  • Page 1 User Manual Returnstar Interactive Technology Group Co., Ltd.
  • Page 2: Table Of Contents

    Content Content -------------------------------------------------------------------------------------------------------------------------------------------------- 01 Chapter1 Product Review ------------------------------------------------------------------------------------------------------------------------------- 02 Chapter2 Central Control Panel ------------------------------------------------------------------------------------------------------------------------ 03 Chapter3 Power on/off the Device ----------------------------------------------------------------------------------------------------------------- 03 3.1 Enable the device ---------------------------------------------------------------------------------------------------------------------------------- 03 3.2 Disable the device ---------------------------------------------------------------------------------------------------------------------------------- 03 Chapter4 Digital Code and Card Setting -------------------------------------------------------------------------------------------------------------- 04 4.1 Digital code ----------------------------------------------------------------------------------------------------------------------------------------- 04 4.2 IC Card ----------------------------------------------------------------------------------------------------------------------------------------------- 04 Chapter5 Wireless MIC -------------------------------------------------------------------------------------------------------------------------------- 05...
  • Page 3: Chapter1 Product Review

    Chapter1 Product Review AC IN AC OUT RJ45 RS232 HDMI AUDIO 1. 2*25W Speakers 6. AC OUT *1 2. Central Control Panel 7. AC IN *1 10 11 3. Document Camera 8. VGA *1 4. Interactive Whiteboard 9. RS232 *1 5.
  • Page 4: Chapter2 Central Control Panel

    Chapter 2 Central Control Panel 1. Card response area: Boot up the device with the card. 2. Power: Power on/off the device. 3. Computer: Power on/off the PC. 4. Lock: Freeze the functions on the panel. 5. Projector : Boot up/shut down the projector. 6.
  • Page 5: Chapter4 Digital Code And Card Setting

    Chapter 4 Digital Password and Card Setting 4.1 Digital code Name Default Password Function Remark User 0000 Boot up Available for changes Boot up Set user’s password Administator 9999 Available for changes Set administrator’s password Set the IC card Steps: ·...
  • Page 6: Chapter5 Wireless Mic

    Chapter 5 Wireless MIC 5.1 Operation Guide · Start the MIC Receiver and then press the power button for two seconds to power Wireless MIC on. Please make sure the distance is within 5 meters. The signal and the PPT icon in the screen will flash. Press switch keys to choose 2.4G (2.4G frequency), IF (infrared frequency) or PPT (PPT alone).
  • Page 7: Chapter6 Document Camera

    With the IQ Control code software, the control code to power on/off the projector could be written and kept in the central system for more convenient operation on the projector. (IQ Control code software is saved in E:/IQBoard) 7.1 Steps to set the control code ·...
  • Page 8: Chapter8 Specifications

    Chapter 8 Specifications Name IQAiO Model GR511 Size 91" 102” Overall Size(mm) 1981*1302 (90.8”) 2308*1302 (101.8”) IWB Size(mm) 1719*1234 (83.1”) 2045*1234 (93.8”) Active Projection Size(mm) 1632*1224 (80.3”) 1958*1224 (90.9”) Aspect Ratio 16:10 Device Main Control i3/i5 Dual Core Processor, 4G RAM, 500G HD with Graphics Card, Gigabite Ethernet External Interfaces USB 2.0*4, External PC USB input*1, Audio 3.5 mm input*1, VGA*1, HDMI*1 Back Interfaces...
  • Page 9: Chapter9 Attention

    Chapter 9 Attention · The power for the IQAiO is 100~240V 50/60Hz. · Please don't disassemble the device or fill it with impurity. · Please keep the device away from the heat, water and the corrosive things. · Please power off the device before clean it with soft cloth. Don't clean it with liquid or gas cleanser. ·...
  • Page 10 Returnstar Interactive Technology Group CO., LTD. 6th Bldg. High-Tech Base. Fuzhou Fujian Prov. China 0086-591-38202660 0086-591-38203003 www.IQBoard.net Master@IQBoard.net © Returnstar Interactive Technology Group CO., LTD [Kd045EN]-IQAiO 20181213...
