- Page 1 HLP 4800 Platform User’s Guide VERSION 1.0 Rev A Manual Part No. 700-0052028...
- Page 2 Harmonic assumes no responsibility or liability arising from the use of the products described herein, except as expressly agreed to in writing by Harmonic. The use and purchase of this product do not convey a license under any patent rights, copyrights, trademark rights, or any intellectual property rights of Harmonic.
- Page 3 Vérifier qu'un fusible ou qu'un disjoncteur de 1 20 V alt., 1 5 A U.S. maximum (240 V alt., 10 A international) est utilisé sur les conducteurs de phase (conducteurs de charge). © 2009 Harmonic Inc. All rights reserved.
- Page 4 Bei Anbringung dieser Einheit in einem zum Teil gefüllten Gestell ist das Gestell von unten nach oben zu laden, wobei das schwerste Bauteil unten im Gestell anzubringen ist. Wird das Gestell mit Stabilisierungszubehör geliefert, sind zuerst die Stabilisatoren zu installieren, bevor Sie die Einheit im Gestell anbringen oder sie warten. © 2009 Harmonic Inc. All rights reserved.
- Page 5 Make sure electrical circuits are not overloaded – consider the nameplate rating of all the connected equipment, and make sure you have over current protection. Make sure the equipment is properly grounded. ace on top of unit. Make sure no objects pl © 2009 Harmonic Inc. All rights reserved.
- Page 6 Harmonic will ensure that product which cannot be reused will be recycled in compliance with the WEEE Directive. To that end, users are advised that (1) Harmonic equipment is not to be discarded in household or office garbage, (2) Harmonic Inc. will pay the...
- Page 7 X: Indicates that the content of the toxic and hazardous substances in at least one of the homogeneous materials of the parts is above the limit defined in SJ/T1 1 363 2006 standard. © 2009 Harmonic Inc. All rights reserved.
- Page 8 Safety: UL 60950-1, CSA C22.2 No 60950-1, 21 CFR 1040 (CDRH) Europe Standards EMI/EMC: EN55022, EN55024, EN61000-3-2, EN61000-3-3 Safety: EN 60950-1, EN 60825-1 Japan Standards EMI: VCCI V-3 / 2007.04 Australia and New Zealand Standards EMI: AS/NZS-CISPR 22:2005 © 2009 Harmonic Inc. All rights reserved.
- Page 9 CAUTION: The Caution symbol calls your attention to information that, if ignored, can adversely affect the performance of your Harmonic product, or that can make a procedure needlessly difficult. LASER DANGER: The Laser symbol and the Danger alert call your attention to information about the lasers in this product that, if ignored, can cause physical harm to you.
-
Page 10: Table Of Contents
HLP 4800 Chassis ........ -
Page 11: Chapter 1 Preface
Chapter 1 Preface Overview of this Manual This manual is the user’s guide to the HLP 4800 Platform. Please read the entire document before beginning installation. HLP 4800 Platform. Please read the entire document before beginning installation or operation. Chapter 1, Preface, (this chapter) gives an overview of the book. -
Page 12: Chapter 2 Overview
Reduced network downtime because of plug-in module replacements. HLP 4800 Chassis The HLP 4800 is a rack-mount platform, three rack units in height, designed to be fitted to a 19-inch EIA standard rack flange. It will accommodate ten of Harmonic’s standard 1.3 inch wide plug-in modules, using appropriate carriers. -
Page 13: Rear Panel Description
Figure 2-1: Front panel HLP 4800 2.1.2 Rear Panel Description Figure 2-2 on page 1 3 shows the HLP 4800 rear panel features and locations. +24v DC backup RJ-1 1 (reserved for future use) Dual ground lug 10-32 UNC Alarm relay Figure 2-2: Rear panel, HLP 4800 ©... -
Page 14: Chapter 3 Installing The Hlp 4800 Platform
1. Mark the exact position in the rack where you want to install the unit. 2. Prepare the four mounting screws and #2 Phillips screwdriver. 3. Use four mounting screws to attach the mounting brackets on the HLP 4800 rack ears to the rack. -
Page 15: Connecting The Grounding Lugs
Never handle live wiring. Connecting the Alarm Relay External alarm equipment can be connected to the HLP 4800. The HLP 4800 has a 5-pin alarm relay located on the rear panel, as shown in Figure 2-2: Rear panel, HLP 4800 page 1 3. - Page 16 Normally closed 1 1 2 3 4 5 Figure 3-2: Alarm relay terminal block Harmonic part number 406-0000560 When operating normally with no alarm present, Pin 1 and Pin 2 are open, while Pin 3 and Pin 5 are closed.
-
Page 17: Chapter 4 Maintenance And Troubleshooting
There are no user-serviceable parts in the HLP 4800. Contacting Harmonic Support The Harmonic Customer and Technical Support groups are available to help you with any questions or problems you may have regarding Harmonic products. For assistance from within the U.S. and Canada, call toll free: 1.888.673.4896... -
Page 18: Appendix A Technical Specifications
Storage Temperature Range to +85 C / -40 to +185 º º º º Relative Humidity Maximum 95% non-condensing User Interface: Rear Panel Alarm activated relay contact +24 VDC backup Grounding nut © 2009 Harmonic Inc. HLP 4800, Version 1.0, Rev A... - Page 19 Appendix A Technical Specifications HLP 4800 Technical specifications: Part Numbers HLP 4800 Chassis HNC 4800 Display and controller CPS 4800-AC AC power supply CPS 4800-DC DC power supply FW-HNC 4800-WEB/SNMP WEB/SNMP license © 2009 Harmonic Inc. HLP 4800, Version 1.0, Rev A...
- Page 20 Harmonic Inc. 549 Baltic Way Sunnyvale, CA 94089, U.S.A. T +1 408 542 2500 F +1 408 490 6708 www.harmonicinc.com © Copyright 2009 Harmonic Inc. All rights reserved. Manual Part No. 700-0052028...
