For Outdoor Use
Installation, Operation,
Maintenance & Parts Guide
Models: SO261BQTR, SO301BQRRL, SO321BQRTRL,
SO381BQRTRL, SO421BQRL
These grills are tested and certified to the ANSI-Z21.58/CSA 1.6.standards
This manual was updated in January 2014
For the latest product information visit the website
Owner's Manual
www.solegourmet.com
Advertisement
Table of Contents
Related Manuals for Sole Gourmet SO261BQTR
Summary of Contents for Sole Gourmet SO261BQTR
- Page 1 For Outdoor Use Installation, Operation, Maintenance & Parts Guide Models: SO261BQTR, SO301BQRRL, SO321BQRTRL, SO381BQRTRL, SO421BQRL These grills are tested and certified to the ANSI-Z21.58/CSA 1.6.standards This manual was updated in January 2014 For the latest product information visit the website Owner’s Manual...
-
Page 3: Table Of Contents
Contents For Your Safety ..........................2 Important Safety Rules ........................3 Gas Connections ..........................3 Installation Location & Clearances ....................4 Build-in Specifications ........................5 Electrical Connections ........................7 Gas Barbeque Specifications ......................7 Fuel Conversion..........................8 LP Tank Requirements ........................10 Leak Testing &... -
Page 4: For Your Safety
For Your Safety FOR YOUR SAFETY !! WARNING !! If You Smell Gas: Read the Lighting Instructions in this manual before lighting this 1. Shut off gas to the appliance appliance. 2. Extinguish any open flames 3. Open the lid 4. -
Page 5: Important Safety Rules
Important Safety Rules It is important to follow these rules to avoid fire hazard, property damage or bodily injury from improper installation or usage of the grill. For safety, READ all rules carefully and check local codes. It is prohibited to install the grill in recreational vehicles/mobile homes, trailers, boats, etc. The grill is for outdoor installation and use only. -
Page 6: Installation Location & Clearances
Installation Location Choose a location where the flow of air on the front of the grill is not obstructed. Due to high temperatures, place the grill out of traffic and keep away from clothing, furniture, etc. Keep the gas line connection as short as possible. Do not install in recreational vehicles/mobile homes, trailers, boats, etc. -
Page 7: Build-In Specifications
Build-in Specifications SO301BQRRL, SO421BQRL 6” Non-Combustible Clearance 15” Combustible Clearance from Grill Model SW** SH** C*** V*** SO301BQRRL 33 ¼” 20” 6” 11” 6 ½” 4 ½” ¾” Varies w/Overhang SO421BQRL 45 ¼” 20” 6” 11” 6 ½” 4 ½” ¾”... - Page 8 Build-in Specifications SO261BQTR, SO321BQRTRL, SO381BQRTRL 6” Non-Combustible Clearance 15” Combustible Clearance from Grill Model SW** SH** SO261BQTR 24 ½” 21 ½” 6” 9 ½” 6 ½” 4 ½” SO321BQRTRL 30 ½” 21 ½” 6” 9 ½” 6 ½” 4 ½”...
-
Page 9: Electrical Connections
Canadian Electrical Code, CSA C22.1. Keep any electrical supply cord and fuel supply hose away from any heated surface. HALOGEN LIGHT: The grill (except SO261BQTR) is provided with a low-wattage transformer and three- prong grounding plug for your protection against This plug is used for connecting the optional shock hazard. -
Page 10: Fuel Conversion
Fuel Conversion (Regulator) *This should only be performed by a licensed gas professional* Currently all Solé grills are supplied with an LP orifice conversion kit and one NG/LP convertible regulator. When converting the gas orifices you must also convert the regulator by removing the large nut on the top of the regulator, remove the plastic plunger, flip it over to the desired fuel, and reinstall the cap. - Page 11 Fuel Conversion (Burners) 1. Determine the existing gas type. (LP or Natural gas) Changing the gas type and orifice change out is the same for both gases. 2. You must remove all grates and burner covers to expose the main burners in the grill. 3.
-
Page 12: Lp Tank Requirements
LP Gas Connection The LP hose regulator is not included with the grill and needs to be purchased separately. Appliance pressure 10” W.C. Inlet pressure 11” – 14” W.C. Purchase a standard 20 LB. LP tank with QCC – 1 fitting. Assemble pipe/hose assembly as shown. -
Page 13: Leak Testing & Burner Adjustments
Leak Testing All gas piping and connections must be tested for leaks after !! WARNING !! installation or service. All leaks must be corrected immediately. Remember-before exchanging an empty bottle for a new one make sure all control valves are in the “off” position. NEVER USE AN OPEN FLAME Open the valve (shut-off or ‘ON’... -
Page 14: Lighting Instructions
Lighting Instructions Before Lighting Visually inspect the gas line, hose and all connections for signs of wear, abrasion or cuts. If evidence of deterioration is visible, replace the part prior to use. If you smell gas, check for leaks. If odor continues, turn off fuel supply and immediately call for service. Keep your face and body away from the grill top when lighting. -
Page 15: Operation, Cleaning & Maintenance
Operation !! WARNING !! - DO NOT LEAVE YOUR GRILL UNATTENDED WHILE IN OPERATION Grill: Grill burners are controlled individually with control knobs. After lighting, turn the knob to HI, LO or in between as desired. Turn on as many burners as required. The top cover may be closed during grilling. Keep the top cover in closed position during the pre-heat period. -
Page 16: Front Panel & Parts Removal
Cleaning & Maintenance Keep outdoor cooking gas appliance area clear and free from combustible materials, gasoline and other flammable vapors and liquids. Do not obstruct the flow of combustion and air ventilation. Keep the ventilation opening(s) of the cylinder enclosure free and clear from debris. Visually check burner flames for proper operation. -
Page 17: Troubleshooting
Parts Removal & Replacement Grill Burner: - Remove top grates. - Remove shields. - Remove cotter pin on the bottom rear of each burner and slide out. - Clean and replace in reverse order. Main Burner Electrode: Remove front panel. - Unscrew the electrode bracket from the valve. -
Page 18: Parts Exploded View
Parts Diagram SO301BQRRL, SO421BQRL Part Description 301 421 01 SO-001 30" - Top Hood 01 SO-002 42" - Top Hood 02 SO-003 Igniter Bracket - IR Burner 03 SO-004 Igniter - IR Burner 04 SO-005 30" - Igniter Wire (15cm) 04 SO-006 42"... - Page 19 Parts Diagram SO261BQTR, SO321BQRTRL, SO381BQRTRL Part Description 261 321 381 01 SOTR-001 26" - Top Hood 01 SOTR-002 32" - Top Hood 01 SO-003 38" - Top Hood 02 SO-004 Igniter Bracket 03 SOTR-003 Igniter - IR Burner 04 SOTR-004 32"...
-
Page 20: Wiring Diagram
Wiring Diagram... -
Page 21: Do's & Don'ts
Do's & Don'ts DO… Have propane cylinder (LP units) filled by authorized LP supplier. Record your grill model number on your instructions and keep the instructions and parts list in a convenient place. Check all gas line connections for leaks with soapy solution prior to lighting, tighten until bubbles disappear. -
Page 22: Warranty
Solé Gourmet Luxury & TR Series Limited Warranty LIMITED WARRANTY Solé, warrants to the ORIGINAL PURCHASER of each Outdoor Gas Grill that when subject to normal residential use, it is free from defects in material and workmanship for set periods below. It does not apply to rust, corrosion, oxidation or discoloration, which may occur due to moisture or overheating. - Page 24 www.solegourmet.com...
