Summary of Contents for Endace DAG 4.5G2 Card

Page 1 DAG 4.5G2/G4/GF Card User Guide EDM01-18...
Page 2 Fax: ++1 703 382 0155 Fax: ++44 1223 370 040 Copyright 2005-2006© Endace Limited. All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means electronic, mechanical, photocopying, recording, or otherwise, without the prior written permission of the publisher.
Page 3 Disclaimer Whilst every effort has been made to ensure accuracy, neither Endace Limited nor any employee of the company, shall be liable on any ground whatsoever to any party in respect of decisions or actions they may make as a result of using this information.
Page 5: Table Of Contents
EDM 01-18 DAG 4.5G2/G4/GF Card User Guide Table of Contents Chapter 1: Introduction Overview Purpose of this User Guide System Requirements Card Description Card Architecture Extended Functions Chapter 2: Installation Introduction DAG Device Driver Inserting the DAG Card Port Connectors Pluggable Optical Transceivers Pluggable Copper Transceivers Chapter 3: Configuring the Card...
Page 7: Chapter 1: Introduction
Note: Unless specifically stated otherwise, throughout this User Guide “DAG 4.5 card” refers to the DAG 4.5G2/G4/and GF cards. The Endace DAG 4.5 card provides the means to transfer data at the full speed of the network into the memory of the host PC, with zero packet loss guaranteed in even worst-case conditions.
Page 8: System Requirements
EDM04-01 Linux FreeBSD Software Installation Guide • ® EDM04-02 Windows Software Installation Guide Other Systems For advice on using an operating system that is substantially different from either of those specified above, please contact Endace Customer Support at support@endace.com ©2005-2006 Version 4: August 2006...
Page 9: Card Description
EDM 01-18 DAG 4.5G2/G4/GF Card User Guide Card The DAG 4.5 card provides two or four optical or copper Gigabit Ethernet interfaces. It is capable of full line rate (1,000Mbps) capture and transmission Description of Ethernet traffic and is protocol independent. Full packet capture at line rate allows recording of all header information and/or payload with a high precision timestamp.
Page 10: Card Architecture
EDM 01-17 DAG 4.5G2/G4/GF Card User Guide The DAG 4.5G2 card is shown below: SFP Cages FPGA with Pluggable Optical Heatsink fitted Connectors x 2. Note: Pluggable copper connectors are also supported. 9-pin socket for time synchronization Note: The DAG 4.5G2/GF card is capable of simultaneous capture and transmission at full line rate across both ports.
Page 11 EDM 01-18 DAG 4.5G2/G4/GF Card User Guide DAG 4.5G4 The diagram below shows the DAG 4.5G4 card’s major components and flow of data. DAG 4.5G2 The diagram below shows the DAG 4.5G2 card’s major components and flow of data. ©2005-2006 Version 4: August 2006...
Page 12: Extended Functions
EDM 01-17 DAG 4.5G2/G4/GF Card User Guide DAG 4.5GF The diagram below shows the DAG 4.5GF card’s major components and flow of data: Failsafe Relays Extended Functions The DAG 4.5GF has failsafe optical relays which allow you to connect the two ports in the event of a power interruption or software or hardware failure on the host.
Page 13 EDM04-10 Data Stream Management API Programming Guide and EDM04-07 dsm-loader User Guide available from the Support section of the Endace website at www.endace.com. Inline Forwarding The DAG 4.5 card supports inline forwarding which enables the card to receive and transmit packets directly from a single memory.
Page 15: Chapter 2: Installation
EDM 01-18 DAG 4.5G2/G4/GF Card User Guide Chapter 2: Installation Introduction The DAG 4.5 card can be installed in any free PCI-X slot. It operates at 66MHz, 100MHz or 133MHz PCI-X mode but will not operate in 32-bit or 64-bit PCI slots. Higher speed slots will achieve better performance. Although the DAG driver supports up to sixteen DAG cards in one system, the DAG card makes heavy use of PCI-X bus data transfer resources.
Page 16: Port Connectors
Setting Power The optical power range depends on the particular SFP module that is fitted to the DAG card. However Endace recommends you use the 1000baseSX 850nm short range modules which are shipped with the card. Optical power is measured in dBm. This is decibels relative to 1 mW where 10 dB is equivalent to a factor of 10 in power.
Page 17: Pluggable Copper Transceivers
• Mechanical chassis attached to the circuit board • Transceiver unit which may be inserted into the chassis Endace recommends that you use Cat6 copper cable. The DAG 4.5 card copper module specification is shown below: Part Type Data Rate...
Page 19: Chapter 3: Configuring The Card
EDM 01-18 DAG 4.5G2/G4/GF Card User Guide Chapter 3: Configuring the Card Introduction Configuring the DAG card for data capture involves the following steps: • Loading the images and programming the FPGA, • Setting the link, • Checking the link, •...
Page 20: Leds And Inputs
EDM 01-17 DAG 4.5G2/G4/GF Card User Guide LEDs and Before you begin to configure the DAG card it is important to understand the function of the various LEDs associated with the card, as well as the sockets Inputs on the PCI bracket. Note: The LEDs and sockets on the DAG 4.5G4 card are different to those on the DAG 4.5G2/GF card.
Page 21: Load The Fpga Image
EDM 01-18 DAG 4.5G2/G4/GF Card User Guide Load the Before you can configure the card for capture you must load the card with the appropriate FPGA image: FPGA Image • For the DAG 4.5G2/GF card use: dagrom –d0 -rvp -f dag45g2pcix-terf-dsm.bit •...
Page 22: Auto-Negotiation
EDM 01-17 DAG 4.5G2/G4/GF Card User Guide DAG 4.5G4 Output Firmware: edag45g4pci_terf-ntr_pci_v2_3 2vp30ff1152 2006/08/08 21:32:42(user) Serial : 0 MAC Address A : 00:00:00:00:00:00 Number of packets dropped during current MAC Address B : 00:00:00:00:00:00 session. Resets to “0” if MAC Address C : 00:00:00:00:00:00 session is restarted Sets (eql) or unsets (noeql) MAC Address D : 00:00:00:00:00:00...
Page 23: Interface Statistics
EDM 01-18 DAG 4.5G2/G4/GF Card User Guide When you have configured the card according to your specific requirements Interface you can view the interface statistics to check the status of each of the links Statistics using: dagconfig –d0 –si Display statistics once (-s) or at 1 sec intervals (-si) Example outputs are shown below: Note: “...
Page 25: Chapter 4: Capturing Data
EDM 01-18 DAG 4.5G2/G4/GF Card User Guide Chapter 4: Capturing Data Starting a For a typical data capture session follow the steps listed below: • Session Move to the directory in which you installed the DAG software • Load the appropriate driver, •...
Page 26 EDM 01-17 DAG 4.5G2/G4/GF Card User Guide Setting Variable/Fixed Length Captured The DAG 4.5 card is able to capture packets in two ways. They are: Packet Size • Variable length capture ( varlen (cont.) • Fixed length capture ( novarlen) In variable length ( ) mode the card will capture the whole packet, varlen...
Page 27: High Load Performance
You can detect any such losses by observing the Loss Counter lctr field) of the Extensible Record Format [ERF]. See Chapter 6: Data Formats later in this User Guide for more information on the Endace ERF. ©2005-2006 Version 4: August 2006...
Page 28: Transmitting
This allows the DAG card to be used as a test traffic generator. For further information on using please refer to the EDM04-06: daggen Daggen User Guide available from the Support section of the Endace website at www.endace.com. ©2005-2006 Version 4: August 2006...
Page 29 # dagmem dsize=128m For Windows® the upper limit is 32MB. This is usually sufficient however if you do need to increase the amount of reserved memory please contact Endace customer support at support@endace.com for more information option sets the amount of memory used per DAG card in the dsize system.
Page 31: Chapter 5: Synchronizing Clock Time
Common synchronization sources include GPS or CDMA (cellular telephone) time receivers. Endace also provides the TDS 2 Time Distribution Server modules and the TDS 6 units that enable you to connect multiple DAG cards to a single GPS or CDMA unit.
Page 32: Timestamps
EDM 01-17 DAG 4.5G2/G4/GF Card User Guide ERF files contains a hardware generated timestamp of each packet’s arrival. Timestamps The format of this timestamp is a single little-endian 64-bit fixed point number, representing the number of seconds since midnight on the January 1970.
Page 33: Card With Reference
EDM 01-18 DAG 4.5G2/G4/GF Card User Guide dagclock -h Usage: dagclock [-hvVxk] [-d] [-K <timeout>] [-l <threshold>] [option] this page --help,--usage increase verbosity --verbose display version information --version clear clock statistics --clearstats wait for duck to sync before exiting --sync the DAG device sync timeout in seconds, default 60 timeout...
Page 34: Building
The DAG time synchronization connector supports an RS-422 (PPS) signal from an external source. This is derived directly from an external reference source, or distributed through the Endace TDS 2 (Time Distribution Server) module which allows two DAG cards to use a single receiver. It is also possible for more than two cards to use a single receiver by “daisy-chaining”...
Page 35: Single Card No Reference
EDM 01-18 DAG 4.5G2/G4/GF Card User Guide Single Card No When a single card is used with no external reference, the card can be synchronized to the host PC clock. Most PC clocks are not very accurate by Reference themselves, but the DUCK drifts smoothly at the same rate as the PC clock. If a PC is running NTP to synchronize its own clock, then the DUCK clock is not as smooth because the PC clock is adjusted in small jumps.
Page 36 EDM 01-17 DAG 4.5G2/G4/GF Card User Guide Two Cards No Synchronizing with Each Other Reference Although the master card’s clock will drift against UTC, the cards will still be locked together. This is achieved by connecting the time synchronization (cont.) connectors of both cards using a standard RJ-45 Ethernet cross-over cable.
Page 37: Connector Pin-Outs
EDM 01-18 DAG 4.5G2/G4/GF Card User Guide Overview Connector Pin-outs DAG cards have an 8-pin RJ45 connector with two bi-directional RS422 differential circuits, A and B. The PPS signal is carried on circuit A, and the serial packet is connected to the B circuit. Pin Assignments The 8-pin RJ45 connector pin assignments and plugs and sockets are shown below:...
Page 39: Chapter 6: Data Formats
EDM 01-18 DAG 4.5G2/G4/GF Card User Guide Chapter 6: Data Formats Overview DAG Cards produce trace files in their own native format called ERF (Extensible Record Format). The ERF type depends upon the type of connection you are using to capture data. The DAG 4.5 supports the following ERF Types: Description Type...
Page 40: Type-2 Record
EDM 01-17 DAG 4.5G2/G4/GF Card User Guide The fields are described below: Generic Header (cont.) timestamp The time of arrival of the cell, an ERF 64-bit timestamp. See Timestamps Chapter 5: Synchronizing Clock Time earlier in this User Guide for more information. type One of the following: TYPE_ETH...
Page 41: Type 16 Record
EDM 01-18 DAG 4.5G2/G4/GF Card User Guide Type 16 Record The TYPE_DSM_COLOR_ETH record is shown below: Byte 3 Byte 2 Byte 1 Byte 0 timestamp timestamp type 16 flags rlen color wlen offset (rlen - 18) bytes of record The TYPE_16 color field is divided into several bit fields as shown below: Bits Attribute Receive stream 0-63...
Page 43: Chapter 7 Troubleshooting
EDM 01-18 DAG 4.5G2/G4/GF Card User Guide Chapter 7 Troubleshooting Reporting If you have problems with a DAG card or Endace supplied software which you are unable to resolve, please contact Endace Customer Support at Problems support@endace.com. Supplying as much information as possible enables Endace Customer Support to be more effective in their response to you.
Page 45: Version History
EDM 01-18 DAG 4.5G2/G4/GF Card User Guide Version History The version history for this user guide is shown below. Version Date Reason April 2006 DAG 4.5GF information added. Changes to formatting and layout. August 2006 DAG 4.5GF information expanded Separate FPGA images for DAG 4.5G2/GF and DAG 4.5G4 Standardization of features with other similar DAG cards.
