Summary of Contents for CAT Pumps DUPM623
- Page 1 Wash Prep Systems featuring CAT PUMPS® DUPM623 DUPM820 / DUPM820-TS DUPM820D / DUPM820D-TS DUPM1010 Owner’s Manual #0779 072415 Serial Number: Installation Date:...
-
Page 2: Table Of Contents
IMPORTANT P l e a s e r e a d a n d u n d e r s t a n d t h i s m a n u a l . S t o r e i n s a f e l oc a t i on f or f u t u r e r e f e r e n c e . -
Page 3: Safety Information | 1
Safety Information | 1 To avoid serious or fatal personal injury or major property damage, read and follow all safety and operation instructions in the manual. This is a Safety Alert Symbol - When you see this symbol in the manual, look for the following signal words & be alert to the potential for personal injury or property damage. -
Page 4: Specifications
6 GPM ............1200 Maximum Inlet Pressure ......40 PSI Maximum Inlet Temperature ....130° F *See Included CAT PUMPS® Service Manual for Higher Temperatures CE131464 5 HP, 3 PH Motor ............Volts: 208 - 230 Amps: 13.7 - 12.6 Pump ............ -
Page 5: Specifications
............CEEM3710T Amps: 18.8 Maximum Inlet Pressure ......40 PSI Maximum Inlet Temperature ....130° F See Included CAT PUMPS® Service Manual for Higher Temperatures Crankcase Capacity ........40 oz. Pump Drive ..........Belt Pump Inlet ..........1” Pump Discharge ........ -
Page 6: Installation
Installation & Operating Instructions | 4 Installation 1. Select a location for your new unit. Place near floor drain, and electrical and water sources. Floor Motor Wiring Box surface must be level. Start Stop 2. Electrician to run power from main supply panel Station to motor starter or stop start station, and then to motor wiring box. -
Page 7: Operation
Installation & Operating Instructions | 5 Operation 1. Check pump for proper oil level. The pump should be filled to or slightly above the red dot on the bubble gauge, located on the back of the pump. (Fig. 3) 2. Turn on water to the system and allow air to purge. -
Page 8: Maintenance & Storage
When running antifreeze through system, open and close trigger gun so entire system is protected. Please refer to the included CAT PUMPS® reference materials for additional information on the Maintenance & Storage of your CAT PUMPS® Pressure Washer. -
Page 9: Parts Breakdown | 7
Parts Breakdown | 7 Parts Breakdown: Model DUPM623 IMPORTANT Pump Rotation: Pump was designed for forward rotation to allow optimum lubrication of the crosshead area. Reverse rotation is acceptable if the crankcase oil level is increased slightly above center dot to assure adequate lubrication. - Page 10 Parts Breakdown | 8 Parts Breakdown: Model DUPM820, DUPM820D IMPORTANT Pump Rotation: Pump was designed for forward rotation to allow optimum lubrication of the crosshead area. Reverse rotation is acceptable if the crankcase oil level is increased slightly above center dot to assure adequate lubrication.
-
Page 11: Parts Breakdown
Parts Breakdown | 9 Parts Breakdown: Model DUPM820-TS, DUPM820D-TS Item Part Number Description ..CC820 ..... Cat Piston Pump ..GU22531A ....Safety Pop Off Valve ..AH2750-3 ....2300# Liquid Filled Pressure Gauge ..GABX47 ....V-Belt, 47” (2 qty. - Not Visible) .. -
Page 12: Warranty Information | 10
Warranty Information | 10 Notice Regarding Manufacturer’s Limited Warranty Dultmeier Sales Limited Liability Company (hereinafter Dultmeier), notifies you that component part(s) carry a manufacturer’s limited warranty provided by the manufacturer of said component part(s). These warranties do not pertain to normal wear of component part(s) that may occur within any specified period. -
Page 13: Checklist | 11
Checklist | 11 Production Checklist Oil Level Pop-Off Valve Set Clamps Tight Unloader Valve Locked Bolts Tight & Anti-Seized Belts Tight Pump RPM Pulleys Aligned & Torqued to Specifications Motor Amps Fittings Straight Motor Wired For Tested Accessories Winterized Safety Pop Off Valve Trigger Gun High Pressure Hose Injector / Injector Hose...
