Morris 72914 Installation Instructions Manual

Catalog Number 72914
UPC Number 60198672914
Description Low Profile Emergency Lighting Ballast
1400 Lumen
T5 & T8 Fixtures

Features

For both normal and emergency Flourescent lighting.
In the event of a Power Failure, the Ballast Switches to the Emergency Mode
and operates one or two of the existing lamps for a minimum of 90 minutes.
Low Profile (Rated for T5 & T8 Ballasts - includes a Time Delay function)
Time Delay Feature for end of life circuitry to prevent AC Ballast from shutting
down when transitioning from Emergency to AC
Open circuit insulation feature to protect unit when load is absent
Contains a Ni-Cad Battery, Charger, and Inverter Circuit in a single package.
Can be mounted in the wireway or on top of the fixture.
90 minute minimum emergency power, 24 hour recharge time
Temperature Range: 20
120/277 Volt
60 Hz
UL listed for factory installation or retrofit applications
UL Listed Damp Location
Standard Ballasts
Low Profile ballasts are rated for use with:
D30T5 & T8 single or bi-pin 1 or 2 lamp
18-50W 4-Pin Long Compact
32W 4-Pin Compact
24-32W U-Bend FBT8 lamps from Phillips, GE & Osram or equal
Compatible with most one, two, three & four lamp electronic
standard energy saving & dimming AC ballasts
Compatible with Instant Start & Rapid Start Ballasts.
General
Housing:
Finish:
Lamp Type:
Battery :
Emergency Power:
Dimension Information
Length:
Height:
Depth:
Specifications
Temperature Rating:
Voltage Rating:
Flammability Rating:
Frequency:
Input Wattage:
Wattage Rating:
Battery:
Packaging
Box Qty
Certifications
UL
cUL
RoHS
Morris Products 53 Carey Road, Queensbury, NY 12804
o o
C to 50 C
Galvanized Steel
Powder Coat
1 or 2 Lamp, 2' - 8' T5, T8
Ni-Cad
90 minutes
14.20"
1.0"
2.0"
o o
20 C to 50 C
120/277 V
N/A
60 Hz
3.25-3.78
14-54 Watt Per Lamp
14-39 Watt per Lamp 2 Lamps
9.6V, 19.2 Wh, 2500 mA
1
UL 924
Yes
Yes
