TI-5700
VER 101
WEIGHING INDICATOR
OPERATION MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TI-5700 and is the answer not in the manual?

Questions and answers

Summary of Contents for TMT TI-5700

  • Page 1 TI-5700 VER 101 WEIGHING INDICATOR OPERATION MANUAL...

  • Page 2: Digital Weighing Indicator Ti

    (4) To improve the product performance, functions can be changed with no notice. (5) Please understand that TMT does not have responsibility for a demand related to loss, lost profit etc. caused by operating the product, regardless of the third clause.

  • Page 3: Table Of Contents

    DIGITAL WEIGHING INDICATOR TI-5700 INDEX 1. Precautions ..................... 4 2. Introduction ....................5 3. Description of Panels and Symbols ............ 6 4. Installation ...................... 8 5. Calibration ....................12 6. Setting Mode ....................18 7. General Function for Weighing Mode ..........32 8. Weighing check & batching mode ...........36 9.

  • Page 4: Precautions

    DIGITAL WEIGHING INDICATOR TI-5700 1. Precautions Please be informed that we‟re not responsible for any incident or mishap caused by partial modification of this product. To avoid such situation, customers need to contact our customer service team or system installation staff in advance, and any modification should be conducted under our surveillance.

  • Page 5: Introduction

    DIGITAL WEIGHING INDICATOR TI-5700 2. Introduction The TI-5700 is a compact simple batch weighing indicator ◆ Standard functions are as below ◆ ◊ Main display of 6 digit FSTN LCD and LED backlight ◊ 3-stage limit comparison to check a mass value ◊...

  • Page 6: Description Of Panels And Symbols

    DIGITAL WEIGHING INDICATOR TI-5700 3. Description of Panels and Symbols 3.1. Front panel Name Description Display Display the weight data & message Battery Indicates when a battery has to be recharged HI/OK/LO Indicates the results of comparison Zero Indicates when the weight is zero Accumulation Indicates when there is accumulation weigh.

  • Page 7: Rear Panel

    DIGITAL WEIGHING INDICATOR TI-5700 3.2. Rear panel Name Description Battery cover Lithium polymer battery compartment cover Panel bracket Standard panel bracket Option panel cover For OP-01, 02, 03, 04, 05, 06 and 07 Load cell connector Connect the load cell Ground terminal Frame ground (F.G.)

  • Page 8: Installation

    Use only approved power adaptor and batteries. Do not connect incompatible products. Use only batteries, chargers, adaptor, and enhancements approved by TMT for use with this particular model. The use of any other types may invalidate any approval or warranty, and may be dangerous.
  • Page 9 DIGITAL WEIGHING INDICATOR TI-5700 Connect the load cell wire to the connector, at the rear panel ◊ Load cell wire color depends on the manufacturer of load cell, please check the load cell specification. ◊ It is possible to connect a 4 wire cable provided that pins EX+/SEN+ and pins EX-/SEN- are shorted.
  • Page 10 DIGITAL WEIGHING INDICATOR TI-5700 Verifying load cell output and input sensitivity Adapt to the following inequality, when you design a weighing instrument using the indicator and load cells. EV: Excitation voltage [mV] EV × RO × e RO: Rated output [mV/V] 0.2 ≤...
  • Page 11 DIGITAL WEIGHING INDICATOR TI-5700 4.3. Option board install This is the procedure for the OP-01 to OP-07 option board. Step 1. After power off, remove the AC adapter or batteries. Step 2. As shown in the figure below, remove the two screws and the blank panel.

  • Page 12: Calibration

    DIGITAL WEIGHING INDICATOR TI-5700 5. Calibration 5.1. Calibration by a balance weight Step Operation & Description Display How to enter the calibration mode: Press the CAL key which is located behind the CAL cover at the front panel of indicator.
  • Page 13 DIGITAL WEIGHING INDICATOR TI-5700 Span calibration: Place balance weight on the weighing unit. When “LOAD” is displayed, press the ENTER key after the Stable mark has turned on. Do not press the keys while the stable mark is off. Fine adjustment: After span calibration, balance weight is shown on the display.
  • Page 14 DIGITAL WEIGHING INDICATOR TI-5700 5.2. Calibration by voltage parameter of load cell Step Operation & Description Display How to enter the calibration mode: Press the CAL key which is located behind the CAL cover at the front panel of indicator.
  • Page 15 DIGITAL WEIGHING INDICATOR TI-5700 5.3. Multi calibration (5 weighing point) Even if the single calibration has been completed, there may still remain a linearity deviation caused by the performance of the weighing unit. The multi calibration can rectify or reduce the linearity deviation using weighing points during the zero and capacity setting.
  • Page 16 DIGITAL WEIGHING INDICATOR TI-5700 span calibration: Place 1 balance weight on the weighing unit. When “LOAD1” is displayed, press the ENTER key after the Stable mark has turned on. Do not press the keys while the stable mark is off.
  • Page 17 DIGITAL WEIGHING INDICATOR TI-5700 5.4. Gravity compensation This function allows it to be calibrated in one location and then adjusted to match the acceleration of gravity at another location where it will be used. Step Operation & Description Display How to enter the calibration mode: Press the CAL key which is located behind the CAL cover at the front panel of indicator.

  • Page 18: Setting Mode

    DIGITAL WEIGHING INDICATOR TI-5700 6. Setting Mode 6.1. How to enter To enter the function settings, do either of the following. A) When the display is off, press ON/OFF key while pressing the TARE key. B) When in the weighing mode, press and hold the TARE key for more 2 seconds.
  • Page 19 DIGITAL WEIGHING INDICATOR TI-5700 ◊ F02: Zero tracking (0~10) Value Description The zero tracking function will automatically bring the 0.5d/1sec. display back to zero when there are small deviations. 1.0d/1sec. 1.5d/1sec. For example: F02-02 setting. 2.0d/1sec. As shown in the figure below, display will automatically 2.5d/1sec.
  • Page 20 DIGITAL WEIGHING INDICATOR TI-5700 ◊ F05: Buzzer beep (0~3) Value Description Not used When LO lamp is on When OK lamp is on When HI lamp is on buzzer beep time: 2times/sec. ◊ F06: Backlight conditions (0~2) Value Description Manual ON/OFF...
  • Page 21 DIGITAL WEIGHING INDICATOR TI-5700 Key & external input ◊ F10: Zero key operating range (0,1) Value Description ±2% The ZERO key is activated within ±2% or ±20% of full capacity. ±20% ◊ F11: F1 key function (0~9) Value Description Not used...
  • Page 22 DIGITAL WEIGHING INDICATOR TI-5700 ◊ F13: External input 1 function (0~12) Value Description Not used ZERO key TARE key NET/GROSS key F1 key F2 key Serial data output (Included in ZigBee wireless output) Print data output (Included in ZigBee wireless output)
  • Page 23 DIGITAL WEIGHING INDICATOR TI-5700 Accumulation & hold operation ◊ F16: Accumulation mode (0~3) Value Description Manual (+ only) Manual (+/-) The selection for the way of adding data. Automatic (+ only) Automatic (+/-) ◊ F17: Set inhibition range for accumulation (0~4)
  • Page 24 DIGITAL WEIGHING INDICATOR TI-5700 Comparator & batch mode ◊ F21: Comparator mode (0~9) Value Description Not used Limit mode Weight check mode Checker mode Limit type checker mode Normal batching 1 Customer programmed control Normal batching 2 Loss in weight batching...
  • Page 25 DIGITAL WEIGHING INDICATOR TI-5700 ◊ F25: Start delay time of finish signal for F21: 4,7 (00~99) Value Description 0.0 sec. It is used when delay time of output is set after Final. 4.0 sec. (Works only when the weight is stable) 9.9 sec.
  • Page 26 DIGITAL WEIGHING INDICATOR TI-5700 RS232C (I) / RS422, 485 / Current loop output ◊ F33: Baud rate (0~2) Value Description 2400 bps (If current loop output is selected, it is fixed at 2400bps) 4800 bps 9600 bps ◊ F34: Data bits, parity (0~2)
  • Page 27 DIGITAL WEIGHING INDICATOR TI-5700 ◊ F38: Output mode (0~5) Value Description No data output Stream mode Transmit only in stable state (Data can be sent after the weight data enters the inhibition range of setting mode F17) Manual mode (Refer to F11,F12-2,3) Command mode (Refer to “11.
  • Page 28 DIGITAL WEIGHING INDICATOR TI-5700 RS232C (II) ◊ F42: Baud rate (0~2) Value Description 2400 bps 4800 bps 9600 bps ◊ F43: Data bits, parity (0~2) Value Description Data 8 bits, Stop 1 bit, Non parity Data 7 bits, Stop 1bit, Even parity Data 7 bits, Stop 1bit, Odd parity ◊...
  • Page 29 DIGITAL WEIGHING INDICATOR TI-5700 ◊ F47: Output mode (0~5) Value Description No data output Stream mode Transmit only in stable state (Data can be sent after the weight data enters the inhibition range of setting mode F17) Manual mode (Refer to F11,F12-2,3) Command mode (Refer to “11.
  • Page 30 DIGITAL WEIGHING INDICATOR TI-5700 Real time clock ◊ F51: Year and date change Description Date Input the date (141013: October 13 2014) ◊ F52: Time change Description Input the date (183125: 6:31:25PM) Time Analog output & BCD output ◊ F53: Output data (0~2)
  • Page 31 DIGITAL WEIGHING INDICATOR TI-5700 ◊ F56: Weight value at 20mA or 10V output (0 to 999999) Value Description Input the weight value at 20mA or 10V. 999999 ◊ F57: BCD Output logic (0,1) Value Description Positive logic Negative logic USB host ◊...

  • Page 32: General Function For Weighing Mode

    DIGITAL WEIGHING INDICATOR TI-5700 7. General Function for Weighing Mode 7.1. Zero Use to correct drifted zero value when the scale is unloaded, and motion is not detected. This function works when ZERO key is pressed, and the ZERO mark turns on.
  • Page 33 DIGITAL WEIGHING INDICATOR TI-5700 7.3. Accumulation The function accumulates weight data and stores the total data and the accumula- tion count. Data is not stored in the memory. Selection of accumulation mode (Refer to F16 of setting mode) There are two methods of accumulation; manual accumulation using the key assigned to operate the accumulation and automatic accumulation.
  • Page 34 DIGITAL WEIGHING INDICATOR TI-5700 Clearing the accumulated data Step1. Press and hold the ACCUMULATION key for more 2 seconds. TOTAL is displayed and the total data is displayed with the ▼ mark blinking. Step2. Press the ZERO key. Then the display blinks once and the accumulated data and count are cleared.
  • Page 35 DIGITAL WEIGHING INDICATOR TI-5700 7.4. Hold There are three methods of hold; average hold, auto average hold and peak hold. Average hold (F18-0) ◊ Manual hold function Step1. Press HOLD key after loading a thing. Step2. Sequentially the message of ------ is shown with appearing the average weight.

  • Page 36: Weighing Check & Batching Mode

    DIGITAL WEIGHING INDICATOR TI-5700 8. Weighing check & batching mode If you do not select OP-01, the HI/OK/LO lamps are displayed without relay ◆ output There are eight code memory for the item code (0 through 7), and each code ◆...
  • Page 37 DIGITAL WEIGHING INDICATOR TI-5700 Checker mode (F21-2) When the scale is stable, LO, HI and OK relays is ON and it is OFF after 1.5sec. The operation of the display lamp and the relay are the same. Limit type checker mode (F21-3) The operation of the display lamp and the relay are the same.
  • Page 38 DIGITAL WEIGHING INDICATOR TI-5700 8.2. Customer programmed control Normal batching 1 (F21-4) Relay OK output can be changed to Over/Under/Finish by setting F24. HI, OK outputs operate in more than 5division. ◊ Relay output signal is as follows. 1. Press TARE key so that the display shows 0kg.
  • Page 39 DIGITAL WEIGHING INDICATOR TI-5700 Normal batching 2 (F21-5) ◊ Relay output signal is as follows. 1. Press TARE key so that the display shows 0kg. 2. Preliminary: It is ON when the net weight is greater than the weight (Final – Preliminary).
  • Page 40 DIGITAL WEIGHING INDICATOR TI-5700 Loss in weight batching (F21-6) Relay OK output can be changed to Over/Under/Full by setting F24. HI, OK outputs operate in more than 5division. ◊ Relay output signal is as follows. 1. Full: It is ON when the gross weight is greater than Full weight and OK lamp turns on.
  • Page 41 DIGITAL WEIGHING INDICATOR TI-5700 8.3. Built in automatic program Normal batching 1 (F21-7) Relay OK output can be changed to Over/Under/Finish by setting F24. HI, OK outputs operate in more than 5division. ◊ Relay output signal is as follows. 1. Press TARE key so that the display shows 0kg.
  • Page 42 DIGITAL WEIGHING INDICATOR TI-5700 Normal batching 2 (F21-8) ◊ Relay output signal is as follows. 1. Press TARE key so that the display shows 0kg. 2. Start input: Preliminary, Final output are ON when start input is ON. 3. Preliminary: It is OFF when the net weight is greater than the weight (Final –...
  • Page 43 DIGITAL WEIGHING INDICATOR TI-5700 Loss in weight batching (F21-9) Relay OK output can be changed to Over/Under/Full by setting F23. ◊ Relay output signal is as follows. 1. Full: It is ON when the gross weight is greater than Full weight and OK lamp turns on.

  • Page 44: Test Mode

    DIGITAL WEIGHING INDICATOR TI-5700 9. Test Mode 9.1. How to enter When the display is off, press ON/OFF key while pressing the ZERO key. Then this test mode is stared. Step 1. “TEST 1” message is shown on the display after “TEST” message.
  • Page 45 DIGITAL WEIGHING INDICATOR TI-5700 ◊ TEST 4: Backlight test Display Description LIHGT The ZERO key toggles turns on and off of the backlight. ◊ TEST 5: Solid state relay output and inputs test Display Description I0--O0 Wait for output and input.

  • Page 46: Solid State Relay And Control Inputs (Op-01)

    DIGITAL WEIGHING INDICATOR TI-5700 10. Solid State Relay and Control Inputs (OP-01) 10.1. External input ◊ The control inputs can control the indicator from an external terminal just like the front panel key operations. ◊ Set the external control functions at F13~15 of the setting mode.

  • Page 47: Rs-232C Interface (Op-02)

    DIGITAL WEIGHING INDICATOR TI-5700 11. RS-232C Interface (OP-02) 11.1. Specifications ◊ Method: Full-duplex, asynchronous transmission format ◊ Baud rate: 2400, 4800, 9600, 19200, 38400, 57600, 115200 bps ◊ Data bit: 7, 8 bits ◊ Parity bit: Even or Odd (For 7 data bits) or Non parity (For 8 data bits) ◊...
  • Page 48 DIGITAL WEIGHING INDICATOR TI-5700 ◊ Format 2 (22 bytes – CAS company standard) Header 1 Header 2 Data Unit Terminator , G S , Lamp status Stable weight data (0x53) (0x54) Unstable weight data (0x55) (0x53) Header 1 Overload (0x4F) (0x4C)
  • Page 49 DIGITAL WEIGHING INDICATOR TI-5700 11.3. Command mode ◊ When performing a command, the received command or reply data is sent back ◊ Command protocols Start code Command End code STX (0x02) ASCII data ETX (0x03) In response protocols do not have start code and end code.
  • Page 50 DIGITAL WEIGHING INDICATOR TI-5700 Commands to control the indicator Function Command Response Zero (Same as ZERO key) Tare (Same as TARE key) Display Gross Data Display Net Data F1 (Same as F1 key) F2 (Same as F2 key) Accumulation Clear Accumulated Data Changing the Code Memory (0~7) e.g., code memory 3...

  • Page 51: Rs-422/485 Interface (Op-03)

    DIGITAL WEIGHING INDICATOR TI-5700 12. RS-422/485 Interface (OP-03) RS-422/485 is to transmit the signal by the voltage variation. ◆ So, it is more safety than other for an electric noise. Recommended distance is in 1.2km. ◆ 12.1. Specifications ◊ Method: Full-duplex, asynchronous transmission format ◊...

  • Page 52: Analog Output (Op-04)

    DIGITAL WEIGHING INDICATOR TI-5700 13. Analog Output (OP-04) TI-5700 has two analog output modes (4~20mA / 0~10V). ◆ But two types of analog output can‟t be used simultaneously. The analog output option is for sending the weight data to an analog input unit.

  • Page 53: Current Loop Output (Op-05)

    DIGITAL WEIGHING INDICATOR TI-5700 14. Current Loop Output (OP-05) The current loop output can be used to output data to a sub display unit. ◆ The output terminals don‟t have a polarity. ◆ The current loop output is of the passive type and requires an external current ◆...

  • Page 54: Bcd Output (Op-07)

    DIGITAL WEIGHING INDICATOR TI-5700 16. BCD Output (OP-07) Parallel BCD output is the interface that transmits the weight as BCD code. ◆ (e.g., In case of BCD 003782, it transmits 0000 0000 0011 0111 1000 0010) Inner circuit is electronically disconnected by photo coupler.
  • Page 55 DIGITAL WEIGHING INDICATOR TI-5700 Adaptable connector: Amphenol 57-30500 (Male) ◆ Signal Signal High: Net / Low: Gross N.C. N.C. N.C. N.C. 1x10 N.C. 2x10 N.C. 3x10 N.C. 4x10 N.C. 1x100 N.C. 2x100 N.C. 3x100 External VCC 4x100 N.C. 1x1,000 External VCC 2x1,000 N.C.

  • Page 56: Usb Host (Op-08)

    DIGITAL WEIGHING INDICATOR TI-5700 17. USB Host (OP-08) The USB host option is for sending the weight data to USB memory or PC. ◆ Settings: Refer to F11, F12 and F57 of setting mode. ◆ 17.1. Specifications ◊ Method: Full-duplex, asynchronous transmission format ◊...
  • Page 57 DIGITAL WEIGHING INDICATOR TI-5700 Example: 140506.csv (Comma separated value - Excel file format) Stable weight data Unstable weight data Header Overload Hold weight data Gross data Net data (22 bytes – F57 2) Format 2 22 bytes - CAS company standard (Refer to 10.2. Data format) 17.3.

  • Page 58: Zigbee Wireless (Op-09)

    DIGITAL WEIGHING INDICATOR TI-5700 18. ZigBee (OP-09) The ZigBee can be used to output data to a sub display unit or PC by wireless. ◆ Using TF200 dongle, wireless data can be transmitted to the PC. ◆ TMT‟s Sub display In case of other brand‟s sub display, must be used...
  • Page 59 DIGITAL WEIGHING INDICATOR TI-5700 19. Bluetooth (OP-10) The Bluetooth can be used to output data to a smart phone. ◆ Smart phone If you select this option, smartphone applications Bluetooth is provided. (Refer to additional manual) Specifications ◆ Fully qualified with Bluetooth v2.0 +EDR...

  • Page 60: Rechargeable Li-Po Battery (Op-11)

    DIGITAL WEIGHING INDICATOR TI-5700 20. Rechargeable Li-Po Battery (OP-11) Connect the battery ◆ Step 1. Remove the battery cover; pull the top cover out. Step 2. Connect the power jack to the OUT port from indicator. Charging the battery ◆...

  • Page 61: Bluetooth Wireless (Op-10)

    DIGITAL WEIGHING INDICATOR TI-5700 21. Specifications General ◆ Display 6 digit FSTN LCD (Height: 30mm) Backlight Amber LED backlight Operating temperature -20℃ ~ 60℃ Operating humidity 85% R.H. (No condensation) Net weight Approx. 700g AC/DC Adaptor 12V Power Less than 10VA...
  • Page 62 DIGITAL WEIGHING INDICATOR TI-5700 Dimensions ◆ - 62 -...

  • Page 63: Check Message

    DIGITAL WEIGHING INDICATOR TI-5700 22. Check Message In weighing mode ◆ Code Description The calibration data isn‟t executed. CH 01 Perform the required specification again in calibration mode. The Load cell is connected wrongly or A/D conversion part has a CH 02 fault.
  • Page 64 DIGITAL WEIGHING INDICATOR TI-5700 [MEMO] - 64 -...
