Summary of Contents for LuxLogic Stealth
- Page 1 LED STEALTH AREA LIGHT Proudly Canadian Company INSTALLATION GUIDES S: SLIP FITTER MOUNTING Dimensions of the slip fitter 7.3” (185mm) 3.1” (79mm) Step 1 Step 2 Connect the AC wire, and then insert Tighten the screws on the side of the arm of the slip fitter to the pole.
- Page 2 LED STEALTH AREA LIGHT Proudly Canadian Company INSTALLATION GUIDES T: TRUNNION MOUNTING Dimensions of the trunnion 5.4” (136mm) Step 1 Step 2 Drill two holes on the wall corresponding to the Use the nuts to fix the fixture to the wall aiming at...
- Page 3 LED STEALTH AREA LIGHT Proudly Canadian Company INSTALLATION GUIDES A1: ARM MOUNTING FOR SQUARE POLE Arm dimensions 5.1” (130mm) 6.7” (170mm) 2” (50mm) 6” (152.1mm) 2.6” (65.3mm) 0.78” (20mm)
- Page 4 LED STEALTH AREA LIGHT Proudly Canadian Company INSTALLATION GUIDES Arm assembly drawing Formula arm pipe installation With circular arm silicone Cover plate Step 1 Step 2 Drill holes on the square pole corresponding to Connect the AC wire of the fixture and tighten the...
- Page 5 LED STEALTH AREA LIGHT Proudly Canadian Company INSTALLATION GUIDES A2: ARM MOUNTING FOR ROUND POLE Step 1 Nut Plate Drill holes on the round pole corresponding to the holes on the arm, and use the bolt and nut plate to fix the fixture to the pole tightly.
- Page 6 LED STEALTH AREA LIGHT Proudly Canadian Company INSTALLATION GUIDES QUALITY ASSURANCE Quality assurance is based on proper storage, transportation, installation, using and maintenance Damages caused by man-made mistake or improper use are not covered by the warranty Risk of electrical shock!
