Summary of Contents for AME Intl. 11001
- Page 1 INSTRUCTION MANUAL Model 11001 Aluminum OTR 5 Piece Bead 2347 Circuit Way, Brooksville, Florida, USA 34604 Phone: (+1) 352-799-1111 Toll Phone: (+1) 877-775-4AME (4263) Fax: (+1) 352-799-1112 E-mail: sales@ameintl.net www.ameintl.net...
-
Page 2: Safety Information
INSTRUCTION MANUAL IMPORTANT RECEIVING INFORMATION Visually inspect all parts for shipping damage. If you find shipping dam- age, notify the carrier at once. Shipping damage is not covered by your warranty. The carrier is responsible for all costs of replacement or repair ! WARNING ! caused by shipping damage. - Page 3 6b. If you are breaking the tire bead with the wheel off the vehicle: Remove the tire/rim assembly from the vehicle and place it flat on the ground with the gutter side up. Then proceed to Step 1below, “Positioning the Bead Breaker.” USING THE 11001 or 11050 BEAD BREAKERS Positioning the Bead Breaker 1.
- Page 4 INSTRUCTION MANUAL Activating the Bead Breaker The bead breaker uses a long stroke and high force. Be careful not to damage or bend rim parts, such as the flange butt weld, when using the bead breaker. Turn on the hydraulic pump to activate the bead breaker. 2.
- Page 5 AME Intl. 13060, between the frame of the vehicle and the back flange ( See Figure 8) Repeat the steps in “USING THE 11001 OR 11050 BEAD BREAKERS” on pages 2 and 3. 2. If the tire is still on the vehicle: Remove the tire using a boom truck and tire sling (AME Intl. Model 91000).
- Page 6 INSTRUCTION MANUAL Inspecting the Tire and Rim Always replace damaged or badly worn tires. When replacing tires, always use a replacement of exactly the same diameter. Destroy old tires, so that they cannot be used. Using badly worn or damaged tires can result in serious injury or death. 1.
