A. ALUMINUM RAILS: 2" X 1-1/2" X 1/8" UNIVERSAL ALUMINUM T-SLOT EXTRUSION WITH
CHAMFERED ENDS
B. CROSS PIECES: 3" X 1-1/2" ALUMINUM ANGLE
C. CENTER TUBE: 2" X 2" SQ. TUBE WITH 3" ROUND TUBE BUSHING
D. TEE SOCKET: STEEL TEE SOCKET WITH SET BOLTS FOR
ADJUSTMENT
Note: Number of panels may vary, length of rail may vary.
UPM 3X
UPM 3X
Standard stock Tee socket sized
for 4" schedule 40 or 80 Pipe
www.generalspecialtiesmfg.com
208-265-5244
Page 1 of 4
REVISION:
02.09.16
Advertisement
Table of Contents
Summary of Contents for General Specialities UPM 3X
- Page 1 Page 1 of 4 UPM 3X A. ALUMINUM RAILS: 2” X 1-1/2” X 1/8” UNIVERSAL ALUMINUM T-SLOT EXTRUSION WITH CHAMFERED ENDS B. CROSS PIECES: 3" X 1-1/2" ALUMINUM ANGLE C. CENTER TUBE: 2" X 2" SQ. TUBE WITH 3" ROUND TUBE BUSHING UPM 3X D.
- Page 2 Page 2 of 4 Materials and Instructions Part UPM 3X Tee Socket (1) 5" O.D. steel socket with 3" O.D. pipe top Center tube (1) 2" X 2" square tube with welded round tube in center Crosspiece (2) 3" X 1 1/2" X 3/16" aluminum angle...
- Page 3 Page 3 of 4 Recommendations for Dimensions of Post Hole for Standard Installation of General Specialties Manufacturing Top of Pole Mounts Width of Square Hole / Diameter of Round Hole / Depth of UPM Model Cubic Yards of concrete Cubic Yards of concrete Hole needed needed...
- Page 4 Page 4 of 4 Rail Configuration A. BLACK POWDER COATED TEE B. SQUARE GALVANIZED CENTER TUBE WITH ROUND TUBE BUSHING C. ALUMINUM ANGLE CROSS PIECE D. UNIVERSAL ALUMINUM T-SLOT EXTRUSTION RAILS E. ALUMINUM FLAT BAR WITH 2 HOLES Note: Rails may toe in or toe out depending on panel mounting hole location. Number of panels may vary.
