MyCharge AMPMAX Quick Start Manual

PACKAGE CONTENTS

• myCharge AMPMAX
• Micro-USB Recharging Cable
• Quickstart Guide
AMPMAX

WELCOME!

Congratulations, you're now the proud owner of the myCharge
AMPMAX! This powerbank was designed with your on-the-go
charging needs in mind and is compatible with virtually all USB
devices.
The portable powerbank's 6000mAh battery capacity guarantees
that your device can stay charged and connected wherever your
travels may take you.

PRODUCT SPECS

• Battery Capacity: High Density 6000mAh Battery
• Micro-USB Input: 5VDC, 0.7A-2.1A
• USB Output: 5VDC, 2.4A
• Dimensions: 2.8 x 2.1 x 0.9 inches
• Weight: 0.29 lbs.

PRODUCT TECHNOLOGIES

Your new powerbank is built with these technologies to give you
the fastest, safest, and smartest user experience possible:
SMART SENSE
™
Detects the connected device and charges it at the maximum
speed allowed by the device, shortening charge time
PEAK POWER
™
Provides faster recharge of the AMPMAX as it maximizes the
amount of available power going into the powerbank
PASS THROUGH CHARGING
Charges the powerbank and the device in parallel. You'll have
both charged for extra power when you need it
BATTERY PROTECTION
Protects the powerbank and your device against overcharging,
undercharging, overtemperature, overcurrent and short circuit for
your safety
HIGH EFFICIENCY
Maximizes power to your device by minimizing the loss of energy
delivered, keeping you powered longer
HIGH DENSITY BATTERY
Increases run-time between charges and makes the AMPMAX
compact and lightweight

COMPATIBILITY

Smartphones, tablets, eReaders,
GPS and other USB devices
HELPFUL TIP
>
Watch the instructional video:
USB port
LED indicators
Power button
Flashlight button

CHARGING DEVICES USING YOUR AMPMAX

If your device is charged through a micro-USB port, feel free to use
the recharging cable provided, otherwise use your own device's
cable to charge it. When the device is plugged in, the AMPMAX
will continue to charge it until it is unplugged or runs out of power.
With SmartSense™ technology, your AMPMAX is compatible with
just about any device on the market – smartphones, tablets,
eReaders, GPS and more. It senses what device it's plugged into
and provides the maximum power allowed, giving you the bene t
of faster charging. The AMPMAX's high e ciency technology
minimizes energy loss from the input source to the powerbank and
from the powerbank to the device.

RECHARGING YOUR AMPMAX

Connect the included recharging cable to your AMPMAX and to a
power source – wall, computer, or car. Your AMPMAX is built with
Peak Power™ technology that maximizes the amount of available
power going into your charger so you can rest assured that it's
recharging at the fastest rate allowed by the power source.
Your AMPMAX has pass-through charging, allowing you to charge
both the powerbank and your device simultaneously.
As your AMPMAX recharges, the LEDs will illuminate to indicate the
battery level. A fully charged unit shows 4 solid, non-blinking LEDs. It
is normal for your AMPMAX to be warm to the touch while in use.
AMPMAX Manual
mycharge.com/pages/videos
Micro-USB recharging port
myCharge AMPMAX Manual
