  • Page 1 Multi MultiTracker s/n: xxx-xx-xxx Tracker Blanko s/n: xxx-xx-xxx Solido s/n: xxx-xx-xxx OxyDuo s/n: xxx-xx-xxx DO cell s/n: xxx-xx-xxx MultiTracker 2018-02-14 C84F5EN19...

  • Page 2: Table Of Contents

    Multi Tracker Table of Content TABLE OF CONTENT ............................2 ..............................4 ENERAL INFORMATION ..............................4 ECURITY INFORMATION ..........................4 ESCRIPTION OF THE PERATION ............................4 EASUREMENT UNCTIONS 2. UNPACKING ..............................4 ..................................5 ABLE ............................5 EMOVING THE CABLE HOOK 3.
  • Page 3 Multi Tracker APPENDIX 2, OXYDUO (DO SENSOR) ...................... 28 Description of the function ............................28 Measurement Functions ..............................28 Sensor body ..................................28 Description of the Display ............................29 ..................................30 AIN MENU Settings ....................................30 Calibration ..................................32 Getting Started ................................33 Maintenance ..................................33 ............................... 34 PECIFICATION XYDUO ............................

  • Page 4: General Information

    Multi Tracker General information It is of great importance to read all parts of this manual prior to start up of the instrument. If the Multitracker is not used and handled according to this manual, then the life and functionality may be jeopardized, and all warranties will be void. Security information This instrument should be handled by trained and authorized personnel only.

  • Page 5: Cable Hook

    Multi Tracker Cable Hook In order to facilitate the handling of the MultiTracker it is supplied with a SS cable hook that is attached to the battery case, see fig 2. It is possible to wind up all of the cable on the cable hook.

  • Page 6: Turning On The Hand Controller

    Multi Tracker 3. Turning On the Hand Controller It is important that any sensor that is attached to the hand controller is in the air when the hand controller is powered up. Sensors should not be in the liquid since this will effect the pressure sensor! To start measuring with the instrument press the key (on/off).

  • Page 7: Description Of The Display In Text Mode

    Multi Tracker Description of the Display in Text Mode At start up, the display is shown in fig 6 and description in fig 7. Measured concentration is displayed on the left and alarm values for Threshold 1 (6) and Threshold 2 (7). General information like time, date and temperature will always be displayed in the top left side of the screen.

  • Page 8: Description Of The Display In Profile Mode

    Multi Tracker Description of the Display in Profile Mode When pressing the Profile button marked the display will show the sludge profile. See fig 3 below. At any time during a measurement it is possible to switch between text mode and profile mode by pressing the button without affecting the measuring value.

  • Page 9: Main Menu

    Multi Tracker 5. Main menu Press to open the main menu. See fig 8. to pick the desired sub menu and open with fig 8 Settings In the SETTINGS menu (fig 9) it is possible to set thresholds concentrations. In this menu the span (max depth) measurement is set to fit the profile scale maximum depth.

  • Page 10: Setup

    Multi Tracker SETUP The SETUP menu (fig 11) enables selection of language, time and date formats, temperature units, concentration format, and depth format. fig 11 Language The following languages are available; Swedish, English, German and French. To select the desired language, perform the following steps; Press to open the menu and step down with and select ”SETUP”...

  • Page 11: Temperature Units

    Multi Tracker Temperature units Following temperature units are available; °C, °F, or °K. Press to open the menu and step down with . Select ”SETUP” with . Step down with . Select ”Temp. unit” and confirm with . Step upwith or downwith until desired unit (C, F, K).

  • Page 12: Getting Started

    Multi Tracker fig 13 Press to open the menu and step down with . Select ”Log” and confirm with Step down with and select Position - Show, Empty, Delete, or Create”. Confirm with . ”Delete” and ”Empty” are local and are only valid in its choosen Location or Field. ”Show”...

  • Page 13: Downloading Data From The Multitracker Controller

    Multi Tracker Downloading data from the MultiTracker Controller To be able to download data from the hand controller to a computer you need a USB communication cable. The USB communication is a part of a package that contains the following parts, see fig 15. We recommend that you download the latest driver for the USB adapter from the www.cerlic.com/software/drivers website.

  • Page 14: Maintenance

    Multi Tracker 7. Maintenance The instrument is designed to reduce the manual maintenance to a minimum. All metal parts are stainless steel (SS 2343/SS316). The enclosure is IP65/NEMA 4. The sensor cable is a specially manufactured PUR™ with a strong shield and extra heavy wires to withstand mechanical wear for a long life.

  • Page 15: Trouble Shooting

    Multi Tracker 8. Trouble shooting Check that the batteries are in good condition. The MultiTracker has built in logic to increase the battery life. If the battery voltage goes below a certain level, then the software will block the following functions; display back light, acoustic and vibration signals.

  • Page 16: Warranty

    Multi Tracker 11. Warranty Instruments delivered from Cerlic Controls AB, are carefully checked and tested prior to the shipment. Cerlic will repair or replace the product if a problem related to manufacturing or design occur during the warranty period. 12. Technical Specifications, MultiTracker Hand Controller Number of Detectable Levels Measuring units g/l, mg/l, %, ppm...

  • Page 17: Appendix 1, Blanko (Sludge Blanket Sensor)

    Multi Tracker Appendix 1, Blanko (Sludge Blanket Sensor) Blanko Sludge Blanket Sensor Description of the function Blanko is a portable optical suspended solids meter designed to measure sludge blanket depth and suspended solids in clarifiers, thickeners, aeration basins, etc. in water and wastewater plants, as well in other facilities.

  • Page 18: Sensor Body

    Multi Tracker Sensor body The sensor body contains optics and electronics that should not be exposed to mechanical abuse or high temperatures. If the sensor body has mechanical damages, water may penetrate into the sensor and destroy the electronics and optics. Please see section Maintenance for more information.

  • Page 19: Description Of The Display In Profile Mode

    Multi Tracker Description of the Display in Profile Mode When pressing the Profile button marked the display will show the sludge profile. See fig 3 below. At any time during a measurement it is possible to switch between text mode and profile mode by pressing the button without affecting the measuring value.

  • Page 20: Main Menu

    Multi Tracker Main menu Press to open the main menu. See fig 5. to pick the desired sub menu and open with fig 5 Settings In the SETTINGS menu (fig 6) it is possible to set the following functions: Threshold 1 – preset Fluff concentration Threshold 2 –...
  • Page 21 Multi Tracker fig 7 Press to open the menu and select ”SETTINGS” confirm with . Step down with and pick ”Threshold 1” with . Step up with or down with until desired concentration is obtained. Confirm and step to next digit with .
  • Page 22 Multi Tracker Blind zone Press to open the menu and select “SETTINGS”. Confirm with . Step down with and select ”Blind zone” with . To scale the “Blind zone” span that is shown at profile measurement, step up with or down with until desired value.Confirm with .

  • Page 23: Calibration

    Multi Tracker Calibration Calibration can be done for both depth measurement and sludge concentration. For depth measurement, zero compensation is performed every time when the MultiTracker is turned on to adjust for barometric pressure. It is also possible to perform a manual calibration of zero and one meter (3.3 ft) depth.

  • Page 24: Getting Started

    Multi Tracker 0 m Cal. - Zero depth calibration Press to open the menu and step down with . Select ”Calibration” with . Step down with and select ”0 m cal. ”. Hold sensor vertically in the air and start zero calibration with .
  • Page 25 Multi Tracker fig 10 Profile mode In order to switch between text mode and profile mode, press the button marked . It is possible to step back and forth with this button without affecting the actual measurement. Save a profile To save a measurement profile, or to perform a new measurement, press , when doing this, an option to save...
  • Page 26 Multi Tracker Maintenance The Blanko is designed to reduce the manual maintenance to a minimum. All metal parts are stainless steel (SS 2343/SS316). The enclosure is IP68/NEMA 7. The sensor cable is a specially manufactured PUR™ with a strong shield and extra heavy wires to withstand mechanical wear for a long life.

  • Page 27: Specification, Blanko

    Multi Tracker Specification, Blanko Function Sludge Concentration and Depth Measuring principle Optical light transmission Wave length NIR 850 nm Measuring range Max – 20,000 mg/l (ppm) Accuracy suspended solids 1% FS (full scale) Repeatability < 2% of Measured Value Type of Measurement Continuous with Profile Number of Detectable Levels Two (fluff and sludge blanket)

  • Page 28: Appendix 2, Oxyduo (Do Sensor)

    Multi Tracker Appendix 2, Oxyduo (DO Sensor) Oxyduo DO Sensor Description of the function Oxyduo is a portable oxygen meter designed to measure oxygen levels in aeration basins, etc. in water and wastewater plants, as well in other facilities. It is possible to display measured value as text on the screen and set two different alarm levels for high and low levels.

  • Page 29: Description Of The Display

    Multi Tracker Description of the Display At start up, the display is shown in fig 1 and description in fig 2. Value for oxygen concentration are displayed on the left and alarm values to the right. Date, time and temperature are shown across the top. ...

  • Page 30: Main Menu

    Multi Tracker Main menu Press to open the main menu. See fig 3. to pick the desired sub menu and open with fig 3 Settings In the SETTINGS menu, below, it is possible to set alarm values for high and low oxygen level concentrations.
  • Page 31 Multi Tracker Press to open the menu and select ”SETTINGS” confirm with . Step down with and pick ”Threshold 1” with . Step up with or down with until desired concentration is obtained. Confirm and step to next digit with .

  • Page 32: Calibration

    Multi Tracker Calibration Calibration of sensor with Optical cell Remove the black protective cover around the new cell's connector. End the circuit with the bracket as shown. Connect the cell. Zero calibration of the sensor:  Open the main menu with Step down to Calibration ...

  • Page 33: Getting Started

    Multi Tracker Changing/installing an Optical cell Unscrew the electrode holder, release the contact. Push out the electrode from the back, clean the electrode holder. Change o-ring (29,87x1,78) apply silicone lubricant, also on the o-ring around the electrode. Carefully mount the electrode in the holder and reconnect. Turn the electrode holder anticlockwise to get the cables right.

  • Page 34: Specification, Oxyduo

    Multi Tracker Inspection of the sensor The sensor head should be cleaned, if any solids are present on the cell it can create a measuring error. To verify that the cell is working properly an air measurement can be performed. Place the sensor in clean, perform an air calibration, See section Calibration. When cleaning the sensor, it is preferred to use the Cerlic Sensor Cleaning (CSC) liquid.

  • Page 35: Oxygen Solubility - Chart

    Multi Tracker Oxygen Solubility - chart...

  • Page 36: Appendix 3, Solido (Suspended Solids Sensor)

    Multi Tracker Appendix 3, Solido (Suspended Solids Sensor) Solido Suspended Solids Sensor Description of the function Solido is a portable optical suspended solids meter designed to measure suspended solids in aeration basins, RAS, aerobic digesters, etc. in water and wastewater plants, as well in other facilities.

  • Page 37: Description Of The Display

    Multi Tracker Description of the Display At start up, the display is shown in fig 1 and description in fig 2. Value for suspended solids concentration is displayed on the left and alarm values to the right. Date, time and temperature are shown across the top.

  • Page 38: Main Menu

    Multi Tracker Main menu Press to open the main menu. See fig 3. Use to pick the desired sub menu and open with . Exit the menu with until one of the main windows appear. fig 3 Settings In the SETTINGS menu (fig 4) it is possible to set alarm values for high and low suspended solids level.
  • Page 39 Multi Tracker Press to open the menu and select ”SETTINGS” confirm with . Step down with and pick ”Threshold 1” with . Step up with or down with until desired concentration is obtained. Confirm and step to next digit with .

  • Page 40: Calibration

    Multi Tracker Calibration Calibration can be done for both zero and lab sample concentration. fig 7 Zero Sample Press to open the menu and step down with . Select ”Calibration” with . Step down with and select ”zero”. Confirm with .

  • Page 41: Getting Started

    Multi Tracker Three Calibration Curve Setup* When using the Solido sensor, the Mulitracker supports up to three different calibration curves. This could be used to improve accuracy when measuring in different types of sludge´s. General The symbol indicated above shows the selected calibration curve (curve 1 is currently active).
  • Page 42 Multi Tracker storing the measurement. Step up with or down with to reach desired log position. The postion tag will be shown in the lower margin in the display window. Fig 8 below, shows that the actual profile will be stored at position ”General” fig 8 It is possible to tag each of the 250 log positions with up to 10 alphanumerical characters.

  • Page 43: Specification, Solido

    Multi Tracker Specification, Solido Function Suspended solids Measuring principle Optical light transmission Wave length NIR 850 nm Measuring range Up to 35,000 mg/l (ppm) dependent on solids type Accuracy suspended solids 1% FS (full scale) Repeatability < 2% of Measured Value Type of Measurement Continuous Number of Detectable Levels...
