Summary of Contents for BiCom Simeon Sprek T
- Page 1 Model No.: SIMEON SPREK T Sprek Digital Wireless Speaker & Microphone...
-
Page 2: Table Of Contents
Table of Contents Must Read Before Use ------------------------------------------------------ 2 Certification ------------------------------------------------------------------ 2 General Information --------------------------------------------------------- 3 Introduction ------------------------------------------------------------------ 3 Product Components (Accessories) ----------------------------------------- 3 Product Overview Speaker ---------------------------------------------------------------- 5 Microphone ------------------------------------------------------------ 6 Speaker ON / OFF ----------------------------------------------------------- 6 Microphone ON / OFF ------------------------------------------------------ 7 Battery Level ----------------------------------------------------------------- 8... -
Page 3: Must Read Before Use
* If you leave Sprek inside a closed car for long time, it could result in deformation, malfunction or product damage. * Please use only Bicom’s charger or cable when using or charging Sprek. If you use a third party’s charger or cable, it could result in explosion, burning or product damage. -
Page 4: General Information
Input and o * Use only the Bicom-provided charger and cable for charging. * You can connect the Bicom-provided microphone to ‘AUX IN’ for use. utput Termi * If you connect a third party audio product to AUX IN‘, check if it works normally. -
Page 5: Introduction
Introduction Sprek is a wireless speaker & microphone. Sprek is designed to amplify your voice so crowd can hear your voice clearly from distance. Sprek works the best as a teacher’s portable amplifier. Also, using 900MHz which is usually not overcrowded, Sprek has no risk of 2.4GHz interference. It offers remarkably good sound performance with a compact and light body. - Page 6 Image Main Device Power / Battery Level Power On.Off / Volume Level Shoulder Strap Pairing Button AUX/Wired MIC Terminal Charging Terminal RESET Button How to Use Shoulder Strap -05-...
- Page 7 Wireless Microphone Strap Hanger Input Terminal Status Display Power Channel Up Volume Up Boom MIC Channel Down Volume Down Charging Terminal I How to Use Boom MIC I Insert the Boom MIC into the termi Insert a head-microphone into the terminal -06-...
-
Page 8: Speaker On / Off
Speaker Power ON / OFF Turn as shown below until you hear sound Power on Power off - Power is on if you turn the switch to the "+" direction - Power is off if you turn the switch to the "-" direction ※... -
Page 9: Microphone On / Off
Microphone ON / OFF Microphone is turned on, if you press & hold the power button for two seconds. Microphone is turned off, if you press & hold the power button for two seconds again. 2Sec -08-... -
Page 10: Battery Level
Remaining Battery Level Battery LED below indicates the current remaining battery level. When battery is running low, battery low audio comes out apart from the battery LED. Recharge the battery when battery is running low. LED blinks three times with 80% of battery LED On LED blinks twice with 50% of battery LED blinks one time with 20% of battery... - Page 11 Volume I How to Set Volume I Volume Up Volume Down Total Volume = Speaker Volume x MIC Volume I Microphone Volume I How to Set Volume from Microphone Mute on / off 0.5 Sec Volume Up or Down 0.5 Sec -10-...
-
Page 12: Microphone Number Setting (For Using Two Mics)
Microphone Number Setting [ for Two MICs ] There is no need to do microphone number setting when using one microphone. However, to use two wireless microphones, each microphone needs to be given its own number t o prevent interference with one another. I Set the second microphone to number 2 for two microphone use I Set to number 2 by pressing c hannel up button short. - Page 13 Pairing between Speaker and Microphone [ for two MICs ] For two microphone transmission, two microphones need to be paired with a speaker. Go to Microphone Pairing Mode 2 Sec Together You can go to pairing mode by pressing & hold power button for 10 seconds as well.
- Page 14 Go to Speaker Pairing Mode Turn on the speaker while pressing&hold pairing button. Press&hold the pairing button until the sound of “Pairing” comes out. Power On Once pairing is done, the red LED below is slowly turned off. -16-...
-
Page 15: Channel Setting
Channel Setting You can change channel number between 0 and 9 to avoid frequency interference. When using two microphones, you need to set them to same channel number. I Microphone Channel Setting I 2 Sec Go to Channel setting mode 0.5 Sec Choose between 0 and 9 2 Sec... - Page 16 Reset (in case the speaker is unresponsive or malfunctions) * Press “RESET” button when power is on. Then speaker re-boots. “RESET” button stays inside so use something sharp to press it. -18-...
- Page 17 Microphone Reset Press Channel down and Volume Up together 0.5 Sec Together Press&hold “Power” button for two seconds. 2 Sec ※ Note Be careful not to press Channel down and Volume up t ogether when a microphone works normally. -19-...
-
Page 18: How To Charge
How to Charge Speaker and MIC Together Speaker: Battery LED turns orange while being charged and turns green once charging is complete. Microphone : Blue and red appears together while being charged and turns blue once charging is comp Charging Charged Charging Charged... -
Page 19: Specification
Specifications Frequency 902 MHz~928 MHz Transmission Method TDMA Modulation System Battery Rechargeable Li-ion 3.7V /3,400mAh Battery for Speaker Rechargeable Li-ion 3.7V / 650mAh Battery for Microphone Battery Life Time 24 hours for speaker at stand-by or 10 hours at constant use 9 hours for microphone at constant use Charging Time 6 Hours for Speaker / 2 hours for microphone... -
Page 20: Warranty
Product Warranty Thank you for purchasing our product. Simeon Sprek Product Name Transmitter : Simeon Sprek T Model Name Speaker : Simeon Sprek R Serial Number Warranty Period 2 Year Purchase Date Make sure you fill in all the blanks. This product has passed the strict quality test and in case of b reakdown, the warranty will cover product repair as stated in the Product Warranty. - Page 21 www.ez-tok.com...
