Summary of Contents for REMKO 248108
- Page 1 Operating and installation instructions REMKO Ethernet adapter Quick guide 0210-2019-02 Edition 1, en_GB Read the instructions prior to performing any task!
- Page 2 Read these operating instructions carefully before commis- sioning / using this device! These instructions are an integral part of the system and must always be kept near or on the device. Subject to modifications; No liability accepted for errors or mis- prints! Translation of the original...
-
Page 3: Table Of Contents
1.11 Transport and packaging....................... 6 1.12 Environmental protection and recycling..................6 Product description and technical data....................7 Mounting the adapter..........................8 3.1 Connection to the REMKO Smart-Control Touch controller............8 3.2 Mounting the adapter........................9 3.3 LAN function..........................10 Index..............................15... -
Page 4: Safety And Usage Instructions
REMKO Ethernet adapter Safety and usage instructions CAUTION! This combination of symbol and signal word 1.1 General safety notes warns of a potentially hazardous situation, which if not avoided may cause injury or mate- Carefully read the operating manual before com- rial and environmental damage. -
Page 5: Safety Notes For The Operator
"certificate of warranty" to The setup, connection and operation of the REMKO GmbH & Co. KG at the time when the units and its components must be undertaken units are purchased and commissioned. -
Page 6: Transport And Packaging
REMKO Ethernet adapter 1.11 Transport and packaging The devices are supplied in a sturdy shipping con- tainer or inside the heat pump casing. Please check the equipment immediately upon delivery and note any damage or missing parts on the delivery and inform the shipper and your contrac- tual partner. -
Page 7: Product Description And Technical Data
480 Mbps, ensuring full 10/100 Mbps Ethernet performance Low energy consumption: The REMKO adapter is designed for effective use of energy and to prevent unnecessary waste of energy. It can dynamically reduce its power supply in order to reduce energy con-... -
Page 8: Mounting The Adapter
NOTICE! Only use the unit in dry areas and protect it from electromagnetic radiation. The REMKO adapter must be used if it is not pos- sible to connect the REMKO Smart-Control Touch controller to the W-LAN network of the in-house router. -
Page 9: Mounting The Adapter
Ethernet adapter to the now free The LAN cable may only be connected to the USB port. port using the REMKO adapter. (see Fig. 2, Pos. 3) Connect the adapter [2] with the LAN (patch) cable and the router. -
Page 10: Lan Function
Installation in house The central controller for the REMKO heat pump via a smart phone or other mobile devices can be installed virtually anywhere in the building. WLAN Fig. - Page 11 After activating the expert level by touching the corresponding icon, a password is required. To To be able to use the LAN function of the REMKO enter the password at this level, touch the icon heat pump, a connection must be established with again to confirm.
- Page 12 Select the "Settings" level by touching the "Set- tion by touching them. tings" icon. The REMKO default password for the expert level is "0321". If this password has not already been changed, the expert level is enabled after entering this password.
- Page 13 After selecting the "Settings" level, select the The "Interfaces" parameter appears in the "Basic "Basic settings" parameter. settings" level. Select this icon by touching it.
- Page 14 Touch controller via your mobile device. The parameters available for the W-LAN function are listed here. If the REMKO heat pump is con- nected to the router via a LAN cable, only the IP address displayed under "Status" is required.
-
Page 15: Index
Index General ......4 Identification of notes ....4 Connection to the controller . - Page 16 REMKO QUALITY WITH SYSTEMS Air-Conditioning | Heating | New Energies Telephone +49 (0) 5232 606-0 REMKO GmbH & Co. KG Hotline within Germany +49 (0) 5232 606-0 Klima- und Wärmetechnik Telefax +49 (0) 5232 606-260 Im Seelenkamp 12 E-mail info@remko.de...
