Vision X Solstice Solo Series Installation Instructions

Package Contents;

1. Solstice Solo Series Pod
2. Wiring Pigtail with Deut
3. Universal Stud Mount
4. Horizontal Omn
5. Allen Wrench

Required Tools;

1. ¼" Drill Bit
2. 10mm Socket and Ratchet
3. 10mm Open End Wrench
4. (2) 16 Gau ge Barrel Crimps or Soldering Iron, Solder and Heat Shrink
5. Crimper
6. Wire Stripper
7. Included Allen Wrench

Mounting Instructions;

1. Drill ¼" Hole in desired mounting location.
a. Note – The center of your hole will be the exact ce
measure the location of your hole before drilling.
b. Note – If you are linking multiple pods together using the included Omni-Link conn
carefully read linking in
placement of mounts.
2. Insert stud mount through the ¼"
to a maximum torque of 20 ft/lb.
a. Note – DO NOT use air impact tool as they will damage the stainless threads.
3. Remove adjustment set screws if installed on adjustment bracket. Tighten the adjustment
nylock snug against the bracket and aim the light to desired position. After the light is aimed,
tighten the adjustment bolt and nylock to a maximum torque of 20 ft/lb. I
hand tighten adjustment set screws for use in high vibration scenarios.
