Summary of Contents for Duralite AL15
- Page 1 OWNER’S / OPERATOR’S MANUAL DURALITE For Models AL15, AL 20, AL25, AL30 & AL35...
- Page 2 Introduction To our customer: This manual has been prepared to help you operate and maintain your new Duralite Trailer safely. Should you have any questions, contact a Duralite factory representative immediately for a clear explanation. We thank you for your patronage and confidence in us through the purchase of your new Duralite Trailer.
- Page 4 ▼ Warning ▼ DO NOT operate or service this trailer without reading and understanding this operators manual. If manual is lost, contact the factory for a new one. ▼ TAKE NOTE! This safety-alert symbol found throughout this manual is used to call your attention to instructions involving your personal safety and the safety of others.
- Page 7 This Symbol Means Attention! Become Alert! Your Saftey Is Involved...
- Page 8 * Located on the left front side * Located on the left rear corner * Located on the left front side * Located on the left rear corner * Located on the left rear corner ATTENTION Tailgate must be in closed position with latches secured when trailer is in use.
- Page 9 * Located on the left front side * Located on Breakaway Kit * Located on the centergate * The following decal is vendor supplied with their product. DUAL PIN CAUTION U.S. PATENT NUMBER: 5,423,518 SPRING LOADED DROP LEG LOCKED POSITION UNLOCKED POSITION TO LOWER LEG: 1.
- Page 10 * Located on the left front side * Located on the left rear corner * Located on neck gate...
-
Page 12: Pre-Trip Inspection
PRE-TRIP INSPECTION ▼ WARNING! Be careful when making any inspections, hookups, and repairs to avoid personal injury. Park on level surface, make sure parking brakes are set or wheel chocks are in place to avoid movement of the trailer which could result in bodily injury. •... -
Page 15: Electrical Diagram
ELECTRICAL DIAGRAM Terminal Block: Located on Hitch Coupler Assembly Open Stop Open ICC Marker Yellow L.H. Turn Green R.H. Turn Brown Tail Marker Ground Blue 7 - Way RV 6 - Way Tail Marker Brown Silver Ground Stop Black White L.H. -
Page 16: Wiring Diagram
WIRING DIAGRAM... - Page 19 AL-KO HUB / DRUM 7000 LB. GROUP Service Replacement Parts 12” Hub/Drum Service...
-
Page 23: General Specifications
GENERAL SPECIFICATIONS Wheel Nut Torque ATTACHMENT FT. LBS. TORQUE Flange Nut 3/4 Dual Wheel to Hub 375 -425 Flange Nut 5/8 Dual Wheel to Hub 275 -325 Cone Nut 5/8 Single Wheel to Hub 175 – 225 Cone Nut 9/16 Single Wheel to Hub 120 –... -
Page 24: Parts List
7- way RV Plug Lug Nut 6 Wire Cable 7 Leaf Slipper Aluminum Light Front Hanger Covers Center Hanger Breakaway Kit Rear Hanger l Parts for trailers built before the year 2004 are available, but not listed. Contact Duralite Trailers for assistance. -
Page 25: Certificate Of Warranty
This warranty does not apply to and no warranty is made by Duralite Trailers, LLC except as to its title, regarding any purchased components, attachments and accessories manufactured,... - Page 26 EXTENDED WARRANTY SCHEDULE Per written warranty conditions covering defect in material and workmanship as to construction and assembly and installation only. SEVEN YEARS ONE YEAR VENDOR WARRANTY APPLIES Side Walls Gates Axles Front Walls Gate Latches Suspensions Neck Frame Gate Hinges Brake Assemblies Rear Frame Doors...
-
Page 27: Reporting Safety Defects
If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the National Highway Safety Administration (NHTSA), in addition to notifying Duralite Trailers, LLC. If NHTSA receives similar complaints, it may open an investigation, and if it finds a safe- ty defect exists in a group of vehicles, it may order a recall and remedy campaign.
