  • Page 1 O W N E R S M A N U A L...
  • Page 2 EXC LUS I VE U . S . D I S T R I B U T O R...

  • Page 3: General Information

    The following information is to inform you of how to operate your NOVA umbrella to ensure trouble free use and ease of operation. Please follow these instructions as they are designed to assist operation and prolong the life of the various parts.

  • Page 4: Simple Maintenance Procedures

    Periodic spraying of silicon spray in the winder hole will assist operation and prolong the life of the winder. • Fold acrylic canvas as mentioned in “CLOSING THE NOVA” (PAGE 6). This will prolong the new look of the canvas and prevent marking caused by “pinching” in the alloy frame.

  • Page 5: Fabric Care

    FABRIC CARE RECacril Marine Grade Acrylic Fabric Infinity Process is a highly technological finish, providing RECacril with a long lasting protection against mold and mildew, excellent water and oil repellency and protection from both sun and water. However, the accumulation of dust, pollution particles, foreign organic materials and general dirt can damage this protection, shortening the life of the RECacril, so they should be removed.
  • Page 6 Casual Care & Cleaning • Brush off dust and dirt with a soft brush. NEVER brush with stiff brushes since this can damage the fabric finish. • Spray the umbrella with clean water. If a hose is used, avoid high pressure.
  • Page 7 OPENING THE NOVA First Time Opening Ensure all packaging and wrapping material has been removed. There may be some wrapping material on the canopy arms underneath the fabric canopy partially open the umbrella and get in underneath the fabric canopy to remove all of this wrapping before fully opening the umbrella.
  • Page 8 CLOSING THE NOVA • Insert the winder handle and rotate in a counter-clockwise direction. • Before the ribs fully close against the mast, pull the canopy out from within the arms to safeguard any “pinching” of the fabric within the umbrella frame. This...

  • Page 9: Installation Procedure

    Make sure you have sufficient space when installing your NOVA Giant Center Post Umbrella. 18’ of space is needed to slide the NOVA onto the hinged spigot. After you slide your NOVA onto the spigot, it is advised 2 or more persons tilt the NOVA to its upright position.
  • Page 11 NOTE: When ready to install the NOVA on to the spigot, be sure to remember this is a 2-3 man operation. After the umbrella is on the spigot and upright, do not forget to install the closing screw on the spigot.
  • Page 12 IN-GROUND MOUNT FITTING GARDEN PLOT/SOIL spigot IN-GROUND MOUNT 27.5” 25.5” IN-GROUND MOUNT FITTINGS CONCRETE / LOOSE PAVERS SPIGOT IN-GROUND MOUNT 27.5” 15.7” | 10...
  • Page 13 3” of fastening in concrete is required. NOTE: When ready to install the NOVA on to the spigot, be sure to remember this is a 2-3 man operation. After the umbrella is on the spigot and upright, do not forget to install the closing screw on the spigot.
  • Page 14 COUNTER SUNK BOLTS 1/4” DECK PANELS DECK PLATE 2” THICK CROSS BEAMS DECK BEARERS CONCRETE 12.4” DIAMETER DECK PLATE M10 CONCRETE SCREW OR DYNA BOLT MINIMUM LENGTH 3” | 12...
  • Page 15 NOTE: When ready to install the NOVA on to the spigot, be sure to remember this is a 2-3 man operation. After the umbrella is on the spigot and upright, do not forget to install the closing screw on the spigot. This will keep the umbrella locked in an upright position.
  • Page 16 SPIGOT Bolts through to the aluminum lid to galvanized steel box frame 62.5” 5” 44” 44” 550lbs. GAVANIZED BASE Base stores (8) 50lb. pavers (400lbs.) in galvanized box frame. | 14...
  • Page 17 15 |...

  • Page 18: Warranty

    Replacement fabric canopy is covered for the time DATE OF PURCHASE OF THE FOLLOWING: remaining in the original warranty and does not Aurora Series, Eclipse Series, NOVA Series, Monaco activate a new 7 or 5 year warranty. Series, Greenwich Series, Monterey Collection, and Catalina Collection.
  • Page 20 Exclusive U.S. Distributor NORTH AMERICAN HEADQUARTERS FRANKFORD UMBRELLAS 110 GAITHER DR. MOUNT LAUREL NEW JERSEY, 08054 (856) 222 4134 www.frankfordumbrellas.com...
