Summary of Contents for Schweitzer Engineering Laboratories SEL-701-1

Page 1 SEL-701-1 Monitor Instruction Manual Schweitzer Engineering Laboratories, Inc. 2350 NE Hopkins Court Pullman, WA USA 99163-5603 Tel: (509) 332-1890 FAX: (509) 332-7990...
Page 2 This product is covered by U.S. Patent Nos: 5,436,784. Foreign Patents issued and other U.S. and Foreign Patents Pending. This product is covered by the standard SEL 10-year warranty. For warranty details, visit www.selinc.com or contact your customer service representative. © 2001 Schweitzer Engineering Laboratories. All rights reserved.
Page 3: Table Of Contents
Section 1: Introduction and Specifications Introduction.......................1.1 Typographic Conventions .................1.3 SEL-701-1 Monitor Models................1.4 SEL-701-1 Monitor Applications ..............1.5 SEL-701-1 Monitor Protection Features............1.6 SEL-701-1 Monitoring and Reporting Features ..........1.7 Monitor Part Number..................1.8 SEL-701-1 Monitor Serial Number Label ............1.10 Specifications....................1.11 Section 2: Installation Panel Cut & Drill Plans..................2.1 Monitor Mounting.....................2.4...
Page 4 Real-Time Clock Battery Replacement............9.8 Firmware Upgrade Installation................. 9.9 Factory Assistance..................9.12 Appendix A: Firmware Versions Appendix B: SEL ® Control Equations and Monitor Logic OGIC Introduction ......................B.1 Monitor Functional Overview ................B.2 Relay Word Bits ....................B.4 Control Equations................B.12 OGIC SEL-701-1 Monitor Date Code 20011009...
Page 5 Appendix D: SEL-2020/SEL-2030 Compatibility Features Introduction......................D.1 Fast Binary Message Lists ................D.2 Fast Binary Message Definitions ..............D.3 Compressed ASCII Commands ..............D.18 CASCII Command..................D.19 CSTATUS Command..................D.22 CHISTORY Command ..................D.23 CEVENT Command ..................D.24 CME E Command..................D.26 CME M Command..................D.27 CME T Command..................D.28 SEL-701-1 Monitor Date Code 20011009...
Page 6 The Basic Thermal Element................E.5 Motor Starting Protection................. E.8 Motor Running Protection................E.9 Interpreting Percent Thermal Element Capacity Values ........ E.12 Motor Starting Thermal Capacity ..............E.13 Appendix F: SEL-701-1 Monitor Settings Sheets Glossary ....................... GL.1 Index ........................IN.1 SEL-701-1 Monitor...
Page 7: List Of Tables
Section 1: Introduction and Specifications Table 1.1 Typographic Conventions .............1.3 Table 1.2 SEL-701-1 Monitor Models ............1.4 Table 1.3 SEL-701-1 Monitor Part Number Creation Table ......1.8 Section 2: Installation Table 2.1 Typical Maximum RTD Lead Length .........2.19 Section 3: Settings Calculation Table 3.1 Identifier Settings ................3.4...
Page 8 Front-Panel Pushbutton Functions ..........4.5 Section 5: ASCII Serial Port Operation Table 5.1 Pin Functions and Definitions for SEL-701-1 Monitor EIA-232 Serial Ports ..5.4 Table 5.2 SEL-701-1 Monitor Serial Communication Default Settings ..5.5 Table 5.3 Serial Port Control Characters ............5.6 Table 5.4...
Page 9 RTD Input Status Messages ............7.4 Table 7.6 Energy Meter Values ..............7.5 Table 7.7 Load Profile Values ...............7.7 Section 8: Event Analysis Table 8.1 SEL-701-1 Monitor Factory Front-Panel Target LED Definitions ............8.2 Table 8.2 Event Commands ................8.8 Table 8.3 EVE Command Options ..............8.8 Table 8.4 Event Report Current and Voltage Columns ........8.9...
Page 10 Table C.11 07h Read Exception Status Command ........C.11 Table C.12 08h Loopback Diagnostic Command .........C.12 Table C.13 10h Preset Multiple Registers Command ........C.13 Table C.14 SEL-701-1 Monitor Modbus Command Region ......C.14 Table C.15 Modbus Command Codes ............C.14 Table C.16 Monitor Self-Test Result in Bit Definition .........C.16 Table C.17 Assign Event Report Channel Using Address 03A2h ....C.17...
Page 11 Figure 2.3 SEL-701-1 Monitor Panel Mounting Detail.........2.4 Figure 2.4 SEL-701-1 Monitor Rear Panel............2.5 Figure 2.5 SEL-701-1 Monitor Left- and Right-Side Panel Drawings..2.6 Figure 2.6 Example AC Wiring Diagram, Four-Wire Wye Voltages and Ground CT......2.7 Figure 2.7 Example AC Wiring Diagram, Open-Delta Voltages and Residual IN Connection.
Page 12 Figure 5.5 ANA Command Example............5.11 Figure 5.6 DATE Command Example............5.13 Figure 5.7 HISTORY Command Example..........5.14 Figure 5.8 METER Command Example............. 5.16 Figure 5.9 METER D Command Example..........5.16 SEL-701-1 Monitor Date Code 20011009...
Page 13 Undervoltage Element Logic............. B.36 Figure B.10 Underpower Element Logic............B.36 Figure B.11 Current Unbalance Element Logic..........B.37 Figure B.12 Phase Reversal Element Logic..........B.38 Figure B.13 Overcurrent Element Logic............B.39 SEL-701-1 Monitor Date Code 20011009...
Page 14 Motor Running Thermal Element With Resistance and Trip Level Undefined. Figure E.6 Calculating the Normal Operating Energy Using Locked Rotor Trip Times........ E.9 Figure E.7 Motor Running Thermal Element..........E.10 Appendix F: SEL-701-1 Monitor Settings Sheets SEL-701-1 Monitor Date Code 20011009...
Page 15 Equation E.2 ....................E.6 Equation E.3 ....................E.6 Equation E.4 ....................E.7 Equation E.5 ....................E.7 Equation E.6 ....................E.7 Equation E.7 ....................E.7 Equation E.8 ....................E.11 Equation E.9 ....................E.13 Appendix F: SEL-701-1 Monitor Settings Sheets SEL-701-1 Monitor Date Code 20011009...
Page 16 This page intentionally left blank...
Page 17: List Of Examples
List of Examples Section 1: Introduction and Specifications Example 1.1 SEL-701-1 Monitor Part Number Creation ......1.8 Section 2: Installation Example 2.1 Phase CT Ratio Selection ............2.11 Section 3: Settings Calculation Example 3.1 Phase CT Ratio Setting Calculation .........3.4 Example 3.2 Phase VT Ratio Setting Calculations........3.6 Example 3.3 Thermal Element Rating Method Setting.........3.9...
Page 18 This page intentionally left blank...
Page 19: Manual Change Information
Summary of Changes in this Release This Manual Change Information section is provided as a record of changes made to this manual since the initial release. 20011005 Update Appendix D. 20010815 Date of Initial Release. SEL-701-1 Monitor Date Code 20011009...
Page 20 This page intentionally left blank...
Page 21: Section 1: Introduction And Specifications
This manual contains the information you need to select, install, set, test, operate, and maintain any SEL-701-1 Monitor. You probably will not need to review the whole book to perform the specific tasks that are your responsibility. The following is an overview of the sections in this instruction manual: Section 1: Introduction &...
Page 22 Appendix F: SEL-701-1 Monitor Settings Sheets. Contains completed monitor settings sheets containing factory default settings and blank settings sheets you can photocopy and complete to record settings for the SEL-701-1 Monitor. SEL-701-1 Monitor Command Summary. Briefly describes the serial port commands...
Page 23: Typographic Conventions
[\] between the main menu selection and subsequent selections. Monitor serial port command responses. SEL-701-1 MONITOR Manual section and heading names are shown in Section 1: Introduction & Specifications italics. Monitor front-panel display information and examples.
Page 24: Sel-701-1 Monitor Models
Introduction and Specifications SEL-701-1 Monitor Models SEL-701-1 Monitor Models Table 1.2 This instruction manual covers the SEL-701-1 Monitor models listed in Table 1.2 SEL-701-1 Monitor Models SEL-701-1 Monitor Model Internal RTD Number Inputs Voltage Inputs Current Inputs 0701100X IA, IB, IC, IN...
Page 25: Sel-701-1 Monitor Applications
Introduction and Specifications SEL-701-1 Monitor Applications SEL-701-1 Monitor Applications ➢ Contactor-isolated motor ➢ SEL-701-1 Monitor provides locked rotor, overload, and unbalance protection ➢ SEL-2600 RTD Module Monitor measures RTD temperatures at the motor and communicates using optical fiber Monitor up...
Page 26: Sel-701-1 Monitor Protection Features
Introduction and Specifications SEL-701-1 Monitor Protection Features SEL-701-1 Monitor Protection Features The SEL-701-1 Monitor offers a full range of elements for motor protection, including: Flexible motor thermal element (49) that provides integrated protection for locked rotor, running overload, unbalanced current/negative-sequence current heating, and repeated or frequent starts.
Page 27: Sel-701-1 Monitoring And Reporting Features
Introduction and Specifications SEL-701-1 Monitoring and Reporting Features SEL-701-1 Monitoring and Reporting Features In addition to the protection functions outlined earlier, the SEL-701-1 Monitor offers advanced measuring and monitoring capabilities not found in other motor monitors, including: Extensive metering capabilities that provide real-time operating data.
Page 28: Monitor Part Number
Monitor Part Number Monitor Part Number To obtain a quotation or place an order for an SEL-701-1 Monitor, it is helpful to have a monitor part number. The following information helps you create a part number for the SEL-701-1 Monitor and provides some additional information that you may wish to include when you place your monitor order.
Page 29 Place a Request for Quotation or Order You may order an SEL-701-1 Monitor from your local SEL Sales Representative or International Distributor Office, one of SEL’s Regional Technical Service Centers, or directly from the factory.
Page 30: Sel-701-1 Monitor Serial Number Label
Figure 1.3 SEL-701-1 Monitor Serial Number Label. Figure 1.3 shows the serial number label for the SEL-701-1 Monitor. The label is affixed to the top of the monitor chassis. From the top of the label, the information includes: Monitor part number.
Page 31: Specifications
FLA = Motor rated full load amps Four-Wire Wye or Load-Loss/Load-Jam Function Open-Delta Voltages Load-Loss Alarm and Trip Burden: <2 VA at 300 V Setting Range: 0.10–1.00 • FLA ± 1%, ± 0.2 V Measuring Error: SEL-701-1 Monitor Date Code 20011009...
Page 32 (without voltage option) or 34 days (with Shock and Bump: IEC 255-21-2 : 1988 voltage option). Bump: Class 1 Shock Withstand: Class 1 Sequential Events Records Shock Response: Class 2 512 Latest Time-Tagged Events Seismic: IEC 255-21-3 : 1993, Level 2 SEL-701-1 Monitor Date Code 20011009...
Page 33 ISO: Monitor is designed and manufactured to an ISO-9001 certified quality program. UL/CSA: UL recognized to the requirements of UL-508; CSA C22.2, N.14 for Industrial Control Equipment; and UL-1053, “Ground- Fault Sensing and Relay Equipment.” CE: CE Mark. SEL-701-1 Monitor Date Code 20011009...
Page 34 This page intentionally left blank...
Page 35: Section 2: Installation
Section 2 Installation Panel Cut & Drill Plans Figure 2.1 on page 2.2 shows the mechanical dimensions of the SEL-701-1 Monitor. Figure 2.2 on page 2.3 shows the dimensions of the panel cutout required to mount the monitor. DANGER: Contact with instrument terminals may cause electrical shock which can result in injury or death.
Page 36 Terminal Block A (optional) Captive Mounting Stud (4 each) 4.45 in (113.0 mm) Weather Gasket 0.77 in (19.4 mm) 9.60 in (243.8 mm) 7.00 in (177.8 mm) Figure 2.1 SEL-701-1 Monitor Mechanical Dimensions (Front and Top Views). SEL-701-1 Monitor Date Code 20011009...
Page 37: Figure 2.2 Sel-701-1 Monitor Cut And Drill Dimensions
(4.78 mm) (149.4 mm) 4 places 8.40 in 5.88 in (213.4 mm) (149.4 mm) 0.19 in (typ) (4.8 mm) 1.26 in (typ) (32.0 mm) 5.50 in (139.7 mm) Figure 2.2 SEL-701-1 Monitor Cut and Drill Dimensions. SEL-701-1 Monitor Date Code 20011009...
Page 38: Monitor Mounting
This film is meant to protect the monitor finish during installation and is not required by the monitor in operation. Mounting Panel Weather Gasket Monitor 6-32 Self-Locking Nut (4 places) Figure 2.3 SEL-701-1 Monitor Panel Mounting Detail. SEL-701-1 Monitor Date Code 20011009...
Page 39: Monitor Rear-Panel Diagram
2.2. These cutaway areas provide additional clearance for swing-panel mounting. The monitor sides include drawings that indicate the factory default function of each monitor terminal and typical wiring diagrams. Figure 2.4 SEL-701-1 Monitor Rear Panel. SEL-701-1 Monitor Date Code 20011009...
Page 40: Figure 2.5 Sel-701-1 Monitor Left- And Right-Side Panel Drawings
Installation Monitor Rear-Panel Diagram Left-Side Panel Right-Side Panel Figure 2.5 SEL-701-1 Monitor Left- and Right-Side Panel Drawings. SEL-701-1 Monitor Date Code 20011009...
Page 41: Example Ac Wiring Diagrams
Installation Example AC Wiring Diagrams Example AC Wiring Diagrams Optional Voltage Inputs Current Inputs Ground CT Motor Figure 2.6 Example AC Wiring Diagram, Four-Wire Wye Voltages and Ground CT. SEL-701-1 Monitor Date Code 20011009...
Page 42 Installation Example AC Wiring Diagrams Optional Voltage Inputs Current Inputs Motor Figure 2.7 Example AC Wiring Diagram, Open-Delta Voltages and Residual IN Connection. SEL-701-1 Monitor Date Code 20011009...
Page 43 Installation Example AC Wiring Diagrams Optional Voltage Inputs Motor Figure 2.8 Example AC Voltage Wiring Diagram, Single Phase-to- Phase Voltage. Optional Voltage Inputs Motor Figure 2.9 Example AC Voltage Wiring Diagram, Single Phase-to- Neutral Voltage. SEL-701-1 Monitor Date Code 20011009...
Page 44: Monitor Connections
Contact with instrument terminals may cause electrical shock which can result in injury or death. Input Power Connections The SEL-701-1 Monitor power supply has a broad operating range that can accept ac or dc inputs. Power Supply Operating Range: 95–240 ±10% Vac 50/60 Hz.
Page 45 CT be placed between the neutral connection to ground and the motor, with the neutral lead included in the CT window. With shielded cable, the shield connection to ground must pass through the CT window. SEL-701-1 Monitor Date Code 20011009...
Page 46: Figure 2.10 Ground Ct Placement
Unshielded Cable Load Source Neutral Connected to Ground on Source Side Only x:1 or x:5 Window CT Shielded Cable Source Load Shields Connected Stress to Ground on Load Side Cone Shields Figure 2.10 Ground CT Placement. SEL-701-1 Monitor Date Code 20011009...
Page 47 Monitor Connections Contact Outputs The SEL-701-1 Monitor is equipped with five contact outputs. Each one provides a normally opened and a normally closed contact. The contacts are rated to switch 8 A resistive at 250 Vac. For dc operation, the contacts are rated for tripping duty, according to IEEE standards.
Page 48: Figure 2.11 Contact Output Factory Default Wiring Diagram
– / N Trip Fail-Safe Wiring Shown Figure 2.11 Contact Output Factory Default Wiring Diagram. Figure 2.12 on page 2.15 shows various wiring methods for fail-safe and nonfail- safe wiring to control breakers and contactors. SEL-701-1 Monitor Date Code 20011009...
Page 49: Figure 2.12 Trip Contact Fail-Safe, Nonfail-Safe Wiring Options
SEL-2600 RTD Module. This output is inactive if the monitor is not equipped with RTD inputs. Output OUT3 can be used to start the motor using the factory default settings as shown in Figure 2.13. SEL-701-1 Monitor Date Code 20011009...
Page 50: Figure 2.13 Optional Motor Start Wiring Using Factory Default Settings For Output Contact Out3
Using Factory Default Settings for Output Contact OUT3. Contact Inputs The SEL-701-1 Monitor is equipped with six internally wetted contact inputs. The monitor supplies 28 Vdc wetting voltage for each input so you only need to connect a dry contact, switch, or jumper to the input.
Page 51: Figure 2.14 Contact Input Factory Default Wiring Diagram
Factory Programmable Default Contact Inputs Functions IN1+ COM 1,2 Direct Trip IN2+ IN3+ Speed Switch COM 3,4 ACCESS2 Switch IN4+ IN5+ Emergency Restart Switch COM 5,6 IN6+ Figure 2.14 Contact Input Factory Default Wiring Diagram. SEL-701-1 Monitor Date Code 20011009...
Page 52: Figure 2.15 Analog Output Wiring
2.18 Monitor Connections Analog Output The SEL-701-1 Monitor single analog output provides a dc current level signal proportional to any one of several monitor measurements. Monitor settings described Analog Output Settings on page 3.43 in Section 3: Settings Calculation allow you to select the analog output range (0 –1 mA, 0 –20 mA, or 4 –20 mA).
Page 53: Table 2.1 Typical Maximum Rtd Lead Length
Platinum or Nickel RTD Copper RTD 950 ft 110 ft (290 m) (290 m) 1500 ft 180 ft (455 m) (54 m) 2400 ft 290 ft (730 m) (88 m) 3800 ft 450 ft (1155 m) (137 m) SEL-701-1 Monitor Date Code 20011009...
Page 54: Figure 2.16 Rtd Input Wiring
Shield RTD1 – COM1,2 RTD2 – RTD3 – COM3,4 RTD4 – RTD5 – COM5,6 RTD6 – RTD7 – COM7,8 RTD8 – RTD9 – COM9,10 RTD10 – RTD11 – COM11 Shield Figure 2.16 RTD Input Wiring. SEL-701-1 Monitor Date Code 20011009...
Page 55 EIA-232 Communication Cables The SEL-701-1 Monitor is equipped with 9-pin EIA-232 serial port connectors on the front and rear panels. The front-panel port is always available for connection to a local PC for setting entry or information download. Use SEL Cable C234A (pinout shown in Connect Your PC to the Monitor on page 5.3 in Section 5: ASCII Serial Port...
Page 56 The SEL-701-1 Monitor is equipped with a rear-panel EIA-485 serial port connector which operates using Modbus protocol when you enable that feature by monitor settings. Connect the SEL-701-1 Monitor EIA-485 port to a Modbus Master device as shown in Figure 2.17 on page 2.23.
Page 57: Figure 2.17 Rear-Panel Eia-485 Serial Port Connections
Characteristic SEL-701 Relay Other Twisted, Shielded Pair Devices Modbus C10 C12 – Master Connect Shield to Ground at One Point Only Figure 2.17 Rear-Panel EIA-485 Serial Port Connections. To minimize reflections in an EIA-485 network, use termination resistors at each end of the line. Also, to ensure that the network will “float” to A logic Level 1 or “high”...
Page 58: Sel-2600 Rtd Module
SEL-2600 RTD Module RTD Connections at the SEL-2600 RTD Module The SEL-701-1 Monitor is compatible with the SEL-2600 RTD Module that monitors up to 12 RTD inputs and a single contact input. The module uses a fiber-optic cable to communicate temperature measurements and the contact status back to the monitor.
Page 59: Section 3: Settings Calculation
Section 3 Settings Calculation Introduction The SEL-701-1 Monitor protection settings are divided into two major categories. The first category, described in this section, includes settings to configure the motor protection elements and basic functions. The second category, described in Appendix B: SELogic® Control Equations and Monitor...
Page 60 As you calculate the settings, record them using a photocopy of the Settings Sheets found in Appendix F: SEL-701-1 Monitor Settings Sheets. If you record the settings manually, you can enter them using the front-panel Set Monitor function, or the front-panel serial port and the Access Level 2 commands listed below.
Page 61: Application Data
Settings Calculation Application Data Application Data It is quicker and easier for you to calculate settings for the SEL-701-1 Monitor if you collect the following information before you begin: Specifications of the protected motor including: Rated full load current. Service factor.
Page 62: General Data
20 Characters TID = MONITOR The SEL-701-1 Monitor prints the Relay and Terminal Identifier strings at the top of responses to serial port commands to identify messages from individual monitors. Enter up to 20 characters, include capital letters A–Z, numbers 0–9, periods (.), dashes (-), and spaces.
Page 63: Figure 3.1 Phase Rotation Settings
North American standard (Month/Day/Year) or engineering standard (Year/Month/Day). The DMTC setting defines the thermal time constant used by the monitor current and power demand meter function, if voltages are included. SEL-701-1 Monitor Date Code 20011009...
Page 64: Table 3.4 Vt Configuration Settings
Metering. When you use one phase-to-phase voltage, the monitor displays that magnitude and phase angle. When you use one phase- to-neutral voltage, the monitor multiplies that magnitude by the SEL-701-1 Monitor Date Code 20011009...
Page 65 The monitor displays zero for the magnitudes of the unmeasured voltages. Balanced voltages are assumed for power and power factor calculations. Monitors that are not equipped with phase voltage inputs hide these settings and disable voltage-based protection and metering functions. SEL-701-1 Monitor Date Code 20011009...
Page 66: Basic Motor Protection
Unbalance Current/Negative-Sequence Current Heating. Repeated or Frequent Starting. The Setting Method setting selects the thermal element algorithm that will be used in the SEL-701-1 Monitor. The Setting Method setting offers four options: Rating, Generic, User, and OFF. Rating Setting Method.
Page 67: Table 3.5 Thermal Element Configuration Settings, Setting Method = Rating
1.2 to determine a cold locked rotor time that is acceptable for most motors. EXAMPLE 3.3 Thermal Element Rating Method Setting A 4160 V, 600 HP motor is to be protected using the SEL-701-1 Monitor Thermal Element Rating Method. The motor data sheet includes the following information.
Page 68 Hot = 16 seconds Service Factor = 1.2 Phase current transformers having 80:5 ratios are selected for the application. The SEL-701-1 Monitor settings for the application are calculated as shown below. Current Transformer Ratio (CTR) = 80/5 = 16 CT Secondary Rating (ITAP) = 5 Full Load Amps (FLA) = 76.9/16 = 4.81 A secondary...
Page 69: Table 3.6 Thermal Element Configuration Settings, Setting Method = Generic
Each increase in the curve number yields a 2.1-second increase in the hot motor thermal limit time at six times full load current. Continue calculating the balance of thermal element settings with Thermal Capacity Alarm Setting on page 3.20. SEL-701-1 Monitor Date Code 20011009...
Page 70 3.12 Basic Motor Protection EXAMPLE 3.5 Thermal Element Generic Method Setting A 4160 V, 800 HP motor is to be protected using the SEL-701-1 Monitor Thermal Element Generic Curve Method. The motor data sheet includes the following information. Rated Horsepower (HP) = 800 HP Rated Voltage (V) = 4160 V Rated Full Load Current (A) = 101.0 A...
Page 71: Figure 3.2 Generic Thermal Limit Curves, Cold Motor
6000 (5000) Curve 3000 (2500) 1500 (1250) 600 (500) 300 (250) 150 (125) 60 (50) .6 .7 .8 .9 7 8 9 Multiples of Full Load Amps Figure 3.2 Generic Thermal Limit Curves, Cold Motor. SEL-701-1 Monitor Date Code 20011009...
Page 72: Table 3.7 Generic Thermal Limit Curve Tripping Times From Reset Versus
Table 3.7 Generic Thermal Limit Curve Tripping Times From Reset versus Multiples of Full Load Amps, Curves 1–10 (Thermal Limit Times in Seconds) Curves Multiples of Full Load Amps 1.01 311.4 622.7 934.1 1245.4 1556.8 1868.1 2179.5 2490.8 2802.2 3113.6 1.10 138.9 277.7...
Page 73: Table 3.8 Generic Thermal Limit Curve Tripping Times From Reset Versus
Table 3.8 Generic Thermal Limit Curve Tripping Times From Reset versus Multiples of Full Load Amps, Curves 15, 20, 25, 30, 35, 40, 45 (Thermal Limit Times in Seconds) Curves Multiples of Full Load Amps 1.01 4670.3 6227.1 7783.9 9340.7 10897.4 12454.2 14011.0...
Page 74 Time to trip at 7.50 o FLA 1.0–400.0 s, NP TTT750 = NP Time to trip at 8.00 o FLA 1.0–400.0 s, NP TTT800 = NP Time to trip at 8.50 o FLA 1.0–350.0 s, NP TTT850 = NP SEL-701-1 Monitor Date Code 20011009...
Page 75: Table 3.9 Thermal Element Configuration Settings, Setting Method = User
Figure 3.3 on page 3.18. EXAMPLE 3.6 Thermal Element User Method Setting A 4000 V, 3000 HP motor is to be protected using the SEL-701-1 Monitor Thermal Element User Method. The motor data sheet includes the following information: Rated Horsepower (HP) = 3000 HP...
Page 76: Figure 3.3 3000 Hp Example Motor Cold Thermal Limit Curve
By examining the curve, we can find the thermal limit times at various multiples of Full Load Current, as listed in Table 3.10 on page 3.19. These times map directly to the monitor settings shown below the table. SEL-701-1 Monitor Date Code 20011009...
Page 77: Table 3.10 3000 Hp Motor Thermal Limit Times
15.2 7.00 13.2 Phase current transformers having 500:5 ratios are selected for the application. The SEL-701-1 Monitor settings for the application are calculated as shown below. Current Transformer Ratio (CTR) = 500/5 = 100 CT Secondary Rating (ITAP) = 5 Full Load Amps (FLA) = 366/100 = 3.66 A secondary...
Page 78: Table 3.11 Thermal Capacity Alarm Setting
Over the past five starts, a motor has used 24%, 27%, 22%, 25%, and 26% of thermal capacity. The largest thermal capacity to start is 27%. The monitor requires that the present thermal capacity drop below 63% (100%–37%) before a new start is allowed. SEL-701-1 Monitor Date Code 20011009...
Page 79: Equation 3.1
Therefore, Use Learned Cooling Time should be disabled (COOLEN = N) in this case, unless a cooling time or time constant is recommended by the motor manufacturer. SEL-701-1 Monitor Date Code 20011009...
Page 80: Table 3.14 Overcurrent Element Settings
Setting range shown for INTAP = 5 A. Range is 0.005–2.000 A when INTAP = 1 A. If the SEL-701-1 Monitor is connected to a motor protected by a fused contactor, disable the phase overcurrent elements by setting their pickups to OFF. If the monitor is connected to a device capable of interrupting fault current, use the Level 1 phase overcurrent element to detect and trip for short circuit faults.
Page 81: Figure 3.4 Ground Fault Currents Using A Window Ct
The resistor is sized to limit the current to 10 A primary. The three motor leads are passed through the window of a 10:1 CT. The CT secondary is connected to the SEL-701-1 Monitor 1 A IN current input, as shown in Figure 3.4.
Page 82: Table 3.16 Load-Jam Function Settings
Jam Trip Pickup setting for longer than the time delay setting, the monitor will trip. Set the Load Jam Trip Pickup greater than the expected normal load current but less than rated locked rotor current. This setting is entered in per unit of the Full Load Amps (FLA) setting. SEL-701-1 Monitor Date Code 20011009...
Page 83: Table 3.17 Load-Loss Element Settings, No Voltage Option
These settings are entered in per unit of the Full Load Amps (FLA) setting. If you expect the motor to operate at no load normally, disable this function by setting LLAPU equal to OFF. The monitor automatically hides the remaining load-loss settings. SEL-701-1 Monitor Date Code 20011009...
Page 84: Table 3.18 Load-Loss Element Settings, With Voltage Option
46UBTD = 5.00 Unbalanced motor terminal voltages cause unbalanced stator currents to flow in the motor. The negative-sequence current component of the unbalance current causes significant rotor heating. While the SEL-701-1 Monitor motor thermal element models SEL-701-1 Monitor Date Code 20011009...
Page 85: Table 3.20 Phase Reversal Tripping Setting
The SEL-701-1 Monitor calculates percent unbalance current in one of two ways depending on the magnitude of the average current. When the average current, Iav, is...
Page 86 Speed Switch Trip Time Delay when the speed switch contact is monitored by the external module. To disable speed switch tripping, set the Speed Switch Trip Time Delay equal to OFF. SEL-701-1 Monitor Date Code 20011009...
Page 87: Rtd-Based Protection
Temperature Preference Setting C, F TMPREF = F INT is only available in Models 0701110X and 0701111X. The SEL-701-1 Monitor can monitor temperature using RTD inputs in one of two ways: Optional internal RTD inputs. An SEL-2600 RTD Module. When RTDs will not be connected to the monitor or to an external module, set the RTD Input Option setting equal to NONE.
Page 88 For inputs connected to monitor temperatures of other apparatus, set RTD Location equal to OTH. If OTH is selected for the RTD Location, the SEL-701-1 Monitor allows you to enter a 10-character description for the RTD. This description will be used when the...
Page 89 If an RTD Location setting is equal to NONE, the monitor does not request that an RTD Type setting be entered for that input. The four available RTD types are: 100-ohm platinum (PT100) 100-ohm nickel (NI100) 120-ohm nickel (NI120) 10-ohm copper (CU10) SEL-701-1 Monitor Date Code 20011009...
Page 90 RTD7T = OFF RTD Alarm Temperature OFF, 32°–482°F RTD7A1 = OFF RTD Alarm Temperature OFF, 32°–482°F RTD7A2 = OFF RTD Alarm Temperature OFF, 32°–482°F RTD7A3 = OFF RTD Trip Temperature OFF, 32°–482°F RTD8T = OFF SEL-701-1 Monitor Date Code 20011009...
Page 91 Y, N RTDBEN = Y The twelfth RTD input is only available when you use the SEL–2600 RTD Module. The SEL-701-1 Monitor provides temperature alarms and trips using the RTD temperature measurements and the alarm and trip temperature settings in Table 3.25.
Page 92 40°C. Provides an RTD Bias Alarm if the winding temperature exceeds 60°C rise over ambient and the RTD % Thermal Capacity exceeds the thermal element % Thermal Capacity by more than 10%. SEL-701-1 Monitor Date Code 20011009...
Page 93: Equation 3.4
To preserve insulation life, NEMA standards suggest a 1°C reduction in RTD trip temperature for each 1°C rise in ambient temperature over 40°C. When you enable RTD biasing, the SEL-701-1 Monitor automatically reduces the RTD trip temperatures for all winding RTDs when ambient temperature is above 40°C.
Page 94: Table 3.26 Rtd Resistance Versus Temperature
190.00 172.46 291.96 231.80 16.39 200.00 175.84 303.46 240.70 16.78 210.00 179.15 315.31 249.80 17.17 220.00 183.17 327.54 259.20 17.56 230.00 186.82 340.14 268.90 17.95 240.00 190.45 353.14 278.90 18.34 250.00 194.08 366.53 289.10 18.73 SEL-701-1 Monitor Date Code 20011009...
Page 95: Voltage-Based Protection (Monitor Models 0701101X & 0701111X)
RTD-Based Protection Voltage-Based Protection (Monitor Models 0701101X & 0701111X) When you purchase the SEL-701-1 Monitor with optional voltage inputs, the monitor enables a number of additional protection functions. The settings for these functions are described below. Under- & Overvoltage Elements Phase-to-Phase Under- &...
Page 96 59P2P = OFF Residual O/V Pickup OFF, 1–300 V 59GP = OFF When you connect the SEL-701-1 Monitor voltage inputs to phase-to-neutral connected VTs, as in Figure 2.6 on page 2.7 in Section 2: Installation Figure 2.9 on page 2.9 in Section 2: Installation, the monitor provides two levels of phase-to-neutral overvoltage and undervoltage elements, plus a residual overvoltage element.
Page 97 Setting range shown for ITAP = 5 A. Range is 6–400 VAR when ITAP = 1 A. When you apply the SEL-701-1 Monitor on a synchronous motor, the VAR Element Arming Delay disarms the reactive power elements for a settable time after the motor starts.
Page 98 Setting range shown for ITAP = 5 A. Range is 6–400 W when ITAP = 1 A. The SEL-701-1 Monitor Underpower Element Arming Delay disarms the underpower elements for a settable time after the motor starts. This allows the motor to be brought to full load.
Page 99: Table 3.31 Power Factor Element Settings
0–15000 s 55DLY = 10 When you apply the SEL-701-1 Monitor on a synchronous motor, the Power Factor Element Arming Delay disarms the power factor elements for a settable time after the motor starts. This allows the motor to be brought to full speed and the field applied.
Page 100 Level 3 Time Delay 0.03–400.00 s 81D3D = 0.03 The SEL-701-1 Monitor provides three over- or underfrequency elements with independent pickup and time-delay settings. When an element pickup setting is less than the Nominal Frequency setting, the element operates as an underfrequency element.
Page 101: Output Configuration
0.1–16.0 A ITAP = 1 A The SEL-701-1 Monitor provides a dc analog current output with three signal ranges and a variety of output parameters. Set the Analog Output Signal Type to select the operating range of dc output current. Select the Analog Output Parameter from the list of available options.
Page 102: Table 3.34 Front-Panel Configuration Settings
The Front-Panel Display Brightness setting adjusts the intensity of the vacuum fluorescent display. If the display dims over a period of years or if the monitor will be installed in a brightly lit location, you may wish to increase the Front-Panel Display Brightness setting. SEL-701-1 Monitor Date Code 20011009...
Page 103: Table 3.35 Display Message Settings
Table 3.35 Display Message Settings Setting Name = Setting Prompt Setting Range Factory Default Display Messages 20 characters; enter NA to NULL DM1_1 = SEL-701-1 DM1_0 = DM2_1 = MONITOR DM2_0 = DM3_1 = RTD FAILURE DM3_0 = DM4_1 =...
Page 104 Y, N FACTLED = Y The SEL-701-1 Monitor includes factory logic that controls the LED operation. Factory Logic LEDs flash to indicate an alarm condition and are on steady to indicate the cause of the latest trip. The function that alarmed or tripped is indicated by the text to the right of each LED.
Page 105: Table 3.37 Output Contact Fail-Safe And Trip Duration Settings
0.00–400.00 s TDURD = 0.50 The SEL-701-1 Monitor allows you to enable fail-safe output contact operation for monitor contacts on an individual basis. When contact fail-safe is enabled, the monitor output contact is held in its energized position when monitor control power is applied and falls to its deenergized position when control power is removed.
Page 106 Factory Default Use Factory Logic Settings Y, N FACTLOG = Y The SEL-701-1 Monitor includes factory logic settings that generate trip and alarm outputs for the protection elements shown in Figure 3.6 on page 3.49 through Figure 3.9 on page 3.51.
Page 107: Figure 3.6 Factory Tripping Logic
Power Factor Element Trip 47T = Phase Reversal Trip 55T = Reactive Power Element Trip IN2 = Direct Trip Contact Input VART = Undervoltage Element 27P1 = SPDSTR = Speed Switch Trip Figure 3.6 Factory Tripping Logic. SEL-701-1 Monitor Date Code 20011009...
Page 108: Figure 3.7 Factory Contact Output Logic
Contact Input IN1 Contact Input IN2 Direct Trip Input Contact Input IN3 or Speed Switch Input Contact Input IN7 (SEL-2600) Contact Input IN4 ACCESS2 Input Contact Input IN5 Emergency Restart Input Figure 3.8 Factory Contact Input Logic. SEL-701-1 Monitor Date Code 20011009...
Page 109: Figure 3.9 Factory Event Triggering Logic
Level 1 Over-/Underfrequency Trip LOSSALRM = Load Loss Alarm 81D2T = Level 2 Over-/Underfrequency Trip 37PA = Underpower Element Alarm 81D3T = Level 3 Over-/Underfrequency Trip 55A = Power Factor Element Alarm Figure 3.9 Factory Event Triggering Logic. SEL-701-1 Monitor Date Code 20011009...
Page 110: Serial Port Settings
3.52 Serial Port Settings Serial Port Settings The SEL-701-1 Monitor provides settings that allow you to configure the communication parameters for the front- and rear-panel serial ports. The front-panel serial port only supports ASCII communications described in detail in Section 5: ASCII Serial Port Operation.
Page 111: Table 3.41 Set P Rear-Panel Serial Port Settings, Protocol = Mod
(RTS/CTS) flow control, set the Enable Hardware Handshaking setting equal to Y. The SEL-701-1 Monitor can accept binary commands to operate output contacts, set and clear logic conditions, or start and stop the motor when the Fast Operate Enable setting equals Y.
Page 112: Sequential Events Recorder (Ser) Settings
Sequential Events Recorder (SER) Settings Sequential Events Recorder (SER) Settings The SEL-701-1 Monitor processes ac and dc inputs four times per power system cycle. During every processing interval, it updates the state of each protection element and logic function. The details of this activity are described in Appendix B: SELogic®...
Page 113 Use NA to WDGTRIP, BRGALRM, BRGTRIP, disable setting. AMBALRM, AMBTRIP, OTHALRM, OTHTRIP, 81D1T, 81D2T, 81D3T, TRGTR, START, 50P1T, 50P2T SER4 24 Relay Word bits, separated SER4 = NA by commas. Use NA to disable setting. SEL-701-1 Monitor Date Code 20011009...
Page 114 Ground Fault. Assert when the monitor issues a ground fault 50N1T, 50N2T trip due to pickup and timeout of a residual (50G1T or 50G2T, sum of phase current inputs) or neutral (50N1T or 50N2T, IN current input) definite-time overcurrent element. SEL-701-1 Monitor Date Code 20011009...
Page 115: Table 3.43 Default Ser Trigger Setting Relay Word Bits Definitions
Motor Start. Asserts when an internal monitor function calls for a motor start. A motor start will only occur if a monitor output contact is programmed and connected to close the contactor or motor circuit breaker. SEL-701-1 Monitor Date Code 20011009...
Page 116 (A–Z), numbers (0–9), and the underscore character (_) within each string. Do not attempt to use a space within a string because the monitor will interpret a space as the break between two strings. If you wish to clear a string, simply type ‘NA’. SEL-701-1 Monitor Date Code 20011009...
Page 117: Table 3.45 Set R Ser Alias Settings
DROPOUT ALIAS14 = SPEEDSW SPEED_SW_IN PICKUP DROPOUT ALIAS15 = IN5 EMERGNCY_RSTART PICKUP DROPOUT ALIAS16 = IN1 MOTOR_BREAKER OPEN CLOSED ALIAS17 = IN4 ACCESS2 ALLOWED PASSWORD _ONLY ALIAS18 = 0 ALIAS19 = 0 ALIAS20 = 0 SEL-701-1 Monitor Date Code 20011009...
Page 118 This page intentionally left blank...
Page 119: Section 4: Front-Panel Operation
Section 4 Front-Panel Operation Front-Panel Layout The SEL-701-1 Monitor front-panel interface consists of LEDs, a vacuum fluorescent display, a six-button keypad, and an EIA-232 serial port connector. The front-panel layout is shown in Figure 4.1. Monitor Enabled LED Vacuum Fluorescent Display...
Page 120: Normal Front-Panel Display
Display Message Settings on page 3.45 in Section 3: Settings Calculation. If you wish to change the conditions under which the monitor displays a message, refer to Appendix B: SELogic® Control Equations and Monitor Logic. SEL-701-1 Monitor Date Code 20011009...
Page 121: Front-Panel Automatic Messages
Section 8: Event Analysis for more information) Monitor Self-Test Failure Has Occurred Type of failure Section 9: Maintenance & Troubleshooting Attempted Motor Start Was Blocked Reason start was blocked and time until a start is allowed SEL-701-1 Monitor Date Code 20011009...
Page 122: Front-Panel Menus & Operations
Front-Panel Menus & Operations Introduction The SEL-701-1 Monitor front panel gives you access to most of the information that the monitor measures and stores. You can also use front-panel controls to start or stop the motor, pulse output contacts, and view or modify monitor settings.
Page 123: Table 4.2: Front-Panel Pushbutton Functions
Access Level 2 password or can assert the ACCESS2 input (factory programmed to input IN4). In the figures that follow, restricted activities are marked with the padlock symbol shown in Figure 4.5. Figure 4.5 Access Level Security Padlock Symbol. SEL-701-1 Monitor Date Code 20011009...
Page 124: Figure 4.6 Password Entry Screen
Step 3. With the correct first character underlined, press the {ENTER} pushbutton. The first character will appear in the upper line of the display and the blinking cursor will move one character to the right. SEL-701-1 Monitor Date Code 20011009...
Page 125 If the password is correct, the monitor displays the message: “Level 2 Access Granted.” Press the {ENTER} pushbutton to continue your task. If the password was incorrect, the monitor displays the message “Invalid Password.” Press the {ENTER} pushbutton to return to your previous task. SEL-701-1 Monitor Date Code 20011009...
Page 126: Front-Panel Main Menu
Meter Values History Data Press this key to select ENTER an underlined menu item. Motor Statistics Status of Monitor View Relay Word Pulse Out Contact Reset Thermal Model Reset Learned Param Figure 4.8 Front-Panel Main Menu. SEL-701-1 Monitor Date Code 20011009...
Page 127: Figure 4.9 Main Menu: Start Motor Function
Stop Motor Function ENTER Stop Motor Stop the motor? Yes No To move between Yes and No. Yes: Initiates action; No: Returns to Main Menu. ENTER To select underlined option. Figure 4.11 Main Menu: Stop Motor Function. SEL-701-1 Monitor Date Code 20011009...
Page 128: Figure 4.12 Main Menu: Reset Trip/Targets Function
Monitor Elements ↓ Front Port Rear Port Press these keys to move within the list. Date Time Password Press this key to select ENTER an underlined menu item. Figure 4.13 Main Menu: Set Monitor Function. SEL-701-1 Monitor Date Code 20011009...
Page 129: Figure 4.14 Set Monitor\Monitor Elements Function
Within the list of setting categories, press the {ENTER} pushbutton to view or change specific settings within the category. To edit a setting, press the {ENTER} pushbutton while the setting is displayed. The monitor requires Level 2 Access to edit settings. SEL-701-1 Monitor Date Code 20011009...
Page 130: Figure 4.15 Set Monitor\Ser Setting Categories
Access Level 2 to edit a setting. The relay will request the Level 2 password if you have not entered it during this session or if input IN4 is not asserted. Figure 4.15 Set Monitor\SER Setting Categories. SEL-701-1 Monitor Date Code 20011009...
Page 131: Figure 4.16 Set Monitor\Front Serial Port Settings
Access Level 2 to edit a setting. The relay will request the Level 2 password if you have not entered it during this session or if input IN4 is not asserted. Figure 4.16 Set Monitor\Front Serial Port Settings. SEL-701-1 Monitor Date Code 20011009...
Page 132: Figure 4.17 Set Monitor\Rear Serial Port Settings
Set Monitor Menu Item Date Function ENTER Date Date= 03/18/1999 Edit? Yes No To move between Yes and No. Yes: Initiates action; No: Returns to Set Relay Menu. ENTER To select underlined option. Figure 4.18 Set Monitor\Date Function. SEL-701-1 Monitor Date Code 20011009...
Page 133: Figure 4.19 Set Monitor\Time Function
Edit the Access Level 2 password using the steps described in Access Level 2 Password Entry on page 4.6 password entry. Remember that the monitor password is case sensitive. To disable Access Level 2 password protection, set Password = DISABLE. SEL-701-1 Monitor Date Code 20011009...
Page 134: Figure 4.21 Main Menu: Meter Values Function
Meter Values Menu Item Instantaneous Meter Display ENTER ↑ Instantaneous Meter 10.6A(RMS) ↓ 10.6A(RMS) 10.5A(RMS) 0.2A(RMS) Press these keys to move within the list. VAB= 480V(RMS) = 0.0% Figure 4.22 Meter Values Display Functions. SEL-701-1 Monitor Date Code 20011009...
Page 135: Figure 4.23 Meter Values Reset Functions
Display History Function History Data Menu Item ENTER Display History Date: 03/18/1999 Time: 06:31:02.257 Trip Type: Move among data for this event. kVA= 452.6 Move among events. PF = 0.85 LAG Figure 4.25 History Data\Display History Function. SEL-701-1 Monitor Date Code 20011009...
Page 136: Figure 4.26 History Data\Clear History Function
ENTER ↑ Motor Use Data Running Time ↓ 10:14:26 Stopped Time Time Running Press these keys to move within the list. Total MWhr Number of Starts Last Reset Figure 4.28 Motor Statistics\Motor Use Data Function. SEL-701-1 Monitor Date Code 20011009...
Page 137: Figure 4.29 Motor Statistics\Average And Peak Data Function
Motor Statistics Menu Item Trip and Alarm Data Display ENTER ↑ Trips/Alarms Data Thermal ↓ Locked Rotor Press these keys to move within the list. Load Loss Last Reset Figure 4.30 Motor Statistics\Trip and Alarm Data Function. SEL-701-1 Monitor Date Code 20011009...
Page 138: Figure 4.31 Motor Statistics\Reset Statistics Function
Main Menu Item Status of Monitor Function ENTER ←→↑↓ Status of Monitor Status: OK FID=SEL-701-1 R100-V0 Offset: IA=OK Offset: IB=OK Press these keys to move within the list of self-test results. TC_START=OK Figure 4.32 Main Menu: Status of Monitor Function.
Page 139: Figure 4.33 Main Menu: View Relay Word Function
TRIP Yes No Other contacts operate similarly. To move between Yes and No. Yes: Initiates action; No: Returns to Pulse Output Contact Menu. ENTER To select underlined option. Figure 4.35 Pulse Output Contact Menu Function. SEL-701-1 Monitor Date Code 20011009...
Page 140: Figure 4.36 Main Menu: Reset Thermal Model Function
Reset Learned Cooling Time? Yes No To move between Yes and No. Yes: Resets Learned CoolingTime; No: Returns to Reset Learned Param Menu. ENTER To select underlined option. Figure 4.38 Reset Learned Param\Reset Cooling Time Function. SEL-701-1 Monitor Date Code 20011009...
Page 141: Figure 4.39 Reset Learned Param\Reset Start Therm Cap Function
Thermal Cap? Yes No To move between Yes and No. Yes: Resets Learned Start Thermal Cap; No: Returns to Reset Learned Param Menu. ENTER To select underlined option. Figure 4.39 Reset Learned Param\Reset Start Therm Cap Function. SEL-701-1 Monitor Date Code 20011009...
Page 142 This page intentionally left blank...
Page 143: Section 5: Ascii Serial Port Operation
ASCII Serial Port Operation Introduction You can interact with the SEL-701-1 Monitor through the front-panel interface or the serial port interface. This section describes the connections and commands used with the serial port interface; the front-panel interface is discussed in...
Page 144: You Will Need
Figure 5.1 on page 5.3. You can use a variety of terminal emulation programs on your personal computer to communicate with the SEL-701-1 Monitor. Examples of PC-based terminal emulation programs include: ® ProComm...
Page 145: Connect Your Pc To The Monitor
ASCII Serial Port Operation Connect Your PC to the Monitor Connect Your PC to the Monitor Connect your PC serial port to the SEL-701-1 Monitor serial port using a cable having the pinout shown in Figure 5.1 or a null-modem cable. This and other cables are available from SEL.
Page 146: Table 5.1 Pin Functions And
ASCII Serial Port Operation Connect Your PC to the Monitor Table 5.1 Pin Functions and Definitions for SEL-701-1 Monitor EIA-232 Serial Ports Pin Function Definition 1, 4, 6 No Connection RXD, RX Receive Data TXD, TX Transmit Data 5, 9...
Page 147: Configure Your Terminal Emulation Software
Configure your terminal emulation software to match the default settings shown Table 5.2. For the best display, use VT-100 terminal emulation. If VT-100 is not available, WYSE-100 and ANSI terminal emulations also work. Table 5.2 SEL-701-1 Monitor Serial Communication Default Settings Setting Default Baud Rate...
Page 148: Using Terminal Commands
You can use the XOFF character to pause in the middle of long transmissions from the monitor, such as event reports and SER reports. To resume the transmission use the XON character. To cancel a transmission in progress, use the <CNTRL>X keystrokes. SEL-701-1 Monitor Date Code 20011009...
Page 149: Serial Port Access Levels
Access Level 1 commands are also available in Access Level 2. When the monitor is in Access Level 2, the monitor sends the following prompt when you press <ENTER> or after a command response is finished: =>> SEL-701-1 Monitor Date Code 20011009...
Page 150: Command Summary
All Access Level 1 commands are also available in Access Level 2. The commands are shown in upper-case letters, but can also be entered with lower-case letters. Table 5.4 SEL-701-1 Serial Port Command Summary Access Serial Port Level...
Page 151 ASCII Serial Port Operation Command Summary Table 5.4 SEL-701-1 Serial Port Command Summary (Continued) Access Serial Port Level Command Command Description Page Number Event Analysis Commands EVENT View event reports 5.13 HISTORY View event summaries/histories 5.13 HISTORY R Reset event history data 5.14...
Page 152: Command Explanations
View the status of monitor elements, inputs, or outputs TARGET R (1 or 2) Reset trip/target LEDs TIME (1 or 2) View or change the time TRIGGER (1 or 2) Trigger an event report => Figure 5.3 HELP Command Response. SEL-701-1 Monitor Date Code 20011009...
Page 153: Figure 5.4 2Ac Command Example
ANA command execution. =>>ANA 75 5.5 Outputing 16.00mA to Analog Output Port for 5.5 minutes. Press any key to end test Analog Output Port Test Completed. =>> Figure 5.5 ANA Command Example. SEL-701-1 Monitor Date Code 20011009...
Page 154: Table 5.5 Sel-701-1 Monitor Control Subcommand
(1–4). The monitor repeats your command followed by a colon. At the colon, type the Control subcommand you wish to perform (see Table 5.5). Table 5.5 SEL-701-1 Monitor Control Subcommand Subcommand Description SRB n Set Remote Bit n ("ON" position) CRB n Clear Remote Bit n ("OFF"...
Page 155: Figure 5.6 Date Command Example
The monitor saves up to fourteen 15-cycle event reports. For more details on the information included in the monitor event summaries, Section 8: Event Analysis. Figure 5.7 shows an example HISTORY command response. SEL-701-1 Monitor Date Code 20011009...
Page 156: Figure 5.7 History Command Example
Display load profile records n2 to n1, starting with n2. LDP d1 Display all the load profile records made on date d1. LDP d1 d2 Display all the load profile records made from d2 to d1, inclusive, starting with d2. SEL-701-1 Monitor Date Code 20011009...
Page 157 –179.99 to 180.00 degrees. To view the instantaneous meter values once, use the METER command. To view the METER values k times, use the METER k command, where k is a number between 1 and 32767. SEL-701-1 Monitor Date Code 20011009...
Page 158: Figure 5.8 Meter Command Example
Figure 5.9 METER D Command Example. Energy Metering: METER E When the monitor is equipped with optional voltage inputs, the METER E command displays the measured kilowatt hours, kilovar hours, and kilovolt-amp hours since the last reset. SEL-701-1 Monitor Date Code 20011009...
Page 159: Figure 5.10 Meter E Command Example
% of Full Load Amps, the present thermal model % Thermal Capacity, and the RTD % Thermal Capacity if ambient and winding temperatures are monitored and a winding RTD trip temperature is set. If the motor is SEL-701-1 Monitor Date Code 20011009...
Page 160: Figure 5.12 Meter T Command Example
The MOTOR command displays the motor operating statistics that include the following: Total motor running hours, stopped hours, and percent running time. Total megawatt hours (if optional voltages are included). Total number of motor starts. SEL-701-1 Monitor Date Code 20011009...
Page 161: Table 5.9 Msr General Command Format
Use the MST R command to reset the data stored in the motor start trend buffers. This should only be done at initial monitor installation, for motor rewinds, or after overhaul of the load equipment. SEL-701-1 Monitor Date Code 20011009...
Page 162: Table 5.10 Pulse Command Format
The output name (TRIP, OUT1, OUT2, OUT3, or ALARM). The pulse duration (1–30) in minutes. If y is not specified, the pulse duration defaults to 1 second. Use the PULSE command to test contact wiring during installation and maintenance testing. SEL-701-1 Monitor Date Code 20011009...
Page 163: Figure 5.13 Pulse Command Example
You can access SER data by record number or by date. The most recent record is always record number 1. The various SER command options are shown in Table 5.11. SEL-701-1 Monitor Date Code 20011009...
Page 164 Settings Command Type Description Monitor Protection elements, timers, etc. SET R Sequential Events Recorder trigger conditions and ALIAS settings. SET P n Port Serial port settings for Serial Port n (n = F or R). SEL-701-1 Monitor Date Code 20011009...
Page 165: Table 5.13 Set Command Editing Keystrokes
Use this parameter to speed up the SET command. If you wish to review the settings before saving, do not use TERSE option. SEL-701-1 Monitor Date Code 20011009...
Page 166 (e.g., SHO 50P1P displays the monitor settings starting with setting 50P1P). The default is the first setting. The SHOW commands display only the enabled settings. To display all settings, including disabled/hidden settings, append an A to the SHOW command (e.g., SHOW A). SEL-701-1 Monitor Date Code 20011009...
Page 167: Figure 5.15 Show Command Example
DM1_0 DM2_1 =MONITOR DM2_0 DM3_1 =RTD FAILURE DM3_0 DM4_1 DM4_0 DM5_1 DM5_0 DM6_1 DM6_0 TRFS OUT1FS OUT2FS OUT3FS TDURD = 0.50 ABSDLY FACTLOG = Y LEUSE 76.8 SETCHK B74A =>> Figure 5.15 SHOW Command Example. SEL-701-1 Monitor Date Code 20011009...
Page 168 Tests the memory locations where the Motor Learned Thermal Capacity to Start data is stored. The monitor indicates OK or FAIL for each self-test result. Refer to Section 9: Maintenance & Troubleshooting for self-test thresholds and corrective actions. SEL-701-1 Monitor Date Code 20011009...
Page 169: Figure 5.16 Status Command Example
ASCII Serial Port Operation 5.27 Command Explanations =>STATUS SEL-701-1 Date: 08/15/2001 Time: 19:01:28.364 MONITOR FID=SEL-701-1-R300-V11xxx-Z100100-D20010815 CID=4A50 SELF TESTS Offset: Offset: +5V_PS -5V_PS +15V_PS +28V_PS TEMP CR_RAM EEPROM BATTERY LC_TIME TC_START Monitor Enabled => Figure 5.16 STATUS Command Example. STATUS R (Level 2) To reset the self-test status and restart the monitor, use the STA R command from Access Level 2.
Page 170: Figure 5.17 Target Command Example
TAR 50P1T displays Relay Word Row 3). Valid names are shown Table 5.18. k is an optional parameter to specify the number of times (1–32767) to repeat the Relay Word row display. If k is not specified, the Relay Word row is displayed once. SEL-701-1 Monitor Date Code 20011009...
Page 171: Table 5.18 Front-Panel Leds And The Tar 0 Command
Table 5.18 Front-Panel LEDs and the TAR 0 Command Motor Thermal LED Name Enabled Energized Overload Overcurrent Unbalance Loal Loss Voltage Frequency When LED is ENABLE MOTRUN THERM_OL OVERCURR UNBAL LOADLOSS VOLTAGE FREQ Dark, TAR 0 Displays When LED is —...
Page 172: Table 5.19 Sel-701-1 Monitor Word And Corresponding Tar Command
ASCII Serial Port Operation 5.30 Command Explanations Table 5.19 SEL-701-1 Monitor Word and Corresponding TAR Command Relay Word Bits STARTING RUNNING STOPPED JAMTRIP LOSSALRM LOSSTRIP 46UBA 46UBT THERMLO NOSLO TBSLO ABSLO 50P1T 50P2T 50N1T 50N2T 50QT 50G1T 50G2T TRGTR START...
Page 173: Figure 5.18 Time Command Example
Figure 5.18 TIME Command Example. TRIGGER (Level 1 or 2) Use the TRIGGER command to generate an event report. See Section 8: Event Analysis for more information on event reports. =>TRIGGER Triggered => Figure 5.19 TRIGGER Command Example. SEL-701-1 Monitor Date Code 20011009...
Page 174: Serial Port Automatic Messages
Section 8: Event Analysis. Self-Test Warning or Failure The monitor sends a status report each time a self- test warning or failure condition is detected. See STATUS Command Row & Column Definitions on page 5.26. SEL-701-1 Monitor Date Code 20011009...
Page 175: Section 6: Commissioning
Section 6 Commissioning Introduction This section provides guidelines for commissioning and testing the SEL-701-1 Monitor. SEL performs a complete functional check and calibration of each monitor before it is shipped. This helps to ensure that you receive a monitor that operates correctly and accurately.
Page 176: Monitor Commissioning Procedure
Monitor Commissioning Procedure Monitor Commissioning Procedure Introduction This procedure is a guideline to help you enter settings into the SEL-701-1 Monitor and verify that it is properly connected. Modify the procedure as necessary to conform with your standard practices. Use the commissioning procedure at initial monitor installation; you should not need to repeat it unless major changes are made to the monitor electrical connections.
Page 177 Step 9. Verify monitor ac connections. Connect the protective monitor ac test signal source to the SEL-701-1 Monitor through the motor control center wiring. (You may connect directly to the monitor; however, this does not verify the accuracy of the wiring in the motor control center.) Apply rated ac current (1 A or 5 A) to the monitor phase...
Page 178: Figure 6.1 Three-Phase Ac Connection Test Signals
When setting PHROT = ACB, set angle Va = angle Ia = 0° set angle Vb = angle Ib = 120° set angle Vc = angle Ic = -120° Figure 6.1 Three-Phase AC Connection Test Signals. SEL-701-1 Monitor Date Code 20011009...
Page 179: Figure 6.2 Open-Delta Ac Potential Connection Test Signals
Step 14. Prepare the monitor for operation by clearing the monitor data buffers, using the monitor commands in Table 6.1. This prevents data generated during installation testing from being confused with operational data collected later. SEL-701-1 Monitor Date Code 20011009...
Page 180: Table 6.1 Serial Port Commands That Clear Monitor Data Buffer
If the monitor reports I1 near zero and I2 nearly equal to IA, IB, and IC, there is a phase rotation problem. Verify the monitor ac current connections and the phase rotation setting, PHROT. A nonzero 3I0 meter value indicates a phase current polarity connection problem. SEL-701-1 Monitor Date Code 20011009...
Page 181 PHROT. A nonzero 3V0 meter value, if shown, typically indicates a single-phase voltage connection problem. Step 18. The SEL-701-1 Monitor is now ready for continuous service. SEL-701-1 Monitor Date Code 20011009...
Page 182: Selected Functional Tests
Figure 6.3 on page 6.9, connect currents connected phase-to-neutral and A-N voltage only. Currents plus three-phase voltages Figure 6.4 on page 6.10 connected phase-to-phase Currents plus three-phase voltages Figure 6.3 on page 6.9 connected phase-to-neutral SEL-701-1 Monitor Date Code 20011009...
Page 183: Figure 6.3 Three Voltage Source And Three Current Source Test Connections
Relay Phase Current (5A) and Voltage Inputs (DELTA_Y = Y) – – – Three Voltage and Three Current Sources Figure 6.3 Three Voltage Source and Three Current Source Test Connections Monitors equipped with ac voltage inputs (Models 0701101X and 0701111X) must be properly grounded for accurate voltage measurement.
Page 184: Figure 6.4 Two Voltage Source And Three Current Source Test Connections
Relay Phase Current (5A) and Voltage Inputs (DELTA_Y = D) – – – Two Voltage and Three Current Sources Figure 6.4 Two Voltage Source and Three Current Source Test Connections Monitors equipped with ac voltage inputs (Models 0701101X and 0701111X) must be properly grounded for accurate voltage measurement.
Page 185: Table 6.3 Phase Current Measuring Accuracy
CTR setting. Table 6.3 Phase Current Measuring Accuracy Expected Reading A-Phase B-Phase C-Phase |I| Applied (A (CTR o |I| A Reading Reading Reading secondary) primary) (A primary) (A primary) (A primary) SEL-701-1 Monitor Date Code 20011009...
Page 186: Table 6.4 Neutral Current Measuring Accuracy
(5 A or 1 A, as indicated by the ITAP setting). Step 2. Using the front-panel Set Monitor\Monitor Elements\General Data and Set Monitor\Monitor Elements\Thermal Model Elements functions or serial port SHOW command, note the CTR, PHROT, and FLA settings. SEL-701-1 Monitor Date Code 20011009...
Page 187: Table 6.5 Current Unbalance Measuring Accuracy
(5 A or 1 A, as indicated by the ITAP setting). Step 2. Using the front-panel Set Monitor\Monitor Elements\Thermal Model Elements function or serial port SHOW command, note the PHROT, FLA, and CURVE settings. Set the Service Factor setting, SF equal to 1.15. SEL-701-1 Monitor Date Code 20011009...
Page 188: Table 6.6 Thermal Element Expected Trip Times
2.0 • FLA CURVE • 23.3 3.0 • FLA CURVE • 10.0 4.0 • FLA CURVE • 5.63 5.0 • FLA CURVE • 3.60 6.0 • FLA CURVE • 2.50 7.0 • FLA CURVE • 1.84 SEL-701-1 Monitor Date Code 20011009...
Page 189: Table 6.7 Analog Output Test
Use the front-panel Meter Values\Thermal & RTD Data function or serial port METER T command to view the present temperature measured by the monitor RTD input. The temperature displayed should be ±2°C or ±4°F from the temperature represented by the variable resistance. SEL-701-1 Monitor Date Code 20011009...
Page 190 Value(ohms) Reading(°C) Reading(°F) 80.31 100.00 119.39 138.50 157.32 175.84 190.45 Table 6.9 100-Ohm Platinum RTD Type (RTDs 7-12) Expected Expected RTD Temperatures Resistance Temperature Temperature Value(ohms) Reading(°C) Reading(°F) 80.31 100.00 119.39 138.50 157.32 175.84 190.45 SEL-701-1 Monitor Date Code 20011009...
Page 191: Table 6.10 120-Ohm Nickel Rtd Type (Rtds 1-6)
Value(ohms) Reading(°C) Reading(°F) 86.17 120.00 157.74 200.64 248.95 303.64 353.14 Table 6.11 120-Ohm Nickel RTD Type (RTDs 7–12) Expected Expected RTD Temperatures Resistance Temperature Temperature Value(ohms) Reading(°C) Reading(°F) 86.17 120.00 157.74 200.64 248.95 303.64 353.14 SEL-701-1 Monitor Date Code 20011009...
Page 192 Value(ohms) Reading(°C) Reading(°F) 71.81 100.00 131.45 167.20 207.45 252.88 294.28 Table 6.13 100-Ohm Nickel RTD Type (RTDs 7–12) Expected Expected RTD Temperatures Resistance Temperature Temperature Value(ohms) Reading(°C) Reading(°F) 71.81 100.00 131.45 167.20 207.45 252.88 294.28 SEL-701-1 Monitor Date Code 20011009...
Page 193: Table 6.14 10-Ohm Copper Rtd Type (Rtds 1-6)
Value(ohms) Reading(°C) Reading(°F) 7.10 9.04 10.97 12.90 14.83 16.78 18.34 Table 6.15 10-Ohm copper RTD Type (RTDs 7–12) Expected Expected RTD Temperatures Resistance Temperature Temperature Value(ohms) Reading(°C) Reading(°F) 7.10 9.04 10.97 12.90 14.83 16.78 18.34 SEL-701-1 Monitor Date Code 20011009...
Page 194 • • 0.4523 0.90 0.2211 ∠ 26 ° 2.5A – • • CTR PTR CTR PTR ∠ 2.5A 94° ∠ 2.5A – 146° Measured: Measured: Measured: ∠ 67V 0° ∠ 67V 120° ∠ – 120° SEL-701-1 Monitor Date Code 20011009...
Page 195: Table 6.17 Power Measuring Accuracy Test Values, Delta Voltages
Expected: • • 0.4677 0.90 0.2286 ∠ 2.5A – 26° • • CTR PTR CTR PTR ∠ 2.5A 94 ∠ 2.5A – 146° Measured: Measured: Measured: ∠ 120V – 30° ∠ 90 ° 120V – SEL-701-1 Monitor Date Code 20011009...
Page 196 This page intentionally left blank...
Page 197: Section 7: Metering & Monitoring
Section 7 Metering & Monitoring Introduction The SEL-701-1 Monitor features metering functions to display the present values of current and (if included) voltage and RTD measurements. The monitor provides several methods to read the present meter values, including: Rotating front-panel display.
Page 198: Table 7.1 Measured Values
Vab or Ia at 0 degrees. RMS quantities do not have a defined phase angle. Reactive and apparent powers (kVAR and kVA) are not defined for RMS measurement. SEL-701-1 Monitor Date Code 20011009...
Page 199: Table 7.2 Demand Meter Values
The monitor records maximum and minimum instantaneous quantities while the following conditions are true: The motor is running. Phase currents are greater than 3% of the Phase CT Secondary Rating, ITAP setting. Phase voltages, if included, are greater than 13 Vac. SEL-701-1 Monitor Date Code 20011009...
Page 200: Table 7.4 Thermal Meter Values
7.5. Table 7.5 RTD Input Status Messages Message Status Open RTD leads open Short RTD leads shorted Comm. Fail Fiber-optic communications to SEL-2600 RTD Module have failed Stat Fail SEL-2600 RTD Module self-test status failure SEL-701-1 Monitor Date Code 20011009...
Page 201: Table 7.6 Energy Meter Values
Models 0701100 and 0701110) With Voltage Inputs (Relay MWhr, MVARhr-in, MVARhr-out, and MVAhr Models 0701101 and 0701111) Magnitudes When voltage inputs are selected and connected, the monitor records the real, reactive, and apparent energy consumed by the motor. SEL-701-1 Monitor Date Code 20011009...
Page 202: Power Measurement Conventions
PF = LAG S3 = VI S4 = VI P– S2 = VI S1 = VI Q– Figure 7.1 Power Measurement Conventions. In the SEL-701-1 Monitor, reported positive real power and energy are always into the motor. SEL-701-1 Monitor Date Code 20011009...
Page 203: Load Profiling
Metering & Monitoring Load Profiling Load Profiling The SEL-701-1 Monitor includes a built-in load profiling function that does not require any configuration. The monitor automatically records selected quantities into nonvolatile memory every 15 minutes, synchronized to the quarter-hour. The monitor...
Page 204: Motor Operating Statistics
Motor Operating Statistics Motor Operating Statistics The SEL-701-1 Monitor retains useful information regarding the protected motor. The serial port MOTOR command and front-panel Motor Statistics commands make the stored data available. The data also appear in the Modbus memory map. Items included in the report are shown below.
Page 205 Motor Operating Statistics Learned Parameters The SEL-701-1 Monitor can learn two protection parameters of the protected motor. When you connect the monitor to monitor at least one motor winding RTD and the ambient temperature, the monitor can learn the cooling time of the protected motor when it is stopped.
Page 206: Figure 7.3 Motor Command Example
Trips Thermal: Locked rotor: Load loss: Load jam: Unbalance current: Phase fault: Ground fault: Speed switch: Undervoltage: Overvoltage: Underpower: Power factor: Reactive power: Phase reversal: Underfrequency: Overfrequency: RTD: Total: => Figure 7.3 MOTOR Command Example. SEL-701-1 Monitor Date Code 20011009...
Page 207: Motor Start Report
Report Format The motor start report comma delimited format makes the data easy to use with spreadsheets or other visualization software. Use the MSR F serial port command to SEL-701-1 Monitor Date Code 20011009...
Page 208: Figure 7.4 Motor Start Report Example
4702 Cycle,Ia (A pri),Ib (A pri),Ic (A pri),In (A pri),Vab (V pri),Vbc (V pri),Vca (V pri),% Thermal Capacity 5,2999,2994,2990,0,4705,4706,4705,17 10,2999,2993,2990,0,4708,4710,4707,18 15,2999,2993,2989,0,4702,4706,4704,18 20,3000,2993,2989,0,4708,4710,4707,19 470,2884,2882,2880,0,4720,4718,4716,71 475,2878,2880,2878,0,4719,4716,4718,71 480,1017,1008,988,0,4750,4752,4754,72 485,348,350,347,0,4780,4782,4784,72 490,348,349,347,0,4782,4782,4784,72 3595,347,348,347,0,4782,4784,4782,70 3600,348,348,348,0,4780,4782,4784,70 Figure 7.4 Motor Start Report Example. SEL-701-1 Monitor Date Code 20011009...
Page 209: Motor Start Trending
Date: 08/15/2001 Time: 10:35:49.755 MONITOR Began Number Accel Starting Maximum Minimum Record Time % Thermal Current Voltage Number Date Starts Capacity (A pri) (VL-L pri) 08/15/2001 3002 4706 => Figure 7.5 Motor Start Trending Report Example. SEL-701-1 Monitor Date Code 20011009...
Page 210 This page intentionally left blank...
Page 211: Section 8: Event Analysis
Event Analysis Introduction The SEL-701-1 Monitor provides several facilities to analyze the cause of monitor operations. Use these tools to help diagnose the cause of the monitor operation and more quickly restore the protected motor to service. Each tool, listed below, provides increasing detail regarding the causes of a monitor operation.
Page 212: Front-Panel Target Leds
(Motor Energized) the motor is starting, and remains on while the motor is running. The LEDs are programmable on the SEL-701-1 Monitor. By setting FACTLOG and FACTLED to N, a SEL control equation can be entered for each LED through OGIC settings LED1 through LED7.
Page 213 The Motor Energized LED flashes. RUNNING. If the positive-sequence current is between 10% and 250% of the Full Load Amps setting, the monitor declares the motor running. The Motor Energized LED remains on. SEL-701-1 Monitor Date Code 20011009...
Page 214: Front-Panel Messages
Speed Switch Trip. Undervoltage Trip. Overvoltage Trip. Underpower Trip. Power Factor Trip. Reactive Power Trip. Phase Reversal Trip. Underfrequency Trip. Overfrequency Trip. RTD Trip. The monitor clears the trip-type message when you reset the tripping target LEDs. SEL-701-1 Monitor Date Code 20011009...
Page 215: History Data & Event Summaries
History Data & Event Summaries History Data & Event Summaries Each time the SEL-701-1 Monitor trips, and in response to other selected conditions, the monitor captures motor current, voltage (if included), RTD (if included), protection element, contact input, and contact output information. This...
Page 216 If the event was stored in response to a rising edge of the TRIP SEL control OGIC equation, but the trip type doesn’t correspond to any of the trip messages in Front- Panel Messages on page 8.4, TRIP will be the listed trip type. SEL-701-1 Monitor Date Code 20011009...
Page 217: Event Reports
Event Analysis Event Reports Event Reports The SEL-701-1 Monitor captures and stores detailed information concerning the monitor measurements, protection element status, and contact input/output status. The monitor stores the 14 most recent event reports in nonvolatile memory. Each report is numbered;...
Page 218: Table 8.2 Event Commands
EVE R Display most recent report at 1/16-cycle resolution; analog data are not digitally filtered (raw). The SEL-701-1 Monitor also provides a facility to allow you to download event â report data using Modbus protocol and the rear-panel serial port. For more information, see Appendix C: Modbus®...
Page 219: Table 8.4 Event Report Current And Voltage Columns
Load Jam Trip picked up. Load Loss Alarm picked up. Load Loss Trip picked up. Current Unbalance Alarm picked up. Current Unbalance Trip picked up. Phase Reversal Trip. Thermal Element Alarm picked up. Thermal Element Trip picked up. SEL-701-1 Monitor Date Code 20011009...
Page 220 Out T1 TRIP contact output asserted. Contact output OUT1 asserted. Both TRIP and OUT1 asserted. Out 23 Contact output OUT2 asserted. Contact output OUT3 asserted. Both OUT2 and OUT3 asserted. Out A Contact output ALARM asserted. SEL-701-1 Monitor Date Code 20011009...
Page 221 Contact input IN7 (from SEL-2600) asserted. Filtered & Unfiltered Event Reports The SEL-701-1 Monitor samples the basic power system measurands (ac current and ac voltage) 16 times per power system cycle. The monitor filters the measurands to remove transient signals. Four times per cycle the monitor operates on the filtered values and reports them in the event report.
Page 222: Sequential Events Recorder (Ser) Report
SER Trigger Condition Aliases You may rename any of the SER trigger conditions using the SEL-701-1 Monitor ALIAS settings. The monitor permits up to 20 aliases to be assigned to conditions that trigger SER row entries. For instance, the factory default logic settings define contact input IN5 for operation as an Emergency Restart input.
Page 223 (date 3/16/97) at the beginning (top) of the report and the oldest row (date 1/5/97) at the end (bottom) of the report. Reverse chronological progression through the report is down the page and in ascending row number. SEL-701-1 Monitor Date Code 20011009...
Page 224 Year/Month/Day. If the requested SER event report rows do not exist, the monitor responds “No SER Data.” Resetting the SER Report Buffer Reset the SER data with the serial port SER R command. SEL-701-1 Monitor Date Code 20011009...
Page 225: Example Event Report
220 R ... T..[12] -0.0 -265 148 .... T..-0.2 -0.2 -220 .... T..[3.5 cycles of event data removed] Continued on next page SEL-701-1 Monitor Date Code 20011009...
Page 226: Figure 8.1 Example Event Report
FPBRITE = 50 FP_KW FP_RTD DM1_1 =SEL-701-1 DM1_0 DM2_1 =MONITOR DM2_0 DM3_1 =RTD FAILURE DM3_0 DM4_1 DM4_0 DM5_1 DM5_0 DM6_1 DM6_0 TRFS OUT1FS OUT2FS OUT3FS TDURD = 0.50 ABSDLY FACTLOG = Y Figure 8.1 Example Event Report. SEL-701-1 Monitor Date Code 20011009...
Page 227: Example Sequential Events Recorder (Ser) Report
Example Sequential Events Recorder (SER) Report Example Sequential Events Recorder (SER) Report This example SER report (Figure 8.2) corresponds to the event report in Figure 8.1. SEL-701-1 Date: 08/15/2001 Time: 19:50:04.744 MONITOR FID=SEL-701-1-R300-V11xxx-Z100100-D20010815 CID=4A50 DATE TIME ELEMENT STATE 06/07/2001 14:34:32.786 MOTOR_STOPPED ENDS 06/07/2001 14:34:32.786...
Page 228: Table 8.7 Example Sequential Events Recorder (Ser) Event Report Explanations
Declining current due to the opening contactor allows the unbalance detecting overcurrent elements to drop out and the relay deasserts output contact OUT1. 2, 1 As the current continues to drop, the relay declares the motor stopped. SEL-701-1 Monitor Date Code 20011009...
Page 229: Section 9: Maintenance & Troubleshooting
Maintenance & Troubleshooting Routine Maintenance Checks Because the SEL-701-1 Monitor is equipped with extensive self-tests, the most effective maintenance task is to monitor the monitor ALARM contact. The ALARM output contact closes when the monitor is deenergized or when monitor self-tests fail.
Page 230: Table 9.1 Data Capture
Motor Start Trending (MST) Every 3-6 months or when you perform motor maintenance. Max/Min Meter (MET M) Every 3-6 months or when you perform motor maintenance. Monitor Status (STA) When you perform motor maintenance. SEL-701-1 Monitor Date Code 20011009...
Page 231: Self-Testing
+5V FAILURE V power supply. -5 V PS Measures the -5 -4.65 V-5.40 V Yes Latched -5V FAILURE V power supply. +15 V PS Measures the +14.00 Latched +15V FAILURE +15 V power V+16.00 V supply. SEL-701-1 Monitor Date Code 20011009...
Page 232 Learned Verifies the Unable to Pulsed Thermal monitor's ability write data to Capacity to to learn the target address Start motor thermal capacity to start. SEL-701-1 Monitor Date Code 20011009...
Page 233: Troubleshooting Procedure
Possible Cause Solution Wiring error. Verify input wiring. Incorrect CTR, ITAP, CTRN, INTAP, or Verify signal source ratios, connections, PTR setting. and associated settings. Voltage neutral terminal (D09) not Verify wiring and connections. properly grounded. SEL-701-1 Monitor Date Code 20011009...
Page 234: Table 9.6 Monitor Does Not Respond To Commands From Device Connected To Serial Port
Monitor improperly set. Verify monitor settings. Improper test source settings. Verify test source settings. CT or PT input wiring error. Verify input wiring. Failed monitor self-test. Use the front-panel Status of Monitor function to view self-test results. SEL-701-1 Monitor Date Code 20011009...
Page 235: Power Supply Fuse Replacement
Schurter, Inc. 0001.2507 Original Equipment Wickman USA, Inc. 181.1200.0.02 Bussman 5505 2A Littelfuse 215 002 Contact SEL for replacement fuses if you have difficulty obtaining an equivalent replacement locally. Use only high breaking capacity replacement fuses. SEL-701-1 Monitor Date Code 20011009...
Page 236: Real-Time Clock Battery Replacement
Step 6. Reenergize the monitor. Set the monitor date and time using the front- panel Set Monitor\Date and Set Monitor\Time functions. SEL-701-1 Monitor Date Code 20011009...
Page 237: Firmware Upgrade Installation
Firmware Upgrade Installation SEL occasionally offers firmware upgrades to improve the performance of the monitor. Since the SEL-701-1 Monitor stores firmware in flash memory, changing physical components is not necessary. Upgrade the monitor firmware by downloading a file from a personal computer to the monitor via the front-panel serial port as outlined in the following sections.
Page 238 “STATUS FAIL EEPROM FAILURE,” reload the monitor settings using the procedure below. Set your communications software settings to 2400 baud, 8 data bits, 1 stop bit. Enter Access Level 2 by issuing the 2AC command. SEL-701-1 Monitor Date Code 20011009...
Page 239 SEL-701-1 Monitor, re-auto-configure the SEL-20x0 port. This step will prevent a future auto-configuration failure of the SEL-20x0 when its power is cycled and the new SEL-701-1 Monitor firmware does not match the original configuration. The monitor is now ready for your commissioning procedure.
Page 240: Factory Assistance
9.12 Factory Assistance Factory Assistance The employee-owners of Schweitzer Engineering Laboratories, Inc. are dedicated to making electric power safer, more reliable, and more economical. We appreciate your interest in SEL products, and we are committed to making sure you are satisfied. If you have any questions, please contact us at: Schweitzer Engineering Laboratories, Inc.
Page 241: Appendix A: Firmware Versions
Appendix A Firmware Versions This manual covers SEL-701-1 Monitors that contain firmware bearing the most recent part numbers and revision numbers listed at the top of the following table (most recent firmware listed at top). Firmware Part/Revision No. Description of Firmware...
Page 242 This page intentionally left blank...
Page 243: Ogic
Control Equations and Monitor Logic Introduction The SEL-701-1 Monitor is equipped with programmable logic so you can customize various monitor functions. Use the programmable logic components described in this appendix to modify the factory default logic settings discussed in OGIC ®...
Page 244: Monitor Functional Overview
Data Acquisition & Filtering The SEL-701-1 Monitor passes ac current and (if included) voltage signals through low-pass filters to remove signals above the eighth harmonic. Then the monitor digitally samples the signals 16 times per power system cycle. The monitor automatically tracks system frequency over the range of 20 to 70 Hz to ensure that exactly 16 samples are taken every cycle.
Page 245: Figure B.1 Monitor Processing Order
Acquire & Filter Data Process Relay Elements Process Logic Perform Background Tasks ➢ Sample Low-Pass ➢ Perform Relay Self-Tests ➢ Process Enabled ➢ Evaluate Fixed Relay ➢ Monitor RTD Filtered AC Signals Logic Element Algorithms ➢ Digitally Filter ➢ Advance Timers ➢...
Page 246: Relay Word Bits
TAR command (see TARGET (Level 1 or 2) on page 5.27 in Section 5: ASCII Serial Port Operation). Table B.1 SEL-701-1 Relay Word Bits Relay Word Bits STARTING RUNNING STOPPED JAMTRIP LOSSALRM LOSSTRIP 46UBA...
Page 247: Table B.2 Relay Word Bit Definitions For Sel-701-1
OGIC ® Control Equations and Monitor Logic Relay Word Bits Table B.2 Relay Word Bit Definitions for SEL-701-1 (Sheet 1 of 7) Row Bit Definition STARTING Asserts when protected motor is starting (current is greater than 2.5 times motor rated full load current).
Page 248 OGIC ® Control Equations and Monitor Logic Relay Word Bits Table B.2 Relay Word Bit Definitions for SEL-701-1 (Sheet 2 of 7) Row Bit Definition Phase Reversal Trip. Asserts when the monitor detects a phase reversal condition, if phase reversal tripping is enabled by the monitor settings.
Page 249 OGIC ® Control Equations and Monitor Logic Relay Word Bits Table B.2 Relay Word Bit Definitions for SEL-701-1 (Sheet 3 of 7) Row Bit Definition AMBALRM Ambient Temperature Alarm and Trip. AMBALRM asserts if the healthy ambient RTD temperature exceeds its alarm AMBTRIP setpoint.
Page 250 OGIC ® Control Equations and Monitor Logic Relay Word Bits Table B.2 Relay Word Bit Definitions for SEL-701-1 (Sheet 4 of 7) Row Bit Definition control equation variables 1 through 4. OGIC SV1T control equation variable 1 through 4 with settable OGIC pickup and dropout time delay.
Page 251 OGIC ® Control Equations and Monitor Logic Relay Word Bits Table B.2 Relay Word Bit Definitions for SEL-701-1 (Sheet 5 of 7) Row Bit Definition Reserved for future use LED1 LED state when FACTLED is set to N LED2 LED3...
Page 252 OGIC ® Control Equations and Monitor Logic B.10 Relay Word Bits Table B.2 Relay Word Bit Definitions for SEL-701-1 (Sheet 6 of 7) Row Bit Definition RTD1A2 RTDx Alarm # 2 (x = 1 to 12). Assert when the RTD temperature exceeds RTDx Alarm #2 setpoint.
Page 253 OGIC ® Control Equations and Monitor Logic B.11 Relay Word Bits Table B.2 Relay Word Bit Definitions for SEL-701-1 (Sheet 7 of 7) Row Bit Definition RTD9A3 RTDx Alarm # 3 (x = 1 to 12). Assert when the RTD temperature exceeds RTDx Alarm #3 setpoint.
Page 254: Sel Ogic Control Equations
B.3. These operators are processed in a control equation in the order shown in Table B.3. OGIC Table B.3 SELOGIC Control Equation Operators (listed in processing order) Operator Logic Function Rising edge detect Falling edge detect parentheses SEL-701-1 Monitor Date Code 20011009...
Page 255: Equation B.1
This allows a recovery from an underfrequency condition to be observed. Figure B.2 demonstrates the action of the falling-edge operator [\] on the underfrequency element in setting ER. SEL-701-1 Monitor Date Code 20011009...
Page 256: Equation B.4
1 (logical 1) or 0 (logical 0) If you set a SEL control equation setting directly to 1, it is always OGIC asserted/on/enabled. If you set a SEL control equation setting equal to 0, it is OGIC always deasserted/off/disabled. SEL-701-1 Monitor Date Code 20011009...
Page 257 SHOW command. The LEUSE value provides a measure of the monitor SEL control equation capability. The remainder OGIC (100% – LEUSE) is available for future expansion. SEL-701-1 Monitor Date Code 20011009...
Page 258: Factory Default Logic Settings
SV4 Dropout Time (0.00 – 3000.00 s) SV4DO=0.00 SET/RESET LATCH VARIABLES Latch Variable 1 SET1 RST1 Latch Variable 2 SET2 RST2 Latch Variable 3 SET3 RST3 Latch Variable 4 SET4 RST4 Continued on next page SEL-701-1 Monitor Date Code 20011009...
Page 259 =/LOSSALRM + /46UBA + /49A + \81D1T + \81D2T + \81D3T + /37PA + /55A + /VARA OUT1 =LOSSALRM + 46UBA + 49A + 37PA + 55A + VARA OUT2 =RTDBIAS + WDGALRM + BRGALRM + AMBALRM + OTHALRM + RTDFLT OUT3 =START SEL-701-1 Monitor Date Code 20011009...
Page 260: Factory Default Led Settings
LEDs shown in Table B.4, and reverts back to the definitions of the LEDs given in Table B.4. Table B.4 SEL-701-1 Monitor Programmable Front-Panel LEDs LED Label Definition Setting Thermal Overload This LED flashes when the thermal element LED1 reaches the alarm level, if any monitored, healthy RTD exceeds its alarm temperature.
Page 261 : Setting FACTLOG to Y will result in the monitor clearing your changes and using the factory definitions in Table B.4 on page B.18. Monitor Settings: LED Logic LED1 =0 LED2 =0 LED3 =0 LED4 =0 LED5 =0 LED6 =0 LED7 =0 SEL-701-1 Monitor Date Code 20011009...
Page 262: Front-Panel Display Message Configuration
Control Equations and Monitor Logic B.20 Factory Default LED Settings Front-Panel Display Message Configuration There are four text display messages available in the SEL-701-1 Monitor. Each text display has two complementary screens. control equation display message setting DMn (n = 1–6) controls the OGIC display of corresponding, complementary text settings.
Page 263: Nondedicated Sel Ogic
Nondedicated SEL Control Equation Variable Settings OGIC Nondedicated SEL OGIC Control Equation Variable Settings The SEL-701-1 Monitor is equipped with four nondedicated SEL control OGIC equation variables. Each variable has a defining SEL control equation, a OGIC time-delay pickup timer, and a time-delay dropout timer.
Page 264: Latch Control Switch Settings
Traditional Latching Relay (–) Figure B.4 Traditional Latching Relay. Four latch control switches in the SEL-701-1 Monitor provide latching relay type functions. The output of the latch control switch in Figure B.5 is a Relay Word bit LTn (n = 1–4), called a latch bit. The latch control switch logic in Figure B.5...
Page 265 Figure B.5 on page B.22) must be set with care. Settings SETn and RSTn must not result in continuous cyclical operation of latch bit LTn. Use timers to qualify conditions set in settings SETn and RSTn. SEL-701-1 Monitor Date Code 20011009...
Page 266: Stop/Trip Logic
Stop/Trip Logic Stop/Trip Logic The SEL-701-1 Monitor tripping logic is designed to trip or stop motors energized through circuit breakers or contactors. The monitor logic lets you define the conditions that cause a trip, the conditions that unlatch the trip, and the performance of the monitor output contact motor contactor or breaker.
Page 267: Figure B.6 Stop/Trip Logic
TRFS = Y Close TRIP A Contact Open TRIP B Contact Initiate Targets and Front-Panel Messages TRIP STOP Command TDURD TRFS = Enable TRIP Contact Fail-Safe Setting Trigger TRIP/TARGET RC = TRIP/TARGET Reset Command Events STOP Command = Serial Port STOP Command STOPPED Modbus RC = Modbus Reset Command...
Page 268 52A contact to the input, set 52A = IN1. The equation result is the 52A Relay Word bit. You can use the result to create custom control functions such as breaker failure logic, if necessary, for your application. SEL-701-1 Monitor Date Code 20011009...
Page 269: Start And Emergency Restart Logic
Relay Word bit asserts, as shown in Program an Output Contact for Motor Starting on page B.28. When you push the button, IN6 is asserted, asserting the START bit, closing the output contact, and initiating the start. SEL-701-1 Monitor Date Code 20011009...
Page 270: Equation B.5
Program an Output Contact for Motor Starting In the factory settings, the result of the start logic in Figure B.7 is routed to output contact OUT3 with the following SEL control equation: OGIC OUT3 START Equation B.5 SEL-701-1 Monitor Date Code 20011009...
Page 271: Access2 Sel Ogic Control Equation Setting
Access Level 2 serial port and front-panel command execution when input IN4 is asserted. You may want to connect a keyswitch contact to the input so monitor settings can be modified by persons having the correct key. SEL-701-1 Monitor Date Code 20011009...
Page 272: Tarr Sel Ogic Control Equation Setting
Control Equation Setting OGIC The TARR SEL control equation setting defines conditions for the reset of OGIC front-panel targets. The factory default setting is disabled. You should assign a contact input to allow remote target reset. SEL-701-1 Monitor Date Code 20011009...
Page 273: Speed Switch Sel Ogic Control Equation Setting
IN3 at the monitor or input IN7 at the SEL-2600 RTD Module, if installed. The Speed Switch Trip logic, described in Section 3: Settings Calculation, uses the result of the SPEEDSW SEL control OGIC equation. SEL-701-1 Monitor Date Code 20011009...
Page 274: Event Triggering Sel Ogic Control Equation
This is used to trigger an event report at alarm inception. Falling-edge operators are used to generate an event report at frequency element dropout, when the system frequency has stabilized at or near the nominal frequency. SEL-701-1 Monitor Date Code 20011009...
Page 275: Contact Output Control
OGIC settings let you program individual contact outputs using single Relay Word bits for element testing purposes or to create more complex functions by combining Relay Word bits and SEL control equation operators. OGIC SEL-701-1 Monitor Date Code 20011009...
Page 276: Remote Control Switches
Any given remote control switch can be put in one of three positions shown in Table B.5. Table B.5 Remote Control Switch Control Switch Position Description logical 1 logical 0 MOMENTARY logical 1 for one processing interval SEL-701-1 Monitor Date Code 20011009...
Page 277 The remote control switches always come back in the OFF position (corresponding remote bit is deasserted to logical 0) when power is restored to the monitor. SEL-701-1 Monitor Date Code 20011009...
Page 278: Selected Monitor Logic Diagrams
27P1P 27P2 27P2P Figure B.9 Undervoltage Element Logic. Relay Word 37DLY Switches close when 37DLY expires RUNNING Relay Word Measured Bits 37PAD Real Power 37PA Settings 37PAP 37PTD 37PT 37PTP Figure B.10 Underpower Element Logic. SEL-701-1 Monitor Date Code 20011009...
Page 279: Figure B.11 Current Unbalance Element Logic
Inputs |IA| IA = Phase Current |IB| Avg. %UB = (|Iav-lm|/FLA) • 100% IB = Phase Current IC = Phase Current |IC| FLA = Full Load Amps Setting 46UBA = Phase Current Unbalance Alarm Setting Enable 46UBT = Phase Current Unbalance Trip Setting Avg.
Page 280: Figure B.12 Phase Reversal Element Logic
Voltage Option = Y DELTA _Y = Y |VA| |VB| |VC| |VAB| |VBC| Relay Word 0.5 • |V2| |V1| |IA| |IB| |IC| 0.03 • ITAP 0.5 • |I2| |I1| Figure B.12 Phase Reversal Element Logic. SEL-701-1 Monitor Date Code 20011009...
Page 281: Figure B.13 Overcurrent Element Logic
Negative- Sequence Current Settings Calculation PHROT Relay Word |IP| Bits 50P1D 50P1P 50P1T 50P2D 50P2P 50P2T |IN| 50N1D 50N1P 50N1T 50N2D 50N2P 50N2T |IG| 50G1D 50G1P 50G1T 50G2D 50G2P 50G2T Figure B.13 Overcurrent Element Logic. SEL-701-1 Monitor Date Code 20011009...
Page 282: Figure B.14 Power Factor Elements Logic
Control Equations and Monitor Logic B.40 Selected Monitor Logic Diagrams Relay Word 55DLY RUNNING Measured Power Factor PF Leading Settings Relay 55LDAP Word Bits 55AD 55LGAP 55LDTP 55TD 55LGTP Figure B.14 Power Factor Elements Logic. SEL-701-1 Monitor Date Code 20011009...
Page 283: Figure B.15 Overvoltage Element Logic
*When DELTA_Y = D, VG is not calculated and phase-to-phase measurements are used. |VP| Relay Word Settings Bits 59P1P 59P1 59P2P 59P2 When DELTA_Y = Y, SINGLEV=N: |VG| 59GP When DELTA_Y = D: |VPP| 59P1 59P1P 59P2 59P2P Figure B.15 Overvoltage Element Logic. SEL-701-1 Monitor Date Code 20011009...
Page 284 OGIC ® Control Equations and Monitor Logic B.42 Selected Monitor Logic Diagrams SEL-701-1 Monitor Date Code 20011009...
Page 285: Figure B.16 Over-/Underfrequency Element Logic
Frequency Elements 1-3 SINGLEV=Y freq = Measured Frequency 81DnP = Frequency Pickup Setting DELTA_Y=D FNOM = Nominal Frequency Setting |Vab| SINGLEV = Single PT Enabled DELTA_Y = Delta PT Enabled Va = Measured Phase Voltage Vb = Measured Phase Voltage Measured Phase Voltage Vb = Vab =...
Page 286: Figure B.17 Load-Jam Elements Logic
Load Loss Trip LLTDLY = Load Loss Trip Delay Setting LOSSALRM = Load Loss Alarm LLSDLY = Load Loss Start Delay Setting LLADLY = Load Loss Alarm Delay Setting Figure B.18 Load-Loss Logic; No Voltage Option. SEL-701-1 Monitor Date Code 20011009...
Page 287: Figure B.19 Load-Loss Logic; Voltage Option Included
LLADLY = Load Loss Alarm Delay Setting LOSSALRM = Load Loss Alarm LLTPU = Load LossTrip Pickup Setting P3 = Three-Phase Power LLAPU = Load Loss Alarm Pickup Setting Figure B.19 Load-Loss Logic; Voltage Option Included. SEL-701-1 Monitor Date Code 20011009...
Page 288: Figure B.20 Reactive Power Elements Logic
Relay Word Word Bits Bits SPDSDLY STARTING SPDSTR SPEEDSW STARTING = Motor is Starting SPDSDLY = Speed Switch Delay SPEEDSW = Speed Switch Input SPDSTR = Speed Switch Trip Figure B.21 Speed Switch Tripping Logic. SEL-701-1 Monitor Date Code 20011009...
Page 289: Introduction
This appendix describes Modbus RTU communications features supported by the SEL-701-1 Monitor at the rear-panel EIA-485 port. Complete specifications for the Modbus protocol are available from Modicon on their web site: www.modicon.com. The SEL-701-1 Monitor supports Modbus RTU protocol when you enable Modbus protocol using the rear-panel serial port settings.
Page 290: Modbus Rtu Communications Protocol
Cyclical Redundancy Check 2 bytes The SEL-701-1 Monitor SLAVEID setting defines the device address when the monitor rear-panel port is set for Modbus communication. Set this value to a unique number for each device on the Modbus network. For Modbus communication to operate properly, no two slave devices may have the same address.
Page 291: Table C.2 Sel-701-1Monitor Modbus Function Codes
Read Exception Status Loopback Diagnostic Command Preset Multiple Registers The SEL-701-1 Monitor supports broadcast operation for these function codes. Broadcast function codes use slave device address 00h. Slave devices do not send a response to broadcast functions. Modbus Exception Responses...
Page 292 CRC value using the same CRC-16 algorithm. If the calculated CRC value matches the CRC value sent by the SEL-701-1 Monitor, the master device uses the data received. If there is not a match, the check fails and the message is ignored.
Page 293: 01H Read Coil Status Command
2 bytes Address of the first bit 2 bytes Number bits to read 2 bytes CRC-16 for message A Successful SEL-701-1 Monitor Response Will Have the Following Format 1 byte Slave address 1 byte Function code (01h) 1 byte Byte count...
Page 294: 02H Read Input Status Command
2 bytes Address of the first bit 2 bytes Number bits to read 2 bytes CRC-16 for message A Successful SEL-701-1 Monitor Response Will Have the Following Format 1 byte Slave address 1 byte Function code (02h) 1 byte Byte count...
Page 295: 03H Read Holding Registers Command
2 bytes Starting register address 2 bytes Number of registers to read 2 bytes CRC-16 for message A Successful SEL-701-1 Monitor Response Will Have the Following Format 1 byte Slave address 1 byte Function code (03h) 1 byte Byte count (should be twice number of registers read)
Page 296: 04H Read Input Registers Command
2 bytes Starting register address 2 bytes Number of registers to read 2 bytes CRC-16 for message A Successful SEL-701-1 Monitor Response Will Have the Following Format 1 byte Slave address 1 byte Function code (04h) 1 byte Byte count (should be twice number of registers read)
Page 297: 05H Force Single Coil Command
05h Force Single Coil Command 05h Force Single Coil Command The SEL-701-1 Monitor uses this function code for a variety of data control purposes. Specifically, you can use it to clear archive records, operate output contacts, and operate breaker and remote bit elements.
Page 298: 06H Preset Single Register Command
06h Preset Single Register Command 06h Preset Single Register Command The SEL-701-1 Monitor uses this function to allow a Modbus master to write directly to a database register. If you are accustomed to 4X references with this function code, for 6-digit addressing, add 400001 to the standard database addresses.
Page 299: 07H Read Exception Status Command
C.11 07h Read Exception Status Command 07h Read Exception Status Command The SEL-701-1 Monitor uses this function to allow a Modbus master to read the present status of the monitor and protected motor. Table C.11 07h Read Exception Status Command...
Page 300: 08H Loopback Diagnostic Command
08h Loopback Diagnostic Command 08h Loopback Diagnostic Command The SEL-701-1 Monitor uses this function to allow a Modbus master to perform a diagnostic test on the Modbus communications channel and monitor. When the subfunction field is 0000h, the monitor returns a replica of the received message.
Page 301: 10H Preset Multiple Registers Command
Byte count (should be twice number of registers) n bytes Byte count bytes of data 2 bytes CRC-16 for message A Successful SEL-701-1 Monitor Response Will Have the Following Format 1 byte Slave address 1 byte Function code (10h) 2 bytes...
Page 302: Controlling Output Contacts
Appendix B: SELogic® Control Equations and Monitor Logic). Use Modbus function codes 06h or 10h to write the appropriate command codes and parameters into the registers shown in Table C.14. Table C.14 SEL-701-1 Monitor Modbus Command Region Address Field 0030h Command Code 0031h...
Page 303 Function Code 05 is allowed for compatibility, but has no effect as the monitor immediately acts on and clears set coils. Parameter 1 of Command Code 7 is bit-masked to allow you to manipulate several Data Regions simultaneously. SEL-701-1 Monitor Date Code 20011009...
Page 304: Reading The Monitor Status Using Modbus
Reading the Monitor Status Using Modbus Reading the Monitor Status Using Modbus The SEL-701-1 Monitor Modbus Register Map provides fields that allow you to read the present monitor self-test results. Read the two registers starting with Modbus Map address 160h.
Page 305: Reading Event Data Using Modbus
Reading Event Data Using Modbus The Modbus Register Map provides a feature that allows you to download complete event data via Modbus. The SEL-701-1 Monitor stores the latest 13 full- length event reports in nonvolatile memory. Section 8: Event Analysis contains a complete description of the event data.
Page 306: Modbus Register Map
FID string 0001 0002 0003 0004 0005 0006 0007 0008 0009 000A 000B 000C 000D 000E 000F 0010 0011 0012 0013 0014 0015 Reserved 0016 Reserved 0017 Revision R100 0018 0019 Reserved 001A Relay ID SEL-701-1 SEL-701-1 Monitor Date Code 20011009...
Page 307 0020 0021 0022 0023 0024 Reserved 0025 Terminal ID Monitor 0026 0027 0028 0029 002A 002B 002C 002D 002E 002F Reserved COMMANDS 0030 Command Function Code 0031 Parameter 1 0032 Parameter 2 0033- Reserved 0048 SEL-701-1 Monitor Date Code 20011009...
Page 308 USER MAP ADDRESSES 00D0 User Map Address # 1 00D1 User Map Address # 2 00D2 User Map Address # 3 • • • 014A User Map Address # 123 014B User Map Address # 124 SEL-701-1 Monitor Date Code 20011009...
Page 309 Rows 18, 19 015A Row 20 015B– Reserved 015F MONITOR STATUS 0160 Status Register 2047 0161 Status Register 0162- Reserved 016F INSTANTANEOUS METERING 0170 Ia Current 65535 0171 Ib Current 65535 0172 Ic Current 65535 SEL-701-1 Monitor Date Code 20011009...
Page 310 0 if no voltage -32768 32767 option 0183 kW3P Avg 0 if no voltage -32768 32767 Power or single volt 0184 0 if no voltage -32768 32767 option 0185 kVAR3P 0 if no voltage -32768 32767 Power option SEL-701-1 Monitor Date Code 20011009...
Page 311 See Note Note Note 0195 RTD #1 See Note Temperature Note Note 0196 RTD #2 See Note Temperature Note Note 0197 RTD #3 See Note Temperature Note Note 0198 RTD #4 See Note Temperature Note Note SEL-701-1 Monitor Date Code 20011009...
Page 312 65535 Thermal available Capacity 01A4 Time to Trip 9999 1, 1 01A5 Minutes Since 65535 Last Start 01A6 Starts This Hour 01A7 Reserved 01A8 Reserved 01A9 Reserved 01AA Reserved 01AB Reserved 01AC Reserved 01AD Reserved SEL-701-1 Monitor Date Code 20011009...
Page 313 Reserved 01BC Reserved 01BD Reserved 01BE Reserved 01BF Reserved DEMAND METERING 01C0 Ia Demand 65535 01C1 Ib Demand 65535 01C2 Ic Demand 65535 01C3 In Demand 65535 01C4 Ig Demand 65535 01C5 3I2 Demand 65535 SEL-701-1 Monitor Date Code 20011009...
Page 314 3I2 Peak 65535 Demand 01D6 kW3P Peak 0 if no voltage 65535 Demand option 01D7 kVAR3P Peak 0 if no voltage 65535 Demand In option 01D8 kVAR3P Peak 0 if no voltage 65535 Demand Out option SEL-701-1 Monitor Date Code 20011009...
Page 315 01E9 ssss (FFFFh if 5999 • 0.01 reset) 01EA Ib Max (FFFFh if reset) 0 65535 Current 01EB Ib Max mm, dd (FFFFh 1, 1 12, 31 1, 1 Current Date if reset) SEL-701-1 Monitor Date Code 20011009...
Page 316 65535 reset) 01FC Ic Min hh, mm (FFFFh 0, 0 23, 59 1, 1 Current Time if reset) 01FD ssss (FFFFh if 5999 • 0.01 reset) 01FE In Max (FFFFh if reset) 0 65535 Current SEL-701-1 Monitor Date Code 20011009...
Page 317 1, 1 Current Date if reset) 020F yyyy (FFFFh if 65535 reset) 0210 Ig Min hh, mm (FFFFh 0, 0 23, 59 1, 1 Current Time if reset) 0211 ssss (FFFFh if 5999 • 0.01 reset) SEL-701-1 Monitor Date Code 20011009...
Page 318 (FFFFh 0, 0 23, 59 1, 1 Temperature if reset) Time 0229 ssss (FFFFh if 5999 • 0.01 reset) 022A RTD # 2 Max FFFFh if reset Temperature or no RTD Note Note SEL-701-1 Monitor Date Code 20011009...
Page 319 (FFFFh 0, 0 23, 59 1, 1 Temperature if reset) Time 0238 ssss (FFFFh if 5999 • 0.01 reset) 0239 RTD # 3 Min FFFFh if reset Temperature or no RTD Note Note SEL-701-1 Monitor Date Code 20011009...
Page 320 (FFFFh 0, 0 23, 59 1, 1 Temperature if reset) Time 0247 ssss (FFFFh if 5999 • 0.01 reset) 0248 RTD # 5 Max FFFFh if reset Temperature or no RTD Note Note SEL-701-1 Monitor Date Code 20011009...
Page 321 (FFFFh 0, 0 23, 59 1, 1 Temperature if reset) Time 0256 ssss (FFFFh if 5999 • 0.01 reset) 0257 RTD # 6 Min FFFFh if reset Temperature or no RTD Note Note SEL-701-1 Monitor Date Code 20011009...
Page 322 (FFFFh 0, 0 23, 59 1, 1 Temperature if reset) Time 0265 ssss (FFFFh if 5999 • 0.01 reset) 0266 RTD # 8 Max FFFFh if reset Temperature or no RTD Note Note SEL-701-1 Monitor Date Code 20011009...
Page 323 (FFFFh 0, 0 23, 59 1, 1 Temperature if reset) Time 0274 ssss (FFFFh if 5999 • 0.01 reset) 0275 RTD # 9 Min FFFFh if reset Temperature or no RTD Note Note SEL-701-1 Monitor Date Code 20011009...
Page 324 (FFFFh 0, 0 23, 59 1, 1 Temperature if reset) Time 0283 ssss (FFFFh if 5999 • 0.01 reset) 0284 RTD # 11 Max FFFFh if reset Temperature or no RTD Note Note SEL-701-1 Monitor Date Code 20011009...
Page 325 (FFFFh 0, 0 23, 59 1, 1 Temperature if reset) Time 0292 ssss (FFFFh if 5999 • 0.01 reset) 0293 RTD # 12 Min FFFFh if reset Temperature or no RTD Note Note SEL-701-1 Monitor Date Code 20011009...
Page 326 1, 1 Voltage Date if reset) 02A2 yyyy (FFFFh if 65535 reset) 02A3 Vab Max hh, mm (FFFFh 0, 0 23, 59 1, 1 Voltage Time if reset) 02A4 ssss (FFFFh if 5999 • 0.01 reset) SEL-701-1 Monitor Date Code 20011009...
Page 327 (FFFFh if 5999 • 0.01 reset) 02B4 Vca Max (FFFFh if reset 65535 Voltage or no voltage option) 02B5 Vca Max mm, dd (FFFFh 1, 1 12, 31 1, 1 Voltage Date if reset) SEL-701-1 Monitor Date Code 20011009...
Page 328 (FFFFh 1, 1 12, 31 1, 1 Voltage Date if reset) 02C5 yyyy (FFFFh if 65535 reset) 02C6 Vg Min hh, mm (FFFFh 0, 0 23, 59 1, 1 Voltage Time if reset) SEL-701-1 Monitor Date Code 20011009...
Page 329 Max kVAR3P hh, mm (FFFFh 0, 0 23, 59 1, 1 Power Time if reset) 02D6 ssss (FFFFh if 5999 • 0.01 reset) 02D7 Min kVAR3P (FFFFh if reset -32768 32767 Power or no voltage option) SEL-701-1 Monitor Date Code 20011009...
Page 330 Last Reset mm, dd (FFFFh 1, 1 12, 31 1, 1 Date if reset) 02E7 yyyy (FFFFh if 65535 reset) 02E8 Last Reset hh, mm (FFFFh 0, 0 23, 59 1, 1 Time if reset) SEL-701-1 Monitor Date Code 20011009...
Page 331 0 if no voltage 65535 Starting option Voltage 02FC Avg Starting 65535 • 0.1 % Therm Cap 02FD Avg Running 65535 • 0.1 % Therm Cap 02FE Avg RTD % 65535 Therm Cap 02FF Avg Running 65535 Current SEL-701-1 Monitor Date Code 20011009...
Page 332 • 0.1 % Therm Cap 030C Peak Running 65535 • 0.1 % Therm Cap 030D Peak RTD % 65535 Therm Cap 030E Peak Running 65535 Current 030F Peak Running 0 if no voltage 65535 option SEL-701-1 Monitor Date Code 20011009...
Page 333 Locked Rotor 65535 Alarm Count 031B Load Loss 65535 Alarm Count 031C Unbalance 65535 Current Alarm Count 031D Under Power 65535 Alarm Count 031E Power Factor 65535 Alarm Count 031F Reactive 65535 Power Alarm Count SEL-701-1 Monitor Date Code 20011009...
Page 334 032B Overvoltage 65535 Trip Count 032C Under Power 65535 Trip Count 032D Power Factor 65535 Trip Count 032E Reactive 65535 Power Trip Count 032F Phase 65535 Reversal Trip Count 0330 Under- 65535 frequency Trip Count SEL-701-1 Monitor Date Code 20011009...
Page 335 Start Voltage option 0344 Latest Start mm, dd 1, 1 12, 31 1, 1 Date 0345 yyyy 65535 0346 Latest Start hh, mm 0, 0 23, 59 1, 1 Time 0347 ssss 5999 • 0.01 SEL-701-1 Monitor Date Code 20011009...
Page 336 12, 31 1, 1 Start Date 0355 yyyy 65535 0356 3rd Latest hh, mm 0, 0 23, 59 1, 1 Start Time 0357 ssss 5999 • 0.01 0358 4th Latest seconds 65535 • 0.01 Accel Time SEL-701-1 Monitor Date Code 20011009...
Page 337 23, 59 1, 1 Start Time 0367 ssss 5999 • 0.01 0368- Reserved 036F HISTORY RECORDS 0370 Number of Event Records 0371 Event Selection 0372 Event Date mm, dd 1, 1 12, 31 1, 1 SEL-701-1 Monitor Date Code 20011009...
Page 338 Hottest See Note Bearing RTD Note Note 038A Ambient RTD See Note Note Note 038B Hottest Other See Note Note Note 038C 0 if no voltage 65535 option 038D 0 if no voltage 65535 option SEL-701-1 Monitor Date Code 20011009...
Page 339 03A7 1 1/4 Cycle -32768 32767 03A8 1 2/4 Cycle -32768 32767 03A9 1 3/4 Cycle -32768 32767 03AA 2 Cycle -32768 32767 03AB 2 1/4 Cycle -32768 32767 03AC 2 2/4 Cycle -32768 32767 SEL-701-1 Monitor Date Code 20011009...
Page 340 32767 03C6 9 Cycle -32768 32767 03C7 9 1/4 Cycle -32768 32767 03C8 9 2/4 Cycle -32768 32767 03C9 9 3/4 Cycle -32768 32767 03CA 10 Cycle -32768 32767 03CB 10 1/4 Cycle -32768 32767 SEL-701-1 Monitor Date Code 20011009...
Page 341 8000h = RTD shorted 7fffh = RTD open 7ffdh = RTD reset 7ffch = SEL-2600 RTD Module Communication Failure 7ff8h = SEL-2600 RTD Module Self-Test Status Failure 7ff0h = RTD Not Attached or Not Available SEL-701-1 Monitor Date Code 20011009...
Page 342 The event type is reported as a character string as shown below: EVENT TYPE STRING: THERMAL LOCKED ROTOR LOAD LOSS LOAD JAM UNBALANCED CURRENT PHASE FAULT GROUND FAULT SPEED SWITCH UNDERVOLTAGE OVERVOLTAGE UNDERPOWER POWER FACTOR REACTIVE POWER PHASE REVERSAL UNDERFREQUENCY OVERFREQUENCY STOP COMMAND TRIP PULSE TRIG SEL-701-1 Monitor Date Code 20011009...
Page 343: Appendix D: Sel-2020/Sel-2030 Compatibility Features
SEL-2020/SEL-2030 Compatibility Features Introduction This appendix describes communication features that the SEL-701-1 Monitor serial ports support when they are configured for ASCII communications. These func- â tions are not provided on the monitor EIA-485 port when it is configured for Modbus protocol support.
Page 344: Fast Binary Message Lists
ASCII Configuration Message List Table D.2 ASCII Configuration Message List Request to Monitor Response From Monitor ASCII ASCII Relay Identification and Configuration Strings ASCII Names of Relay Word Bits ASCII Names of Bits in the A5B9 Status Byte SEL-701-1 Monitor Date Code 20011009...
Page 345: Fast Binary Message Definitions
Settings change bit 444E410D0000 DNA Command 0004 Settings change bit 49440D000000 ID Command 0004 Settings change bit 4341530D0000 CAS Command 0100 SEL protocol, Fast Operate 0002 Modbus protocol Reserved checksum 1-byte checksum of preceding bytes SEL-701-1 Monitor Date Code 20011009...
Page 346 SEL-2020/SEL-2030 Compatibility Features Fast Binary Message Definitions A5C1 Fast Meter Configuration Block In response to the A5C1 request, the SEL-701-1 Monitor sends the block shown Table D.4. Table D.4 A5C1 Fast Meter Configuration Block (Sheet 1 of 5) Data Description...
Page 347: Table D.4 A5C1 Fast Meter Configuration Block
Analog channel name (%Unbal) Analog channel type Scale factor type 0000 Scale factor offset in Fast Meter message 465245510000 Analog channel name (Freq) Analog channel type Scale factor type 0000 Scale factor offset in Fast Meter message SEL-701-1 Monitor Date Code 20011009...
Page 348 Analog channel name (VG) Analog channel type Scale factor type 0000 Scale factor offset in Fast Meter message 335632000000 Analog channel name (3V2) Analog channel type Scale factor type 0000 Scale factor offset in Fast Meter message SEL-701-1 Monitor Date Code 20011009...
Page 349 Analog channel type Scale factor type 0000 Scale factor offset in Fast Meter message 425247000000 Analog channel name (BRG) [Hottest Bearing RTD Temp.] Analog channel type Scale factor type 0000 Scale factor offset in Fast Meter message SEL-701-1 Monitor Date Code 20011009...
Page 350 Scale factor offset in Fast Meter message 4F5448000000 Analog channel name (OTH) [Hottest Other RTD Temp.] Analog channel type Scale factor type 0000 Scale factor offset in Fast Meter message All Versions Reserved checksum 1-byte checksum of all preceding bytes SEL-701-1 Monitor Date Code 20011009...
Page 351: Table D.5 A5D1 Fast Meter Data Block
SEL-2020/SEL-2030 Compatibility Features Fast Binary Message Definitions A5D1 Fast Meter Data Block In response to the A5D1 request, the SEL-701-1 Monitor sends the block shown Table D.5. Table D.5 A5D1 Fast Meter Data Block Data Description A5D1 Command Length (specific value of xx based on monitor model,...
Page 352: Table D.6 A5C2/A5C3 Demand/Peak Demand Fast Meter Configuration Messages
SEL-2020/SEL-2030 Compatibility Features D.10 Fast Binary Message Definitions A5C2/A5C3 Demand/Peak Demand Fast Meter Configuration Messages In response to the A5C2 or A5C3 request, the SEL-701-1 Monitor sends the block shown in Table D.6. Table D.6 A5C2/A5C3 Demand/Peak Demand Fast Meter Configuration Messages...
Page 353 0000 Scale factor offset in Fast Meter message 51332B000000 Analog channel name (Q3+) Analog channel type Scale factor type 0000 Scale factor offset in Fast Meter message 533300000000 Analog channel name (S3) Analog channel type SEL-701-1 Monitor Date Code 20011009...
Page 354 All Versions Reserved checksum 1-byte checksum of preceding bytes A5D2/A5D3 Demand/Peak Demand Fast Meter Message In response to the A5D2 or A5D3 request, the SEL-701-1 Monitor sends the block shown in Table D.7. Table D.7 A5D2/A5D3 Demand/Peak Demand Fast Meter Message...
Page 355: Table D.8 A5Ce Fast Operate Configuration Block
Fast Binary Message Definitions A5B9 Fast Meter Status Acknowledge Message In response to the A5B9 request, the SEL-701-1 Monitor clears the Fast Meter (message A5D1) Status Byte. The SEL-701-1 Monitor Status Byte contains one active bit, STSET (bit 4). The bit is set on power up and on settings changes. If the STSET bit is set, the external device should request the A5C1, A5C2, and A5C3 messages.
Page 356 SEL-2020/SEL-2030 Compatibility Features D.14 Fast Binary Message Definitions The SEL-701-1 Monitor performs the specified remote bit operation if the following conditions are true: The Operate code is valid. The Operate validation = 4 • Operate code + 1. The message checksum is valid.
Page 357: Table D.10 A5E3 Command
1-byte 1-byte checksum of all preceding bytes ID Message In response to the ID command, the SEL-701-1 Monitor sends the firmware ID, boot code ID, monitor RID setting, the Modbus device code, part number, and configuration as described below. <STX>"FID STRING ENCLOSED IN QUOTES","yyyy"<CR>...
Page 358 In response to the Access Level 1 DNA command, the monitor sends names of the Relay Word bits transmitted in the A5D1 message. The first name is associated with the MSB and the last name with the LSB. The SEL-701-1 Monitor DNA message is: <STX>...
Page 359 LSB. The BNA message is: <STX>"*","*","*","STSET","*","*","*","*","yyyy" <ETX> where: "yyyy" is the 4-byte ASCII representation of the checksum. "*" indicates an unused bit location. The BNA command is available from Access Level 1 and higher. SEL-701-1 Monitor Date Code 20011009...
Page 360: Compressed Ascii Commands
Compressed ASCII Commands Compressed ASCII Commands The SEL-701-1 Monitor provides compressed ASCII versions of some of the monitor ASCII commands. The compressed ASCII commands allow an external device to obtain data from the monitor in a format that directly imports into spread- sheet or database programs and can be validated with a checksum.
Page 361: Cascii Command
The compressed ASCII configuration message provides data for an external com- puter to extract data from other compressed ASCII commands. To obtain the configu- ration message for the compressed ASCII commands available in an SEL monitor, type: CAS <CR> The SEL-701-1 Monitor sends: <STX>"CAS",n,"yyyy"<CR> "COMMAND 1",Ll,"yyyy"<CR> "#H","xxxxx","xxxxx",..,"xxxxx","yyyy"<CR> "#D","ddd","ddd","ddd","ddd",..,"ddd","yyyy"<CR>...
Page 362 <STX>"No Data Available","0668"<CR> <ETX> SEL-701-1 Monitor Command Response Contents Display the SEL-701-1 Monitor compressed ASCII configuration message by typing: CAS <CR> The monitor replaces the items in italics with the actual monitor data. The SEL-701-1 Monitor sends: <STX>...
Page 363 "RTD TC(%)" is the RTD estimated thermal capacity used in percent. "CALC TIME" is the calculated time to thermal trip in seconds. "MINUTES" is the number of minutes since the last motor start. "STARTS" is the number of motor starts in the past hour. SEL-701-1 Monitor Date Code 20011009...
Page 364: Cstatus Command
D.22 CSTATUS Command CSTATUS Command Display status data in compressed ASCII format by typing: CST <CR> The monitor replaces the items in italics with the actual monitor data. The SEL-701-1 Monitor sends: <STX>"FID","yyyy"<CR> "Monitor FID string","yyyy"<CR> "MONTH","DAY","YEAR","HOUR","MIN","SEC","MSEC","yyyy"<CR> xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,"yyyy"<CR> "IA","IB","IC","IN","VA","VB","VC","N","+5V_PS","- 5V_PS","+15V_PS","+28V_PS","TEMP","RAM","ROM","CR_RAM","EEPROM","BATTERY","RTC","LC_TIME","TC_STAR T","MONITOR","yyyy"<CR>...
Page 365: Chistory Command
CHISTORY Command CHISTORY Command Display history data in compressed ASCII format by typing: CHI <CR> The monitor replaces the items in italics with the actual monitor data. The SEL-701-1 Monitor sends: <STX>"FID","yyyy"<CR> "Monitor FID string","yyyy"<CR> "REC_NUM","MONTH","DAY","YEAR","HOUR","MIN","SEC","MSEC","TYPE","FREQ","THM CAP(%)","UB_CURR(%)","IA","IB","IC","IN","IG","3I2","WDG (C)","BRG (C)","AMB (C)","OTH (C)","VAB","VBC","VCA","kW","kVAR","kVA","PF","LD/LG","yyyy"<CR>...
Page 366: Cevent Command
(1–n), defaults to 1. The monitor responds to the CEV command with the nth event report as shown below. The monitor replaces the items in italics with the actual monitor data. The SEL-701-1 Monitor sends: <STX>"FID","yyyy"<CR> "Monitor FID string","yyyy"<CR>...
Page 367 00100000. Mapping the labels to the bits yields: Labels STARTING RUNNING STOPPED JAMTRIP LOSSALRM LOSSTRIP 46VBA 46BVT Bits In this example, the STOPPED Relay Word bit is asserted (logical 1); all others are deasserted (logical 0). SEL-701-1 Monitor Date Code 20011009...
Page 368: Cme E Command
CME E Command CME E Command Display energy meter data in compressed ASCII format by typing: CME E <CR> The monitor replaces items in italics with the actual monitor data. The SEL-701-1 Monitor sends: <STX>"FID","yyyy"<CR> "Monitor FID string","yyyy"<CR> "MONTH","DAY","YEAR","HOUR","MIN","SEC","MSEC","yyyy"<CR> xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,"yyyy"<CR>...
Page 369: Cme M Command
CME M Command CME M Command Display Max/Min meter data in compressed ASCII format by typing: CME M <CR> The monitor replaces the items in italics with the actual monitor data. The SEL-701-1 Monitor sends: <STX>"FID","yyyy"<CR> "Monitor FID string","yyyy"<CR> "MONTH","DAY","YEAR","HOUR","MIN","SEC","MSEC","yyyy"<CR> xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,"yyyy"<CR>...
Page 370: Cme T Command
CME T Command CME T Command Display thermal meter data in compressed ASCII format by typing: CME T <CR> The monitor replaces the items in italics with the actual monitor data. The SEL-701-1 Monitor sends: <STX>"FID","yyyy"<CR> "Monitor FID string","yyyy"<CR> "MONTH","DAY","YEAR","HOUR","MIN","SEC","MSEC","yyyy"<CR> xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,xxxx,"yyyy"<CR>...
Page 371: Appendix E: Motor Thermal Element
Appendix E Motor Thermal Element Introduction The SEL-701-1 Monitor provides effective motor thermal protection using a patented protection algorithm. The monitor offers three convenient methods to set the thermal element. They are: Motor ratings method. Generic thermal limit curve method.
Page 372 Provides an alarm output if the present heat estimate exceeds the present alarm threshold (user settable as a percentage of the trip threshold). Adjusts the present trip threshold based on RTD ambient temperature measurement when enabled. SEL-701-1 Monitor Date Code 20011009...
Page 373: Purpose Of Motor Thermal Protection
The purpose of motor thermal protection is to allow the motor to start and run within the manufacturer’s published guidelines, but trip if the motor heat energy exceeds those ratings due to overloads, negative-sequence current, or locked rotor starting. SEL-701-1 Monitor Date Code 20011009...
Page 374 The SEL-701-1 Monitor thermal element, with its integrated design, offers distinct advantages over the use of discrete elements. The SEL-701-1 Monitor thermal element always operates in one of two modes: starting or running. In starting mode, the thermal element provides locked rotor...
Page 375: The Basic Thermal Element
Equation • • Heat Source Equation E.1 Heating factors K and K are defined by the positive-sequence rotor resistance and negative-sequence rotor resistance, respectively. SEL-701-1 Monitor Date Code 20011009...
Page 376: Figure E.3 Typical Induction Motor Current, Torque, And Rotor Resistance Versus Slip
When rotor speed is zero, the counter-rotating poles induce fundamental frequency currents in the rotor: negative-sequence slip equals positive-sequence slip, S. When the rotor is spinning at near synchronous speed, the counter-rotating magnetic poles induce SEL-701-1 Monitor Date Code 20011009...
Page 377: Equation E.4
The differences in the positive- and negative-sequence heating factors immediately suggest that the thermal element should have two states representing the starting and running states of the motor. The SEL-701-1 Monitor thermal element automatically selects which state to use based on the measured positive-sequence current.
Page 378: Motor Starting Protection
2.5 times full load current, the monitor switches from the starting thermal element to the running thermal element. The present heat estimate, U, is transferred directly to the running element, representing the heat build-up that occurred during motor starting. SEL-701-1 Monitor Date Code 20011009...
Page 379: Motor Running Protection
(To). Locked Rotor Trip Energy • Ta • To Normal Operating Energy • (Ta - To) Base or Ambient Energy Figure E.6 Calculating the Normal Operating Energy Using Locked Rotor Trip Times. SEL-701-1 Monitor Date Code 20011009...
Page 380 SF, is accounted for in the running thermal element trip threshold. Figure E.7 shows the final running thermal element. Relay Word • (Ta - To) • SF + 5 • I • (Ta - To) Figure E.7 Motor Running Thermal Element. SEL-701-1 Monitor Date Code 20011009...
Page 381 RC circuit from the initial starting value to the final running value. SEL-701-1 Monitor Date Code 20011009...
Page 382: Interpreting Percent Thermal Element Capacity Values
E.12 Interpreting Percent Thermal Element Capacity Values Interpreting Percent Thermal Element Capacity Values Several of the SEL-701-1 Monitor reporting functions include a % Thermal Capacity value. At all times, the monitor calculates the percent thermal capacity using Equation E.9. Present Heat Estimate, U •...
Page 383: Motor Starting Thermal Capacity
The SEL-701-1 Monitor provides two facilities to help ensure that a motor start is not attempted while the motor is still too hot to be started safely. The Thermal Capacity Used to Start (TCSTART) setting allows you to define a fixed value of thermal capacity that you expect the motor to use on a start.
Page 384 This page intentionally left blank...
Page 385 Date ________________ Factory Defaults Created by ____________ Appendix F SEL-701-1 Monitor Settings Sheets MONITOR SETTINGS (Factory Defaults, Model 070111X) General Data Relay Identifier RID = SEL-701-1 Range: 20 Characters Terminal Identifier TID = MONITOR Range: 20 Characters Phase (IA, IB, IC) CT Ratio...
Page 386 Page 2 of 22 Date ________________ Factory Defaults Created by ____________ Thermal Model Elements Setting Method SETMETH = RATING Range: OFF, Rating, Generic, User Thermal Element Settings when Setting Method = RATING (Hidden when SETMETH = GENERIC or USER) Full Load Amps Range: 1.00–8.00 A;...
Page 387 Page 3 of 22 Date _______________ Factory Defaults Created by ___________ Time to Trip at 1.40 x FLA TTT140 = (Hidden) Range: 1.0–6000.0 s, NP Time to Trip at 1.50 x FLA TTT150 = (Hidden) Range: 1.0–6000.0 s, NP Time to Trip at 1.75 x FLA TTT175 = (Hidden) Range: 1.0–6000.0 s, NP...
Page 388 Page 4 of 22 Date ________________ Factory Defaults Created by ____________ The balance of Thermal Element Settings are used regardless of setting method. Thermal Capacity Alarm Pickup TCAPU = Range: 50%–100% Thermal Capacity Used to Start TCSTART = Range: 20%–100% Use Learned Starting Thermal Capacity TCLRNEN = Range: Y, N...
Page 389: Jogging Block Element Settings
Page 5 of 22 Date _______________ Factory Defaults Created by ___________ Level 2 Neutral O/C Pickup Range: OFF, 0.025–10.000 A; INTAP = 5 A 50N2P = OFF, 0.005–2.000 A; INTAP = 1 A Level 2 Neutral O/C Time Delay 50N2D = (Hidden) Range: 0.00–400.00 s Negative-Sequence O/C Pickup...
Page 390: Speed Switch Tripping Time Delay Setting
Page 6 of 22 Date ________________ Factory Defaults Created by ____________ Load-Loss Trip Threshold LLTPU = Range: 0.10–1.00 pu FLA Load-Loss Starting Time Delay LLSDLY = Range: 0–15000 s Load-Loss Alarm Time Delay LLADLY = 5.00 Range: 0.00–400.00 s Load-Loss Trip Time Delay LLTDLY = 10.00 Range: 0.00–400.00 s...
Page 391 Page 7 of 22 Date _______________ Factory Defaults Created by ___________ RTD Location RTD4LOC = (Hidden) Range: WDG, BRG, AMB, OTH, NONE RTD Location RTD5LOC = (Hidden) Range: WDG, BRG, AMB, OTH, NONE RTD Location RTD6LOC = (Hidden) Range: WDG, BRG, AMB, OTH, NONE RTD Location RTD7LOC = (Hidden)
Page 392 Page 8 of 22 Date ________________ Factory Defaults Created by ____________ RTD Identifier RTD10NAM = (Hidden) Range: 10 Characters RTD Identifier RTD11NAM = (Hidden) Range: 10 Charachers RTD Identifier RTD12NAM = (Hidden) Range: 10 Characters RTD Type Settings (Hidden when RTDOPT = NONE) RTD Type RTD1TY = (Hidden)
Page 393 Page 9 of 22 Date _______________ Factory Defaults Created by ___________ RTD Alarm Temperature Range: OFF, 0 ° –250 ° C OFF, 32 ° –482 ° F RTD1A2 = (Hidden) RTD Alarm Temperature Range: OFF, 0 ° –250 ° C OFF, 32 °...
Page 394 Page 10 of 22 Date ________________ Factory Defaults Created by ____________ RTD Trip Temperature Range: OFF, 0 ° –250 ° C OFF, 32 ° –482 ° F RTD5T = (Hidden) RTD Alarm Temperature Range: OFF, 0 ° –250 ° C OFF, 32 °...
Page 395 Page 11 of 22 Date _______________ Factory Defaults Created by ___________ RTD Alarm Temperature Range: OFF, 0 ° –250 ° C OFF, 32 ° –482 ° F RTD8A2 = (Hidden) RTD Alarm Temperature Range: OFF, 0 ° –250 ° C OFF, 32 °...
Page 396 Page 12 of 22 Date ________________ Factory Defaults Created by ____________ RTD Trip Temperature Range: OFF, 0 ° –250 ° C OFF, 32 ° –482 ° F RTD12T = (Hidden) RTD Alarm Temperature Range: OFF, 0 ° –250 ° C OFF, 32 °...
Page 397: Reactive Power Element Settings
Page 13 of 22 Date _______________ Factory Defaults Created by ___________ VOLTAGE-BASED PROTECTION Undervoltage (U/V) Elements (Hidden if no voltage option or if DELTA_Y = Y) Level 1 Phase-Phase U/V Pickup 27P1P = (Hidden) Range: OFF, 1–300 V Level 2 Phase-Phase U/V Pickup 27P2P = (Hidden) Range: OFF, 1–300 V...
Page 398: Underpower Element Settings
Page 14 of 22 Date ________________ Factory Defaults Created by ____________ Positive VAR Trip Pickup (Hidden if NVARTP = OFF) Range: 30–2000 VAR; ITAP = 5 A PVARTP = (Hidden) 6–400 VAR; ITAP = 1 A VAR Trip Time Delay (Hidden if NVARTP = OFF) VARTD = (Hidden)
Page 399: Frequency Element Settings
Page 15 of 22 Date _______________ Factory Defaults Created by ___________ Frequency Elements Settings (Hidden if no voltage option) Level 1 Pickup 81D1P = 59.10 Range: OFF, 20.00–70.00 Hz Level 1 Time Delay (Hidden if 81D1P = OFF) 81D1D = 0.03 Range: 0.03–400.00 s Level 2 Pickup...
Page 400: Analog Output Settings
Front-Panel RTD Display (Hidden if RTDOPT = NONE) FP_RTD = (Hidden) Range: Y, N Front-Panel Display Message Settings Display Messages DM1_1 = SEL-701-1 Range: 20 Characters; enter NA to null DM1_0 = DM2_1 = MONITOR DM2_0 = DM3_1 = RTD FAILURE...
Page 401: Antibackspin Setting
Page 17 of 22 Date _______________ Factory Defaults Created by ___________ DM5_0 = DM6_1 = DM6_0 = Output Contact Settings Enable TRIP Contact Fail-Safe TRFS = Range: Y, N Enable OUT1 Contact Fail-Safe OUT1FS = Range: Y, N Enable OUT2 Contact Fail-Safe OUT2FS = Range: Y, N Enable OUT3 Contact Fail-Safe...
Page 402 Page 18 of 22 Date ________________ Factory Defaults Created by ____________ SV3 = SV4 = Set/Reset Latch Variables (Hidden if FACTLOG = Y) Latch Variable (1-4) SET1 = Range: SEL Control Equation OGIC RST1 = SET2 = RST2 = SET3 = RST3 = SET4 = RST4 =...
Page 403 Page 19 of 22 Date _______________ Factory Defaults Created by ___________ Output Variables 1–3 Range: SEL Control Equation OGIC OUT1 = LOSSALRM + 46UBA + 49A + 37PA + 55A + VARA OUT2 = RTDBIAS + WDGALRM + BRGALRM + AMBALRM + OTHALRM + RTDFLT OUT3 = START...
Page 404 Page 20 of 22 Date ________________ Factory Defaults Created by ____________ SERIAL PORT SETTINGS (SERIAL PORT COMMAND SET P F OR SET P R) SET P Serial Port Settings Protocol (Hidden, Equal ASCII for Front Port) PROTO = ASCII Range: ASCII, MOD Protocol = ASCII (Hidden when Protocol = MOD) Baud Rate...
Page 405 Page 21 of 22 Date _______________ Factory Defaults Created by ___________ SEQUENTIAL EVENTS RECORDER SETTINGS (SET R) SER Trigger Settings SER1 Range: 24 Relay Word bits, separated by commas. SER1 = IN1, IN2, IN3, IN4, IN5, IN6, IN7 Use NA to disable setting. SER2 Range: 24 Relay Word bits, separated by commas.
Page 406 Page 22 of 22 Date ________________ Factory Defaults Created by ____________ Alias Settings (Hidden when EALIAS = N, ALIAS# > EALIAS setting are hidden.) NOTE: Relay Word bit (space) Alias (space) Asserted text (space) Alias and text strings can each be up to 15 text characters. Asserted and deasserted text strings are not required.
Page 407 Date ________________ Created by ____________ Appendix F SEL-701-1 Monitor Settings Sheets MONITOR SETTINGS General Data Relay Identifier RID = Range: 20 Characters Terminal Identifier TID = Range: 20 Characters Phase (IA, IB, IC) CT Ratio CTR = Range: 1-600 to 10...
Page 408 Page 2 of 22 Date _______________ Created by ___________ Thermal Model Elements Setting Method SETMETH = Range: OFF, Rating, Generic, User Thermal Element Settings when Setting Method = RATING (Hidden when SETMETH = GENERIC or USER) Full Load Amps Range: 1.00–8.00 A; ITAP = 5 A FLA = 0.20–1.60 A;...
Page 409 Page 3 of 22 Date _______________ Created by ___________ Time to Trip at 1.40 x FLA TTT140 = Range: 1.0–6000.0 s, NP Time to Trip at 1.50 x FLA TTT150 = Range: 1.0–6000.0 s, NP Time to Trip at 1.75 x FLA TTT175 = Range: 1.0–6000.0 s, NP Time to Trip at 2.00 x FLA...
Page 410 Page 4 of 22 Date _______________ Created by ___________ The balance of Thermal Element Settings are used regardless of setting method. Thermal Capacity Alarm Pickup TCAPU = Range: 50%–100% Thermal Capacity Used to Start TCSTART = Range: 20%–100% Use Learned Starting Thermal Capacity TCLRNEN = Range: Y, N Motor Stopped Cooling Time...
Page 411 Page 5 of 22 Date _______________ Created by ___________ Level 2 Neutral O/C Pickup Range: OFF, 0.025–10.000 A; INTAP = 5 A 50N2P = OFF, 0.005–2.000 A; INTAP = 1 A Level 2 Neutral O/C Time Delay 50N2D = Range: 0.00–400.00 s Negative-Sequence O/C Pickup Range: OFF, 0.25–100.00 A;...
Page 412 Page 6 of 22 Date _______________ Created by ___________ Load-Loss Trip Threshold LLTPU = Range: 0.10–1.00 pu FLA Load-Loss Starting Time Delay LLSDLY = Range: 0–15000 s Load-Loss Alarm Time Delay LLADLY = Range: 0.00–400.00 s Load-Loss Trip Time Delay LLTDLY = Range: 0.00–400.00 s Current Unbalance Elements Settings...
Page 413 Page 7 of 22 Date _______________ Created by ___________ RTD Location RTD4LOC = Range: WDG, BRG, AMB, OTH, NONE RTD Location RTD5LOC = Range: WDG, BRG, AMB, OTH, NONE RTD Location RTD6LOC = Range: WDG, BRG, AMB, OTH, NONE RTD Location RTD7LOC = Range: WDG, BRG, AMB, OTH, NONE RTD Location...
Page 414 Page 8 of 22 Date _______________ Created by ___________ RTD Identifier RTD10NAM = Range: 10 Characters RTD Identifier RTD11NAM = Range: 10 Charachers RTD Identifier RTD12NAM = Range: 10 Characters RTD Type Settings (Hidden when RTDOPT = NONE) RTD Type RTD1TY = Range: PT100, NI100, NI120, CU10 RTD Type...
Page 415 Page 9 of 22 Date _______________ Created by ___________ RTD Alarm Temperature Range: OFF, 0 ° –250 ° C OFF, 32 ° –482 ° F RTD1A2 = RTD Alarm Temperature Range: OFF, 0 ° –250 ° C OFF, 32 ° –482 ° F RTD1A3 = RTD Trip Temperature Range: OFF, 0 °...
Page 416 Page 10 of 22 Date _______________ Created by ___________ RTD Trip Temperature Range: OFF, 0 ° –250 ° C OFF, 32 ° –482 ° F RTD5T = RTD Alarm Temperature Range: OFF, 0 ° –250 ° C OFF, 32 ° –482 ° F RTD5A1 = RTD Alarm Temperature Range: OFF, 0 °...
Page 417 Page 11 of 22 Date _______________ Created by ___________ RTD Alarm Temperature Range: OFF, 0 ° –250 ° C OFF, 32 ° –482 ° F RTD8A2 = RTD Alarm Temperature Range: OFF, 0 ° –250 ° C OFF, 32 ° –482 ° F RTD8A3 = RTD Trip Temperature Range: OFF, 0 °...
Page 418 Page 12 of 22 Date _______________ Created by ___________ RTD Trip Temperature Range: OFF, 0 ° –250 ° C OFF, 32 ° –482 ° F RTD12T = RTD Alarm Temperature Range: OFF, 0 ° –250 ° C OFF, 32 ° –482 ° F RTD12A1 = RTD Alarm Temperature Range: OFF, 0 °...
Page 419 Page 13 of 22 Date _______________ Created by ___________ VOLTAGE-BASED PROTECTION Undervoltage (U/V) Elements (Hidden if no voltage option or if DELTA_Y = Y) Level 1 Phase-Phase U/V Pickup 27P1P = Range: OFF, 1–300 V Level 2 Phase-Phase U/V Pickup 27P2P = Range: OFF, 1–300 V Overvoltage (O/V) Elements...
Page 420 Page 14 of 22 Date _______________ Created by ___________ Positive VAR Trip Pickup (Hidden if NVARTP = OFF) Range: 30–2000 VAR; ITAP = 5 A PVARTP = 6–400 VAR; ITAP = 1 A VAR Trip Time Delay (Hidden if NVARTP = OFF) VARTD = Range: 0.00–400.00 s VAR Element Arming Delay...
Page 421 Page 15 of 22 Date _______________ Created by ___________ Frequency Elements Settings (Hidden if no voltage option) Level 1 Pickup 81D1P = Range: OFF, 20.00–70.00 Hz Level 1 Time Delay (Hidden if 81D1P = OFF) 81D1D = Range: 0.03–400.00 s Level 2 Pickup 81D2P = Range: OFF, 20.00–70.00 Hz...
Page 422 Page 16 of 22 Date _______________ Created by ___________ OUTPUT CONFIGURATION Analog Output Settings Analog Output Signal Type AOSIG = Range: 0–1 mA, 0–20 mA, 4–20 mA Analog Output Parameter Range: %Load_I Percentage of Full Load Current %THERM Percentage Thermal Capacity WDG_RTD Hottest Winding RTD Temperature...
Page 423 Page 17 of 22 Date _______________ Created by ___________ DM5_0 = DM6_1 = DM6_0 = Output Contact Settings Enable TRIP Contact Fail-Safe TRFS = Range: Y, N Enable OUT1 Contact Fail-Safe OUT1FS = Range: Y, N Enable OUT2 Contact Fail-Safe OUT2FS = Range: Y, N Enable OUT3 Contact Fail-Safe...
Page 424 Page 18 of 22 Date _______________ Created by ___________ SV3 = SV4 = Set/Reset Latch Variables (Hidden if FACTLOG = Y) Latch Variable (1–4) SET1 = Range: SEL Control Equation OGIC RST1 = SET2 = RST2 = SET3 = RST3 = SET4 = RST4 = Output Variables...
Page 425 Page 19 of 22 Date _______________ Created by ___________ LED Logic (Hidden if FACTLOG = Y) Use Factory LED Settings FACTLED = Range: Y, N LED Variables 1–7 (Hidden if FACTLED = Y) LED1 = Range:SEL Control Equation OGIC LED2 = LED3 = LED4 = LED5 =...
Page 426: Appendix C: Modbus
Page 20 of 22 Date _______________ Created by ___________ SERIAL PORT SETTINGS (SERIAL PORT COMMAND SET P F OR SET P R) SET P Serial Port Settings Protocol (Hidden, Equal ASCII for Front Port) PROTO = Range: ASCII, MOD Protocol = ASCII (Hidden when Protocol = MOD) Baud Rate SPEED =...
Page 427 Page 21 of 22 Date _______________ Created by ___________ SEQUENTIAL EVENTS RECORDER SETTINGS (SET R) SER Trigger Settings SER1 Range: 24 Relay Word bits, separated by commas. SER1 = Use NA to disable setting. SER2 Range: 24 Relay Word bits, separated by commas.
Page 428 Page 22 of 22 Date _______________ Created by ___________ Alias Settings (Hidden when EALIAS = N, ALIAS# > EALIAS setting are hidden.) NOTE: Relay Word bit (space) Alias (space) Asserted text (space) Alias and text strings can each be up to 15 text characters. Asserted and deasserted text strings are not required.
Page 429 SEL-701-1 Monitor Command Summary The table below lists the serial port commands associated with particular activities. All Access Level 1 commands are also available in Access Level 2. The commands are shown in upper-case letters, but can also be entered with lower-case letters.
Page 430 Relay Setting Commands SHOW Show/view relay settings 5.24 Enter/change relay settings 5.22 Relay Output Control Commands ANALOG Test analog output 5.11 Control remote bit 5.12 Pulse output contact 5.20 STOP Stop motor 5.27 Start motor 5.27 SEL-701-1 Monitor Date Code 20011009...
Page 431: Glossary
Alias User assigned name of a Relay Word bit used in the SEL-701-1 Monitor Sequential Events Recorder (SER) function. The assigned alias appears in the SER report in place of the Relay Word bit, making the SER report easier to review.
Page 432 ASCII Abbreviation for American Standard Code for Information Interchange. Defines a standard way to communicate text characters between two electronic devices. The SEL-701-1 Monitor uses ASCII text characters to communicate using its front- and rear- panel EIA-232 serial ports. Assert To activate;...
Page 433 The unbalance element can trip the motor in the presence of heavy unbalance to prevent rotor damage due to overheating. In the SEL-701-1 Monitor, this element works together with the motor thermal element which also provides unbalance current protection.
Page 434 When a motor ground fault occurs, this current can be large. Neutral current measured by the monitor IN input. The IN input is typically connected to the secondary winding of a window-CT for motor ground fault detection on resistance-grounded systems. SEL-701-1 Monitor Date Code 20011009...
Page 435 Glossary GL.5 Instantaneous Meter-Load Profile Instantaneous Meter Type of meter data presented by the SEL-701-1 Monitor that includes the present values measured at the monitor ac inputs. The word “Instantaneous” is used to differentiate these values from the measurements presented by the demand, thermal, energy, and other meter types.
Page 436: Appendix E: Motor Thermal Element
GL.6 Max/Min Meter -Phase Rotation Max/Min Meter Type of meter data presented by the SEL-701-1 Monitor that includes a record of the maximum and minimum of each value, along with the date and time that each maximum and minimum occurred.
Page 437 Fast Operate command, or Modbus command. Residual Current The sum of the measured phase currents. In normal, balanced operation, this current is very small or zero. When a motor ground fault occurs, this current can be large. SEL-701-1 Monitor Date Code 20011009...
Page 438: Equation E.8
Abbreviation for Resistance Temperature Device. An RTD is made of a metal having a precisely known resistance and temperature coefficient of resistance. The SEL-701-1 Monitor and SEL-2600 RTD Module can measure the resistance of the RTD, and thus, determine the temperature at the RTD location.
Page 439 The second and third voltage transformers are connected to measure the voltage from B-phase and C-phase-to-ground, respectively. This connection is frequently called ‘four-wire wye,’ alluding to the three phase leads plus the neutral lead. SEL-701-1 Monitor Date Code 20011009...
Page 440 This page intentionally left blank...
Page 441 5.26 glossary entry GL.2 STOP 5.27 meter 5.27 ASCII Protocol TARGET 5.27 EIA-232 port 2.21 TIME 5.31 TRIGGER 5.31 Average Data Commissioning Procedure – See Motor Statistics connection check Battery required equipment See Clock Battery SEL-701-1 Monitor Date Code 20011009...
Page 442 B.40 using % unbalance element 3.26 reactive power elements B.46 using overcurrent element 3.24 speed switch B.46 using thermal element start logic B.27 Current Unbalance Element stop/trip logic B.25 glossary entry GL.3 underpower elements B.36 SEL-701-1 Monitor Date Code 20011009...
Page 443 Fast Operate serial port command 5.16 A5CE D.13 EVENT Command 5.13 A5E0 D.14 Event History A5E3 D.15 See History binary commands enable setting 3.53 Event Report Firmware Upgrade clearing the buffer 8.11 column definitions instructions SEL-701-1 Monitor Date Code 20011009...
Page 444 4.20 reset using front panel 4.22 stop motor starting thermal capacity 3.20 view relay word 4.21 view using See also TARGET Command front panel 5.18 password entry MOTOR command 5.18 pushbuttons removal SEL-701-1 Monitor Date Code 20011009...
Page 445 4.16 5.18 Motor Starts Count 4.16 5.17 motor start report 7.11 serial port command 5.15 motor start trend 7.13 starts this hour 4.16 5.17 motor statistics 5.18 temperature 4.16 5.17 thermal 4.16 5.17 SEL-701-1 Monitor Date Code 20011009...
Page 446 See Motor Statistics See Power Phase Reversal Tripping Rear Panel 3.27 glossary entry GL.6 diagram logic diagram B.38 Relay Enabled LED Phase Rotation normal operation phasor diagram Relay Models setting, PHROT See also Part Number SEL-701-1 Monitor Date Code 20011009...
Page 447: Equation E.9
SER Command 5.21 Running Serial Number Label 1.10 LED indication Serial Ports Safety Ground EIA-232 See Chassis Ground access levels SEL-2600 RTD Module 2.24 automatic messages 5.32 contact input 3.28 command summary failure messages communication cable SEL-701-1 Monitor Date Code 20011009...
Page 448 3.24 50P2P 3.22 LJTPU 3.24 50QD 3.22 LLADLY 3.25 3.26 50QP 3.22 LLAPU 3.25 3.26 55AD 3.41 LLSDLY 3.25 3.26 55DLY 3.41 LLTDLY 3.25 3.26 55LDAP 3.41 LLTPU 3.25 3.26 55LDTP 3.41 55LGAP 3.41 LRTCOLD SEL-701-1 Monitor Date Code 20011009...
Page 449 STATUS Command 5.26 VARTD 3.39 Status of Relay setting prompts See also STATUS Command analog output full scale current 3.43 front-panel function 4.20 antibackspin starting delay 3.48 current unbalance trip pickup 3.26 date format 5.22 8.14 SEL-701-1 Monitor Date Code 20011009...
Page 450 2.15 required to start 3.20 E.13 Trip Counters RTD % thermal capacity 3.35 starting 7.11 7.13 Trip Logic Thermal Element – 3.21 factory default 3.49 alarm 3.20 Trip Reset front-panel reset 4.22 front-panel function 4.10 SEL-701-1 Monitor Date Code 20011009...
Page 451 3.37 single phase-to-neutral wiring diagram single phase-to-phase wiring diagram starting 7.11 7.13 Wiring Diagrams 4-wire wye voltages contact inputs 2.17 contact output 2.14 delta voltages EIA-485 port 2.23 ground CT motor starting 2.16 SEL-701-1 Monitor Date Code 20011009...
Page 452 This page intentionally left blank...
