Thermaco Big Dipper W-250-IS Technical Data

MOTOR/TIMER
ENCLOSURE
14.75"
2" PIPE
INLET/OUTLET
17.5"
END VIEW

FEATURES:

• Fully automatic self cleaning cycle. Removes collected
grease & oils from tank without any operator assistance.
Comes complete with 24-hour timer and Grease Collector.
• Constructed of corrosion resistant materials suitable for
installation in virtually any location. Attractive sanitary
Stainless Steel exterior.
• Integrated Motor/Grease Outlet/Heater/Lid enables a
fast, do-it-yourself unit operation reversal.
• Compact footprint.
• Two (2) No-Hub Connectors provided.
Materials:
Electrical:
Maximum Inlet Flow Rate:
Number of Skimming Wheels:
Skimming Rate:
Grease Retention Capacity:
Internal Solids Strainer Capacity:
©2005 Thermaco, Inc. • All rights reserved • Patented/Patents Pending • Specifications subject to change without notice
Thermaco, Inc. • PO Box 2548 • Asheboro, NC 27204-2548 • Phone: (336) 629-4651 • Online: www.big-dipper.com
4/05
24.5"
8.75"
TECHNICAL DATA
Exterior: 304 Stainless Steel, Bright Finish
Interior: Rotationally Molded Polyethylene
115 VAC, 60 Hz, 520 Watts (4.5 Amps)
Big Dipper Point Source Automatic
®
Grease Removal Systems
W-250-IS Specifications
TOP OF TANK REQUIRED FOR
STRAINER BASKET & LID REMOVAL
INLET
GC-6
GREASE
10.5"
COLLECTOR
6 QUART
CAPACITY
25.5"
SIDE VIEW
28.5"
INLET
TOP VIEW
25 GPM
1
20 Pounds Per Hour
50+ Pounds
1.16 Gallons
14" CLEARANCE FROM
OUTLET
10.5"
OUTLET
24.5"
®
19.5"
1
