Summary of Contents for FITRE TWIN S
- Page 1 TWIN S Weatherproof Optical/acoustical Signalling device USER MANUAL...
- Page 3 You have bought a modern product subject to strict quality control. If any questions or malfunctions should occur – even after the guarantee has expired – please contact your FITRE partner. Please have the product number (to be found on the nameplate) ready.
- Page 4 Care and maintenance The TWIN-Kombi is maintenance free. Still, if the operating area is highly contaminated by dust, fat, oil etc., the device should be cleaned from time to time.Use a moist cloth to dust off the device. Warning! Never use sharp objects for cleaning. Do not use polishing or abrasive substances. EMC-Directive The device complies with the requirements of the new EMCdirective 2004/108/EC and the low voltage directive 2006/95/EC.
- Page 5 Setting the ringing signal Use the DIPswitch to set the ringing signal of the TWIN-Kombi. Switch position] Tone sequence frequency [kHz Tone sequence [sec] No. 1 No. 2 Dimension illustration Technical Data Connection data: Cable glands ............M20 x 1.5 mm, clamping capacity ø 5-9 mm Terminals...............for strands up to 1.5 mm2 Mains connection: Terminal designation........L1, N, on the housing...
- Page 6 Continuous use of the device and/or too short a distance between persons and the sound source may cause hearing damage. External protection devices The telephone call repeater TWIN S need local power 230VAC for activating the bell and the lamp, the activation command is made by the analogue telephone line ACB Local power 230VAC The TWIN S must be protected from eventual short circuits or overcharges by external devices, i.e.
- Page 8 Subject to alteration or errors FITRE S.p.A. – telecomunicazioni & elettronica 20142 MILANO – ITALY – via Valsolda, 15 tel.: (+39) 02.8959.01 – fax: (+39) 02.8959.0400 e-mail: info@fitre.it – internet http://www.fitre.it Filiali ROMA e VENEZIA...
