SWIMMING POOL HEAT PUMP UNIT
Head Office
New South Wales
62 Parkhurst Drive
Unit 1, 20-22 Foundry Road
Knoxfield VIC 3180
Seven Hills NSW 2147
T: 03 9887 2131
T: 02 9838 0000
Installation & Instruction Manual
Inverter Series
I9 | I12 | I17 | I19
Queensland
Unit 1, 8 Reichert Drive
Molendinar QLD 4214
T: 07 5679 6821
sales@sunloverheating.com.au
sunloverheating.com.au

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Oasis Inverter Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Sunlover Oasis Inverter Series

  • Page 1 SWIMMING POOL HEAT PUMP UNIT Installation & Instruction Manual Inverter Series I9 | I12 | I17 | I19 Head Office New South Wales Queensland 62 Parkhurst Drive Unit 1, 20-22 Foundry Road Unit 1, 8 Reichert Drive sales@sunloverheating.com.au Knoxfield VIC 3180 Seven Hills NSW 2147 Molendinar QLD 4214 sunloverheating.com.au...

  • Page 2: Table Of Contents

    CONTENTS 1. PREFACE ................................. 3 2. SPECIFICATION ............................. 5 2.1 Performance data of Swimming Pool Heat Pump Unit................. 5 2.2 The dimensions for Swimming Pool Heat Pump Unit ................... 6 3. INSTALLATION AND CONNECTION ......................7 3.1 Installation illustration ..........................7 3.2 Swimming Pool Heat Pumps Location ......................

  • Page 3: Preface

    1. PREFACE In order to provide our customers with quality, reliability and versatility, this product has been made to strict production standards. This manual includes all the necessary information about installation, debugging, discharging and maintenance. Please read this manual carefully before you open or maintain the unit. The manufacture of this product will not be held responsible if someone is injured or the unit is damaged, as a result of improper installation, debugging, or unnecessary maintenance.
  • Page 4 1. PREFACE WARNING • The appliance shall be stored in a room without continuously operating ignition sources (for example open flames, an Operating gas appliance or an operating electric heater.) If any leakage of the gas , fire can be occur. •...

  • Page 5: Specification

    2. SPECIFICATION 2.1 Performance data of Swimming Pool Heat Pump Unit *** REFRIGERANT: R32 Model Oasis Oasis Oasis Oasis Performance Condition: Air 27°C / Water 26°C Heating Capacity 2.2 ~ 9 2.9 ~ 12 3.8 ~ 17 4.6 ~ 19.5 Running Current 0.8 ~ 7 1.1 ~ 9.4...

  • Page 6: The Dimensions For Swimming Pool Heat Pump Unit

    2. SPECIFICATION 2.2 The dimensions for Swimming Pool Heat Pump Unit Oasis I9 / Oasis I12 Oasis I17 / Oasis I19 sales@sunloverheating.com.au sunloverheating.com.au INSTALLATION & INSTRUCTION MANUAL - INVERTER SERIES – I9, I12, I17, I19 - SWIMMING POOL HEAT PUMP UNIT...

  • Page 7: Installation And Connection

    3. INSTALLATION AND CONNECTION 3.1 Installation illustration Installation items: The factory only provides the main unit and the water unit; the other items in the illustration are necessary spare parts for the water system, that provided by users or the installer. Attention: Please follow these steps when using for the first time 1.

  • Page 8: Swimming Pool Heat Pumps Location

    3. INSTALLATION AND CONNECTION 3.2 Swimming Pool Heat Pumps Location The unit will perform well in any outdoor location provided that the following three factors are presented: 1. Fresh Air 2. Electricity 3. Pool filter piping The unit may be installed virtually anywhere outdoors. For indoor pools please consult the supplier.

  • Page 9: Swimming Pool Heat Pumps Plumbing

    3. INSTALLATION AND CONNECTION 3.4 Swimming Pool Heat Pumps Plumbing The Swimming Pool Heat Pumps exclusive rated flow titanium heat exchanger requires no special plumbing arrangements except bypass (please set the flow rate according to the nameplate). The water pressure drop is less than 10kPa at max.

  • Page 10: Swimming Pool Heat Pumps Electrical Wiring

    3. INSTALLATION AND CONNECTION 3.5 Swimming Pool Heat Pumps Electrical Wiring NOTE: Although the unit heat exchanger is electrically isolated from the rest of the unit, it simply prevents the flow of electricity to or from the pool water. Grounding the unit is still required to protect you against short circuits inside the unit.

  • Page 11: Usage And Operation

    4. USAGE AND OPERATION 4.1 Interface display 4.2 Key and icon function instruction 4.2.A - Key function instruction Symbol Meaning Function Mute key Under the heating mode or heating mode under the automatic mode, the mute key operation is effective and used to enter and exit the mute mode with one click.

  • Page 12: B - Icon Function Instruction

    4. USAGE AND OPERATION 4.2.B - Icon function instruction Symbol Meaning Function Cooling It will display during cooling (there is no limit to startup & shutdown, and it is optional when the unit is cooling-only unit or heating-and-cooling unit). Heating It will display during heating (there is no limit to startup &...

  • Page 13: Startup & Shutdown

    4. USAGE AND OPERATION 4.3 Startup & shutdown Notes: Startup & shutdown operation can only be conducted in the main interface. When it displays with half screen off or full screen off, click any key for returning to ON/OFF main interface. When the unit is started under the control of wire controller, if using the emergency switch to shut down, the wire controller will display as follows: Operations are the same as under ON/OFF main interface.

  • Page 14: Mode Switch

    4. USAGE AND OPERATION 4.4 Mode switch Under the main interface, Short press" "to switch the unit among heating “ ” , cooling “ ” and automatic mode " ". Operation descriptions: 1) Mode switch operation can only be conducted in the main interface. 2) When the unit is under the defrosting state, the defrosting symbol is on ,with the display interface as follows: Notes:...

  • Page 15: Temperature Setting

    4. USAGE AND OPERATION 4.5 Temperature setting Notes: Under the temperature setting interface, if short press " ", the system will return to the main interface without any changes saved; If there is no operation for 5 s or short press " ", the current mode will be saved, and return to the main interface.

  • Page 16: B Setting And Cancelling The Timer On/Off Function

    4. USAGE AND OPERATION 4.6.B Setting and cancelling the Timer ON/OFF function Select ON1, OFF1, ON2 or OFF2 timer setting interface Setting the Timer ON/OFF function sales@sunloverheating.com.au sunloverheating.com.au INSTALLATION & INSTRUCTION MANUAL - INVERTER SERIES – I9, I12, I17, I19 - SWIMMING POOL HEAT PUMP UNIT...

  • Page 17: Silent Setting

    4. USAGE AND OPERATION Cancelling the Timer ON/OFF function Notes: 1). Under the Timer ON/OFF setting interface, if there is no operation for 20 s, the system will automatically memorize user's settings, and return to the main interface; 2). Under the Timer ON/OFF setting interface, If the timing symbol and entire time digits flash at the same time, click "...

  • Page 18: B Setting And Cancelling The Silent Function

    4. USAGE AND OPERATION 4.7.B Setting and cancelling the silent function Notes 1). When the silent icon" " is lighten the timing mute has been set, but it's not under silent status. 2). When the silent icon" " flash it's under the silent status. 3).

  • Page 19: Keyboard Lock

    4. USAGE AND OPERATION 4.8 Keyboard lock To avoid others' misoperation, please lock the wire controller after completing the setting. Notes: 1) Under the locked screen interface, only unlocking operation is available, and the screen will be lighten after other operations conducted. 2) Under the OFF interface, locking operation is available , and the operation method is the same as locking screen under the ON interface.

  • Page 20: Parameter List And Breakdown Table

    4. USAGE AND OPERATION 4.10 Parameter list and breakdown table 4.10.A Electronic control fault table Can be judged according to the remote controller failure code and troubleshooting sales@sunloverheating.com.au sunloverheating.com.au INSTALLATION & INSTRUCTION MANUAL - INVERTER SERIES – I9, I12, I17, I19 - SWIMMING POOL HEAT PUMP UNIT...
  • Page 21 4. USAGE AND OPERATION Frequency conversion board fault table: sales@sunloverheating.com.au sunloverheating.com.au INSTALLATION & INSTRUCTION MANUAL - INVERTER SERIES – I9, I12, I17, I19 - SWIMMING POOL HEAT PUMP UNIT...

  • Page 22: B Parameter Table

    4. USAGE AND OPERATION 4.10.B Parameter table Meaning Default Remark Heating inlet target temp. 28°C Adjustable Cooling inlet target temp. 28°C Adjustable Auto inlet target temp. 27°C Adjustable The wire controller can display the temperature unit as "℉" or "℃" according to the unit Model you bought.

  • Page 23: Main Board (Oasis I7/I19)

    4. USAGE AND OPERATION 4.12 Main board (Oasis I7/I19) Controller interface diagram and definition sales@sunloverheating.com.au sunloverheating.com.au INSTALLATION & INSTRUCTION MANUAL - INVERTER SERIES – I9, I12, I17, I19 - SWIMMING POOL HEAT PUMP UNIT...
  • Page 24 4. USAGE AND OPERATION Main board of the input and output interface instructions below P10-(U) P10-(V) Compressor ( output 220-230VAC） P10-(W) CN18(EMV) Water pump ( output 220-230VAC） CN13(HEAT) 4-way valve ( output 220-230VAC） CN96(H) High speed of fan ( output 220-230VAC） CN96(L) Low speed of fan (output 220-230VAC）...

  • Page 25: Maintenance And Inspection

    5. MAINTENANCE AND INSPECTION 5.1 Maintenance • Check the water supply device and the release often. You should avoid the condition of no water or air entering into system, as this will influence unit's performance and reliability. You should clear the pool/spa filter regularly to avoid damage to the unit as a result of the dirty of clogged filter.
  • Page 26 5. MAINTENANCE AND INSPECTION • No ignition sources No person carrying out work in relation to a refrigeration system which involves exposing any pipe work that contains or has contained flammable refrigerant shall use any sources of ignition in such a manner that it may lead to the risk of fire or explosion.
  • Page 27 5. MAINTENANCE AND INSPECTION • Repairs to sealed components 1) During repairs to sealed components, all electrical supplies shall be disconnected from the equipment being worked upon prior to any removal of sealed covers, etc. If it is absolutely necessary to have an electrical supply to equipment during servicing, then a permanently operating form of leak detection shall be located at the most critical point to warn of a potentially hazardous situation.
  • Page 28 5. MAINTENANCE AND INSPECTION • Removal and evacuation When breaking into the refrigerant circuit to make repairs or for any other purpose conventional procedures shall be used. However, it is important that best practice is followed since flammability is a consideration.
  • Page 29 5. MAINTENANCE AND INSPECTION • Decommissioning Before carrying out this procedure, it is essential that the technician is completely familiar with the equipment and all its detail. It is recommended good practice that all refrigerants are recovered safely. Prior to the task being carried out, an oil and refrigerant sample shall be taken in case analysis is required prior to re-use of reclaimed refrigerant.

  • Page 30: Trouble Shooting Guide

    5. MAINTENANCE AND INSPECTION 5.2 Trouble Shooting Guide Malfunction Display Cause Solution Water inlet temp. Sensor failure The water inlet temp. Sensor Check or change the is open or short circuit water inlet temp. Sensor Water outlet temp. Sensor failure The water outlet temp.

  • Page 31: Appendix

    6. APPENDIX 6.1 Caution & Warning 1. The unit can only be repaired by qualified installer centre personnel or an authorised dealer. （for Europe market） 2. This appliance can used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.

  • Page 32: Cable Specification

    6. APPENDIX 6.2 Cable specification 1. Single phase unit Three phase unit When the unit will be installed at outdoor, please use the cable which can against UV. sales@sunloverheating.com.au sunloverheating.com.au INSTALLATION & INSTRUCTION MANUAL - INVERTER SERIES – I9, I12, I17, I19 - SWIMMING POOL HEAT PUMP UNIT...

  • Page 33: Comparison Table Of Refrigerant Saturation Temperature

    6. APPENDIX 6.3 Comparison table of refrigerant saturation temperature sales@sunloverheating.com.au sunloverheating.com.au INSTALLATION & INSTRUCTION MANUAL - INVERTER SERIES – I9, I12, I17, I19 - SWIMMING POOL HEAT PUMP UNIT...

  • Page 34: Explosive View Of The I 9 Unit

    6. APPENDIX 6.4 Explosive view of the I 9 unit Electrical control structure explosion diagram sales@sunloverheating.com.au sunloverheating.com.au INSTALLATION & INSTRUCTION MANUAL - INVERTER SERIES – I9, I12, I17, I19 - SWIMMING POOL HEAT PUMP UNIT...
  • Page 35 6. APPENDIX sales@sunloverheating.com.au sunloverheating.com.au INSTALLATION & INSTRUCTION MANUAL - INVERTER SERIES – I9, I12, I17, I19 - SWIMMING POOL HEAT PUMP UNIT...

  • Page 36: Explosive View Of The I 12 Unit

    6. APPENDIX 6.5 Explosive view of the I 12 unit Electrical control structure explosion diagram sales@sunloverheating.com.au sunloverheating.com.au INSTALLATION & INSTRUCTION MANUAL - INVERTER SERIES – I9, I12, I17, I19 - SWIMMING POOL HEAT PUMP UNIT...
  • Page 37 6. APPENDIX sales@sunloverheating.com.au sunloverheating.com.au INSTALLATION & INSTRUCTION MANUAL - INVERTER SERIES – I9, I12, I17, I19 - SWIMMING POOL HEAT PUMP UNIT...

  • Page 38: Explosive View Of The I 17 Unit

    6. APPENDIX 6.6 Explosive view of the I 17 unit Electrical control structure explosion diagram sales@sunloverheating.com.au sunloverheating.com.au INSTALLATION & INSTRUCTION MANUAL - INVERTER SERIES – I9, I12, I17, I19 - SWIMMING POOL HEAT PUMP UNIT...
  • Page 39 6. APPENDIX sales@sunloverheating.com.au sunloverheating.com.au INSTALLATION & INSTRUCTION MANUAL - INVERTER SERIES – I9, I12, I17, I19 - SWIMMING POOL HEAT PUMP UNIT...

  • Page 40: Explosive View Of The I 19 Unit

    6. APPENDIX 6.7 Explosive view of the I 19 unit Electrical control structure explosion diagram sales@sunloverheating.com.au sunloverheating.com.au INSTALLATION & INSTRUCTION MANUAL - INVERTER SERIES – I9, I12, I17, I19 - SWIMMING POOL HEAT PUMP UNIT...
  • Page 41 6. APPENDIX sales@sunloverheating.com.au sunloverheating.com.au INSTALLATION & INSTRUCTION MANUAL - INVERTER SERIES – I9, I12, I17, I19 - SWIMMING POOL HEAT PUMP UNIT...
  • Page 42 NOTES sales@sunloverheating.com.au sunloverheating.com.au INSTALLATION & INSTRUCTION MANUAL - INVERTER SERIES – I9, I12, I17, I19 - SWIMMING POOL HEAT PUMP UNIT...
  • Page 43 NOTES sales@sunloverheating.com.au sunloverheating.com.au INSTALLATION & INSTRUCTION MANUAL - INVERTER SERIES – I9, I12, I17, I19 - SWIMMING POOL HEAT PUMP UNIT...
  • Page 44 Sunlover Heating are the sole distributor of Oasis Heat Pumps in Australia Victoria New South Wales Queensland South Australia Auckland 62 Parkhurst Drive Unit 1, 20-22 Foundry Road Unit 4, 8 Reichert Drive Sahara Pools & Solar 5b Estuary Views...
