PHX-150
Dry Ice Cleaning System
U S E R ' S G U I D E
30295-UG-040517

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PHX-150 and is the answer not in the manual?

Questions and answers

Related Manuals for Phoenix PHX-150

Summary of Contents for Phoenix PHX-150

  • Page 1 PHX-150 Dry Ice Cleaning System U S E R ’ S G U I D E 30295-UG-040517...

  • Page 2: Table Of Contents

    SYSTEM I.D. …………………………………………………… Page 3 EQUIPMENT WARRANTY…………………………………… Page 4 INTRODUCTION ……………………………………………… Page 5 SAFETY PRECAUTIONS AND WARNINGS……….……… Page 6, 7 KEY COMPONENT I.D. ………..………………………..…… Page 8 CONTROL PANEL/WARNING LABEL ….………………… Page 9 OPERATION INSTRUCTIONS Connecting the Air Supply ………………………..…………. Page 10 Connecting the Blast Gun …………………………...………..

  • Page 3: System I.d

    It may not be duplicated or disclosed to other parties. Inspected By: __________________________ Date: __________________________ ©2017 Phoenix Unlimited LLC. All rights reserved. Federal law provides severe civil and criminal penalties for the unauthorized reproduction or distribution of copyrighted material.

  • Page 4: Equipment Warranty

    2000 hours of operation from the date of shipment, whichever occurs first. Upon written request, Phoenix Unlimited shall, at its option, correct any nonconformity by suitable repair to such Equipment, or furnish a replacement part F.O.B. point of shipment,...

  • Page 5: Introduction

    Once you are comfortable with the information provided, you will be ready to say goodbye to old-fashioned methods of cleaning and begin using your new dry ice blaster. With proper equipment care, you will soon see that the PHX-150 is one tool you cannot be without.

  • Page 6: Safety Precautions And Warnings

    Your unit is equipped with an Arm/Disarm switch located in the center of the control panel. Under normal use, this switch acts as a convenient way to quickly interrupt power to your PHX-150. However, the true designated E-STOP is the full-flow valve (bright yellow with a red handle) located on the air system manifold under the control panel.
  • Page 7 Ergonomics The training process for using your new PHX-150 is relatively easy, but there will still be a “learning curve” where technique and experience is concerned. The operator should understand that high velocity air exits the gun barrel. Upon triggering the gun, the operator will experience a small reactive thrust, which increases or decreases depending on pressure settings and air flow.

  • Page 8: Key Component I.d

    KEY COMPONENT IDENTIFICATION Control Panel Lubricator E-Stop Valve Separator/Regulator Ratchet Motor Auger Drive/Chain Guard Air Supply Inlet Airlock Assembly Vibrator Assembly Page 8...

  • Page 9: Control Panel/Warning Label

    CONTROL PANEL/WARNING LABEL Read User's Guide Information Ice Rate Gauge Asphyxiation Hazard Ice Rate Regulator Wear Proper Protective Gear Arm/Disarm Switch High Velocity Particles Pressure Indicator Burn Hazard Blast Air Regulator Static Discharge Blast Air Gauge Equipment I.D. Tag Page 9...

  • Page 10: Operation Instructions

    Familiarize yourself with its’ contents before operating this equipment. CONNECTING THE AIR SUPPLY Since the PHX-150 is an “all pneumatic” design, it is critical that only clean, dry air be supplied to the unit. Air containing excess amounts of moisture, oil, rust, or other contaminants may clog filters and damage the logic control and internal components.

  • Page 11: Connecting The Blast Gun

    (pics 3, 4, 5) 4. Using the 1½” wrench, connect the remaining end of the blast hose to the front of the PHX-150. (pic 6) 5. Connect the two trigger lines to the unit, pushing firmly until seated. Failure to attach trigger lines will result in the non-functioning of the unit.

  • Page 12: Loading Dry Ice

    LOADING DRY ICE 1. Before you begin loading dry ice, it is important that you have the protective gear previously mentioned in the “Safety Precautions and Warnings” section (page 6). This includes basic items such as earplugs or muffs (or both), eye protection, face shield, heavy-duty gloves, long sleeves, long pants, and safety shoes.

  • Page 13: Setting The Panel Controls

    Applying Air to the Unit 1. Slowly open the main air supply valve (source). (pic1) 2. With the gun pointed in a safe direction, slowly open the E-Stop valve on the PHX-150. (pic 2) Pic 1 Pic 2 Setting the Panel Controls 1.

  • Page 14: Setting The Panel Controls

    4. Next set the blast pressure. Pull the ‘blast pressure’ knob outwards to unlock it. (pic 4) 5. Turn the knob clockwise until desired pressure is reached. The PHX-150 has a blast pressure range from 45 psi to 125 psi. Satisfactory results are generally achieved in the 80-100 psi range for most applications.

  • Page 15: Temporary Shutdown

    TEMPORARY SHUTDOWN 1. When blasting is complete, release the trigger and wait for airflow to stop. (There is a short delay while residual ice is purged from the blast hose. Keep gun pointed at the target until air stops flowing!) (pic 1) 2.

  • Page 16: Overnight / Long Term Shutdown

    OVERNIGHT / LONG TERM SHUTDOWN 1. If you won’t be blasting again soon, release the trigger and wait for airflow to stop. (There is a short delay while residual ice is purged from the blast hose. Keep gun pointed at the target until air stops flowing!) (pic 1) 2.

  • Page 17: Maintenance

    MAINTENANCE CAUTION! Do not attempt to perform any maintenance or service on your PHX-150 unless safety guidelines and lock out/tag out procedures have been satisfactorily met! DAILY PREVENTIVE MAINTENANCE Before starting the machine each day/shift, a quick preventive maintenance inspection should be performed to ensure that your unit operates problem-free now and in the future.

  • Page 18: Emptying The Separator

    To perform this: 1. Locate the filter housing on inner leg of the PHX-150 near the trigger connectors. (pic1) 2. Disconnect the tubing from filter housing push fittings (both ends), then remove filter housing from unit.

  • Page 19: Changing / Adding 10W Oil

    Changing / Adding 10W Oil 1. Turn the lubricator retaining ring counter-clockwise by hand, then lower the bowl/housing away from suction wick. (pic 1) 2. Add 10W tool oil (or equivalent) until level with fill line. (pic 2) 3. Be sure that the O-ring is properly seated in the top of the lubricator bowl. (pic 3) 4.
  • Page 20 Checking / Adjusting the Drive Chain Tension (cont.) 7. Use a 7/16” box wrench to loosen the adjustment screw retaining nut by turning counter-clockwise. (pic 7) 8. Hold the retaining nut in position and use a 3/16” hex key wrench to adjust the screw (clockwise to increase tension, counter-clockwise to relieve) until proper tension is achieved.

  • Page 21: Periodic Maintenance

    In order to properly inspect or replace the critical components, the airlock assembly must be removed from the unit. To do this: 1. Remove air supply hose from the PHX-150. Also remove the gun and blast hose assembly if attached. (pic 1) 2.
  • Page 22 STEPS 1-10 Pic 11 12. Reinstall airlock assembly onto the PHX-150 by reversing steps 1-10. (text box) Airlock Motor / Spline: 13. While the housing is disassembled, inspect the motor and spline. If replacement is necessary, the motor will need to be removed from the housing. (pic 12) 14.
  • Page 23 21. Carefully install the pads into the airlock housing. Fully installed, they will be flush with the housing walls, with no part of the O-rings showing. (pic 19) 22. Reinstall airlock assembly onto the PHX-150 by reversing steps 1-11. (text box) Pic 15...
  • Page 24 Lubrication- Planetary gears, ball and needle bearings and seal ring should be lubricated with grease in conjunction with the regular overhaul of the motor. Molykote BR2 Plus gives long intervals between lubrications. Contact Phoenix Unlimited LLC or a qualified service center for motor overhaul options.
  • Page 25 6. 50114-158 ELBOW 7. 50004-002 ELBOW 8. 50053-001 VALVE 9. 50015-002 CONNECTOR 10. 50002-F04 PLUG 11. 50057-628 ELBOW FOLLOWING ITEMS NOT SHOWN 12. 10020-P12 BOLT (2) 13. 10018-005 LOCKWASHER (2) PHOENIX UNLIMITED LLC 30275-002A AIRLOCK MOTOR ASSEMBLY COMPLETE Page 25...

  • Page 26: Troubleshooting Chart

    TROUBLESHOOTING Symptom Item Check Corrective Measure The PHX-150 will Air supply valve is not opened. Open the air supply valve (E-Stop valve). not start. The unit is not armed (indicator will be Turn Arm/Disarm switch clockwise (indicator should red). turn green).
  • Page 27 TROUBLESHOOTING (cont.) “ ” “ ” “ “ ” ” ” ” ” ” ” ” ” ” * Page 27...

  • Page 28: Drawing Reference

    PHX-150 DRAWING REFERENCE 30089-001 30100-KIT POKER HOPPER LID KIT ASSEMBLY 30029-001 20011-K35 CONTROL PANEL BUMPER 30016-001 PHX-150 CONTROL SHELF ICE RATE BLAST AIR (BEHIND PANEL) PHOENIX DRY ICE CLEANING SYSTEM UNLIMITED LLC www.phoenixunlimitedllc.com 30060-001 FILTER/REGULATOR 30024-001 AIR SYSTEM 30031-001 30049-001...

  • Page 29: Control Panel Assembly

    GAUGE, BLAST AIR PILOT, 160 PSI 50051-001 REGULATOR, BLAST AIR PILOT 50025-060 GAUGE, ICE RATE, 60 PSI 50069-001 NUT, REGULATOR 30032-001A REGULATOR, ICE RATE 50109-005 SELECTOR, ARM/DISARM 30030-001B CONTROL PANEL, PHX-150 _-001 Part No. Description Item No. 30029-001D PARTS LIST * Page 29...

  • Page 30: Control Shelf Assembly

    23,24,27 SHOWN 4 REQ (30025-SHELFA) NOTES: A. REMOVE RESET JUMPER ON LCD TIMER CONNECT WIRES TO LCD TIMER START TERMINALS B. BE SURE PNEUMATIC TIMER IS SET TO 10 C. TIGHTEN SPEED CONTROLLER UNTIL WASHER IS SLIGHTLY COMPRESSED D. SET LUBRICATOR ADJUSTMENT TO ITS MIDPOINT 30291-004 REGULATOR ASSY 30288-001...
  • Page 31 50057-628 ELBOW 30291-004 AIRLOCK/VIBE/PURGE 50044-001 REGULATOR ASSY REGULATOR PHX-150 50059-002 50053-001 MUFFLER POPPET VALVE 50016-002 ELBOW 50056-628 CONNECTOR 50002-Z04 PIPE PLUG 50060-131 NIPPLE PHOENIX UNLIMITED LLC 50063-003 VIBRATOR ASSY VIBRATOR 30028-001 DRAWN BY: SAS 2/13/04 CHECKED BY: * Page 31...

  • Page 32: Air System Assembly

    Page 32...

  • Page 33: Filter/Regulator Assembly

    30060-001 FILTER/REGULATOR SERVICE INSTRUCTIONS 30061-001 BONNET PISTON UPPER 10031-001   PISTON SEAL LOWER PISTON SEAL MOUNTING SCREWS (4) TORQUE TO 13-18 INCH POUNDS 30062-001  FLANGE SLEEVE BE SURE THAT ALIGNMENT NOTCH AROUND SCREW HOLE IS PROPERLY ALIGNED POPPET ...
  • Page 34 Page 34...

  • Page 35: Airlock Assembly

    * Page 35...

  • Page 36: Auger Section

    AUGER SECTION 2 REQ 2 REQ ITEM DESCRIPTION 20004-005 Bearing,Auger Output 30004-001 Auger,PHX 10012-029 Standoff/Bearing Retainer 10007-I06 Screw,1/4 x 3/8 10019-013 Flatwasher,1/4" 10018-004 Lock washer, 1/4" 30035-001 Sprocket,Auger 30090-001 Key,Auger 10032-812 Screw,Bearing Retainer 10006-240 Set Screw,Sprocket 30005-001 Bearing,Auger Input 10019-017 Flatwasher,1/2"...

  • Page 37: Gun Assembly

    GUN ASSEMBLY 20 16 22 23 6 REQ 3 REQ SECTION A-B 2 REQ SECTION A-A * Page 37...
  • Page 38 GUN ASSY PARTS LIST 30083-001D ITEM LIST ITEM DESCRIPTION 30091-001 THERMAL BREAK/ GASKET 50065-001 UNION, 5/32" TUBE 50065-003 UNION, 1/4" TUBE 10020-G12 SCREW, SOCKET HEAD, 6-32 X 3/4" LONG, SS 30057-001B HANDLE, GUN 50022-2BK 18" TUBING, POLYURETHANE, 5/32", BLACK 50070-4BK 18"...
  • Page 39 * Page 39...
  • Page 40 #37 FROM REG-4 INLET TEE #12 FROM F-1 #32 FROM AUGER DRIVE #36 TO PV-3 #26 FROM RED 4WAY ELBOW #25 TO INLET BARB ON V-2 #21 FROM LOGIC 5A #14 FROM BLACK TEE MANIFOLD #20 TO LOGIC 5a #3 TO LOGIC 1a #8 FROM REG-4 Y FITTING Page 40...
  • Page 41 #11 FROM REG-3 CONTROL AIR REGULATOR #17 TO PV-1 AIRLOCK MOTOR CONTROL VALVE PILOT #30 FROM F-3 TRIGGER FILTER #5 TO REG-2 PILOT PORT #39 TO AIRLOCK/VIBE TEE AIRLOCK SPEED/ VIBE STRENGTH/ PURGE PRESSURE REGULATOR #37 TO REG-5 ICE RATE REGULATOR #38 FROM REG-2 FILTERED PORT #40 TO TRIGGER SUPPLY...
  • Page 42 CONTROL PANEL CONTROL SHELF REG-2 REG-3 HOPPER VIBRATOR AT-2 PV-2 VB-1 PV-1 PV-3 TRIGGER SUPPLY TRIGGER RETURN AIRLOCK AUGER DRIVE Page 42...

  • Page 43: Tube Diagram / Factory Settings

    FACTORY SETTINGS There are two factory set and locked regulators on the PHX. Problems can stem from these regulators being out of adjustment. There is also a speed control valve that controls the duration of the purge delay. This allows the Airlock Motor and the purge air pressure to continue to run for a time period to clear the airlock and hose of ice.

  • Page 44: Recommended Spare Parts

    Logic Element, “YES” 50021-002 Speed Controller, Purge Delay 30088-001 Ratchet Assembly, PHX-150 30081-001 Chain Assembly 30006-002 Bearing and Sprocket Assembly 30034-001 Pad, Airlock, PHX-150 10013-035 O-ring, Airlock Pad 10011-327 Quad-Ring, Airlock Pad 30175-025 Hose Assembly, 25’, Blast, PHX-150 Page 44...

  • Page 45: Specifications

    SPECIFICATIONS Dimensions: 18” x 20” x 47” (W x L x H) (47cm x 51cm x 120cm) Dry Weight: 140 lbs. (63.5 kg) Hopper Capacity: Over 100 lbs. (45.5 kg) of pellets Ice Consumption Range: 0.5 lbs. – 5 lbs. (0.23 kg – 3.2 kg) / min. Supply Air Pressure Range: 70 psi –...
  • Page 46 310 N. Cota Street, Suite H Corona, CA. 92880 Telephone: (951) 278-2229 Fax: (951) 278-0084 http://www.phoenixunlimitedllc.com...
