Heiland electronic GmbH
TRD 2
B&W-Densitometer
User manual
Version 6.2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TRD 2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Heiland electronic TRD 2

Summary of Contents for Heiland electronic TRD 2

  • Page 1 Heiland electronic GmbH TRD 2 B&W-Densitometer User manual Version 6.2...

  • Page 2: Table Of Contents

    Table of Contents 1. GENERAL INFORMATION..............3 2. SAFETY REGULATIONS ............... 3 3. AREA OF APPLICATIONS..............3 4. INSTRUMENT DESCRIPTION 4.1. STANDARDVERSION (FIGURE 1)............4 4.2. OPTIONS (FIGURE 2,3) ..............6 5. INSTALLATION 5.1. LOCATION CONDITIONS ..............8 5.2. SWITCHING ON .................. 9 6.

  • Page 3: General Information

    Please contact the manufacturer, if you like to use the instrument for other applications. The modular construction of the instrument enables the user to optimise it according to his requirements. TRD 2 USER MANUAL Version 6.2...

  • Page 4: Instrument Description

    4. Instrument description. Figure 1, TRD 2 standard version Measuring head Mode-LED‘s Display Probe Aperture Base unit Mode and reference buttons...
  • Page 5 The switches on the top of the measuring arm are only active, when the display is on. The Min switch sets the display to zero, with T/R you switch between remission and transmission mode. TRD 2 USER MANUAL Version 6.2...
  • Page 6 Figure 2, Rear side and options Opt.02 Opt.03 Power Supply Opt.01...

  • Page 7: Options (Figure 2,3)

    Tighten the screw with the black knob. Use no tool. If you attach the head to the base unit later on please connect the cable again, otherwise the transmission lamp will not work. Figure 3: Moving the measuring head TRD 2 USER MANUAL Version 6.2...

  • Page 8: Installation

    Option 02: Changeable apertures The apertures have 4 different diameters (0.5/1/2/3mm). Like the standard diffuser they are made out of opal material. Smaller diameters reduce the amount of light, thus the maximum density is lowered. The aperture is changed by pressing slightly on the edge of the diffuser, e.g.

  • Page 9: Switching On

    § Thick glass plates or filters should be read in low ambient light because of their light conducting tendency. § Films should be placed on the reading area with the emulsion side down. TRD 2 USER MANUAL Version 6.2...

  • Page 10: Instructions For Reset To Zero

    6.2 Instructions for reset to zero Reset the display before starting a series of density measurements. If the part of the subject used for zeroing does not have the lowest density, a negative sign will appear while measuring lower density. Reset of transmission reading §...

  • Page 11: Density Measurement

    "T/R" button. § Place subject in a way that the area to be read is centred under the tip of the measuring head. Press "Min"-button until display reads 0.00. § Take series of readings. TRD 2 USER MANUAL Version 6.2...

  • Page 12: Care Of Instrument

    7. Care of instrument § The housing and especially the reading area should only be cleaned with a lightly dampened soft cloth or chamois, if necessary with the addition of a mild cleaner § Do not use solvents or abrasive materials. §...

  • Page 13: Guarantee

    For the warranted period, the manufacturer will pay cost of replacement parts and repair. However, the manufacturer reserves the right to exchange the instrument. Important: Both the instrument and calibration strips must be send back together! TRD 2 USER MANUAL Version 6.2...

  • Page 14: Technical Data

    10. Technical data § Dimensions length x width x height : 200 x 100 x 100 mm § Weight : 1 kg § Voltage requirements : 12 V DC by use of a wall plug power supply § Power consumption : 3 VA §...
  • Page 15 45 Percent of dot area T+.278D Transm. in case of Opt.06 Density: +0,278 log D 0+..D Stand By mode or measuring head is up Issue date: January 2007 Technical data may change without notice. TRD 2 USER MANUAL Version 6.2...
  • Page 16 Heiland electronic GmbH Schulstraße 8 D-35579 Wetzlar Telefon: ++49 6441 26978 Fax: ++49 6441 26988 email: heielec@t-online.de Internet: http://www.heilandelectronic.de...
