iStartek V520 User Manual

3g/4g industrial router

Quick Links

iStartek 3G/4G INDUSTRIAL ROUTER

USER GUIDE

Contents

1 Connector Description .................................................................................................. 2

2 Setting Preparation ....................................................................................................... 4

3 Working Mode .............................................................................................................. 7

4 Wireless Safety Setting ................................................................................................ 13

5 System Service ............................................................................................................ 16

6 Admin ......................................................................................................................... 18

File Name:

Original Industrial Router

Guide

Project:

V520

Version

Update Date:

Nov.16

2018

1.0

Need help?

Do you have a question about the V520 and is the answer not in the manual?

Questions and answers

Summary of Contents for iStartek V520

Page 1: Table Of Contents
Version Guide Project: V520 Update Date: Nov.16 2018 iStartek 3G/4G INDUSTRIAL ROUTER USER GUIDE Contents 1 Connector Description ....................2 2 Setting Preparation ....................... 4 3 Working Mode ......................7 4 Wireless Safety Setting ....................13 5 System Service ......................16...
Page 2: Connector Description
5) Serial port: Serial port 0 is used as Console, and serial port 1 is used as serial communication interface. 6) Micro USB port: can be connected to the computer to dial directly, then V520 can be used as a USB network card.
Page 3 File Name: Original Industrial Router Version Guide Project: V520 Update Date: Nov.16 2018 Indicator status description Name Status Description Constant on GPS is connected GPS Light GPS is not connected Constant on RJ45 port is connected LAN0-LAN3 Light RJ45 port is not connected...
Page 4: Setting Preparation
File Name: Original Industrial Router Version Guide Project: V520 Update Date: Nov.16 2018 2 Setting Preparation 2.1 Connecting Equipment You can connect your computer and router as below procedure. 2.2 Set Computer ‘s IP Address Before access to the web setting, we advise you to setting your computer into obtain IP address and DNS IP address automatically.
Page 5 File Name: Original Industrial Router Version Guide Project: V520 Update Date: Nov.16 2018 2.5 Router Login Then login Web setting configuration of router. Click http://192.168.10.1 in the address field of web browser, then click the user name and password in pop-up window.
Page 6 File Name: Original Industrial Router Version Guide Project: V520 Update Date: Nov.16 2018...
Page 7: Working Mode
Wireless AP+ wireless customer end bridge mode, wireless AP+ Wireless customer end. 3.1 3G/4G Wireless Router Mode The default to V520 is 3G/4G wireless router, Insert 3G/4G SIM card, Router will search 3G/4G internet automatically .You can also define the internet supplier what you want to.
Page 8 File Name: Original Industrial Router Version Guide Project: V520 Update Date: Nov.16 2018 Server 3G/4G Dial number User Password network name China mobile TD-SCDM cmnet *99# or card card *98*1# TDD-LTE China Telecom CDMA200 ctnet #777 card card 0 FDD-LTE...
Page 9 File Name: Original Industrial Router Version Guide Project: V520 Update Date: Nov.16 2018 3.2.2 Dynamic Internet Connection Way Entering working mode to choose standard router mode, Choose the dynamic IP address under WAN setting windows. Click apply button, then the router will obtain ISP assigned parameter automatically.
Page 10 3.3 Wireless AP+ Customer End Bridge Mode Choose this mode, we can use V520 as a bridge connection for AP using, it’s used as bridge connection of former grade wireless router. At first, Set your computer’s IP address into 192.168.10.100, and enter Web by wire cable connect LAN2 connector, then enter the router admin page, Choose wireless AP+ Customer end bridge mode.
Page 11 File Name: Original Industrial Router Version Guide Project: V520 Update Date: Nov.16 2018 3.3.1 Click LAN setting button, search for wireless network. 3.3.2 You can see the name of wireless AP within current coverage range, Choose wireless AP accordingly. 3.3.3 Fill wireless AP password chose, then you can bridge connection former Wireless AP.
Page 12 File Name: Original Industrial Router Version Guide Project: V520 Update Date: Nov.16 2018 4. Wireless AP+Customer End Mode Web– working mode – Wireless AP+ Customer end mode, click apply.  Wireless connection –Use menu of Internet ways to choose AP client – Dynamic address (Get from ...
Page 13: Wireless Safety Setting
File Name: Original Industrial Router Version Guide Project: V520 Update Date: Nov.16 2018 4．Wireless Safety Setting 4.1 Wireless Safety Wireless safety mode has several types, It can choose different safe mode as your requirement. • Stop in use • Open System •...
Page 14 File Name: Original Industrial Router Version Guide Project: V520 Update Date: Nov.16 2018 Only two encryption type to choose: None and WEP. Encryption type Choose ”None”means no encryption, choose “WEP” showed as above. The length of WEP Only two length of WEP encryption types to choose: 64 bit and encryption 128bit.
Page 15 File Name: Original Industrial Router Version Guide Project: V520 Update Date: Nov.16 2018 4.4 WPA2-PSK Description listed as below: Web item Description Safe mode Choose WPA2-PSK. WPA-PSK Only three choices: TKIP, AES and TKIPAES. encryption WPA-PSK Set key, legal key length: 8-63个ASCII character 64 sexadecimal (0~9、a~f or A~F).
Page 16: System Service
5．System Service V520 offer many items to choose, here we mainly describe Virtual server, serial service and SMS service. 5.1 Virtual Service BC-628E can be use data Internet server, offer many service function, Only need to fill right IP address of...
Page 17 Regarding to this content of this chapter, we will give brief description. 5.3 SMS Service We can send SMS to V520 router and control the start, close and restart by setting telephone number if V520 have 3G/4G SIM card for sending and receiving messages. The details listed below:...
Page 18: Admin
File Name: Original Industrial Router Version Guide Project: V520 Update Date: Nov.16 2018 6．Admin 6.1 Equipment Function Windows ME, 2000, XP use UPnP Protocols. These systems can find router automatically by this Protocols...
Page 19: Software Updating
File Name: Original Industrial Router Version Guide Project: V520 Update Date: Nov.16 2018 if we start this function. UPnP (Universal Plug and Play, namely is use immediately when you plug ) is mainly used for realizing intelligent connection and communication for equipment, There is no need tat tending and using main server for users to find automatically and control from different types web equipment of different suppliers.
Page 20 (1) fill the original password in the< original password>radio box;Fill the new password in the<new password>text box, Refill the new password in the<confirm password>and confirm edit . (2) Click<confirm>button, completed the password revision. Please e-mail us at info@istartek.com if any question or feedback.
