1
Assemble pieces of Bow 1 by
attaching both Bow 1 sides to
Rear Label
3
Lay bimini fabric face down on
a flat clean surface (label on rear
sleeve will be facing up)
y
2-Bow Aluminum Bimini Assembly Instructions
Line up 2 holes on both sides
and install screws.
. . . and inserting 5/8" screws as
2
shown.
Repeat steps 1 and 2 for remaining bow.
4
Position Bow 1 as shown with
jaw slides facing up. Thread Bow 1
through rear sleeve and bow strap
loops.
Bow Pieces
Bow 1
Bow 2
Bow Center
Hardware Kit
S trap eyes
#8 5/8" screw
(4)
(24)
Swivel mount
Washer (4)
(2)
Strap Kit
Hold down
strap (4)
Tools Required
*Phillips and Flat Head Screwdrivers
Position Bow 2 as shown with holes
5
facing up. Thread Bow 2 through front
sleeve of fabric.
Package Contents
Important!
Each bow part is labeled
(2)
with the bow number -1,
-2, etc. Organize bow
(2)
pieces by grouping together
all -1s, all -2s, etc.
(2)
If your bimini is missing
any of these parts,
please contact the
retailer or dealer from
whom you purchased
the bimini before
proceeding with the
installation.
*Drill and 9/64" Drill Bit
