Operation, Installation and Service Manual
Rudder Angle Indicator System
05014-0128-01; 056357/B; 05 Oct 2017
Northrop Grumman Sperry Marine B.V. (Representative Office)
Woltmanstr. 19 • D-20097 • Hamburg, Germany
Tel.: +49-40-299 00-0 • Fax: +49-40-299 00-146 • E-mail: service.eu@sperry.ngc.com
RUDDER
RUDDER
RUDDER
X
RUDDER
RUDDER
RUDDER

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Rudder Angle Indicator System and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Sperry Marine Rudder Angle Indicator System

  • Page 1 Operation, Installation and Service Manual RUDDER RUDDER RUDDER RUDDER RUDDER RUDDER Rudder Angle Indicator System 05014-0128-01; 056357/B; 05 Oct 2017 Northrop Grumman Sperry Marine B.V. (Representative Office) Woltmanstr. 19 • D-20097 • Hamburg, Germany Tel.: +49-40-299 00-0 • Fax: +49-40-299 00-146 • E-mail: service.eu@sperry.ngc.com...
  • Page 2 This document and the information herein is and remains the intellectual property of Northrop Grumman Sperry Marine B.V. [NGSM BV] and its associate companies and may not be copied, reproduced or translated without the express permission of NGSM BV. A limited license is grant- ed for the user to reproduce this documentation for his own internal use, but not for distribution to third parties.

  • Page 3: Table Of Contents

    RAIS 056357/B Contents Chapter 1: Introduction System Description................... 1-1 Intended Use ..................... 1-1 Not Intended Use ..................1-1 Design and Main Features................ 1-2 Principle of Operation ................1-3 RAIS Overview ..................1-4 System Components................. 1-4 RAIS Technical Data .................. 1-6 Declaration of Conformity ................

  • Page 4: Table Of Contents

    056357/B RAIS In- and Output Calibration..............6-12 Input Calibration Table ................6-14 Output Calibration Table ................. 6-14 General Remarks on Calibration ............6-15 Initial Calibration ..................6-16 Adding, Editing and Deleting Calibration Points ........6-22 Input Calibration using Dummy Values ..........6-24 Chapter 7: Troubleshooting General Troubleshooting Instructions .............

  • Page 5: Safety Instructions

    RAIS 056357/B Safety Instructions Safety Notice Conventions The following safety notice conventions are followed throughout this manual: A Danger notice contains an operating or main- DANGER tenance procedure, practice, condition, state- ment, etc., which, if not strictly observed, will result in injury or death of personnel. A Warning notice contains an operating or WARNING maintenance procedure, practice, condition,...
  • Page 6 Note All content of the appended third party documentation is on behalf of the owners of the documentation. Sperry Marine is not responsible and not liable for any content of third party documentation. In case of doubt, verify the content of third party documentation with the owners of the documentation.
  • Page 7 RAIS 056357/B General Safety Information for Service Personnel DANGER Life danger through electrical shock Certain alarm devices may operate with hazardous voltages, switched by the alarm relay output contacts. NEVER connect live wires to the unit’s terminals, when wiring up the Rudder Angle Calibrator.
  • Page 8 056357/B RAIS CAUTION Risk of damage As the feedback potentiometer supply voltage is provided by the Rudder Angle Calibrator, connecting the RAC to a feedback potentiometer in par- allel to any device other than a second Rudder Angle Calibrator bears the risk of damage in case of wire breaks or short-circuits.

  • Page 9: System Description

    Chapter 1: Introduction 1.1 System Description Intended Use The Sperry Marine Rudder Angle Indicator System (RAIS) is a system for electric rudder angle indication on maritime vessels and must be oper- ated only from appropriately trained and educated personnel familiar with all mandatory safety and operating procedures.

  • Page 10: Design And Main Features

    056357/B RAIS 1.2 Design and Main Features The Sperry Marine Rudder Angle Indicator System(RAIS) is a system for electric rudder angle indication on maritime vessels. The Rudder Angle Indicator System has been type approved by DNV GL SE based on the...

  • Page 11: Principle Of Operation

    RAIS 056357/B In dual-rudder systems, RACs for the port and starboard rudder are used in a paired configuration. Each unit reads the feedback signal and drives the analogue outputs for its own side. Through a crosslink, it also reads the other unit’s digital output and produces a $--RSA sentence including port and starboard rudder angles according to IEC 61162 (NMEA 0183).

  • Page 12: Rais Overview

    056357/B RAIS 1.4 RAIS Overview The Sperry Marine Rudder Angle Indicator System (RAIS) in total con- sists of the Rudder Angle Calibrator (RAC), a microprocessor-controlled signal conditioning device for electric rudder angle indicators, a series of different Rudder Angle Indicators RAI) types and a series of Rudder Angle Feedback Units (RAFU) including limit switches and lever link- ages.
  • Page 13 RAIS 056357/B System Component Name Stock No. Limit Switches (inside 074723-0000-000 RAFU housing, not shown) Lever Linkage 020508-0000-000 022501-0000-000 Note For all details regarding the Rudder Angle Indicators, refer to the third party documentation from the supplier Faiveley Mors Smitt, as listed in the appendix of this manual.

  • Page 14: Rais Technical Data

    24 VDC RAC max. ripple content - 10 – + 20% Vpp RAC power consumption 3 W max. Rudder Angle Indicator System 15 W max. in total, power consumption for rudder angle indicator illumi- nation via RAC: RAC Magnetic Clearance to standard magnetic compass 0.30 m...
  • Page 15 RAIS 056357/B RAC Signal and Data Inputs rudder angle feedback input Wiper signal from rudder angle feedback potentiometer; ±15 VDC supply voltage provided by RAC. RS-422 input NMEA 0183 / IEC 61162; other side’s rudder angle in dual rudder systems ($--RSA) RAC Signal, Data and Status Outputs analogue rudder angle outputs six independently calibratable...
  • Page 16 056357/B RAIS RAC Service I/O Port USB service port Connects to a Windows host PC through a vendor-specific USB communications device class driver. The Rudder Angle Calibra- tor is accessed via the “SUSI” application, using a proprietary data protocol. RAIS Technical Data...

  • Page 17: Declaration Of Conformity

    Maritime and Hydrographic Agency of Germany. Note The current issue of the detailed Marine Equipment Directive EC Declara- tion of Conformity of Northrop Grumman Sperry Marine B.V. Hamburg is part of the client CD stock no. 56 800. For further details please contact: Northrop Grumman Sperry Marine B.V.
  • Page 18 056357/B RAIS 1-10 Declaration of Conformity...

  • Page 19: Normal Operational Mode

    RAIS 056357/B Chapter 2: Operation The RAC possesses no user-accessible controls. Once installed and properly configured, it will take up operation unattended, as soon as power is applied to the RAIS. Likewise, no special procedures need to be followed to power off the system.
  • Page 20 056357/B RAIS Normal Operational Mode...

  • Page 21: Alarm Indication

    RAIS 056357/B Chapter 3: Alarms System CAUTION Risk of misusage The ALR sentence as serial output of the RAC is not MED complaint and therefore NOT allowed as system setting for a ship under wheelmark certification. Always make sure that the ALR sentence setting is INACTIVATED when the RAC is used on a ship under wheelmark certification.
  • Page 22 056357/B RAIS Note The RAC does not support remote alarm acknowledgement via the $--ACK sentence. Alarms will be transmitted as being “not acknowl- edged”, even if acknowledged locally at the receiving end. Alarm Indication...

  • Page 23: Alarm Numbers

    Note Currently, $--ALR sentences are only generated in case of data I/O errors. If the RAC exhibits malfunction without generating a corresponding $--ALR sentence, contact Sperry Marine Service (Net) for troubleshooting assistance. Table 3-1: Error Error Text...
  • Page 24 056357/B RAIS Error Error Text Cause Corrective Action "no nmea message expected NMEA If RAC is not used in received (RxD1)" sentences not re- dual rudder system, ceived disable the RS-422 input. In dual rudder sys- tem, check configu- ration of other side’s RAC (baud rate, selected sen- tences);...

  • Page 25: Viewing Rac Errors Through Susi

    RAIS 056357/B 3.3 Viewing RAC Errors through SUSI When connected to the RAC, the Sperry Universal Service Instrument application (SUSI) provides an “Errors” page which displays current state and counts the occurrence of the alarms listed in table above: Figure 3-1: SUSI’s Error Page for the RAC For more information on the SUSI application, refer to chapter 6 (Sys-...
  • Page 26 056357/B RAIS Viewing RAC Errors through SUSI...

  • Page 27: Maintenance By Shipboard Personnel

    4.2 Maintenance by Service Personnel If re-calibration of the RAC is required, field service attendance must be requested from Sperry Marine directly or through an authorized Sperry Marine service representative. Note The RAC is re-calibrated using the Sperry Universal Service Instrument (SUSI).
  • Page 28 056357/B RAIS Maintenance by Service Personnel...

  • Page 29: Mechanical Installation

    056357/B Chapter 5: Installation 5.1 Mechanical Installation The RAC is to be installed at a protected location. In most cases, it will be placed inside a bridge console or bulkhead mounted in the vicinity of the connected RAIs. Attach the RAC to a level surface with four M6 screws (or nuts and bolts).

  • Page 30: Rudder Angle Feedback Unit Potentiometer

    056357/B Rudder Angle Feedback Unit Potentiometer WARNING Risk of injury Connecting the Rudder Angle Calibrator to a rudder angle feedback unit in parallel with the steering gear feedback loop bears the risk of malfunc- tion of the steering gear in case of wire breaks or short-circuits resulting in possible injury and/or damage.
  • Page 31 RAIS 056357/B Chapter 6: System Configuration DANGER Life danger through electrical shock Certain alarm devices may operate with hazardous voltages, switched by the alarm relay output contacts. During configuration, the Rudder Angle Calibrator must be operated with the housing open. Make sure that any external device or power supply connected to the alarm relay outputs is de-energized and safe- guarded against accidental switching-on.

  • Page 32: Initial System Configuration

    056357/B RAIS 6.1 Initial system configuration Configuring the RAC with SUSI 1. If the RAC is currently powered up, switch off the power first. 2. Open the RAC housing and locate the USB service port receptacle, J3, on the PCB. Make sure that the port is freely accessible for plug- ging and unplugging the USB cable.
  • Page 33 RAIS 056357/B 8. Plug in the USB cable at the PC and at the RAC’s service port. The “Online” button should now become clickable (not greyed-out), indicating that SUSI has found a device to connect to: The LED icon next to the button will remain grey, as no connection has been made yet.
  • Page 34 056357/B RAIS 11. If you clicked in the previous step, a dialogue box will pop up, asking whether the parameters should be saved as default set- tings for this device: Click . to save the parameters as default settings or click to cancel.
  • Page 35 RAIS 056357/B 17. Determine the calibration accuracy attained through the initial cali- bration. For this purpose, compare the actual angle at the rudder stock with the angles displayed at the RAIs. In conformance with the requirements of ISO 20673, the angles should be recorded every 5°...

  • Page 36: System Parameters

    056357/B RAIS 6.2 System Parameters The Rudder Angle Calibrator application Main page contains a number of settable interface controls. These are used to configure the RAC’s basic system parameters as required for the installation at hand. The settable system parameters fall into three groups, the Feedback Type setting, the Serial I/O settings and the Relay Setup.

  • Page 37: Feedback Type

    RAIS 056357/B Feedback Type Selects the type of the input feedback signal. Setting: single rudder The input signal is read from the feedback unit of a single rudder steering gear. The RAC’s serial data outputs transmit the own rudder angle as the “starboard (or single) rudder sensor angle”...

  • Page 38: Serial I/O

    056357/B RAIS Serial I/O These settings configure the RAC’s serial data ports. RS-422 In Configures the RS- 422 serial data input. Baudrate Selects the receive baudrate. Settings: 4800 Baud Data is received at 4800 Baud (standard according to NMEA / IEC 61162-1). 9600 Baud Data is received at 9600 Baud (non-standard).
  • Page 39 RAIS 056357/B RS-422 Out 1 Configures the RS- 422 serial data output 1 (rudder angle output). Baudrate Selects the transmit baudrate. Settings: 4800 Baud Data is transmitted at 4800 Baud (standard according to NMEA / IEC 61162-1). 9600 Baud Data is transmitted at 9600 Baud (non-standard).
  • Page 40 056357/B RAIS RS-422 Out 2 Configures the RS- 422 serial data output 2 (VDR output). Baudrate Selects the transmit baudrate. Settings: 4800 Baud Data is transmitted at 4800 Baud (standard according to NMEA / IEC 61162-1). 9600 Baud Data is transmitted at 9600 Baud (non-standard).

  • Page 41: Relay Setup

    RAIS 056357/B Settings: Transmit the rudder angle(s) using the $--RSA sentence. Select (check) this option to activate transmission of the $-- RSA sentence at the RS-422 serial output 2. De-select (uncheck) this option to disable transmission of the $--RSA sentence at the RS-422 serial output 1. Settings: Transmit the RAC’s set alarm state using the $--ALR sentence.

  • Page 42: In- And Output Calibration

    056357/B RAIS 6.3 In- and Output Calibration WARNING Risk of personal injury To calibrate the feedback input, the rudder has to be moved over its entire range. Always make sure that the steering gear is operative and that the rudder may be actuated safely without any risk of personal injury or damage to equipment, especially when the vessel is drydocked and works are carried out by shipyard personnel.
  • Page 43 RAIS 056357/B Figure 6-2: Controls on the RAC calibration page Input Calibration Controls: Rudder Angle dial and spin box Calibration Point spin box Delete and Save buttons Output Calibration Controls: Rudder Angle Indicator dial and spin box Calibration Point spin box Delete and Save buttons Output Digit sliders and spin boxes Note...

  • Page 44: Input Calibration Table

    056357/B RAIS Input Calibration Table To compensate for possible misalignment of the feedback unit and non- linearity of the feedback potentiometer, the RAC permanently applies correction to the input value, according to a stored calibration table. The input calibration table contains a number of calibration points, each of which maps a feedback input value to the corresponding true rudder angle, as read from the rudder stock scale.

  • Page 45: General Remarks On Calibration

    RAIS 056357/B General Remarks on Calibration With regard to the RAC in- and output calibration using SUSI, observe the following points: • Port rudder angles are displayed as negative numbers in SUSI. Accordingly, port angles must also be entered as negative numbers, prefixed with a minus sign.

  • Page 46: Initial Calibration

    At least three input and three output calibration points must be set to make the outputs become functional. Sperry Marine recommends to carry out an initial calibration directly after the basic configuration parameters have been set. During this initial calibration, input calibration points are to be set at the hardover and midships rudder positions.
  • Page 47 RAIS 056357/B To carry out the initial calibration: 1. If not already connected, connect to the RAC with SUSI now, as described in “Configuring the RAC with SUSI”, steps 1 through 12, starting on page 6-2. 2. Click on the “Calibration” tab of the Rudder Angle Calibrator applica- tion to enter the calibration page.
  • Page 48 056357/B RAIS 8. Read the exact rudder angle from the rudder stock scale and enter it in the input calibration rudder angle control: enter exact angle read from rudder stock scale 9. Click to set a new calibration point. 10. Put the rudder to the hardover starboard position. 11.
  • Page 49 RAIS 056357/B 14. At least three output calibration points must be set now before the calibration page can be quit and the calibration settings are written to the RAC. Note If no RAIs are connected to the RAC at this point in time, zero output val- ues may be entered as a temporary measure, to be able to finish the ini- tial calibration and transfer the calibration settings to the RAC.
  • Page 50 056357/B RAIS enter zero adjust output for exact (rudder midships) rudder midships indication In case no RAIs are connected to the RAC at this point in time, leave all output settings at the default value of 2048. 20. Click to set a new calibration point. 21.
  • Page 51 RAIS 056357/B Note In case dummy signals or zero values have been supplied during the in- or output calibration, the RAC may not be taken into operation yet. The configuration of the unit is not complete before the input has been calibrated using the actual input signal from the feedback potentiometer and the outputs have been calibrated for the individual RAIs installed.

  • Page 52: Adding, Editing And Deleting Calibration Points

    056357/B RAIS Adding, Editing and Deleting Calibration Points After the initial calibration procedures, a performance check of the RAI system may reveal that the required calibration accuracy is not yet attained over the entire rudder angle range. This may happen especially if the feedback lever linkage is poorly aligned or the feedback unit’s shaft runs not exactly parallel to the rud- der stock.
  • Page 53 RAIS 056357/B To edit in- or output calibration points: 1. If not already connected, connect to the RAC with SUSI and enter the RAC application’s calibration page. 2. With the spin control, scroll down the list of existing calibration points to the point you wish to edit. 3.

  • Page 54: Input Calibration Using Dummy Values

    056357/B RAIS Input Calibration using Dummy Values In some installations, it may be required to carry out the output calibra- tion before the input calibration. E. g., if the RAI system is installed and wired up, but the rudder cannot be actuated because the steering gear is not operational.

  • Page 55: General Troubleshooting Instructions

    Defective units must be sent back to Sperry Marine for repair. Field service personnel should limit troubleshooting to the basic checks given below.

  • Page 56: Location Of Parts On The Rudder Angle Calibrator Pcb

    056357/B RAIS Location of Parts on the Rudder Angle Calibrator PCB Figure 7-1 below shows the locations of connectors and diagnostic LED indicators on the RAC. Figure 7-1: CR 33 CR 28 CR 29 CR 23 CR 16 CR 12 CR 9 Location of parts CR 34...

  • Page 57: Diagnostic Leds

    RAIS 056357/B Diagnostic LEDs As an aid in troubleshooting, a number of diagnostic LED indicators are provided on the PCB. These indicate the presence of supply voltages, activities on the serial data I/O lines and the current states of the status output ports.
  • Page 58 056357/B RAIS General Troubleshooting Instructions...

  • Page 59: Updating The Rac Firmware With Susi

    Avoid touching any of the electronic circuitry. is generally not field-serviceable on the com- Rudder Angle Calibrator ponent level. Defective devices must be sent back to Sperry Marine for repair. Maintenance by field service personnel is limited to the software-based configuration and update procedures supported by the Sperry Universal Software Instrument application (SUSI).
  • Page 60 056357/B RAIS Firmware files issued by Sperry Marine will usually be named such that the filename identifies the device type and the firmware revision. The file extension used for firmware files is “ .upd” . To update the Rudder Angle Calibrator firmware: 1.
  • Page 61 RAIS 056357/B Power up the RAC. The “Online” button should now become clickable (not greyed-out), indicating that SUSI has found a device to connect to: The LED icon next to the button will remain grey, as no connection has been made yet. 8.
  • Page 62 056357/B RAIS Note The file open dialogue searches for files with the extension ”.upd” only. In case the update file has been given another extension for any reason, the filename, including the complete access path, must be entered man- ually in the respective text box of the update tab. 10.

  • Page 63: Replacing Alarm Output Relays

    The alarm output relays, K1 and K2, are socketed solid state relays in a 6-pin DIL package. In case of failure, these components can easily be replaced against a new ones. Both relays are photocoupler photo relays (TLP 598GA), available from Sperry Marine Hamburg upon request. Replacing Alarm Output Relays...
  • Page 64 056357/B RAIS Replacing Alarm Output Relays...
  • Page 65 RAIS 056357/B Abbreviations Note The following list contains abbreviations and shortcuts used in this man- ual and in displayed text of CDU menus. 1x1 frame Standard frame 96x96 mm 6 step/° scale measure setting of servomotor A/DO-160 Section A, DO-160E, Environmental Conditions and Test Procedures for Airborne Equipment Acknowledge alarms Name of a Programming Language...
  • Page 66 056357/B RAIS CAL. Calibration Central Alert Management cal. no. s. Calibration numbers CCFL Cold Cathode Fluorescent Lamp Compass Controller Unit processor Control and Display Unit CompassNet CN Ringbus CompassNet Ethernet Bus CNET CompassNet Course over ground COMP Compass Comp. Mon. Compass monitor CONST.
  • Page 67 RAIS 056357/B Det Norske Veritas DNV Naut-AW Det Norske Veritas Class notation for enhanced nauti- cal safety Dynamic positioning dwg. drawing East European Union Council ECCN Export Control Classification Number ECDIS Electronic Chart Display and Information System Environmental conditions EM-Log Electromagnetic (speed) log European Norm ERR.STAT.BITS...
  • Page 68 056357/B RAIS Gyrocompass 1 Gyrocompass 2 G/M headings Gyro /Magnetic headings Grounding avoidance system Gen. General NMEA sentence which provides the GPS current fix data. Germanischer Lloyd Geographic position - latitude/longitude GMDSS Global Maritime Distress and Safety System Ground GNSS Global Navigation Satellite System Global Positioning System Global Positioning System...
  • Page 69 RAIS 056357/B Heading track control data Hertz Input/Output Integrated circuit Interface Control Document Identifier International Electro Technical Commission International hydrographic office. International Maritime Organization Inertial Measurement Unit Integrated navigation system INT HDG ONLY Internal heading only INT/EXT HDG Internal or external heading International Protection Illustrated Parts Data Illustrated Parts List...
  • Page 70 056357/B RAIS lat. Latitude Liquid crystal display Light Emitting Diode LEHMK Lehmkuhl (transmission standard company Lehm- kuhl) Line feed Litef Faser Kreisel (Litef fiber optic gyroscope) lon. Longitude Lon. Longitude LORAN Long Range Navigation LORAN-C Long Range Navigation C Least significant Bit Magnetic Mag Hdg.
  • Page 71 RAIS 056357/B Most significant Bit Maritime Safety Committee MTBF Mean time between failure North NAUT-AW Class notation with augments requirements for bridge congfiguration for ships largely operating largely in coastal and narrow waters NAUT-HSC Class notation for high speed craft NAUT-OC Class notation with fundamental requirements for ships largely operating largely at high seas...
  • Page 72 056357/B RAIS NMEA-HDM NMEA-HDM sentence NMEA-RMA NMEA-RMA sentence NMEA-RMC NMEA-RMC sentence n.o. Normally open Normally open Number None Volatile RAM Off Hdg Off heading alarm OUTP Output Pulse P .Gnd Power ground Part number Pre-programmed IC Printed circuit board PLATH Binary protocol of company C.
  • Page 73 Rudder angle calibrator RAFU Rudder angle feedback unit Rudder angle indicator RAIs Rudder angle indicators RAIS Rudder angle indicator system Random Access Memory Ref. Voltage Reference voltage Recommended minimum navigation information Recommended minimum navigation information NMEA sentence A Recommended minimum navigation information...
  • Page 74 056357/B RAIS Sentence A self-contained line of data SFA unit Steering failure alarm unit sin. Sine Steering mode switch Speed over ground (actual measured speed of advance of a vessel over the surface of the earth) SOLAS Safety of life at sea Scope of supply Switch-over unit SPEED N...
  • Page 75 RAIS 056357/B Unified Modelling Language USCG United states coast guard Volt Volt alternating current Volt direct current Voyage data recorder Water speed and heading Voyage management system VMS/ECDIS Voyage management system / electronic chart display and information system VOSS Vessel optimization & safety system Vpp.
  • Page 76 056357/B RAIS Z/DO-160 Section Z, DO-160E, Environmental Conditions and Test Procedures for Airborne Equipment Abbreviations...
  • Page 77 Note After installation of the Rudder Angle Calibrator, please return a filled-out copy of the Setup Table to Sperry Marine for inclusion in the ship’s file. When permanent changes are made to the system configuration, please return an updated copy of the Setup Table to Sperry Marine.
  • Page 78 All appended documents and drawings are revision-controlled sepa- rately at Sperry Marine. In case of doubt, verify the current revision status of the drawings with Sperry Marine. This manual’s revision status does not change when the revision of an appended document or drawing changes.
  • Page 79 RAC is used on a ship under wheelmark certification. Relay Setup General Alarm Spare closed on no alarm closed on no alarm closed on alarm closed on alarm Northrop Grumman Sperry Marine B.V. (Representative Office) Woltmanstr. 19, 20097 Hamburg, Germany Tel.: +49-40-29900-0, Fax: +49-40-29900-146, E-mail: service.de@sperry.ngc.com...
  • Page 80 Rudder Angle Calibrator (RAC) Setup Table Input Calibration Table Rud. Angle A/D Digits Rud. Angle A/D Digits Northrop Grumman Sperry Marine B.V. (Representative Office) Woltmanstr. 19, 20097 Hamburg, Germany Tel.: +49-40-29900-0, Fax: +49-40-29900-146, E-mail: service.de@sperry.ngc.com...
  • Page 81 Output Calibration Table Rudder Digits Digits Digits Digits Digits Digits Angle Out 1 Out 2 Out 3 Out 4 Out 5 Out 6 Northrop Grumman Sperry Marine B.V. (Representative Office) Woltmanstr. 19, 20097 Hamburg, Germany Tel.: +49-40-29900-0, Fax: +49-40-29900-146, E-mail: service.de@sperry.ngc.com...
  • Page 82 Output Calibration Table (continued) Rudder Digits Digits Digits Digits Digits Digits Angle Out 1 Out 2 Out 3 Out 4 Out 5 Out 6 Northrop Grumman Sperry Marine B.V. (Representative Office) Woltmanstr. 19, 20097 Hamburg, Germany Tel.: +49-40-29900-0, Fax: +49-40-29900-146, E-mail: service.de@sperry.ngc.com...

  • Page 83: Installation Instructions

    Installation instructions Rudder Angle Indication Systems Index: Erstellt: 06/17 2017-07-03 installation instructions rudder angle indication systems.docx Page 1...
  • Page 84 Console mounting:     PANAMA TYPE  Frontsize: 96x96: 060334-0000-000 Range ±45° 060331-0000-000 Range ±45 060335-0000-000 Range ±70° 060337-0000-000 Range ±70° Frontsize: 144x144: 060338-0000-000 Range ±45° 060340-0000-000 Range ±45° 060339-0000-000 Range ±70° 060341-0000-000 Range ±70° Frontsize: 192x192: 060352-0000-000 Range ±45° 060354-0000-000 Range ±45° 060353-0000-000 Range ±70°...
  • Page 85 Panel-cutout: Frontsize: Dimensions (mm) “A” +0.8 96x96 144x144 192x192 Mounting withe fastening clamp: Mounting withe angleclamp:   Index: Erstellt: 06/17 2017-07-03 installation instructions rudder angle indication systems.docx Page 3...
  • Page 86 Zero adjustment: At the back of the indicator is a small “screw”. Turn gently with a well-fitting screwdriver to left or right (max +/-30°) to adjust the pointer to zero on the scale. Span adjustment: At the back of the meter is a small blue potentiometer. This is intended for the adjustment of the span of the meter.
  • Page 87 Housing with bracket, built-in dimmer:     PANAMA TYPE  Scale 144x144mm: 060327-0000-000 Range ±45° 060325-0000-000 Range ±45° 060328-0000-000 Range ±70° 060326-0000-000 Range ±70° Scale 192mmx192mm: 060357-0000-000 Range ±45° 060332-0000-000 Range ±45° 060359-0000-000 Range ±70° 060362-0000-000 Range ±70° Drilling scheme:   Scale: Dimensions (mm) “A”...
  • Page 88 Zero adjustment: At the back of the indicator is a small “screw”. Turn gently with a well-fitting screwdriver to left or right (max +/-30°) to adjust the pointer to zero on the scale. Span adjustment: At the back of the meter is a small blue potentiometer. This is intended for the adjustment of the span of the meter.
  • Page 89 Instructions for the exchange of the measuring instrument: Tools you need: inbus 6mm, socket wrench 5,5mm, small screwdriver Open the case (4x mm inbus bolt (hex key or Allen key)) BCI without cover Index: Erstellt: 06/17 2017-07-03 installation instructions rudder angle indication systems.docx Page 7...
  • Page 90 Disconnect cable (blue -> 2; red -> 1; black -> 11, gray -> 12) Instrument with disconnected cable Disconnect the 8x screw which fixing the instrument (8x M3 screw and key) Index: Erstellt: 06/17 2017-07-03 installation instructions rudder angle indication systems.docx Page 8...
  • Page 91 Remove the instrument from the housing Check the new instrument ( is the rubber seal present) Put the new instrument in the housing Index: Erstellt: 06/17 2017-07-03 installation instructions rudder angle indication systems.docx Page 9...
  • Page 92 8x screw which fixing the instrument (8x M3 screw and key 5,5mm) connect cable (blue -> 2; red -> 1; black -> 11, gray -> 12) close the case (4x mm inbus bolt (hex key or Allen key)) Finished! Index: Erstellt: 06/17 2017-07-03 installation instructions rudder angle indication systems.docx Page 10...
  • Page 93 Three-face panorama rudder angle indicator: Scale 144x144mm: 060396-0000-000 Range ±45° 060397-0000-000 Range ±70° Drilling scheme: Ø6,5 Index: Erstellt: 06/17 2017-07-03 installation instructions rudder angle indication systems.docx Page 11...
  • Page 94 Zero adjustment: Remove the plate with the dimmer potentiometer Turn gently with a well-fitting screwdriver the potentiometer “ZERO” to left or right to adjust the pointer to zero on the scale. The instrument must be supplied with 24V! And the input to be set to zero  ...
  • Page 103 α α...
  • Page 116 Sperry Marine Service: www.sperrymarine.com/offices Northrop Grumman Sperry Marine B.V. (Representative Office) Woltmanstr. 19 • D-20097 • Hamburg, Germany Tel.: +49-40-299 00-0 • Fax: +49-40-299 00-146 • E-mail: service.eu@sperry.ngc.com...
