Summary of Contents for Sunshare Solar Solar LED Batten Light
- Page 1 USER MANUAL SOLAR LED BATTEN LIGHT sunsharesolar.com.au shop@sunsharesolar.com.au Version.04.2018 +61 3 9779 6223...
- Page 2 20CM Fix the two metal clips into posi•on and a•ach to surface. It is recommended that each clip is posi•oned approximately 20CM from each end of the Ba•en Light. Cau•on : Ensure correct anchor sleeves are used for surface material. Plese see package contents before installa•on. Using a screw driver, secure each clip onto the Ba•en Insert Tensioning Bolt and a•ach the Light with the Tensioning bolt.
- Page 3 Assembly Mounting Bracket to Solar Panel M6*16 Screws . This is to fix to solar panel M6*16 Screws . Can fix in different holes for different moun•ng angle. M8*16 Screws . NOTICE Please note the brackets for le! and right sides are different, make sure it is well-assembled properly. sunsharesolar.com.au shop@sunsharesolar.com.au +61 3 9779 6223...
- Page 4 Assembly Mounting Bracket to Solar Panel Finished assembly sunsharesolar.com.au shop@sunsharesolar.com.au +61 3 9779 6223...
- Page 5 MANUAL OF KEY FUNCTION MAGIC romote control is used to change the program of the light. there are two sec•ons , one is Modes for se!ng modes. the other is to change the •me. Se!ng This remote controller are able to meet most of requirements for different ligh•ng situa•on.
-
Page 6: General Operation
GENERAL OPERATION Status Light RED/GREEN/BLUE * A!er turning the ba"en light ON. A Red/Green/Blue status light will cycle for two seconds then stop. This signals the ba"en light system is OK and will work in the default opera#on of 0%+100% sensi#vity powersurface material. Plese see package contents before installa#on. -
Page 7: Solar Controller
12W All in One Solar LED Batten Light for Retailer Model Lighting Name Solar LED Batten Light Model AI-X1200 Rated power Luminous flux 1,500lm >80 Input voltage 18VDC Beam angle 120° LED brand: SMD 2835 LED qty 240Pcs Lamp size... -
Page 8: Solar Panel
Solar Panel Cell brand type Taiwan brand Dimension 620*340*25mm Max power Max voltage 18VDC Max. working current 1.67A Max. system voltage 1000V Cable section 1.5mm2 Connection Waterproof cable 5M Distribution Curve: Light Distribution Curve [Unit: cd] Max Plane Light Distribution Curve [Unit: cd] Dimension (mm) Product Advantage Packagin...
