individually controlled support points: 1. Choose the surface you want to level. For example a turntable platter.
- Page 5 Switches assignment: Each platform has 3 virtual support points. Each switch controls each point. Looking from the control panel, the leftmost switch (close to the vent) controls the center point on the left side of the platform. The middle switch controls the far right corner and the switch close to the manometer - the closer right corner of the platform.
- Page 6 In case of any questions or problems please contact us at info@stacore.pl WARRANTY: We offer 1 year warranty for parts, labor, and functionality. The slate surfaces are not covered by this warranty. STACORE Team wishes you happy listening and many exciting musical moments with our platforms!
