Summary of Contents for Entel DN Series
- Page 1 Network Radio User Guide Designed in the United Kingdom...
- Page 2 IMPORTANT By using this product you agree to the terms and conditions of Entel’s E-PoC Service License which can be viewed here: www.entel.co.uk/EPoC_LICENSE 1. Controls & Indicators On/Off/Volume control. Rotate clockwise to turn ON and increase Green rapid flash - Call hang time volume.
- Page 3 Please note: When a unit has been switched OFF using the ON-OFF Volume control (1) and the battery is not removed, the unit remains in a low-power standby state. Leaving a unit in this state will slowly use batter power. www.entel.co.uk...
- Page 4 Option A – Using the rotary Group Control (2) to select a group. Rotate Selector Fig.5 Changing Groups with Group Control Option B – Using the Group List. Open Groups Choose Group Press PTT side button Fig.6 Changing Groups from the Group List www.entel.co.uk...
- Page 5 Option B – To make a Temporary Group call follow the sequence below. The radio will automatically revert to the selected Group after the call hang timer ends or you hang up the call using either the Softkey or Red button. Sending Radio Hang Timer Navigate to Group Press PTT Release PTT Select Groups Receiving Radio Fig.8 Temporary Group Call www.entel.co.uk...
- Page 6 5. Making / Receiving Individual Calls An individual call can be made in two ways: A) Impolite – speak directly to the individual B) Polite – ring the individual and wait for an answer Option A – To impolitely call an individual, follow the sequence below. Note: online contacts are indicated by a solid icon, offline contacts are greyed out and may not be called.
- Page 7 To clear the individual from the display and revert to group calling rotate the Group Selector one click in either direction. A timer will also revert to the default Group address after 5-minutes of inactivity. Open Contacts Selected Choose Contact Select Press PTT Fig.11 Individual PTT www.entel.co.uk...
- Page 8 6. Over-the-Air Programming (OTA) DN is capable of updating its firmware and configuration ‘over-the-air’ (OTA). • The OTA updates are pushed from Entel • The user is able to select when to install the firmware update. The OTA process follows two main steps.
- Page 9 • DO NOT DISASSEMBLE OR MODIFY THE BATTERY IN ANY WAY! Your Entel battery pack incorporates a safety circuit to avoid danger, if the safety circuit is damaged or bypassed, or the battery cells are damaged directly, they may generate extreme heat, smoke, rupture and emit flames.
