- Page 1 AT1 Series Waterproof Enclosure Assembly Manual Revision: 01 Revision Date: 2013/06/10 ATrack Technology Inc. Tel: +886-2-27975852 3F., No. 88, Sec. 1, Neihu Rd., Neihu Dist., Fax: +886-2-27974030 Taipei City 11493 Taiwan (R.O.C.) http://www.atrack.com.tw...
-
Page 2: Table Of Contents
Confidential Document Contents Notification ..........................3 1.1. Disclaimer ............................ 3 1.2. Copyright ............................3 1.3. Warning ............................3 Introduction ..........................4 Package Contents ........................4 Part Descriptions ........................5 Installation Instructions ......................5 Page 2 of 9... -
Page 3: Notification
ATrack Technology Inc. products shall be avoided. ATrack Technology Inc. holds all parts of intellectual rights applicable in the copyright laws in all the countries. Any or all parts of this document shall not be exposed to non-authorized party without any form of approval from ATrack Technology Inc. -
Page 4: Introduction
Confidential Document Designed for outdoor applications, the AT1 Waterproof Enclosure provides you with extreme level of sealing protection against water, dust and corrosion. The following are the step-by-step instructions and part descriptions of the waterproof enclosure. Please use a Philip-head Screwdriver when starting the installation. When you open the package, please verify that you received the following items: (A) Waterproof Enclosure x 1 (B) Mount Plate x 1... -
Page 5: Part Descriptions
Confidential Document Assembly of Cable Gland Connector In this section, we will work you through the installation process. Each part or item is labeled with a capital letter in parentheses, for instance, Lock Nut (G). Please refer to the package contents and part description sections for more information. - Page 6 Confidential Document Make sure that the SIM card is already inserted before installing the AT1 tracker on the Mount Plate (B). Please refer to the SIM Card Installation section on the AT1 user manual for more information. Install the AT1 tracker on the Mount Plate (B) with two Small Metal Screws (F). Page 6 of 9...
- Page 7 Confidential Document Attach the GPS cable to the AT1 tracker and pass the cable through the Body (I) of the cable gland. Open the Sealing Insert (J) to place the GPS cable through it and then thread the GPS cable through the Clamping Claw (K) and the Thread-Lock Sealing Nut (L).
- Page 8 Confidential Document Align the parts as shown below. Plug the Sealing Insert (J) and the Clamping Claw (K) into the Body (I) and tighten the Thread-Lock Sealing Nut (L). In order to have an adequate seal, there is a foolproof mechanism as shown below. Please follow this way to close the enclosure lid.
- Page 9 Confidential Document Drive those four Plastic Screws (D) to seal the Waterproof Enclosure (A). Page 9 of 9...
