Piranha Panoramic Holder
Getting Started
Congratulations to your new Piranha OPG Holder from RTI. The Piranha OPG Holder is
specially designed for attaching the Piranha to dental panoramic equipment. The holder can
also with advantage be used for other purposes where the Piranha has to be attached to a
surface, e.g. Dental Cone Beam CT units, or a wall bucky.
The Piranha Panoramic Holder consists of the following parts:
1.
1 holder base with fine adjustment lever and position markers
2.
1 fluorescent position guide with scales
3.
2 adjustable strap with clips and suction cup
4.
2 magnets
1
2
The Piranha Panoramic holder can be mounted in different ways. The images above show
from left to right – The Holder Base mounting with straps, and with magnets.
9644507-00 Getting Started Piranha Pan Holder v4, 2017.1A.
3
4
Page 1
