Summary of Contents for MANIP MPower Series
- Page 1 MANIP’ MPower Operators manual Réf. 25001403 - Février 2010 English...
-
Page 2: Table Of Contents
14• Hydraulic coupling Manip’Fast 14-15 Connect Disconnect 15• Manip’Lock implement detachment 16• Manip’Lock implement attachment 17• Hydraulic coupling Manip’Fast Outil 2 and 4 18• Level indicator 19• Manip’Pic 20• Manip’activ suspension 21• Collectivity kit safety with lifting and tipping 22•... -
Page 3: 1• User Information
GENERAL INFORMATION To the user You have just bought a Manip loader and we thank you for this. Spare a moment to read this manual as it has been made to help you use your loader at its maximum capacity. -
Page 4: 2• Safety Instructions
At your work place loaded implements should be transported in Reminder. Only tools recom- a lowered position at all times and at a low speed, in particular mended by Manip should be on uneven ground. Avoid working on slopes. used. -
Page 5: 3• Prohibitions
FOR LIFTING WORK, not made for. IT HAS TO BE EQUIPPED Any modification of the Manip equipment and the fitting of an WITH SAFETY VALVES implement of another origin than Manip automatically cancels the liability and the warranty on the entire equipment. -
Page 6: 4• Safety Stickers
4• SAFETY STICKERS Never use the loader Do not stand under the loader To carry people Read and keep the maintenance and user manual. Compulsory protections against tipping over and falling objects Unlocking Security device Lifting hooks for Loader maintenance... -
Page 7: 5• Location Of The Stickers
5• LOCATION Operators manual MANIP’ MPower OF THE STICKERS Left bearing box Right bearing box Tool carrier right hand side Tool carrier left hand side Tipping balancing system left and right 6• IDENTIFICATION PLATE The identification plate is located on the outside of the rear left arm, is mentioned: Year of manufacture, Type or model;... -
Page 8: 7• Counter Load
7• COUNTER LOAD Usage without METHOD OF CALCULATION counterweight 12525:2000 When the use of a counterweight is not possible, then the stability can be maintained by adding weights on the rear wheel or liquid in the tires in accordance to the following formula: Fig B.1 –... -
Page 9: 9• Switching From Double To Single Effect
9• SWITCHING FROM DOUBLE Operators manual MANIP’ MPower TO SINGLE EFFECT LIFTING Loader with Manip monolever and Manip Drive only A valve situated underneath the distributor allows you to switch from SINGLE EFFECT (VALVE OPEN) DOUBLE EFFECT (VALVE CLOSED) 10• 3... -
Page 10: User Instructions
Control the loader exclusively from the driver’s seat; keep control of the controls until movements are completed. Never leave the tractor with its loader in a raised position. All MANIP tools valves generate an internal oil leak necessary for operation, have been designed consequently the loader may drop. -
Page 11: Advice
Operators manual MANIP’ MPower INTERDICTIONS Never use the loader or the tool as a working plan. Never use the loader to carry or lift people. Never pass or stand under a lifted loader. Never stay under a lifted loader unless the mechanical or hydraulic shut off device is in a locked position. -
Page 12: Mm And Hd Loader Detachment
8• CHECK the pin’s clearance in relation to the hooks; otherwise lightly push the lever towards tipping. KEEP IN A FLOATING POSITION. 9• DISCONNECT the hydraulic plugs or the Manip Fast (depending on options) (see pages 14 and 15 HYDRAULIC COUPLING). 10• Put the flex away in the according support. - Page 13 ORDER TO BE Operators manual MANIP’ MPower RESPECTED 1- Dig the tool 1 meter from 2- Lower the loader to the 3- Put to float position the ground ground 4- Tool flat on the ground 5- Cylinder travel dimension 6- Parking props on the ground...
-
Page 14: Mm And Hd Loader Attachment
Always connect according to the colour coding. Manip’Fast, (see pages 14 and 15 HYDRAULIC COUPLING). 5• CHECK the position (on each side) of the pins in relation to the hooks. If necessary, move the tractor slowly forward again, without pushing the loader. - Page 15 ORDER TO BE Operators manual MANIP’ MPower RESPECTED 1- Centre the tractor between the loader arms, slowly go forward 2- Position of the pins before attachment 3- Floating position 4- Hydraulic coupling 5- Check position of pins before attachment 6- Slowly manipulate lift cylinders...
-
Page 16: Hydraulic Coupling Manip'fast
14• HYDRAULIC COUPLING MANIP’FAST DISCONNECT 1- Press on the lock and raise the lever. IMPORTANT Faulty use or maintenance provoked by high oil pressure may cause serious damage to the couplings. If you cannot 2- Remove the upper part of manually connect, the mobile unit. - Page 17 Operators manual MANIP’ MPower CONNECTER 1- Open the cover (Protection cover) Carefully clean the space for the couplings. 2- Position the removable unit opposite the fixed unit. Centre the guiding pins. 3- Press on the lock. Raise the lever. 4- Position the roller...
-
Page 18: Manip'lock Implement Detachment
Release the oil pressure, move the lever left and right by pressing on the 3 and 4 function switches. Disconnect the hydraulic plugs or the Manip Fast tool (According to option, see page 18) Put the flex away. Tip the implement slightly. -
Page 19: Manip'lock Implement Attachment
Release the oil pressure. Move the lever left and right by itself and have severe pressing on the 3 and 4 function switches. or even lethal Connect the hydraulics or the MANIP Fast tool, (according to consequences. option see page18). Respect the safety regulations. -
Page 20: Connect
17• HYDRAULIC COUPLING MANIP’FAST OUTIL 2 AND 4 DISCONNECT IMPORTANT Press on the lock switch. Faulty use or Raise the lever. maintenance provoked Remove the upper part of the mobile unit. by high oil pressure Hook the disconnected unit on the tool. -
Page 21: Level Indicator
Operators manual MANIP’ MPower 18• LEVEL INDICATOR THE INDICATOR ENABLES YOU TO POSITION THE IMPLEMENT WHILST LOWERING. ADJUSTMENT Position the implement flat on the ground. Check that the white index can be seen by the driver, if not, slide the rod using the nut. -
Page 22: Manip'pic
For transport, dismount the tines and put then away in its TRANSPORTED storage space. AT ONCE. The Manip Pic is not a tool but an accessory; ALWAYS use a tool to detach the loader. USAGE Loosen the security screw of the drawer situated inside the loaders tube;... -
Page 23: Manip'activ Suspension
Operators manual MANIP’ MPower 20• MANIP’ACTIV SUSPENSION IMPORTANT The Manip Activ suspension is there to absorb the shocks when driving on uneven surfaces. The batteries used The Manip Activ suspension does not need a shut-off tap; it by the Manip Activ works with an empty or loaded attached tool. -
Page 24: Maintenance
22• MAINTENANCE SAFETY For any kind of intervention on a raised loader, apart from hydraulic system, ALWAYS switch the stop valve on the lifting devise supply line into a closed position. Do not use the stopping valve for intervention on the hydraulic system. In this case the loader should rest on the ground. -
Page 25: Subframe Maintenance
Operators manual MANIP’ MPower SUB-FRAME MAINTENANCE Check that the screws are tightened at the torque, the first time after 10 hours of use and then every 50 hours. The torques indicated are given for dry and clean threading. An out of place tightening can damage the tractor structures and cause expensive repair costs. -
Page 26: Trouble Shooting
23• TROUBLE SHOOTING PROBLEM CAUSE SOLUTION I=Insufficient lifting and Oil pressure too low. Check oil pressure before and after excavation capacity. Damaged hydraulic pump. valve. Control lever inverted. Double Acting valve Valve incorrectly connected. See valve assembly instructions. without floating Control cables incorrectly adjusted. -
Page 27: Technical Characteristics
80 x 50 80 x 50 80 x 50 80 x 50 90 x 50 Lifting DE commutable SE *** Tipping parallelogram mechanical mechanical mechanical mechanical mechanical mechanical mechanical Tool carrier (with Manip’Lock) euro euro Euro Euro Euro Euro Euro... -
Page 28: Warranty
25• WARRANTY EXTRACT OF THE GENERAL SALES CONDITIONS PRICE LIST : Our discounts are applicable to the “FRANCE” PRICE LIST - EX-WORKS. Our price list may be reviewed int he light of economical changes, this revision would be notified 1 month beforehand. This clause also applies to all orders already registered. -
Page 29: Certificat Of Conformity
26• DECLARATION C.E. Operators manual MANIP’ MPower OF CONFORMITY The manufacturer: MANIP Avenue de la coopération 86200 LOUDUN France Declares that the equipment. MPower60, MPower80, MPower100, MPower120, MPower140, MPower160, MPower180 Is according to the directive dispositions “Machines” 98/37/CE et 2004/108/CE and to the national legislations Is according to the NF.EN.953, NF.EN.14018 and NF 12525... -
Page 30: Notes
NOTES... - Page 31 OPERATORS MANUAL MANIP’ MPower NOTES...
- Page 32 LE SAVOIR-FAIRE MANIP’ For Manip' your satisfaction is our priority. This is why from the design to the forwarding of the product; we do all that is possible to deliver you a high quality product. Oxycutting with numerical control. Environment friendly painting powders.
