- Page 1 Kit form OVEN RANGE Installation Guide & Operating Instructions MODELS: Piccolo Medio Supremo Please read carefully BE FO R Einstalling. R etain for future reference.
-
Page 2: General Precautions
General Precautions Carefully read this booklet BEFOREinstalling the oven C heck that all components are present (see parts list on page 11). If there are any missing or damaged parts do not start installation, contact the supplier to arrange replacement. Similarly if the colour marked on the labels for the primer and fine sand do not match the ordered colour contact the supplier to arrange replacement. -
Page 3: Installation Considerations
Installation Considerations The C leanAir Act allowed the establishment of Smoke C ontrol Zones by local authorities. Smoke may not be emitted froma chimney unless it is from an authorised fuel or the appliance is exempt • - W ood is not an authorised fuel - The IMSO utdoor O ven is not an exempt appliance Free standing O utdoor O vens, like barbecues, are excluded from this legislation but to satisfy the exclusion: •... -
Page 4: Installing The Oven
Piccolo 1 piece Medio 1 piece Supremo 2 piece set Piccolo shown • W ith suitable assistance place the dense hearth on top of the insulated hearth • For Medio & Supremo, the join in the hearth sections should be sealed (maximum2mmjoint) using the U ltraW rightset Super. - Page 5 NO TE : Insulation is based upon amorphous silica which can cause hands to feel dry. W ash thoroughly after handling Piccolo shown Step 6 • T ape the foiled insulation together using the supplied foil tape. Medio and Supremo. Piccolo delivered as one piece. Piccolo shown...
- Page 6 • Pull the chicken wire down around the dome cutting aV -shaped Piccolo shown notch up the back to the top of the dome • T wist the cut ends together along each side of the cut to hold the...
- Page 7 • Application temperature 5˚C- 30˚C Method: • Do not apply if frosty/raining or frost/rain are anticipated Piccolo shown • Mix 5.1 litres of water per 30kg bag • Thoroughly mix the product until it is an even consistency •...
- Page 8 Mixing vessel/bucket Equipment: • E lectric paddle mixer (slow speed) • Stainless Steel smoothing trowel, spatula, notched trowel Piccolo shown • Application temperature 5˚C- 30˚C Method: • Do not apply if frosty/raining or frost/rain are anticipated • Mix 5.1 litres of water per 30kg bag •...
- Page 9 Stainless Steel float Equipment: • Smooth plastic float • Application temperature 5˚C- 30˚C Method: Piccolo shown • Do not apply if frosty/raining or frost/rain are anticipated • Thoroughly mix the product until it is an even consistency • Avoid creating air bubbles or foam •...
-
Page 10: Using Your Oven
Usingyour oven Curing the Outdoor Oven C uring your oven is a crucial step immediately after finishing construction and before using it for the first time • If your oven is rapidly heated to a high temperature it can result in cracks or fissures affecting performance •... -
Page 11: Parts List
PartsList O ven size Piccolo - Small Medio - Medium Supremo - Large Part Description Q uantity Part No Q uantity Part No Q uantity Part No Insulated H earth 10864 10865 2 pc set 10866 Dense H earth 10867... - Page 12 IMPO R T ANT : Directionsfor installationandusearegivenfor guidanceonlyandare not intended to form part of any contract. G oods supplied by the company are made to approved standards from the highest quality raw materials but no warranty or guarantee is given as to their suitability for any particular purpose or application, and no liability is accepted for any loss or damage arising directly or indirectly from the use of the C ompany’s products irrespective of any information given to us as to intended use of such products.
