Kingfer Industrial Blue Flame KF-B006-TP User Manual

With thermostat
Hide thumbs

Advertisement

Quick Links

Download this manual
READ INSTRUCTIONS CAREFULLY: READ AND FOLLOW ALL INSTRUCTIONS.
PLACE INSTRUCTIONS IN A SAFE PLACE FOR FUTURE REFERENCE.
ONLY USE IN A WELL VENTILATED AREA
USER MANUAL
FOR
BLUE FLAME HEATER
（with Thermostat）
（KF-B006-TP）
WARNING: IF THE INFORMATION IN THIS MANUAL IS NOT FOLLOWED EXACTLY. A FIRE OR
EXPLOSION MAY RESULT CAUSING PROPERTY DAMAGE. PERSONAL
INJURY OR LOSS OF LIFE

Advertisement

loading
Need help?

Need help?

Do you have a question about the Blue Flame KF-B006-TP and is the answer not in the manual?

Questions and answers

Summary of Contents for Kingfer Industrial Blue Flame KF-B006-TP

  • Page 1 READ INSTRUCTIONS CAREFULLY: READ AND FOLLOW ALL INSTRUCTIONS. PLACE INSTRUCTIONS IN A SAFE PLACE FOR FUTURE REFERENCE. ONLY USE IN A WELL VENTILATED AREA USER MANUAL BLUE FLAME HEATER （with Thermostat） （KF-B006-TP） WARNING: IF THE INFORMATION IN THIS MANUAL IS NOT FOLLOWED EXACTLY. A FIRE OR EXPLOSION MAY RESULT CAUSING PROPERTY DAMAGE.

  • Page 2: Safety Precautions

    SAFETY PRECAUTIONS 1. Always use heater in accordance with 2. DO NOT place clothes or other materials instructions supplied with each heater. on the heater. This could cause a fire risk Keep instructions in a safe place. and/or affect the efficiency of the appliance. position heater close...

  • Page 3: Using Environment

    USING ENVIRONMENT Your heater consumes oxygen while it is in function. For that reason, adequate ventilation should be provided in rooms in which the heater is used. This ensures the removal of products of combustion and allows the entry of replacement air. Adequate ventilation should considerably reduce the possibility of condensation occurring.
  • Page 4 any leakage. Do not use naked flame to test for leaks. Use soapy water. Always use your cylinder always in an upright position. Always turn off the regulator control when the heater is not in use. When lighting your heater for the first time or after a period of time has passed since the last use, light the heater outside and burn outdoors for 15 minutes.

  • Page 5: Fault Finding Chart

    FAULT FINDING CHART Problem Problem Causes What To Do Regulator & hose connection Use soap form for leakage control, loose check all connection system replace Valve & pipe connection loose defected parts Pipe broken Smell of gas Inspect perimeter of each plaque and Missing piece of ceramic locate place where some fireclay has fireclay...
  • Page 6 REPAIRS SHOULD ONLY BE CARRIED OUT BY A COMPETENT PERSON IN ACCORDANCE WITH THE GAS SAFETY (INSTALLATIONS AND USE) REGULATIONS 1998 CONSTRUCTION AND FUNCTION 3, Thermostat 2,Ignition 1,Gas control knob gas control knob Ignitor and Thermostat Guard Pilot and ignition system Rear cover...
  • Page 7 1, CONNECTING THE CYLINDER Place the gas filled cylinder into the back of the heater, and fix the back cover to the back side of the heater by tightening the screws. Clip on the gas regulator to the gas cylinder Turn the regulator on.

  • Page 8: Heat Settings

    3, OPERATION GUIDE (Max) Pos. 1 (lighting/pilot) Pos.2 LIGHTNG INSTUCTION The heater has two settings. Lighting/Pilot(Pos.1) and Max (Pos.2) Place the gas filled cylinder into the back of the heater. and Fix the back cover by tightening the screws. Clip on the gas regulator to the gas cylinder. Turn on the gas regulator.
  • Page 9 Temperature Setting: TURN OFF THE HEATER Turn off heater at cylinder valve. NOTE: The heater can be turned off at the cylinder valve ONLY. If the heater is not used for a period of time, disconnect the regulator from the cylinder and replace any value protection plug or cover. 4, WARNING Read the instructions before using this appliance.
  • Page 10 switch-on valve and the regulator disconnected from the cylinder. 17. After use turn off the appliance at the gas container valve. 18. Only use in a well ventilated area. 5, STORAGE Disconnect cylinder. Store cylinder in a well-ventilated area away from combustible material. Storage preferable be in an outhouse but must not be in a basement or high-rise flat.
  • Page 11 Technical data: Manufacturer KINGFER INDUSTRIAL CO., LTD. Model KF-B006-TP Product name Blue Flame Heater (With Thermostat) Standard EN 449-2002+A1-2007 Appliance category I3B/P(30) I3B/P(50) I3B/P(37) Type of gas Gas Pressure (mbar) 28-30 28-30 Injector’s diameter 0.98 0.98 0.85 0.98 0.91 (mm)
