Page 2 NOTES...
Page 3: Table Of Contents
INSIGHT CMOS CAMERA USER GUIDE CONTENTS: WHAT’S IN THE BOX ..................1 MINIMUM SYSTEM REQUIREMENTS ............1 REGULATORY AND COMPLIANCE NOTES ........... 2 SAFETY INSTRUCTIONS .................. 3 CONNECTING TO A MICROSCOPE ..............4 CONNECTING THE CAMERA TO A COMPUTER........... 5 CAMERA SPECIFICATIONS ................6-7 TROUBLESHOOTING GUIDE ................
Page 4: Regulatory And Compliance Notes
REGULATORY AND COMPLIANCE NOTES This equipment complies with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. The equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.
Page 5: Safety Instructions
SAfETY INSTRUCTIONS • Read these instructions • Save these instructions • Follow these instructions Install in accordance with the manufacturer’s instructions. • Only use the attachments/accessories specified by the manufacturer. • Do not attempt to use this product in any manner not specified by the • manufacturer, as manufacturer will not be held responsible. Do not remove the camera covers, as this will void the warranty. •...
Page 6: Connecting To A Microscope
CONNECTING THE CAMERA TO A MICROSCOPE Select the correct C-mount optical adapter (sold separately) to fit the photo port on your microscope. Unscrew the C-mount dust cap from the camera. Screw the C-mount optical adapter into the camera. BE GENTLE! When started correctly, the adapter should easily thread into the camera.
Page 7: Connecting The Camera To A Computer
CONNECTING THE CAMERA TO A COMPUTER 1. Install SPOT Software before connecting the camera to a computer. 2. A USB 3.0 Type-A-to-micro B (locking) cable is supplied to connect the camera to your computer. (Fig. 1) a. One end of the cable has a micro-B connector with two thumb screws for locking the cable to the camera.
Page 8: Camera Specifications
SPECIfICATIONS SPOT Insight CMOS camera Sensor Specs Model IN41C5IR Sensor type Color Captured Image Resolution 5.1MP Live Image Resolution, no decimation 1.3MP 22 f/s (Typical frame rate on a brightfield microscope image using a Dell Optiplex Live Image Frame Rate, no decimation, 36-bit color 3020 computer with an Intel 4-core i5-4570 3.2 GHz CPU.
Page 9 SPECIfICATIONS Continued Trigger I/O Connector Hirose HR25-7TR-8A Power Required 5V supplied via USB3 Interface ON-OFF Switch Tripod Mount Optional Power Supply Optional USB Connector USB 3.0 micro-B (locking) Regulatory CE, FCC Class A, RoHS Windows SPOT Software Application Windows SDK support Linux Color Mosaic + IR Filter QE The suggested applications...
Page 10: Troubleshooting Guide
Using a USB 3.0 cable other approved USB3 cable than the one tested and During imaging session, included in the SPOT approved by SPOT Imaging “No Cameras or Interface camera box Card Found” message appears A USB 3.0 cable more than...
Page 11: Part Numbers
PART NUMbERS Insight CMOS camera ................ IN41C5IR USB 3.0 cable, Type-A to micro-B (locking), 3m (9 ft.) ....USB3AMB3M Optional Accessories USB 3.0 cable, Type-A to micro-B (locking), 5m (15 ft.) .....USB3AMB5M Power Supply for Insight CMOS camera ..........IN41PS Tripod Mount ................QUARTER20IN USB 3.0 PCI Express Computer Interface Card ......
Page 12 The unauthorized duplication or distribution of this software or documentation is an infringement of Diagnostic Instruments, Inc. rights to the software and may be subject to criminal and/or civil penalties. 6540 Burroughs Avenue • Sterling Heights • MI • 48314-2133 Toll free: 866.604.SPOT • Phone: 586.731.6000 • Fax: 586.731.6469 www.spotimaging.com Insight CMOS Camera Installation Guide...
