Summary of Contents for Entrematic Ditec ION4
- Page 1 Ditec ION4-ION6 IP2288EN • 2019-04-10 Technical Manual Sliding gates (translation of the original instructions) www.entrematic.com...
-
Page 2: Table Of Contents
Contents Subject Page General safety precautions General safety precautions for the user Declaration of incorporation of partly completed machinery 2.1 Machinery Directive Technical specifications Standard installation Dimensions Main components Installation 7.1 Preliminary checks 7.2 Base plate position 7.3 Gearmotor installation 7.4 Rack installation 7.5 Operation with virtual encoder 7.6 Installation of optional accessories... -
Page 3: General Safety Precautions
Read the instructions carefully before installing the product. Bad installation could be dangerous. This manual and those for any accessories can be downloaded from www.entrematic.com. The packaging materials (plastic, polystyrene, etc.) should not be discarded in the environ- ment or left within reach of children, as they are a potential source of danger. -
Page 4: General Safety Precautions For The User
General safety precautions for the user These precautions are an integral and essential part of the product and must be supplied to the user. Read them carefully since they contain important information on safe installation, use and maintenance. These instructions must be kept and forwarded to all possible future users of the system. -
Page 5: Declaration Of Incorporation Of Partly Completed Machinery
- the technical documentation complies with Annex VII-B of the Directive 2006/42/EC; - the technical documentation is managed by the Technical Office of Entrematic Italy (with headquarters in Largo U. Boccioni 1 – 21040 Origgio (VA) – ITALY) and is available upon request, sending an e-mail to ditec@entrematic.com ;... -
Page 6: Technical Specifications
3. Technical specifications ION4 ION4J ION6 ION6J Maximum stroke Maximum gate weight 400Kg 600Kg Gate speed 0,1÷0,3 m/s Thrust 200N nominal, 600N start-up 300N nominal, 800N start-up Power supply 230 V~ 50/60Hz 120 V~ 50/60Hz 230 V~ 50/60Hz 120 V~ 50/60Hz Power absorption 0,45A 0,9A... -
Page 7: Standard Installation
4. Standard installation Rif. Description Cable Remote control Flashing light 2 x 1 mm² Antenna (integrated into the flashing light) coaxial 58 Ω Key selector switch 4 x 0,5mm² Digital combination wireless keypad Photocells 4 x 0,5 mm² Actuator ION with control panel 3G x 1,5 mm²... -
Page 8: Dimensions
5. Dimensions 6. Main components Rif. Descrizione Motor Control panel Key release Pinion Cable inlet Power supply terminal and fuse... -
Page 9: Installation
7. Installation The given operating and performance features can only be guaranteed with the use of DITEC ac- cessories and safety devices. Unless otherwise specified, all measurements are expressed in mm. 7.1 Preliminary checks Check the stability of the wing (derailing and lateral falls) and the sliding wheels and that the upper guides do not cause any friction. -
Page 10: Gearmotor Installation
7.3 Gearmotor installation -5 +20 Release the gearmotor [1] (see OPERATING INSTRUCTIONS). Loosen the front screw [2] and remove the casing by pressing on its sides [3-4]. Place the gearmotor on the base plate. Adjust the gearmotor horizontally by sliding it along the slots of the gearmotor base and vertically with four levelling screws [A]. -
Page 11: Rack Installation
7.4 Rack installation Release the gearmotor (see OPERATING INSTRUCTIONS) and open the gate. Place the rack against the pinion and sliding the gate manually fix it along its whole length. NB: To make it easier to align the rods correctly, use a scrap piece of rack and rest it underneath the junction point, as shown in the figure detail. -
Page 12: Operation With Virtual Encoder
7.5 Operation with virtual encoder ION4-ION6 gearmotors do not require limit switches because they have a virtual encoder. Mechanical opening and closing end stops must be installed. The gate automatically slows when approaching the end stops. WARNING: when the gate reaches the opening or closing limit stop, it reverses briefly to facilitate manual release of the gearmotor. -
Page 13: Electrical Connections
8. Electrical connections Before connecting the power supply, make sure the plate data correspond to that of the mains power supply. An omnipolar disconnection switch with a contact opening distance of at least 3mm must be fitted on the mains supply. Check there is an adequate residual current circuit breaker and overcurrent cutout upstream of the electrical system. -
Page 14: Lcu48 Card
9. LCU48 card Alimentazione Power supply 24V~ Microswitch Release di sblocco microswitch Finecorsa Limit switch NES100FCM NES100FCM... -
Page 15: Using Of The Menus
10. Using of the menus NB: pressure on the keys may be quick (less than 2 s) or prolonged (longer than 2 s). Unless specified otherwise, quick pressure is intended. To confirm the setting of a parameter, prolonged pressing is necessary. 10.1 Switching the display ON and OFF The procedure to switch on the display is as follows: •... -
Page 16: Menu Map
10.3 Menu map Opening direction RT= right Thrust adjustment on LF= left obstacles and closure current Automatic closure Contact 1-5 command enabling operation Automation status Automatic closure at switch-on Obstacle recognition enabling time adjustment Reversal safety Automatic clos- operation Start-up time ing time adjustment Activation of anti-... - Page 17 Selection of device con- Maximum number of Alarm reset nected to terminals 1-6 remote controls that can and 1-8 be stored in the integrated memory Motor current visu- alisation Display mode Menu navigation via remote control keypad Visualisation of maximum and minimum tempera- Partial opening com- tures recorded...
-
Page 18: Product Start-Up
11. Product start-up For rapid configuration of the product, use the WIZARD (WZ) menu or the second level AT (Auto- matic Configurations) menu [See par. 15.2]. For detailed, customised configuration, use the main menus BC, BA, RO, SF, CC, EM, AP. 11.1 WZ configuration wizard menu To access the WZ configuration wizard menu: Hold down the ENTER button for 2 seconds. - Page 19 VC - Selection of closing speed • LO: 15 cm/s • ME: 20 cm/s (default) • HI: 25 cm/s D6 - Selection of device connected to terminals 1-6 • NO: none • PH: photocells (default) For other options, see the specific menu. D8 - Selection of device connected to terminals 1-8 •...
-
Page 20: Commands
12. Commands You are advised to read paragraph 15 for all the details about the possible adjustments. WARNING: terminal 30 (common positive for commands) has the same functions as terminal 1, so the commands visualised on the display are indicated with 1-5, 1-3, etc. It is different from terminal 1, however, because of the maximum current that can be dispensed and it is also active when the control panel is in standby →... -
Page 21: Sofa1-Sofa2 Or Gopavrs Self-Controlled Safety Edge
12.1 SOFA1-SOFA2 or GOPAVRS self-controlled safety edge Command Function Description Insert the SOFA1-SOFA2 or GOPAVRS device in the slot SOFA1-SOFA2 for plug-in boards AUX1 or AUX2. GOPAV SAFETY TEST If the test fails, an alarm message appears on the display. When selecting →... -
Page 22: Jumper Setting
Value of Output Description accessories The control panel is fitted with a housing for modules of the 6ZENRS radio receiver type (433.92 MHz). Can be replaced with a module of the ZENPRS radio receiver type (868.35 6ZENRS MHz). ZENPRS When using slot-in radio boards, remove the RDX module. The display will show WARNING: the modules must be inserted and removed with the power supply disconnected. -
Page 23: Adjustments
15. Adjustments NB: depending on the type of automation and control panel, some menus may not be available. 15.1 Main menu Display Description WZ - Wizard Quick configuration menu AT - Automatic Configurations. The menu allows you to manage the automatic configurations of the control panel. BC - Basic Configurations. -
Page 24: Second Level Menu - At (Automatic Configurations)
15.2 Second level menu - AT (Automatic Configurations) Selections Display Description available DM - Direction mode RT-opens to the right LF-open to the left H0 - Predefined setting, residential use 0 This selection loads predefined values for certain standard parameters: AC - enabling of automatic closing : 1-2 C5 - step-by-step/opening command operation... -
Page 25: Second Level Menu - Bc (Basic Configurations)
15.3 Second level menu - BC (Basic Configurations) Selections Display Description available AC - Enabling of automatic closure ON - Enabled 1-2 - Dependent on input 1-2 SS - Selection of automation status at start OP - Open CL - Closed Indicates how the control panel considers the automation at the time of switch-on, or after a POWER RESET command. -
Page 26: Additional Bc Level Parameters That Can Be Configured (Available With At → Aa Enabled)
15.3.1 Additional BC level parameters that can be configured (available with → enabled) Selections Display Description available HR - Enabling of "operator present" function ON - Enabled OF - Disabled → → NB: Set → only if WARNING: • If the OPERATOR PRESENT function is activated, make sure that no- one is near the automation when an opening or closing command is given. -
Page 27: Second Level Menu - Ba (Basic Adjustment)
15.4 Second level menu - BA (Basic Adjustment) Selections Display Description available TC - Setting of automatic closing time [s] It is set with different intervals of sensitivity. • from 0” to 59” with intervals of 1 second • from 1’ to 2’ with intervals of 10 seconds 1’00”... -
Page 28: Additional Ba Level Parameters That Can Be Configured (Available With At → Aa Enabled)
Selections Display Description available R2 - Adjustment of thrust on obstacles and motor current during closure. [%] The control panel is fitted with a safety device which, when it detects an obstacle: - reverses the movement during closure operations outside the limit area for detecting obstacles;... - Page 29 Selections Display Description available OB - Adjustment of deceleration distance during closing. [cm] Indicates the distance from the end of the closure stroke for the start of the deceleration ramp. 05 - Minimum 99 - Maximum PO - Adjustment of approach speed during opening [cm/s] Indicates the speed from the end of the deceleration ramp to the end of the opening stroke 03 - Minimum...
-
Page 30: Second Level Menu - Ro (Radio Operations)
15.5 Second level menu - RO (Radio Operations) Display Description SR - Remote control storage You can directly access the Remote control storage menu even with the display turned off, but only with the Display visualisation mode option set to 00 or 03: - for transmitting a remote control not present in the memory;... -
Page 31: Additional Ro Level Parameters That Can Be Configured (Available With At → Aa Enabled)
Selections Display Description available RK - Menu navigation using remote control keyboard ON - Enabled OF - Disabled 3 3 2 4 With the display turned off, quickly type in the sequence of keys from the stored remote control you want to use. Make sure all the CH keys are stored. -
Page 32: Second Level Menu - Sf (Special Functions)
Selections Display Description available ER - Deletion of a single remote control → → 2” EA - Total memory deletion → → → 2” 2” RE - Setting memory opening from remote control OF - Disabled ON - Enabled When enabled (ON), the remote programming is activated. To store new remote controls without using the control panel, refer to the remote control instructions. -
Page 33: Additional Sf Level Parameters That Can Be Configured (Available With At → Aa Enabled)
Display Description RL - Loading of last configuration set → → 2” The control panel automatically saves the last configuration set, and keeps it memorised in the storage module. In the event of a fault or the replacement of the control panel, the last configuration of the auto- mation can be restored by inserting the storage module and loading the last configuration set. -
Page 34: Second Level Menu - Cc (Cycle Counter)
Display Description AR - Alarm reset Resets all the alarms in the memory (counters and log). → 2” NB: when the installation has been completed, you are advised to delete the alarms in order to facilitate future checks. IM - Motor current visualisation TT - Display min / max temperatures recorded - by pressing for 2 seconds the values are reset - minimum value with active right point... -
Page 35: Additional Cc Level Parameters That Can Be Configured (Available With At → Aa Enabled)
15.7.1 Additional CC level parameters that can be configured (available with → enabled) Display Description Selections available CA - Setting the maintenance alarm (factory setting - alarm deactivated: 0.0 00. 00). You can set the required number of operations (regarding the partial operations counter) for signalling the maintenance alarm. -
Page 36: Additional Em Level Parameters That Can Be Configured (Available With At → Aa Enabled)
Display Description Selections available LB - Indication that batteries are almost flat 00 - Visualisation on display (alarm message 01 - Visualisation on flashing light (with the automation idle, 2 flashes are made and then repeated every hour) and on display (alarm message 02 - Visualisation on "open gate"... - Page 37 Selections Display Description available D6 - Selection of device connected to terminals 1-6 NO - None PH - Photocells P41 - Photocells with safety test SE - Safety edge (if contact 1-6 opens, there is a disengagement of 10cm after the stop) S41 - Safety edge with safety test (if contact 1-6 opens, after the stop there is a disengagement of a duration depending on the selection →...
-
Page 38: Additional Ap Level Parameters That Can Be Configured (Available With At → Aa Enabled)
15.9.1 Additional AP level parameters that can be configured (available with → enabled) Selections Display Description available 20 - Partial opening command of terminal 1-20 P3 - Partial opening command 1-2 - Enabling of automatic closure 1-9 - Stop input LU - Setting the courtesy light switch-on time (s) To enable the parameter, set the selection →... - Page 39 Selections Display Description available DC - Setting of disengagement on stop during closure [mm] Regulates the distance of the disengagement on the mechanical open- ing stop. 00 - Disabled 99 - Maximum NB: not active if → OT - Selection of type of obstacle identification 00 - Overcurrent or gate stopped 01 - Overcurrent 02 - Door stopped...
-
Page 40: Signals Visualised On The Display
Selections Display Description available TB - Permanent display of the internal control panel temperature [°C] WO - Setting of pre-flashing time on opening [s] Adjustment of the lead time for the switch-on of the flashing light, in relation to the start of the opening operation from a voluntary command. - Page 41 Automation stopped in intermediate position Automation stopped in intermediate position Release door open Automation closing Automation that slows down during closing. Automation opening Automation that slows down during opening. Display Description Automation closed Automation closed Release door open Automation open Automation open Release door open Automation stopped in intermediate position Automation stopped in intermediate position Release door open...
-
Page 42: Display Of Safety Devices And Commands
16.2 Display of safety devices and commands NB: the safety device and command display mode is only visible with Display visualisation mode set at 01 or 03. Display Description Display Description 1-2 - Automatic closing activation com- 68 - Selection of the device simultane- mand ously connected to terminals 1-6 and 1-8 1-3 - Opening command... -
Page 43: Display Of Alarms And Faults
16.3 Visualisation of alarms and faults WARNING: the visualisation of alarms and faults is possible with any visualisation selection. The signalling of alarm messages takes priority over all other displays. Type of Display Description Operation alarm Check the mechanical parts. M3 - Automation blocked Check connection of motor. - Page 44 Type of Display Description Operation alarm V0 - Request for maintenance intervention Proceed with the scheduled maintenance intervention. Check there is no short circuit in connec- I5 - No voltage 0-1 (faulty voltage regulator tion 0-1. or short-circuit on accessories) If the problem persists, replace the control panel.
- Page 45 Type of Display Description Operation alarm To save the system configurations on the R0 - Insertion of a storage module contain- storage module, delete any stored remote ing over 100 stored remote controls controls and bring the total to less than Warning: the →...
-
Page 46: Troubleshooting
17. Troubleshooting Problem Possible cause Alarm Operation signalling The control panel No power supply. Check the power supply cable and the does not switch on relative wiring automation No power. Check power supply cable. does not open or close. Short circuited accessories Disconnect all accessories from termi- nals 0-1 (a voltage of 24V= must be pre- sent) and reconnect them one at a time. - Page 47 Problem Possible cause Alarm Operation signalling The remote control The radio transmission is im- Install the antenna outside. has limited range peded by metal structures and and does not work reinforced concrete walls. Replace the transmitter batteries. with auto- mation moving.
- Page 48 All the rights concerning this material are the exclusive property of Entrematic Group AB. Although the contents of this publication have been drawn up with the greatest care, Entrematic Group AB cannot be held responsible in any way for any damage caused by mistakes or omissions in this publication.
