- Page 1 User Manual for GPRS Modem Gateway for DeltaLINK-Cloud DLC-GPRS -UM-1.1 Delta-T Devices Ltd...
- Page 2 If the equipment is used with any non Delta-T products it is the responsibility of the user to ensure the EMC compliance of any such measuring systems. Design changes Delta-T Devices Ltd reserves the right to change the designs and specifications of its products at any time without prior notice. User Manual Version: 1.1...
-
Page 3: Table Of Contents
Parts and wiring used with GP1 and DL6 loggers 1: Ensure SIM Card is properly installed 2: Ensure the modem is powered. 3: Set up DeltaLINK-Cloud Wiring GPRS Modem Cable Harness for GP2 logger GP2 Network cabling Options with GPRS Modem... -
Page 4: Scope Of This Document
GPRS DeltaLINK-Cloud Gateway for GP1 and/or DL6 loggers: GPRS-DLC-BX1/B: polymer Modem Box with DeltaLINK-Cloud enabled GPRS and battery. GPRS-DLC- BX1/SP: polymer Modem Box with DeltaLINK-Cloud enabled GPRS plus solar power & battery. The GP1 or DL6 logger(s) are mounted outside the box. -
Page 5: Introduction
SIM card provided • Secure and encrypted DeltaLINK-Cloud is a secure cloud connectivity, data management and automatic data retrieval solution. The website lets you monitor the status of your loggers and modem gateways, graph and export the uploaded data and share access to data with project collaborators/stakeholders. - Page 6 Delta-T’s GP2, GP1 and DL6 data loggers can be connected to DeltaLINK-Cloud using the GPRS modem gateways described in this user manual or via PC based gateway software (Windows). Gateway upload schedules can be customised from DeltaLINK-Cloud. The SIM cards provided by Delta-T for the GPRS Cloud modem enable us to provide an optimum user experience and support service.
-
Page 7: Support For Gp1, Dl6 Or Gp2 Loggers
Delta-T supplies these systems fully wired up so you don’t have to worry about wiring. The modem firmware and SIM card are preconfigured at Delta-T with the system ready to automatically connect to the DeltaLINK-Cloud as soon as it is powered up. -
Page 8: Health And Safety
Health and Safety Installation The solar panels should be covered to exclude light before starting the installation. Batteries Batteries that are prone to give off explosive gases at any stage of their charge or discharge cycle must not be mounted in the enclosure without sufficient additional ventilation. -
Page 9: Install Gprs Modem Gateway With A Gp1, Dl6 Or Gp2
Requirements 1 MD-GPRS-DLC: GPRS cloud modem kit for mounting with GP2 Logger into M-ENCL-B2 metal enclosure GPRS-DLC-BX1/B: polymer Modem Box with DeltaLINK-Cloud – enabled GPRS and battery GPRS-DLC- BX1/SP: polymer Modem Box with DeltaLINK-Cloud enabled GPRS modem plus solar power & battery. -
Page 10: Modem Parts
Modem Parts 10 pin Microfit connector for power supply and reset signal Mini USB interface to connect to PC. Its use may be requested by Delta-T Technical Support if diagnosing faults SUB-D 15 pin serial connector SIM card slot with sliding latch Figure 1 Modem parts 10 ... -
Page 11: Parts And Wiring Used With Gp2 Loggers
Parts and wiring used with GP2 Loggers RS232 & Power Aerial GPRS Modem Power Mode Reset signal Text message signal Fuse (2A 250V slow break 5.2x20mm) Regulator/charger Solar Panel Not currently in use Power Power Power Battery Battery Fuse (6.3A 20mm) Figure 2 GP2 Logger/Controller in MD-GPRS-DLC enclosure with GPRS modem, cabling, aerial, SOL4 solar power regulator and LBAT4 battery. - Page 12 SIM card To aerial Push button to synchronise with DeltaLINK- Cloud Power Not currently + Reset signal in use + Text message alarm Fuse holder for 2A/250V Slow To logger break fuse, (Serial comms 5.2mmx20mm + power) Figure 3 GP2-GPRS Cable harness functions. See also Fig 1 and page 26.
-
Page 13: Parts And Wiring Used With Gp1 And Dl6 Loggers
Left : GPRS-DLC-BX1/B with battery. Right: GPRS-DLC-BX/SP solar power option, with solar power regulator /charger, solar panel (not shown) and battery. These DeltaLINK-Cloud GPRS Modem Box systems are used with one or more externally connected GP1 or DL6 loggers via a GP1 network cable. -
Page 14: 1: Ensure Sim Card Is Properly Installed
1: Ensure SIM Card is properly installed The Smart SIM card provided for the DeltaLINK-Cloud Modem gateway has no particular label on it, so all you can do is to check it (apart from actually using it) – is to check the SIM card actually is present in the modem. -
Page 15: 2: Ensure The Modem Is Powered
2: Ensure the modem is powered. Connect the battery to provide power to the modem. Powering the modem when using GP2 Logger RS232 & Power Aerial GPRS Modem Power Mode Reset signal Text message signal Fuse (2A 250V slow break 5.2x20mm) Regulator/charger Solar... - Page 16 Powering the modem when using GP1 or DL6 Loggers Regulator/charger Aerial Solar Panel GPRS Modem Modem Power Fuse Power Reset signal RS232 Power Battery Power to the GPRS modem is supplied via the cable harness in Figure 9 Cabling scheme in GPRS Gateway Box type GPRS-DLC-BX1/SP for use with GP1 or DL6 loggers.
- Page 17 2.1 Check the Modem Flashes. Check to see the Modem LED start to flash next to the SIM card. This indicates that the modem is powered and it is trying to connect to the DeltaLINK-Cloud. Modem LED Flashing Codes Modem LED...
-
Page 18: 3: Set Up Deltalink-Cloud
3: Set up DeltaLINK-Cloud Requirements By this stage you should have achieved the following:- Obtained a Delta-T logger Obtained a DeltaLINK-Cloud GPRS Modem Gateway, including GPRS modem and SIM card with a data package. Connected logger to modem ... - Page 19 Figure 11 The registration form for DeltaLINK-Cloud. Install GPRS Modem Gateway with a GP1, DL6 or GP2 logger 19...
-
Page 20: Add Gateway
Once registered the DeltaINK-Cloud Welcome page should appear:- Help Figure 12 Welcome page. The actual layout will change depending on the size of your screen. 3.2 Add Gateway 3.2.1 Click on Manage Devices Help Figure 13 Manage Devices page 20 Install GPRS Modem Gateway with a GP1, DL6 or GP2 logger... - Page 21 GPRS modem this is written on the side of the modem- see below. (This may not be required for the desktop gateway Access Code: Enter the Access Code for the gateway. For the DeltaLINK-Cloud GPRS modem this is written on a label - see below Name*...
- Page 22 Figure 15 Waiting for a new gateway to open 3.3 Add a Logger to the new Gateway 3.3.1 Click on Add Logger. Figure 16 The Add Logger form. 22 Install GPRS Modem Gateway with a GP1, DL6 or GP2 logger...
- Page 23 This information is needed so that the DeltaLINK-Cloud server knows how to interact with the logger correctly. Serial Number: This is required for DeltaLINK-Cloud to connect to the logger e.g GP1-01-024 This information is written on the logger and can also be obtained by connecting directly to the logger from a PC using DeltaLINK.
- Page 24 Figure 17 Showing the Gateway and Logger Status Your logger is now added to DeltaLINK-Cloud and will automatically update once a day. The schedule can be changed by going to the gateway Settings/Status page.
-
Page 25: Wiring
Wiring GPRS Modem Cable Harness for GP2 logger Reset button Not used Blue To modem Orange Brown Power, reset and alarm Signal to modem Black Ferrite Fuse bead White Serial communication Black to GP2 and power from GP2 Grey Blue 5-way M12 connector 15-way D Connector... -
Page 26: System Wiring For Gp2 Logger With Gprs Modem Gateway In M-Encl-B2 Metal Enclosure
System Wiring for GP2 Logger with GPRS modem gateway in M-ENCL-B2 metal enclosure RS232 & Power Aerial GPRS Modem Power Mode Reset signal Text message signal Fuse (2A 250V slow break 5.2x20mm) Regulator/charger Solar Panel Not currently in use Power Power Power Battery... -
Page 27: Gprs-Bx1 Modem Box Wiring Harnesses
GPRS-BX1 Modem Box Wiring Harnesses LED status indicator 15-way To GP1 and/or DL6 D Connector logger(s) 5-way M8 connector Grey on outside of Modem Grey Blue Grey White Green Black Reset button Optional alarm modem signal from logger Orange Blue Black Blue Fuse... -
Page 28: Gprs-Dlc-Bx1-Sp System Wiring With Gp1 Logger
GPRS-DLC-BX1-SP System Wiring with GP1 Logger Regulator/charger Aerial Solar Panel GPRS Modem Modem Power Fuse Power Reset signal RS232 Power Battery Figure 23 Wiring Scheme using Modem Box GPRS-DLC-BX1-SP which includes solar power, showing a GP1 logger connected 28 Warranty and Service... -
Page 29: Terms And Conditions Of Sale
Warranty and Service Terms and Conditions of Sale Our Conditions of Sale (ref: COND: 1/07) set out Delta-T's legal obligations on these matters. The following paragraphs summarise Delta-T's position but reference should always be made to the exact terms of our Conditions of Sale, which will prevail over the following explanation. -
Page 30: Service, Repairs And Spares
In your enquiry, always quote instrument serial numbers, software version numbers, and the approximate date and source of purchase where these are relevant. Contact Details: Tech Support Team Delta-T Devices Ltd 130 Low Road, Burwell, Cambridge CB25 0EJ, UK email: tech.support@delta-t.co.uk email: repairs@delta-t.co.uk...
