Ponpe BX615 User Manual

4 in 1 gas detector
Hide thumbs

Advertisement

Quick Links

Download this manual
H S
EX
2
O
2
CO
BX615
BX615
BX615
BX615
BX615
4 IN 1 GAS DETECTOR

Advertisement

loading
Need help?

Need help?

Do you have a question about the BX615 and is the answer not in the manual?

Questions and answers

Summary of Contents for Ponpe BX615

  • Page 1 BX615 BX615 BX615 BX615 BX615 4 IN 1 GAS DETECTOR...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS I. DESCRIPTION II. SPECIFICATION III. OPERATION INSTRUCTIONS IV. CALIBRATION V. MAINTENANCE VI. STORE CONDITION VII. ACCESSORIES...

  • Page 3: Description

    4-IN-1 GAS DETECTOR I. DESCRIPTION WARNING INDICATOR GAS SENSORS COVER SCREW BUZZER LCD SCREEN POWER UP DOWN OK WWW.PONPE.COM...

  • Page 4: Specification

    ＜±5% （F.S） 1ppm ≤60MINS Sampling method：natural diffusion air；  Battery：3.7V Li-on rechargeable battery, 1800mAh；  Battery life：18 hours of continuous use (15 hours for  flammable gas detection)； Sensor type：electro-chemical (flammable gases, i.e.  H2S, CO and O2 as catalysts)； WWW.PONPE.COM...

  • Page 5: Operation Instructions

    Press and hold “ ”, the LCD will count down for 5 seconds before the buzzer rings shortly, after which the device will turn off. If holding “ ” too shortly, the detector will return back to measuring status。 3. Low battery WWW.PONPE.COM...
  • Page 6 （The first three times of use require a full charge each time of more than 12 hours）. 4. Descriptions of function keys Power on/off Up ▲ Down ▼ Select a menu Select a menu Power on item item Power off Increase number Decrease number WWW.PONPE.COM...
  • Page 7 4-IN-1 GAS DETECTOR Self testing Turn on backlight Turn on backlight Zero-calibration Sensitivity level Confirmation WWW.PONPE.COM...
  • Page 8 If performing routine check in a low-light environment,  backlight can be activated manually by pressing the Up or Down keys once. 1 2 3 4 5 6 WWW.PONPE.COM...
  • Page 9 3、Success indicator 4、Failure indicator 5、Alarm 6、Vibration 7、Alarm 8、Battery indicator 9、Measurement result 10、Type of gas detected and its unit 11、Menu setup 12、Calibration 13、Save data 14、Zero - calibration 15、Type of gas 16、Measuring unit: LEL, Vol 17、Warning (Level 2): 18、Reserved mark 1: WWW.PONPE.COM...
  • Page 10 The main advantage of this method is the short response and measurement time. When the targeted source gas is too far away from the detector, a “feeding” method is needed to measure the WWW.PONPE.COM...
  • Page 11 User can reset both warning level 1 and level 2 in setting mode。 Note： STEL: Shot Time Exposure Limit； TWA: Time Weighted Average。 ！ ：warning level 1 must be lower than warning level 2. If they are same, the detector will be working in warning WWW.PONPE.COM...
  • Page 12 Note： when detector is in the setting mode， detector cannot take measurements. User setting：  Turn on or off the warning mode;  Behaviours of the flash and sound indicators;  Vibration；and  Set points for warning level 1 and warning level 2. IV. Adjustment 4.1 Power on WWW.PONPE.COM...
  • Page 13 4-IN-1 GAS DETECTOR ①Press ON/OFF key, and hold 3 seconds, the detector will display all characters, then warning light, buzz, vibration go off subsequently once. ② one second later, the current version of the software will be on display. ③ one second after, warning level 1 will be displayed for 2 seconds.
  • Page 14 2 seconds. ⑧ 2 seconds later, the detector initiates by counting down 10 seconds. ⑨After the initiation process and self-checking, the device will enter measurement mode. Error messages will be displayed if according to each error type accordingly. WWW.PONPE.COM...
  • Page 15 4.3 Warning setup ①in measuring status, press key “▲” in 5seconds， buzzing 1 time in shorter audio，get into ID setting。 ②select key“▲”or“▼”, then press key“OK”for confirm， display in 2 seconds。 WWW.PONPE.COM...
  • Page 16 ④ CO’s warning level 2 setting status。 Due time，press▲or▼ to adjust target value， press “OK” for confirm，so then get into next next step (H S’s warning level 1 setting status。 If do not modify, press” ”, get into next step WWW.PONPE.COM...
  • Page 17 1 2’ status)。 If do not modify, press ” ”,get into next step ⑦ O s warning level 1 setting 2’ status。 Due time , press ▲or▼ to WWW.PONPE.COM...
  • Page 18 “ OK” for confirm，get into next step(EX’s warning level 1 setting status)。 If do not modify, press” ”,get into next step ⑨ EX’s warning level 1 setting status。 Due time，press ▲or▼ to adjust target value, press“OK” WWW.PONPE.COM...
  • Page 19 If do not modify, press” ”,get into measuring status。 4.4 Zero calibration ① in measuring status, press “▲”in 5-second, buzzing 1 time in shorter audio, get into ID setting。 WWW.PONPE.COM...
  • Page 20 S， 、EX value will be 0ppm or 0%LEL。O value will be 20.9%VOL。it is basic standard level, and display 0 or 20.9%VOL。 in this status, press “OK”, return to testing status ④ if it is not in right status, disply Err。 press“ ” for return WWW.PONPE.COM...

  • Page 21: Calibration

    300ppm in CO area。And then show real value in CO area。 Press ” ”for skip，get into S calibration ④ if it is same as standard gas in 300ppm, press “OK” for confirm。 if it is not same as standard gas WWW.PONPE.COM...
  • Page 22 And then show real value in S area, if it is same as standard gas in 50ppm, press “OK” for confirm。 press “ ” for skip， get into O calibration ⑥ if it is not same as standardgas in 50ppm， press ▲or▼ to adjustment，press WWW.PONPE.COM...
  • Page 23 Due time, open gas valve, allow gas flow into detector, waiting for stable situation，press “OK” , finish O calibration, and get into next step, EX calibration。 press ” ” for skip，get into EX calibration ⑧ in EX calibration, disply and WWW.PONPE.COM...
  • Page 24 ⑨ if it is not same as standard gas in 50%LEL， press ▲or ▼ to adjustment，press “OK”for confirm。 Due time, open gas valve, allow gas flow into detector, waiting for stable situation，press “OK” , finish EX calibration, and get into measuring status。 4.6 Flow chart checking WWW.PONPE.COM...
  • Page 25 1 time in shorter audio, get into flow chart checking status。The detector will display maximum value in measurment。 ② press “ OK “, the detector will display minimum value in measurment。 ③ press“OK“，it will display STEL value (average in 15 minuts)。 WWW.PONPE.COM...
  • Page 26 4-IN-1 GAS DETECTOR ④ press“OK“， it will display TWA value(average in 8 hours)。 ⑤press“OK“，get into measuring status。 WWW.PONPE.COM...

  • Page 27: Maintenance

    5.7 the detector should be not stored or used neither underthe circumstance with caustic gas (such as Cl ), not under the other rugged circumstances, including excessive high or low temperature, high humidity, electromagnetic field and strong sunshine. WWW.PONPE.COM...

  • Page 28: Store Condition

    4-IN-1 GAS DETECTOR Store condition 6.1 warranty period is 12 month. 6.2 The manufacturers disclaim all responsibility for damage caused by misuse. Accessories 7.1 Detecor 7.2 User Manual 7.3 Calibration cap 7.4 Charger WWW.PONPE.COM...
