Revisão: 02
Data de Criação: 00.00.0000
Data de revisão: 24.01.2019
AWPLC GATEWAY MANUAL
MODEL: AWGTY-DGOISG86A0
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AWGTY-DGOISG86A0 and is the answer not in the manual?

Questions and answers

Summary of Contents for AWPLC AWGTY-DGOISG86A0

  • Page 1 Revisão: 02 Data de Criação: 00.00.0000 Data de revisão: 24.01.2019 AWPLC GATEWAY MANUAL MODEL: AWGTY-DGOISG86A0...
  • Page 2 The AWPLC manual was developed with the intuition to make the maintenance and operational process of the equipment the smoothest and easiest as possible.

  • Page 3: Table Of Contents

    Revisão: 02 Data de Criação: 00.00.0000 Data de revisão: 24.01.2019 SUMMARY SUMMARY ......................2 IMAGE INDEX ....................... 3 KNOWING YOUR DEVICE ................4 GENERAL VIEW ................... 4 INTERFACES ..................4 FRONTAL PANEL LEDS ..............6 TECHNICAL SPECIFICATION – OVERVIEW ........8 SETUP AND OPERATING ................

  • Page 4: Image Index

    Data de Criação: 00.00.0000 Data de revisão: 24.01.2019 IMAGE INDEX Figure 1 - Perspective of AWPLC Gateway ..............4 Figure 2 - Interfaces of AWPLC Gateway ..............5 Figure 3 - AWPLC Gateway LED Panel............... 6 Figure 4 – Login Screen ....................9 Figure 5 - Initial Screen.

  • Page 5: Knowing Your Device

    Revisão: 02 Data de Criação: 00.00.0000 Data de revisão: 24.01.2019 1. KNOWING YOUR DEVICE 1.1 GENERAL VIEW Figure 1 - Perspective of AWPLC Gateway 1.2 INTERFACES...

  • Page 6: Figure 2 - Interfaces Of Awplc Gateway

    AWPLC Gateway information (Model and Serial Number). USB connector. Those connectors have a reserved function. Future applications may be provided to interconnection with other AWPLC modules. Do Not connect any type of device to those connectors! Ethernet Connector. Used for MODBUS over TCP/IP connection.

  • Page 7: Frontal Panel Leds

    Revisão: 02 Data de Criação: 00.00.0000 Data de revisão: 24.01.2019 1.3 FRONTAL PANEL LEDS Figure 3 - AWPLC Gateway LED Panel. The frontal panel of AWPLC GATEWAY has 8 LEDs indicators. Their functions are better explained in table below.
  • Page 8 Revisão: 02 Data de Criação: 00.00.0000 Data de revisão: 24.01.2019 Main Group Figure Description The RUNTIME LED blinks if the AWPLC is running normally. It remains off at the AWPLC initialization time and in case of Fail Conditions. GATEWAY Operation The POWER indicators remains on if the MPU is energized and the AWPLC is ready to run.

  • Page 9: Technical Specification - Overview

    Revisão: 02 Data de Criação: 00.00.0000 Data de revisão: 24.01.2019 1.4 TECHNICAL SPECIFICATION – OVERVIEW PHYSICAL Characteristic Symbol Typical Unity Length 85.4 85.5 85.8 Width 125.0 125.25 125.4 Height 46.9 47.0 47.2 Weight Degree Protection IP40 CLIMATIC CONDITIONS Characteristic Symbol Typical Unity Operating temperature...

  • Page 10: Setup And Operating

    Revisão: 02 Data de Criação: 00.00.0000 Data de revisão: 24.01.2019 2. SETUP AND OPERATING 2.1 LOGIN Gateway’s login screen: Figure 4 – Login Screen After the login process you will be redirected to the main menu screen of the Gateway.

  • Page 11: User

    Revisão: 02 Data de Criação: 00.00.0000 Data de revisão: 24.01.2019 Figure 5 - Initial Screen. 2.2 USER Clicking on the user menu you will initially list all the existing users registered to access the Gateway. New users can be added by clicking on the new button on the right side of the screen.

  • Page 12: Devices

    Revisão: 02 Data de Criação: 00.00.0000 Data de revisão: 24.01.2019 After clicking on the New User button: Figure 8 – New User Screen Fill in all the data and press Save. A new user will be added on the list of users. 2.3 DEVICES Devices screen: Figure 9 –...

  • Page 13: New Devices

    Revisão: 02 Data de Criação: 00.00.0000 Data de revisão: 24.01.2019 By clicking on the Edit button, you can change the name, address or even disable the device as seen in image below: Figure 11 - Edit devices. It is also possible to see all the Public Objects of the Parameters and Status attached to the device as the image below: Figure 12 - Public Objects 2.3.1 NEW DEVICES...

  • Page 14: Figure 13 - New Device

    Revisão: 02 Data de Criação: 00.00.0000 Data de revisão: 24.01.2019 Figure 13 - New device. Please fill out all the fields. The Address field accepts numeric values from 1 to 247. To add a Public Object on Status or Parameters, simply click on the desired tab followed by the Add button.

  • Page 15: Importing Devices

    2.3.2 IMPORTING DEVICES To make the importing process, simply click on the Import Button on the Devices Screen and select the AWBUS.conf file generated by the AWPLC Studio. Figure 15 - Import devices. It is also possible to import the Public Objects to a already existing device. For that click on the Edit button on the device you want to make the change and after that click on the Import button as seen on the Image 13.

  • Page 16: Network

    Revisão: 02 Data de Criação: 00.00.0000 Data de revisão: 24.01.2019 Figure 17 - Screen of radio. Click on Save button to update the informations. 2.5 NETWORK On the Network Screen there is two Tabs (Ethernet and Wi-Fi), both are suited to define the parameters for this two kind of communication of the Gateway.

  • Page 17: Figure 19 - Mode Of Ethernet Operations

    Revisão: 02 Data de Criação: 00.00.0000 Data de revisão: 24.01.2019 Figure 19 - Mode of ethernet operations. Each one of the operational mode enables a set of fields that must be filled out correctly. Below are the explanations of each one of those necessary fields: •...

  • Page 18: Figure 20 - Mode Ethernet Dhcp Server

    Revisão: 02 Data de Criação: 00.00.0000 Data de revisão: 24.01.2019 On the DHCP Server mode, the gateway will be responsible for managing all the connected devices on this network. Here comes a very important WARNING, the Highlander rule. DHCP Server devices are like Highlanders, “there can be only one”...

  • Page 19: Figure 21 - Static Ethernet Mode

    Revisão: 02 Data de Criação: 00.00.0000 Data de revisão: 24.01.2019 Figure 21 - Static ethernet mode On the Dynamic mode there’s nothing to be done, since all the configurations are received from a DHCP Server: Figure 22 - Dynamic ethernet mode The Default mode is a DHCP Server mode with default values.

  • Page 20: Wi-Fi Network Setup

    Gateway. The parameters here are: IP Address, Netmask, Gateway, DNS, SSID, Password, Start IP and Final IP. On the current version of the AWPLC there are 5 different operational modes for the Wi-Fi interface: DHCP Server, Static IP, Dynamic IP, Disabled and Default, as shown on the image below: Figure 24 - Mode operation Wi-Fi.
  • Page 21 Revisão: 02 Data de Criação: 00.00.0000 Data de revisão: 24.01.2019 resolver address. (*DNS resolver equals “DNS Lookup” - resolves and individual host name to a Public IP address). • Primary DNS: The first option for DNS resolver. (I.E. a normally used address for Primary DNS is the Google Primary DNS address 8.8.8.8.

  • Page 22: Figure 25 - Mode Wi-Fi Dhcp Server

    Revisão: 02 Data de Criação: 00.00.0000 Data de revisão: 24.01.2019 The fields Address IP, Netmask, Start IP, Final, SSID and Password must be filled as explained before. See the image below with an example: Figure 25 - Mode Wi-Fi DHCP Server. On the Static IP mode the fields Address IP, Netmask, Start IP, Final IP, SSID and Password must be filled as explained before.

  • Page 23: Figure 26 – Mode Wi-Fi Static

    Revisão: 02 Data de Criação: 00.00.0000 Data de revisão: 24.01.2019 Figure 26 – Mode Wi-Fi Static. On the Dynamic mode only the SSID and Password fields are able to be changed. The others fields are received from a DHCP Server. See the example on the image below: Figure 27 –...

  • Page 24: Backup/Restore

    The Default mode is a DHCP Server mode with default values. The IP will be set as 1.0.0.1, the SSID will be [AWPLC + Wi-Fi MAC Address] and the Password will be AWPLC@PW. Those are values determined by us, just to make sure they are different from the ones commonly used on computer networks and are able to not generate some kind of conflict.

  • Page 25: Figure 31 - Message Of Security

    Revisão: 02 Data de Criação: 00.00.0000 Data de revisão: 24.01.2019 Figure 31 - Message of security. After the OK clicking a file selection window will appear. Select you restore file (probably BACKUP.xml or the one you named) and click OK once again. Remembering, after restoring all the current settings will be lost.
