Summary of Contents for Axiom Luna SD9 Series
- Page 2 Luna Installation Manual...
- Page 3 Axiom is not liable for physical or financial injury, loss or damage or consequential loss or damage of any kind arising out of: the supply, layout, assembly, installation or operation of the Goods or Services; or (ii) Axiom’s negligence or other act or omission.
- Page 4 Axiom BRSCS SCREWS. install 4 screws into the top of each post to secure the DRH under cap in position AFGHR handrail to be snap fitted over Innerrail AFGIR Innerrail RETAINED GASKET to the outer face of glass, either SRB for 6mm and 8mm glass, or SRE for 10mm and 12mm glass.
- Page 5 BPFG Baseplate (12mm Thick) FV10-45 FASTENERS Self tapping stainless steel countersunk screws supplied by AXIOM GROUP. Use of other screws is strictly not permitted and invalidates all Producer Statements and Warranty. Insert screws until they are fully inserted. All screws must be...
- Page 6 Refer elsewhere for corners, slopes and other situations not illustrated here. BRSCS SCREWS. install 4 screws into the top of each post to secure the DRH under cap in position AFGHR handrail to be snap fitted over Innerrail AFGIR Innerrail RETAINED GASKET to the outer face of glass, either SRB for 6mm and 8mm glass, or SRE for 10mm and 12mm glass.
- Page 7 AFG post with overhang cutout FGC-35 Bottom cap BRSCS Screws supplied by AXIOM GROUP. Use of other screws is strictly not permitted and invalidates all Producer Statements and Warranty. Insert screws until they are fully inserted. All screws must be...
- Page 8 Refer elsewhere for corners, slopes and other situations not illustrated here. BRSCS SCREWS. install 4 screws into the top of each post to secure the DRH under cap in position AFGHR handrail to be snap fitted over Innerrail AFGIR Innerrail RETAINED GASKET to the outer face of glass, either SRB for 6mm and 8mm glass, or SRE for 10mm and 12mm glass.
- Page 9 BPFGC Baseplate (12mm Thick) FV10-45 FASTENERS Self tapping stainless steel countersunk screws supplied by AXIOM GROUP. Use of other screws is strictly not permitted and invalidates all Producer Statements and Warranty. Insert screws until they are fully inserted. All screws must be...
- Page 10 FIG 1. CONNECTION TO IN-LINE POSTS Axiom BRSCS Axiom BRSCS screws screws BRSCS screws required, 4 per post. 5.5mm Ø fixing holes to be drilled on the outer groove lines of the Inner Rail. See Fig 1 which illustrates use...
- Page 11 GLAZING RETAINED GLAZING GASKET Install the correct retained glazing gasket. Refer table below. This section covers the measuring and Installation of the glass panes. Ensure the correct thickness of toughened glass is used. INSTALL GLASS Glazing Gasket Guide Glass is to be installed by shuffle glazing. Fit Setting block within the post to ensure glass is blocked in accordance with AS1288 and can not dislodge Glass Thickness External Rubber...
