Connecting your Genee Vision visualiser to a projector
You can simply use your visualiser as a presentation
tool with a single connection to a projector.
You will need:
The power pack
The VGA cable
This is the simplest of all the
set-ups. There will be situations
where mobile projectors are
being used and all that is
required is the visualiser
image to be displayed.
The built-in functionality of the
visualiser means that the
projected image can be frozen,
split, mirrored etc.
Alternatively, with a fixed
projector there will most likely be
a connecting wall plate that the
VGA lead will plug into.
P.S. Don't forget to take the lens
cap off!
The remote control is slotted into
the side of the visualiser.
PROJECTOR
Wall
plate
VGA
cable
VISUALISER
'PROJECTOR'
'12V IN'
VGA
Visualiser 'PROJECTOR'
socket
VGA
cable
Visualiser
'PROJECTOR'
socket
