User Manual
www.doughty-engineering.co.uk
Easydeck
Modular System
Easydeck is a modular performance system, perfectly suited for use in smaller
venues. Designed to provide temporary staging. It is a 'no fuss' system which is
simplicity itself to install and requires no special tools to assemble.
The Deck Panels are phenol coated birch ply and feature a
smooth surface and a non slip surface on opposing sides.
Easydeck conforms to the following standards, DIN 53799, BS6566:1 1985
IMPORTANT NOTE: Responsibility lies with the user to undertake their own risk assessment
following installation, to ensure the floor plan is set-out such that injuries resulting from falling
objects, e.g. furniture falling from staging, are either eliminated or reduced to an acceptable level.
www.doughty-engineering.co.uk
Version 03/13
Advertisement
Summary of Contents for Doughty Engineering Easydeck
-
Page 1: User Manual
Easydeck Modular System Easydeck is a modular performance system, perfectly suited for use in smaller venues. Designed to provide temporary staging. It is a ‘no fuss’ system which is simplicity itself to install and requires no special tools to assemble. - Page 2 Parts & Features T77500 - Joint Clip - Easydeck Joint Clips are used to secure runways and step units. T77600 - Joint Channel - Joint Channels are used to create a secure joint between two adjacent frames. T77650 - Support Channel -...
- Page 3 Parts & Features Easydeck Square Frames EASYDECK FRAMES ARE SUPPLIED WITHOUT DECK PANELS 1000mm Series T76000 Square Frame 1000 x 1000 x 250mm SWL 500 Kg T76100 Square Frame 1000 x 1000 x 500mm SWL 500 Kg T76200 Square Frame...
- Page 4 Parts & Features Easydeck Triangular Frames EASYDECK FRAMES ARE SUPPLIED WITHOUT DECK PANELS 1000mm Series T76300 Triangular Frame 1000 x 1000 x 250mm SWL 250 Kg T76400 Triangular Frame 1000 x 1000 x 500mm SWL 250 Kg T76500 Triangular Frame...
- Page 5 Parts & Features Easydeck Step Units EASYDECK STEP FRAMES ARE SUPPLIED WITHOUT STEP DECK PANELS 250mm 470mm 690mm Single Step Double Step Triple Step 1000mm Series T76505 Single Step Unit 1000 x 250 x 250mm T76506 Double Step Unit 1000 x 470 x 500mm...
- Page 6 T79900 Ramp Section T77110 Primary Ramp Handrail T79910 Primary Ramp Handrail Easydeck Chair Stops Chair Stops create a raised edging to eliminate the chance of a chair leg slipping off the stage. T77300 1000mm Series Chair Stop T80100 750mm Series Chair Stop...
- Page 7 750mm series = 2250mm 750mm series = 2250mm 1000mm series = 2720mm 1000mm series = 3000mm 1000mm series = 3000mm ALL EASYDECK RAMP SYSTEMS ARE SUPPLIED WITH DECK PANELS 1000mm Series T77900 Ramp System 1 1000 x 1000 x 250mm...
- Page 8 Usage Purpose Easydeck is designed as a modular performance system for use as staging in small venues. Safety Inspection Never exceed the Safe Working Load (SWL) as shown in the below table. Type Size Square Frame 1000 x 1000 500 Kg...
- Page 9 Assembly Assembling 2 Easydeck Square Frames with Panels 2 x Reversible Square Deck Panel 2 x Square Frame 2 x Support Channel 2 x Joint Channels 2 x Joint Clips www.doughty-engineering.co.uk...
- Page 10 Assembly Assembling 4 Easydeck Square Frames with Panels and Chair Stops 4 x Reversible Square Deck Panel 4 x Square Frame 4 x Support Channels 8 x Joint Channels 4 x Joint Clips 6 x Chair Stops www.doughty-engineering.co.uk...
- Page 11 Assembly Assembling 4 Easydeck Square Frames with Panels and Chair Stops cont... www.doughty-engineering.co.uk...
- Page 12 Assembly Assembling Easydeck Handrails on 3x3 base 2 x Handrail Corner Section 7 x Handrail Standard Section Before installing Handrail ensure all top caps are removed where necessary www.doughty-engineering.co.uk...
- Page 13 Assembly Assembling Easydeck Handrails on 3x3 base cont... www.doughty-engineering.co.uk...
- Page 14 Assembly Assembling Easydeck Risers between 2 Square Frames Assembling Easydeck Risers between 2 Square Frames 1 x Reversible Square Deck Panel 2 x Square Frame 4 x Riser Bracket www.doughty-engineering.co.uk...
- Page 15 Assembly Assembling Easydeck Risers between 2 Square Frames cont... Assembling Easydeck Risers between 2 Square Frames cont... www.doughty-engineering.co.uk...
- Page 16 Assembly Assembling Easydeck Risers between 2 Square Frames 1 x Reversible Square Deck Panel 1 x Square Frame 3 x Step Deck Panel 1 x Triple Step Unit 3 x Support Channel 2 x Joint Clip 2 x Joint Channel...
- Page 17 Assembly Assembling Easydeck Risers between 2 Square Frames cont... 2 x Ramp System 2nd & 3rd Panel 1 x Ramp System 1st Panel 1 x Ramp System 1 1st Section 1 x Ramp System 1 2nd Section 1 x Ramp System 1 3rd Section...
- Page 18 Declaration of Conformity www.doughty-engineering.co.uk...
- Page 19 Note: Whilst every effort has been made to ensure that the information contained within this manual is correct, Doughty Engineering does not accept any liability for errors or omissions. Specifications and technical data are intended for guidance purposes only and may vary.
