1.
2.
Stacking the omniSHAPE ....................................................................................................... 4
3.
Building a concave or convex wall ........................................................................................ 6
4.
Removing the Engine .............................................................................................................. 7
5.
Assembling the Screen ........................................................................................................... 9
6.
Plugging the cables .............................................................................................................. 10
7.
omniSHAPE Configuration Software ................................................................................... 12
7.1.
Start Up of the Software .................................................................................................... 12
7.2.
Designing a wall ............................................................................................................. 13
7.3.
Connecting to the omniSHAPE ..................................................................................... 15
7.3.1.
Network connection Settings ..................................................................................... 15
7.3.2.
Serial connection Settings ......................................................................................... 16
7.4.
Adjusting the Geometry ................................................................................................. 18
7.5.
Mapping .......................................................................................................................... 20
8.
Color adjustment ................................................................................................................... 21
8.1.
Shading correction ......................................................................................................... 21
8.2.
Color Adjustment ........................................................................................................... 21
9.
Saving of the Adjustment ..................................................................................................... 27
10.
Packaging of omniSHAPE ................................................................................................. 28
10.1.
Packaging of the screen ............................................................................................. 28
10.2.
Packaging of the Base Frame .................................................................................... 29
10.3.
Packaging of the accessories ....................................................................................... 31
10.4.
Packing all together ....................................................................................................... 31
Document Nr.:
Version:
OSH-Manual-EN
1.3
Manual
omniSHAPE
1.Vers. from date:
1.Version from:
28.02.2012
A. Schutz
Modified from:
Modified at:
A. Schutz
11.05.2012
Page Nr.
1 von 33

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the omniSHAPE and is the answer not in the manual?

Questions and answers

Summary of Contents for Eyevis omniSHAPE

  • Page 1: Table Of Contents

    Configuration Software ................... 12 7.1. Start Up of the Software ....................12 7.2. Designing a wall ......................13 7.3. Connecting to the omniSHAPE ..................15 7.3.1. Network connection Settings ..................15 7.3.2. Serial connection Settings ..................16 7.4. Adjusting the Geometry ....................18 7.5.
  • Page 2: Safety Guidelines / Sicherheitsrichtlinien / Directives De Sécurité

    1. Safety Guidelines / Sicherheitsrichtlinien / Directives de sécurité WARNING Electrical shock hazard: Do not open the housing of OSH-E-01 or cleaning the device before turning the power switch off and unplugging all connected cables. WARNUNG Gefahr eines elektrischen Schlages: DANGER Auf keinen Fall das Gehäuse öffnen oder eine Reinigung durchführen, bevor das Gerät ausgeschaltet ist und alle Kabel...
  • Page 3 NOTICE Do not cover the fan-area of the OSH-E-01. Otherwise it may result that the device overheats. ACHTUNG Verschließen sie niemals die Lüfter-Bereiche. Andernfalls kann ATTENTION das Gerät überhitzen. Ils n'ont jamais fermer les zones de fans. Sinon, l'appareil peut surchauffer.
  • Page 4: Stacking The Omnishape

    Before starting to build a wall you have to loosen the screws in the corners. If this isn’t done, the accuracy of the screens flatness won’t be very good. To build a tower of some omniSHAPES you have to put the first omniSHAPE on a stable ground. Optional you can use the omniSHAPE Basements.
  • Page 5 After this you can stack the omniSHAPES. You have to pull the latch of the next omniSHAPE to the front side. Stack the second omniSHAPE on the first. Then lock the second omniSHAPE on the first by using a soft-head hammer.
  • Page 6: Building A Concave Or Convex Wall

    For safety, as shown in the picture, pull the cotter pin into the guiderail 3. Building a concave or convex wall You can use the connection plate to build walls in different angles. These angles are: -12°/ -6°/ 0°/ +6°/ +12° Look below for choosing the right holes for the angle you need.
  • Page 7: Removing The Engine

    The connection bars on the left and the right side are needed to get the same height, when stacking the next omniSHAPES on top. 4. Removing the Engine On the backside of the omniSHAPE you have to release the internal hexagon screws (Allen- Key) that are marked in the picture. Document Nr.: Version: 1.Vers.
  • Page 8 Now you have to put your fingers into the handhold pull to remove the OSH-E-01. Now you can haul the engine out and in. After removing the Engine you have to remove the cover of the lens. Document Nr.: Version: 1.Vers.
  • Page 9: Assembling The Screen

    5. Assembling the Screen The OSH-CS-480 has an upper and a lower side. The lower side is marked by the serial number. The upper side is market by a label Oben / Top. On the backside of the Screen there are 4 screws. You have to unscrew the screws to a distance of 1cm between the screw head and the frame of the Screen.
  • Page 10: Plugging The Cables

    After this you have to fasten the screws at the four positions. 6. Plugging the cables It’s your choice to connect each omniSHAPE with the single power cable EY-SCHUKO- VDE-1,8m or to connect some omniSHAPES together with the Y-cables. Connecting the power supply is shown by using the Y-cables.
  • Page 11 Sub-D-9 female connector 2_Sub-D -> 3_RJ45 Configure the addresses of the omniSHAPES: FIRST omniSHAPE Address 001 SECOND omniSHAPE Address 002 Switch on each omniSHAPE by pushing the ON / OFF switch at the backside. Document Nr.: Version: 1.Vers. from date: 1.Version from:...
  • Page 12: Omnishape Configuration Software

    7. omniSHAPE Configuration Software 7.1. Start Up of the Software Copy the folder “omniSHAPES-Designer Release” to a chosen directory of your computer. Run the executable file: The main window opens. Description of symbols: Wall: To design a wall with the different shapes of screens...
  • Page 13: Designing A Wall

    To power on the chosen omniSHAPES Standby: To set the chosen omniSHAPES to standby mode 7.2. Designing a wall To add a new omniSHAPE you have to choose the screen-shape in the drop down list. Document Nr.: Version: 1.Vers. from date: 1.Version from:...
  • Page 14 Also you have to choose the Screentype in the drop down list beneath. Press the to add this omniSHAPE to the wall. Document Nr.: Version: 1.Vers. from date: 1.Version from: Modified from: Modified at: Page Nr. 14 von OSH-Manual-EN 28.02.2012 A.
  • Page 15: Connecting To The Omnishape

    7.3. Connecting to the omniSHAPE 7.3.1. Network connection Settings For Network usage you can connect the first omniSHAPE by Network, then go on with the cabling as seen at point 6 ->plugging the cables. First you have to configure the network settings of your network adapter. Go to the preferences of internet protocol version 4 (TCP/IPv4) as seen below.
  • Page 16: Serial Connection Settings

    2. Choose the baud-rate 115200 baud or 256000 baud. 3. Choose “8N1” 4. Press “Open Serial Port” Choose on omniSHAPE or the complete wall, after it’s chosen, the color switches from grey to light purple. Press Connect to get connected to the omniSHAPE.
  • Page 17 After being connected to the wall without chosen any omniSHAPE, all will have dark color. Not connected connected Document Nr.: Version: 1.Vers. from date: 1.Version from: Modified from: Modified at: Page Nr. 17 von OSH-Manual-EN 28.02.2012 A. Schutz A. Schutz...
  • Page 18: Adjusting The Geometry

    To adjust the geometry you first have to choose one omniSHAPE. Click on the symbol in the main Window. The omniSHAPE, what you want to adjust has to be chosen.
  • Page 19 Picture Description Click inside the box and then use the arrow keys to adjust the size. Up or right will let the picture grow, left or down will let the picture get smaller. Click inside the box, you could use the arrow keys to rotate.
  • Page 20: Mapping

    To add a source, press “+” after choosing the resolution. Now you can move the Source over the omniSHAPE in any position you want to have. By pressing the Apply Mapping button, the pictures on the chosen omniSHAPE will be mapped.
  • Page 21: Color Adjustment

    8. Color adjustment 8.1. Shading correction To activate the Shading correction, press the button Service at the left side. Then type “set(0;image_shading_select;1)” into the command line and press “Send”. Now the Shading image will be loaded. This will need 30 to 40 seconds. After it’s completely loaded you have to save by pressing the save button To deactivate the Shading correction, press the button Service at the left side.
  • Page 22 Choose all omniSHAPES (Strg+A) and press the button “Factory Reset” to reset the color calibration to the factory values. It will take a few minutes until all the omniSHAPES are reset to the factory values. After it’s done there will be information in the lower side of the window Then you have to save the settings, therefore choose the omniSHAPES and press the save button .
  • Page 23 Now adjust one omniSHAPE to the color you want to have. Therefore you can adjust the three values as seen in the picture below. Now press the button “Apply to Wall” to send the values of this one unit to the whole wall.
  • Page 24 After pressing the Enable button, the Auto Adjustment switched to Inactive. Document Nr.: Version: 1.Vers. from date: 1.Version from: Modified from: Modified at: Page Nr. 24 von OSH-Manual-EN 28.02.2012 A. Schutz A. Schutz 11.05.2012...
  • Page 25 Now you can readjust the one unit as seen in the picture below. After you have done the readjust, press “Apply to Selection”to set it. After pressing the button, the Auto Adjustment will switch back to Active. Repeat it again with the other units you want to readjust. After you waited 20 minutes the wall has auto adjusted automatically.
  • Page 26 8.3. Color Temperature You can use these sequence indexes to change the color temperatures. You can set them in typing the following commands into the command-line: Sequence Index Colortemperature / K Command approx. 6200 set(1;led_seq_index;1) approx. 5700 set(1;led_seq_index;2) approx. 5000 set(1;led_seq_index;3) approx.
  • Page 27: Saving Of The Adjustment

    Then press File -> Save Adjustment as… as seen below. Then choose a filename and save it to the directory you want. It could be that the omniSHAPE wall looks misaligned after you did some adjustments. Now you can load the saved adjustment.
  • Page 28: Packaging Of Omnishape

    10. Packaging of omniSHAPE 10.1. Packaging of the screen Screw the screws of the screen into the screen frame. Pack the Screen into the screen protection fleece. Put the screen into the screen cardboard box. Close the screen cardboard box with Scotch tape.
  • Page 29: Packaging Of The Base Frame

    Packaging of the Base Frame Fix the lens protection cover in front of the lens. Place the connection plate on the omniSHAPE. Use the T-Position to stack it on the bolts. Also place the connection bar on the bolts. Document Nr.: Version: 1.Vers.
  • Page 30 Put the rubber foam bars on the bolts. Put it into the foil bag. Put it into the Base Frame cardboard box and close the foil bag with some Scotch tape. Document Nr.: Version: 1.Vers. from date: 1.Version from: Modified from: Modified at: Page Nr.
  • Page 31: Packaging Of The Accessories

    Close the Base Frame cardboard box with some Scotch Tape. 10.3. Packaging of the accessories Pack all the accessories into the accessories cardboard box. 10.4. Packing all together Put one of the two rubber foams for Base Frame cardboard box into the outer cardboard box.
  • Page 32: Document Nr.: Version

    Put the second rubber foam on the Base Frame cardboard box. Put the rubber foam for screen cardboard box on the screen cardboard box. Put it into the outer cardboard box. Document Nr.: Version: 1.Vers. from date: 1.Version from: Modified from: Modified at: Page Nr.
  • Page 33 Put the accessories cardboard box into the outer cardboard box as seen in the picture. Close the outer cardboard box and tape it with some Scotch tape. Document Nr.: Version: 1.Vers. from date: 1.Version from: Modified from: Modified at: Page Nr. 33 von OSH-Manual-EN 28.02.2012...
