Summary of Contents for Revolution Revolution l
- Page 1 REVOLUTION I Robotic Pool Cleaner Operating Instructions Robotic Pool Cleaner REVOLUTION I ....8151626...
-
Page 3: Table Of Contents
5.2. Putting the Pool Cleaner into the pool .......4 5.3. Removing the Pool Cleaner from the pool ......5 5.4. Maintenance ................6 5.4.1. Cleaning the filtration system........6 5.4.2. Cleaning the impeller..........5.5. Off-season storage ...............8 Robotic Pool Cleaner REVOLUTION I | Operating Instructions... -
Page 4: Introduction
1. INTRODUCTION Thank you for purchasing a REVOLUTION Pool Cleaner. We are sure that your REVOLUTION Robotic Pool Cleaner will provide you with reliable, convenient and cost effective pool cleaning. Its reliable filtration in all pool conditions and all-surface climbing brush enhance maximum pool hygiene. -
Page 5: Pool Cleaner Parts
There are two filter level options, only one is provided with your robot cleaner. Cartridge with ultra-fine filter included. Optional net filters for heavy debris. Cartridge with ultra-fine filters included filters (x4), net filters optional Power Supply Unit Robotic Pool Cleaner REVOLUTION I | Operating Instructions... -
Page 6: Using The Pool Cleaner
5.2. Putting the Pool Cleaner into the pool Shake the Pool Cleaner from side to side or turn it upside down to release trapped air. Let it sink to the pool floor. Robotic Pool Cleaner REVOLUTION I | Operating Instructions... -
Page 7: Removing The Pool Cleaner From The Pool
Turn Off and unplug the power supply. CAUTION Using the floating cable, bring the Pool Cleaner to the pool’s edge. DO NOT PULL THE POOL CLEANER FROM THE POOL USING THE CABLE. CAUTION Robotic Pool Cleaner REVOLUTION I | Operating Instructions... -
Page 8: Maintenance
Unplug the power supply. CAUTION With the pool cleaner upside down open the bottom lid and pull it out. Open the clips and remove the filters. Clean the filters with a hose. Robotic Pool Cleaner REVOLUTION I | Operating Instructions... -
Page 9: Cleaning The Impeller
Place the impeller cover at an angle so that the notch is on the second ring of the spring. Press down on the impeller cover in the direction of the spring, pushing it into place. Replace the screws. Robotic Pool Cleaner REVOLUTION I | Operating Instructions... -
Page 10: Off-Season Storage
• Roll up the cable so that it has no kinks. • Store the pool cleaner upright in a protected area out of direct sun/rain/frost at a temperature of between 5˚-45˚C / 41˚-113˚F. Storage stand optional Robotic Pool Cleaner REVOLUTION I | Operating Instructions... - Page 11 Robotic Pool Cleaner REVOLUTION I 8151626...
