Summary of Contents for ASE Citadel CIT02
- Page 1 ASE - CIT02 Installation Manual ver. 1.0...
-
Page 2: System Components
ComCenter II Outdoor transceiver with GPS and integrated antenna ASE-MNT20 Universal Mounting Bracket with vibration dampening ASE-12150T 150' (45m) Composite Cable (ASE-CIT01 package) ASE-12328T 328' (100m) Composite Cable (ASE-CIT02-EXT package) ASE-JB03 Junction Box for ADU cable with RJ-11, RJ-45, and power (optionally includes AC/DC adapter) -
Page 3: Engine Room
RJ-45 ETHERNET (standard CAT5 cable) RJ-45 RJ-11 ASE-12xxxT LAPTOP or LAN (OPTIONAL) ASE COMPOSITE CABLE WITH TURRET CONNECTORS [328 feet (100m) option] Combined Max Cable Lengths 150 feet (45m) standard Up to 250'(76m) (Power & Ethernet Data) RJ-11 Voice: 8,000' (3Km) -
Page 4: Above Deck Unit (Adu)
ABOVE DECK UNIT (ADU) The Above Deck Unit (MC05G) has the antenna and tranceiver all contained in one unit. THERE ARE SOME CRITICAL INSTALLATION DETAILS BELOW. PLEASE REVIEW CAREFULLY. Although a funnel installation is recommended as a steath solution, this device is not sutiable for all funnels. Be sure to install in a clear 360°... -
Page 5: Junction Box
11.30” (standard 2-wire RJ-11 cable) (251mm) (287mm) Optional RJ-45 ETHERNET (standard CAT5 cable) RJ-45 RJ-11 ASE - 12xxT to ADU OPTION 2: Hook-up from DC (UPS) 8.05” ( 204mm) Optional 24VCD Direct (fused) Fuse .31 X .77” 24VDC (8 X 20mm) - Page 6 POTS CABINET The POTS Cabinet connects to the POTS (2-wire RJ-11 port) in the Junction Box. The POTS Cabinet ships with 50ft (15M) of 2-wire pre-connected to the POTS Cabinet. This 2-wire is terminated with an RJ-11 header and plugs directly into the RJ-11 port in the Junction Box. 8.98 Cable Exit from back (228mm)
