Mic 98610 Operation Manual

Thermo-hygro anemometer
Hide thumbs
1
2
3
4

Advertisement

Quick Links

Download this manual
Thermo-Hygro Anemometer
FEATURES
Contacted temperature measurement.
Relative humidity/Web Bub/Dew Point (98620/98621)
Heat Index/WBGT(98621 only)
Data hold/Maximum/Average functions.
Auto power off function(15 minutes).
Quick response and high accuracy
Low battery indication
MATERIAL SUPPLIED
Meter
Battery(CR2032 battery included)
Operation manual
Box
OPERATIONMANUAL
98610/98620/98621

Advertisement

loading
Need help?

Need help?

Do you have a question about the 98610 and is the answer not in the manual?

Questions and answers

Related Manuals for Mic 98610

Summary of Contents for Mic 98610

  • Page 1 OPERATIONMANUAL Thermo-Hygro Anemometer 98610/98620/98621 FEATURES Contacted temperature measurement. Relative humidity/Web Bub/Dew Point (98620/98621) Heat Index/WBGT(98621 only) Data hold/Maximum/Average functions. Auto power off function(15 minutes). Quick response and high accuracy Low battery indication MATERIAL SUPPLIED Meter Battery(CR2032 battery included) Operation manual...

  • Page 2: Lcd Display

    WNCL BFT FPM/H KMH m/s KNT KEY FUNCTION POWER: Max/Min/Average(5s’10s’13s’) HOLD: Data hold mode/wind speed unit/Temp. unit MODE: WNCL/Temp.(98610)/RH/DP/WB(98620/98621) HI/WBGT(98621 only) OPERATION (1)Power On/Off With meter off, short press POWER to turn on the meter. To turn the meter off, long press POWER to turn off.

  • Page 3: Trouble Shooting

    (3)Data Hold Press HOLD button to freeze the displayed reading. The ‘HOLD’ icon and the held reading will appear on the display. Press the HOLD button again, the meter will return to the normal measurement. HOLD ( 4)Auto Power OFF The meter will shut off automatically after approximately 15 minutes, if no action is taken.

  • Page 4: Battery Replacement

    SPECIFICATION Spec./Model no. 98610 98620 98621 -15.0~50.0°C(5~122°F) Temp. range Resolution 0.1°C ±1ºC Accuracy 0.4~25m/s,80~4920ftm Air Velocity range ±3%of FS Accuracy m/s,ftm,kmh,mph,knot,BFT Wind Unit 5.0~95.0% RH% range 0.1% Resolution ±3%RH(at25ºC Accuracy 10~90%),others 5% Dew point/Web bulb/ Windchill Heat index/WBGT HOLD MAX/MIN/AVG...

This manual is also suitable for:

9862098621
