StarLeaf Pronto Cable USB 4100 Read This First

Read this first: Installing Pronto Cable USB 4100
This information represents a Pronto Cable USB installation for (A) StarLeaf Touch 2036 and (B) StarLeaf Touch 2035 and room system codec.
For more information about installing Pronto with your StarLeaf room system, go to support.starleaf.com/installing
Pack contents
Identify your StarLeaf Touch
On the underside of every Touch is a label identifying
Touch
whether it is a 2036 or 2035.
ƒ For a Touch 2036, follow Option (A) instructions
ƒ For a Touch 2035, you must connect Pronto directly
to the room system codec. Follow Option (B)
instructions overleaf
Codec
Pronto
Alternative USB-A cable
Cable connectors
Angled micro
Pronto
USB-B
Option (A) Install with a StarLeaf Touch 2036
Pronto comes with an angled micro USB-B cable fitted.
1. Connect this angled cable to the micro USB port on the underside of
the Touch 2036.
2. Remove the cable tie from the bottom of this page.
3. Secure the cable tie tightly around the Ethernet cable and the angled
cable to position them as shown in the image below.
Micro USB-B USB-A
480-00320
