Page 2
ZigBee/High Power Hardware Technical Operation Manual User’s Guideline Index: Pre-operation instruction Introduction of ZigBee/High Power Wireless Products & Parts Installation Procedure Attachment: Jump Setting/LED Display Interpretation A) Pre-operation Instruction Check the model numbers/quantities. Get the external equipment & tools ready for use. Install the software attached with this product to computer set.
Page 3
Wireless Ethernet Network COZ100 coordinator transmission 5dBi DC6V cable (Ethernet) interface Wireless analog Connect to three AIZ100 2dBi DC9V-30V input transmitter analog signal sets Wireless digital Connect to four DIZ100 2dBi DC9V-30V input transmitter analog signal sets Wireless digital Output three sets of...
C) Installation Procedure ZigBee Wireless USB Coordinator (COZ101) Model No.: COZ101 USB transmission interface Reset(Reset hardware power) SMA(Antenna connector) FUNC(Mode-switchover button) LED Green LED Red 5 dBi Omni-directional antenna Communication Mode 1. Connect the USB cables to both the wireless coordinator and computer port. 2.
Page 5
ZigBee Wireless Ethernet Coordinator (COZ100) Model No.: COZ100 Ethernet transmission interface Power supply port SMA(Antenna connector) FUNC(Mode-switchover button) LED Green LED Red 5 dBi Omni-directional antenna Communication Mode 1. Connect the Ethernet cable to both the wireless coordinator and computer port. 2.
ZigBee Wireless Analog Input Transmitter (AIZ100) Model No.: AIZ100 Externally connect to three sets of analog signals DC IN (Power supply port) SMA(Antenna connector) FUNC(Mode-switchover button) LED Green LED Red 8-pin socket 2 dBi Omni-directional antenna Communication Mode 1.
Page 7
ZigBee Wireless Digital Input Transmitter (DIZ100) Model No.: DIZ100 Externally connect to four sets of dry contact signals GND(Common point ground wire) DC IN(Power supply port) SMA(Antenna connector) FUNC(Mode-switchover button) LED Green LED Red ...
Page 8
ZigBee Wireless Digital Output Transmitter (DOZ100) Model No.: DOZ00 Externally connect to three sets of dry contact signals Dry-contact-points-switchover button DC IN(Power supply port) SMA(Antenna connector) FUNC(Mode-switchover button) LED Green LED Red 8-pin socket ...
Page 9
ZigBee RS-232 Wireless Transmitter (RSZ232/COZ232) Model No.: RSZ232/COZ232 RS-232transmission interface DC IN(Power supply port) SMA(Antenna connector) FUNC(Mode-switchover button) LED Green LED Red 2-pin socket 2 dBi Omni-directional antenna Communication Mode 1. Ensure that the wireless coordinator is under communication mode status. 2.
Page 10
ZigBee RS-485 Wireless Transmitter (RSZ485/COZ485) Model No.: RSZ485 RS-485transmission interface GND(Common point ground wire) DC IN(Power supply port) SMA(Antenna connector) FUNC(Mode-switchover button) LED Green LED Red 6-pin socket 2 dBi Omni-directional antenna Communication Mode 1.
Page 11
ZigBee Wireless Temperature & Humidity Sensor (THZ100) Model No.: THZ100 Power supply port Power switch External-extension port Sensing window basin SMA(Antenna connector) FUNC(Mode-switchover button) LED Green LED Red Battery basin 2 dBi Omni-directional antenna Communication Mode 1.
Page 12
ZigBee Electronic Diaper Humidity Sensor (EDP100) Model No.: EDP100 RJ11 transmission interface Power switch Belt clamp FUNC(Mode-switchover button) Emergency pushbutton Hidden LED Blue Hidden LED Red Humidity sensing conductor Communication Mode 1. Ensure that the wireless coordinator is under communication mode status. 2.
Page 13
ZigBee Soil Moisture Sensor (MDP100) Model No.: MDP100 RJ11 transmission interface Power switch Belt clamp FUNC(Mode-switchover button) Emergency pushbutton Hidden LED Blue Hidden LED Red Humidity sensing conductor Communication mode 1. Ensure that the wireless coordinator is under communication mode status. 2.
Page 14
High Power RS-232 Wireless Router (RTZ232/RSH232) Model No.: RTZ232/RSH232 RS-232 transmission interface DC IN(Power supply port) SMA(Antenna connector) FUNC(Mode-switchover button) LED Green LED Red 2-pin socket 2 dBi Omni-directional antenna Communication Mode 1.
Page 15
D) Attachment D-1 Jump setting interpretation 0-1V, 0-5V & 0-10V Jump locations 0-20mA & 4-20mA Jump location Operation procedure Confirm the conversion mode of detecting device (V/mA). Use cross pliers to take out outer cover. Set up same signal mode to all wireless analog input transmitters. Follow graphical instruction to install jump location and put on the outer cover;...
Page 16
D-2 LED Display Interpretation Status Display Interpretation 【COZ101/COZ100/COZ232/COZ485/AIZ100/DIZ1 LED Green constantly 00/DOZ100/RSZ232/RSZ485】 is under normal lights up; LED Red communication status. The flash frequency varies flashes according to the time interval of module signal transmission / reception. Normal 【THZ100】is under normal communication status.
