IMPORTANT SAFEGUARDS
When using electrical equipment, basic safety precautions should always be followed, including the following:
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
1.
CAUTION – To prevent electrical shock, do not mate unit connector until installation is complete and A.C.
power is supplied to the unit.
2.
CAUTION – This fixture provides more than one power supply output source. To reduce the risk of
electrical shock, disconnect both normal and emergency sources by turning off the A.C. branch circuit and
by disconnecting the unit connector.
3.
CAUTION – This is a sealed unit. The integral, high temperature Ni-Cad battery is not replaceable. Replace
the entire unit when necessary and recycle or dispose of the nickel-cadmium battery properly.
4.
The ICE-80 is for use with grounded, UL Listed, damp location rated and enclosed and gasketed fixtures
except in heated air outlets or hazardous locations.
5.
The ICE-80 requires an unswitched A.C. power source of either 120 or 277 volts. Properly cap the unused
A.C. lead.
6.
Do not mount near gas or electric heaters.
7.
The ICE-80 should be mounted in locations and at heights where it will not readily be subjected to tampering
by unauthorized personnel.
8.
The ICE-80 is suitable for mounting in the ballast compartment only.
9.
The ICE-80 will cold strike and operate one 28W or 54W T5 or 2´-8´ T8-T12 or two 2´-4´ T8-T12 instant
start, rapid start, U shape or circline fluorescent lamps, including energy saving and long 4 pin compact
lamps for 90 minutes.
10.
The ICE-80 is compatible with most A.C. ballasts (including multiple lamp) as follows:
Magnetic ballasts – either one or two lamp emergency operation.
Electronic ballasts – one lamp emergency operation, consult Customer Service for two lamp emergency
Operation wiring diagrams.
11.
Suitable for use in damp locations and in enclosed and gasketed fixtures.
12.
For use in -18
°
C minimum, 50
13.
The use of accessory equipment not recommended by the manufacturer may cause an unsafe condition.
14.
Do not use this equipment for other than intended use.
15.
Install in accordance with the National Electrical Code and local regulations.
16.
Installation and servicing should be performed by qualified personnel.
17.
Lighting fixture manufacturers, electricians, and end-users need to ensure product system compatibility
before final installation.
INSTRUCTION MANUAL
°
C maximum ambient temperatures.
SAVE THESE INSTRUCTIONS
ICE-80
ICE-80
ICE-80
ICE-80
ICE-80
COLD-WEATHER SERIES D
EMERGENCY
LIGHTING EQUIPMENT
THIS UNIT CONTAINS A
RECHARGEABLE NICKEL-
CADMIUM BATTERY. PLEASE
RECYCLE OR DISPOSE OF
PROPERLY.
Advertisement
Table of Contents
Related Manuals for IOTA ICE-80
Summary of Contents for IOTA ICE-80
- Page 1 The ICE-80 is suitable for mounting in the ballast compartment only. The ICE-80 will cold strike and operate one 28W or 54W T5 or 2´-8´ T8-T12 or two 2´-4´ T8-T12 instant start, rapid start, U shape or circline fluorescent lamps, including energy saving and long 4 pin compact lamps for 90 minutes.
- Page 2 INSTALLATION INSTRUCTIONS CAUTION: Before installing, make certain the A.C. power is off and the ICE-80 unit connector is disconnected. 1. LAMPS OPERATED The ICE-80 can be used with most 2′–8′ lamps. Refer to the chart below for the type of lamp(s) operated and the number of lamps to be operated in emergency mode.
- Page 3 C. When the ICE-80 is used with a switched fixture, the A.C. input to the ICE-80 must be connected ahead of the fixture switch. Refer to Illustration 3 for switched and unswitched fixture wiring diagrams.
- Page 4 BLACK BLUE BLUE ORG (277V) YELLOW BLUE/WHT UNSWITCHED BLACK (120V) UNSWITCHED BLACK BROWN WHITE BLUE BLUE/WHT RED/WHT A.C. A.C. EMERGENCY ICE-80 ➃ BLK/ORG BLK (120V) WHITE BROWN ICE-80 RED/WHT BALLAST EMERGENCY WHITE BLK/ORG ➃ BLU/WHT Ballast BLUE Ballast COMMON YELLOW...
