MOTION SENSOR
SETTINGS GUIDE
For use with:
LED Commercial Linear Strip:
CS-484-4
|
CS-484-4-347
CS-484-MS-4
|
CS-484-MS-4-347
LED Vapor Proof Fixture:
VP-484-5
|
VP-484-5-347
|
VP-484-MS-5
LED Garage Luminaire
CF3-404-MS-1
|
CF3-604-MS-1
VP-Series
CS-Series
CF3-Series
BEFORE YOU BEGIN
Before beginning the setup of your motion sensor, please familiarize yourself with
the sensor's layout and dip switches.
HOLD
TIME
SETTINGS
DETECTION
TURN OFF
AREA
PERIOD
SETTINGS
SETTINGS
Premise LED Inc.
82-86 Carrier Drive
Toronto, ON Canada
M9W 5R1
NOT
IN
USE
STAND-BY
DIMMING LEVEL
SETTINGS
Advertisement
Table of Contents
Summary of Contents for Premise VP-CS-CF3
- Page 1 Premise LED Inc. 82-86 Carrier Drive Toronto, ON Canada M9W 5R1 MOTION SENSOR SETTINGS GUIDE For use with: BEFORE YOU BEGIN LED Commercial Linear Strip: CS-484-4 CS-484-4-347 Before beginning the setup of your motion sensor, please familiarize yourself with CS-484-MS-4 CS-484-MS-4-347 the sensor’s layout and dip switches.
- Page 2 TO SETUP THE MOTION SENSOR 1. Next, use the STAND-BY DIMMING LEVEL SETTINGS 1. Use the DETECTION AREA SETTINGS to set your desired detection area. to indicate the reduced light level that you would like the luminaire to The maximum detection radius is 65 feet (20 m) and 30 feet (10 m) in remain at after no motion is detected and the hold time has elasped.
